What the Heck Are OAuth and OIDC - JHipster Conf 2019

OAuth is not an API or a service: it is an open standard for authorization and any developer can implement it. OAuth is a standard that applications can use to provide client applications with “secure delegated access”. OAuth works over HTTPS and authorizes devices, APIs, servers, and applications with access tokens rather than credentials, which we will go over in depth below. OpenID Connect (OIDC) is built on top of the OAuth 2.0 protocol. It allows clients to verify the identity of the user and to obtain their basic profile information.

This session covers how OAuth 2.0 and OIDC work, when to use them, and frameworks/services that simplify authentication.

Blog: https://developer.okta.com/blog/2017/06/21/what-the-heck-is-oauth

Online Tools:

- https://oauth.com/playground
- https://oauthdebugger.com
- https://oidcdebugger.com

Never Build Auth Again → https://developer.okta.com

Transcript

1. Matt Raible | @mraible What the Heck is OAuth and OIDC? June 27, 2019 Photo by Trish McGinity
2. Blogger on raibledesigns.com and developer.okta.com/blog Web Developer and Java Champion Father, Skier, Mountain Biker, Whitewater Rafter Open Source Connoisseur Who is Matt Raible? Bus Lover Okta Developer Advocate
4. developer.okta.com
5. Authentication Standards
6. What about You? Have you heard of OAuth or OIDC? Do you consider yourself a developer? Have you ever written authentication from scratch? Have you implemented OAuth or OIDC?
7. OAuth 2.0 Overview
8. Web Authentication GET /index.html HTTP/1.1 Host: www.example.com Authorization: Basic QWxhZGRpbjpvcGVuIHNlc2FtZQ==
9. Federated Identity Identity Provider (IdP) Service Provider (SP) End User Trust Obtains Assertion Provides Assertion
10. SAML 2.0 OASIS Standard, 15 March 2005 Authentication Request Protocol Assertion
11. SAML 2.0 Authentication Request Protocol
12. SAML 2.0 Assertion <Assertion xmlns="urn:oasis:names:tc:SAML:2.0:assertion" ID="b07b804c-7c29-ea16-7300-4f3d6f7928ac" Version="2.0" IssueInstant="2004-12-05T09:22:05" <Issuer>https://example.okta.com</Issuer> <ds:Signature xmlns:ds="http://www.w3.org/2000/09/xmldsig#">...</ds:Signature> <Subject> <NameID Format="urn:oasis:names:tc:SAML:2.0:nameid-format:unspecified"> matt@example.com </NameID> <SubjectConfirmation Method="urn:oasis:names:tc:SAML:2.0:cm:bearer"> </SubjectConfirmation> </Subject> <Conditions NotBefore="2004-12-05T09:17:05" NotOnOrAfter="2004-12-05T09:27:05"> <AudienceRestriction> <saml:Audience>https://sp.example.com/saml2/sso</saml:Audience> </AudienceRestriction> </Conditions> <AuthnStatement AuthnInstant="2004-12-05T09:22:00" SessionIndex="b07b804c-7c29-ea16-7300-4f3d6f7928ac"> <AuthnContext> <AuthnContextClassRef> urn:oasis:names:tc:SAML:2.0:ac:classes:PasswordProtectedTransport </AuthnContextClassRef> </AuthnContext> </AuthnStatement> <AttributeStatement> <Attribute Name="displayName"> <AttributeValue>Matt Raible</AttributeValue> </Attribute> </AttributeStatement> </Assertion>
13. SAML = Web SSO
15. What’s Changed Since 2005?
16. Confusion
17. Identity Use Cases (circa 2006) Simple login — basic, forms, and cookies Single sign-on across sites — SAML Mobile app login — N/A Delegated authorization — N/A
18. The Delegated Authorization Problem How can you let a website access your data (without giving it your password)?
19. Don’t do it this way!
20. Have you ever seen one of these?
21. © Okta and/or its affiliates. All rights reserved. Okta Confidential
22. Hotel Key Cards, but for Apps
23. Hotel Key Cards, but for Apps OAuth Authorization Server Resource (API) Access Token
24. Delegated Authorization with OAuth 2.0 I trust Gmail and I kind of trust Yelp. I want Yelp to have access to my contacts only. yelp.com Connect with Google
25. Delegated Authorization with OAuth 2.0 yelp.com Connect with Google accounts.google.com Email ********** accounts.google.com
 Allow Yelp to access your public profile and contacts? No Yes contacts.google yelp.com/callback
26. OAuth 2.0 Terminology Actors Clients Authorization Server Resource Server Access Tokens Redirect URI
27. Authorization
 Server (AS) Resource Owner (RO) Client Delegates Obtains Token Uses Token Resource
 Server (RS) Actors
28. Authorization
 Server (AS) Resource Owner (RO) Client Delegates Obtains Token Uses Token Resource
 Server (RS) Actors
29. Clients Public (Client Identification) Confidential
 (Client Authentication)
30. Clients Client Registration is the DMV of OAuth
31. Authorization Server Authorize Endpoint (/oauth2/authorize) Token Endpoint (/oauth2/token) Authorization Server Authorization Grant Refresh Token Access Token Introspection Endpoint (/oauth2/introspect) Revocation Endpoint (/oauth2/revoke)
32. Tokens • Short-lived token used by Client to access Resource Server (API) • Opaque to the Client • No client authentication required (Public Clients) • Optimized for scale and performance • Revocation is dependent on implementation Access Token (Required) • Long-lived token that is used by Client to obtain new access tokens from Authorization Server • Usually requires Confidential Clients with authentication • Forces client to rotate secrets • Can usually be revoked Refresh Token (Optional) OAuth doesn’t define the format of a token!
33. Access Token Types Self-encoded tokens Protected, time-limited data structure agreed upon between Authorization Server and Resource Server that contains metadata and claims about the identity of the user or client over the wire. Resource Server can validate the token locally by checking the signature, expected issuer name and expected audience or scope. Commonly implemented as a signed JSON Web Tokens (JWT) Reference tokens (aka opaque tokens) Infeasible-to-guess (secure-random) identifier for a token issued and stored by the OAuth 2.0 Authorization Server Resource Server must send the identifier via back-channel to the OAuth 2.0 Authorization Server’s token introspection endpoint to determine if the token is valid and obtain claims/scopes
34. OAuth 2.0 Authorization Code Flow yelp.com Connect with Google accounts.google.com
 Allow Yelp to access your public profile and contacts? No Yes yelp.com/callback Resource owner clicks ^^ Back to redirect URI with authorization code contacts.google Talk to resource server with access token Exchange code for access token accounts.google.com Email ********** Go to authorization server Redirect URI: yelp.com/cb Response type: code Authorization Server Client
35. More OAuth 2.0 Terminology Scopes Consent Grants
36. Scopes Additive bundles of permissions asked by client when requesting a token Decouples authorization policy decisions from enforcement Who owns the data? End user or the target service Who gets to specify the authorization policy? End user or application owner Scopes to Deny Scopes to Allow
37. Capturing User Consent Authorization Grant (Trust of First Use)
38. OAuth 2.0 Authorization Code Flow yelp.com/callback Back to redirect URI with authorization code contacts.google Talk to resource server with access token Exchange code for access token accounts.google.com Email ********** Go to authorization server Redirect URI: yelp.com/cb Scope: profile contacts Authorization Server yelp.com Connect with Google Resource owner Client accounts.google.com
 Allow Yelp to access your public profile and contacts? No Yes Request consent from resource owner
39. Flow Channels Resource
 Server (RS) Authorization
 Server (AS) Resource Owner (RO) Client Delegates Obtains Token Uses Token Back Channel Front Channel
40. Front Channel Flow Authorize via User Agent Resource
 Server (RS) Authorization
 Server (AS) 4 2 3 1 Resource Owner starts flow to delegate access to protected resource 1 Client 2 Client sends authorization request with desired scopes via browser redirect to Authorize Endpoint on Authorization Server 3 User authenticates and consents to Delegated Access (Grant) 4 Authorization Code Grant or Access Token is returned to Client via browser redirect Resource Owner (RO)
41. Authorization Request GET https://accounts.google.com/o/oauth2/auth?
 scope=gmail.insert gmail.send&
 redirect_uri=https://app.example.com/oauth2/callback&
 response_type=code&
 client_id=812741506391&
 state=af0ifjsldkj HTTP/1.1 302 Found
 Location: https://app.example.com/oauth2/callback?
 code=MsCeLvIaQm6bTrgtp7&
 state=af0ifjsldkj Request Response Note: Parameters are not URL-encoded for example purposes
42. Back Channel Flow Exchange Grants for Tokens Resource
 Server (RS) Authorization
 Server (AS) 1 Client 2 Client accesses protected resource with Access Token Resource Owner (RO) 2 Client exchanges Authorization Code Grant with token endpoint on Authorization Server for an Access Token and optionally Refresh Token 1
43. Token Request POST /oauth2/v3/token HTTP/1.1 Host: www.googleapis.com Content-Type: application/x-www-form-urlencoded code=MsCeLvIaQm6bTrgtp7& client_id=812741506391& client_secret={client_secret}& redirect_uri=https://app.example.com/oauth2/callback& grant_type=authorization_code Note: Parameters are not URL-encoded for example purposes
44. Token Response { "access_token": "2YotnFZFEjr1zCsicMWpAA", "token_type": "Bearer", "expires_in": 3600, "refresh_token": "tGzv3JOkF0XG5Qx2TlKWIA" }
45. Making Protected Resource Requests curl -H "Authorization: Bearer 2YotnFZFEjr1zCsicMWpAA" \ https://www.googleapis.com/gmail/v1/users/1444587525/messages
46. OAuth 2.0 Authorization Code Flow yelp.com/callback Back to redirect URI with authorization code (front channel) contacts.google Talk to resource server (back channel) Exchange code for access token (back channel) accounts.google.com Email ********** Go to authorization server Redirect URI: yelp.com/cb (front channel) Authorization Server yelp.com Connect with Google Resource owner Client accounts.google.com
 Allow Yelp to access your public profile and contacts? No Yes Request consent from resource owner
47. OAuth 2.0 Grant Types (Flows) • Optimized for browser-only Public Clients • Access token returned directly from authorization request (Front-channel only) • Does not support refresh tokens • Assumes Resource Owner and Public Client are on the same device • Most vulnerable to security threats Implicit (2 Legged) • Front channel flow used by Client to obtain authorization code grant • Back channel flow used by Client to exchange authorization code grant for access token and optionally refresh token • Assumes Resource Owner and Client are on separate devices • Most secure flow as tokens never passes through user- agent Authorization Code (3 Legged) • Optimized for server-only Confidential Clients acting on behalf of itself or a user • Back-channel only flow to obtain an access token using the Client’s credentials • Supports shared secrets or assertions as Client credentials signed with either symmetric or asymmetric keys Client Credential
48. OAuth 2.0 Grant Types (Flows) • Legacy grant type for native username/password apps such as desktop apps • Username/password is authorization grant to obtain access token from Authorization Server • Does not support refresh tokens • Assumes Resource Owner and Public Client or on the same device Resource Owner Password • Allows Authorization Server to trust authorization grants from third party such as SAML IdP (Federation) • Assertion is used to obtain access token with token request • Does not support refresh tokens Assertion • Optimized for devices that do not have access to web- browsers • User code is returned from authorization request that must be redeemed by visiting a URL on a device with a browser to authorize • Back channel flow used by Client to poll for authorization approval for access token and optionally refresh token Device
49. OAuth Flows Six different flows Necessary because of: How you get consent from client? Who is making consent? Adds a lot of complexity to OAuth When people ask if you support OAuth, are they asking for all six? Image: Ian Sane, Spring Runoff
 https://www.flickr.com/photos/31246066@N04/4620052369
50. OAuth 2.0 Debugger https://oauthdebugger.com
51. OAuth 2.0 Playground https://oauth.com/playground
52. © Okta and/or its affiliates. All rights reserved. Okta Confidential Token State Management Developer Friction 52
53. Common OAuth 2.0 Security Issues Too many inputs that need validation Token hijacking with CSRF Always use CSRF token with state parameter to ensure OAuth flow integrity Leaking authorization codes or tokens through redirects Always whitelist redirect URIs and ensure proper URI validations Token hijacking by switching clients Bind the same client to authorization grants and token requests Leaking client secrets Unbounded & Bearer Tokens See draft specification of OAuth Proof-of-Possession Token Extension
54. Key Enterprise OAuth 2.0 Use Cases Decouples authorization policy decisions from enforcement Enables the right blend of fine & coarse grained authorization Replaces traditional Web Access management (WAM) Policies Restrict and revoke which apps can access specific APIs Ensure only managed and/or complaint devices can access specific APIs Deep integration with identity deprovisioning workflow to revoke all tokens for a user and device Federation with an IdP
55. OAuth 2.0 Facts Not backward compatible with OAuth 1.0 Interoperability issues exists as its not a protocol but rather an authorization framework OAuth 2.0 is not an authentication protocol OAuth 2.0 alone says absolutely nothing about the user
56. Identity Use Cases (circa 2012) Simple login — OAuth 2.0 Single sign-on across sites — OAuth 2.0 Mobile app login — OAuth 2.0 Delegated authorization — OAuth 2.0
57. © Okta and/or its affiliates. All rights reserved. Okta Confidential Not an Authentication Protocol?
58. OAuth 2.0 as Pseudo-Authentication Client accessing a https:// api.example.com/me resource with an access token is not authenticating the user Access tokens just prove the Client was authorized, are opaque, and intended to only be consumed by the Resource Server Who is the user (claims)? When did the user authenticate? Does the user still have an active or expired session? How did the user authenticate? Just password or password + second factor As made famous by Facebook Connect and Twitter
59. OpenID Connect OpenID Connect
60. OAuth 2.0 and OpenID Connect OpenID Connect is for authentication
 OAuth 2.0 is for authorization OpenID Connect OAuth 2.0 HTTP
61. OpenID Connect Extends OAuth 2.0 with new signed id_token for the Client and UserInfo endpoint to fetch user attributes Provides a standard set of scopes and claims for identities profile email address phone Built-in registration, discovery & metadata for dynamic federations Bring Your Own Identity (BYOI) Supports high assurance levels and key SAML use cases (enterprise) OAuth 2.0 + Facebook Connect + SAML 2.0 (good parts)
62. Authorization Request GET https://accounts.google.com/o/oauth2/auth?
 scope=openid email&
 redirect_uri=https://app.example.com/oauth2/callback&
 response_type=code&
 client_id=812741506391&
 state=af0ifjsldkj HTTP/1.1 302 Found
 Location: https://app.example.com/oauth2/callback?
 code=MsCeLvIaQm6bTrgtp7&
 state=af0ifjsldkj Request Response Note: Parameters are not URL-encoded for example purposes
63. Token Request POST /oauth2/v3/token HTTP/1.1 Host: www.googleapis.com Content-Type: application/x-www-form-urlencoded code=MsCeLvIaQm6bTrgtp7& client_id=812741506391& client_secret={client_secret}& redirect_uri=https://app.example.com/oauth2/callback& grant_type=authorization_code Note: Parameters are not URL-encoded for example purposes
64. Token Response { "access_token": "2YotnFZFEjr1zCsicMWpAA", "token_type": "Bearer", "expires_in": 3600, "refresh_token": "tGzv3JOkF0XG5Qx2TlKWIA", "id_token": "eyJhbGciOiJSUzI1NiIsImtpZCI6IjFlOWdkazcifQ..." }
65. Validate ID Token Token Endpoint Authorization Endpoint /.well-known/
 openid-configuration JWKS Endpoint UserInfo Endpoint OAuth 2.0 Authorization Server & OpenID Connect Provider (OP) OAuth 2.0 Resource Server Client (Relying Party) 1 3 2 5 4 1 Discover OpenID Provider Metadata 2 Perform OAuth flow to obtain a ID token and/or access token 3 Get JSON Web Key Set (JWKS) for signature keys 4 Validate ID token
 (JSON Web Token) 5 Get additional user attributes with access token from UserInfo endpoint OpenID Connect
66. OIDC Authorization Code Flow yelp.com/callback Back to redirect URI with authorization code Exchange code for access token and ID token accounts.google.com Email ********** Go to authorization server Redirect URI: yelp.com/cb Scope: openid profile Authorization Server yelp.com Connect with Google Resource owner Client accounts.google.com
 Allow Yelp to access your public profile and contacts? No Yes Request consent from resource owner Hello Matt! accounts.google Get user info
 with access token /userinfo
67. JSON Web Token (JWT) base64url(Header) + “.” + base64url(Claims) + “.” + base64url(Signature) eyJhbGciOiJSUzI1NiJ9.eyJpc3MiOiJodHRwczovL2 V4YW1wbGUub2t0YS5jb20iLCJzdWIiOiIwMHVncmVuT WVxdllsYTRIVzBnMyIsImF1ZCI6IncyNTVIRVdpU1U0 QXVOeEVqZWlqIiwiaWF0IjoxNDQ2MzA1MjgyLCJleHA iOjE0NDYzMDg4ODIsImFtciI6WyJwd2QiXSwiYXV0aF 90aW1lIjoxNDQ2MzA1MjgyLCJlbWFpbCI6ImthcmxAZ XhhbXBsZS5jb20iLCJlbWFpbF92ZXJpZmllZCI6dHJ1 ZX0.XcNXs4C7DqpR22LLti777AMMVCxM7FjEPKZQnd- AS_Cc6R54wuQ5EApuY6GVFCkIlnfbNmYSbHMkO4H- L3uoeXVOPQmcqhNPDLLEChj00jQwZDjhPD9uBoNwGyi Z9_YKwsRpzbg9NEeY8xEwXJFIdk6SRktTFrVNHAOIhE Qsgm8 { "alg": "RS256”
 "kid": "123456789" } { "iss": "https://example.okta.com", "sub": "00ugrenMeqvYla4HW0g3", "aud": "w255HEWiSU4AuNxEjeij", "iat": 1446305282, "exp": 1446308882, "amr": [ "pwd" ], "auth_time": 1446305282, "email": "matt@example.com", "email_verified": true } Header Claims Signature Header Claims
68. jsonwebtoken.io https://www.jsonwebtoken.io
69. Which grant type is right for you? Authorization
 Code Implicit Authorization
 Code Client Credentials
70. Session Best Practices ID Tokens should be used to create a session for a traditional web application or single-page application Use subject claim (sub) as stable identifier for the user account Session cookies should be protected with HTTPOnly flag to prevent JavaScript access Avoid using ID Tokens as a stateless “session token” for Single Page Apps API is not the audience of the token ID Tokens can be large in size and often contain PII or other sensitive data ID Token lifetime is not your app’s session lifetime
71. Native App Best Practices Do not use an embedded web views for authenticating users! App (or 3rd party library/script) can directly obtain the user’s credentials which goes against OAuth’s raison d'être Users can’t reuse their existing session with their IdP (SSO) increasing friction for sign-in/sign-up IdPs can’t implement new authentication methods Do not store client secrets in apps that are distributed via App Stores! Use PKCE (RFC 7636) to protect authorization code from interception Follow guidelines outlined in OAuth 2.0 for Native Apps Best Current Practice
 https://tools.ietf.org/html/draft-ietf-oauth-native-apps-12 302 Found
 Location: app://redirect
72. Just Use AppAuth! https://appauth.io Implements OAuth 2.0 for Native Apps Best Current Practice
73. OAuth and OIDC Demos github.com/oktadeveloper
74. Google OAuth Client Library ScribeJava Spring Security OAuth Nimbus OAuth SDK List of client and server libraries for many languages: https://oauth.net/code/ OAuth and OIDC Libraries
75. ORY Hydra https://github.com/ory/hydra Apereo CAS https://github.com/apereo/cas Keycloak https://github.com/keycloak/keycloak JHipster UAA https://jhipster.github.io/using-uaa/ Open Source OAuth and OIDC Servers
76. OAuth Specification oauth.net OAuth 2.0 Servers oauth.com Additional Resources
77. © Okta and/or its affiliates. All rights reserved. Okta Confidential What does JHipster use?
78. My JHipster 6 Blog Posts Better, Faster, Lighter Java with Java 12 and JHipster 6 Upgrading Spring Security OAuth and JUnit Tests through the of a Java Hipster Java Microservices with Spring Cloud Config and JHipster Build Mobile Apps with Angular, Ionic 4, and Spring Boot
79. developer.okta.com/blog @oktadev
80. Written with Asciidoctor Quick and to the point, 164 pages Developed a Real World App: 21-points.com Free Download from infoq.com/minibooks/jhipster-mini-book-5 The JHipster Mini-Book
81. Play with OAuth 2.0 and OIDC
82. YouTube: OAuth 2.0 in plain English https://youtu.be/996OiexHze0
83. Questions? Keep in touch! raibledesigns.com @mraible Presentations speakerdeck.com/mraible Code github.com/oktadeveloper
84. @oktadev
