Java EE 6 Security in practice with GlassFish

Java EE 6 Security in practice with GlassFish

Markus Eisele

October 01, 2012
Tweet

More Decks by Markus Eisele

Other Decks in Technology

Transcript

  1. Agenda • Introduction • The Top 10 Most Critical Web

    Application Security Risks • Take Away
  2. Markus Eisele http://blog.eisele.net http://twitter.com/myfear [email protected] Java EE 7 EG, architect,

    husband, father of two, photographer, speaker, writer Masoud Kalali http://kalali.me http://twitter.com/MasoudKalali [email protected] software engineer, author, blogger, climber and flute enthusiast
  3. Galleria and Security • Form based authentication • JDBCRealm •

    request.login(userId, new String(password)); • @RolesAllowed({ "RegisteredUsers" }) Enough? State-of-the-Art? Feeling-good-with-it™?
  4. Motivation for this talk • Seen a lot • Providing

    a starting point • Sharing something • Making you aware • Plus: Finding out about “the security state of Galleria”
  5. The Top 10 Most Critical Web Application Security Risks Attribution-ShareAlike

    3.0 Unported (CC BY-SA 3.0) Source: http://owasptop10.googlecode.com Aka OWASP Top-10*
  6. What is OWASP? • Open Web Application Security Project •

    Improving the security of (web) application software – Not-for-profit organization since 2001 – Raise interest in secure development • Documents – Top 10 – Cheat Sheets – Development Guides • Solutions – Enterprise Security API (ESAPI) – WebScarab – WebGoat
  7. What is it? • Sending unintended data to applications •

    Manipulating and reading Data stores (e.g. DB, LDAP) • Java EE 6 affected: – UI technology of choice (e.g. JSF, JSP) – Database access (JPA, JDBC)
  8. How to spot it String id = "x'; DROP TABLE

    members; --"; // user-input Query query = em.createNativeQuery("SELECT * FROM PHOTO WHERE ID =" + id, Photo.class); Query query2 = em.createNativeQuery("SELECT * FROM MAG WHERE ID ?1", Magazine.class); query2.setParameter(1, id);
  9. Prevent Injection • Sanitize the input • Escape/Quotesafe the input

    • Use bound parameters (the PREPARE statement) • Limit database permissions and segregate users • Use stored procedures for database access (might work) • Isolate the webserver • Configure error reporting
  10. What is it? • Inject malicious code into user interfaces

    • Get access to browser information – E.g. javascript:alert(document.cookie) • Steal user’s session, steal sensitive data • Rewrite web page or parts • Redirect user to phishing or malware site • Java EE 6 affected: – UI technology of choice (e.g. JSF, JSP)
  11. How to spot it <h:outputText value="#{user.content}" escape="false"/> • Problems with

    sanitizing • Weird Input <a href="data:text/html;base64,PHNjcmlwdD5hbGVydCgvWFNTLyk8L3NjcmlwdD4=">T est</a>
  12. Prevent • Sanitize the input • Escape/Quotesafe the input •

    Use Cookie flags: – httpOnly (prevents XSS access) https://code.google.com/p/owasp-esapi-java/
  13. What is it? • Container Security vs. own solution •

    Session Binding / Session Renewal • Passwords – Strength (length/complexity) – Plain text passwords (http/https) – Recovery mechanisms • Number of factors used for authentication • Java EE 6 affected: – JAAS / JASPIC – Filter / PhaseListener – Container and Web-App configuration
  14. How to spot it • Authentication over http • Custom

    security filter • Not using Container Functionality • No password strength requirements • No HttpSession binding • Way of saving Passwords • Not testing security
  15. Best Practices • Go with provided Standard Realms and LoginModules

    whenever possible • If you need custom ones: Test them extremely carefully! • Use transport layer encryption (TLS/SSL) • Use Cookie flags: – secure (avoid clear text transmission)
  16. What is it? • Accessing domain objects with their PK

    https://you.com/user/1 => https://you.com/user/21 • Opening opportunities for intruders • Information hiding on the client • Parameter value tampering • Java EE 6 affected: – All layers – Especially data access
  17. How to spot it • Data separation for users (tenants)

    • Request mode access for data (RUD) • Query constraints
  18. Best Practices • Use AccessReferenceMaps • Validate object references •

    Use data-driven security • Always Perform additional data authorization on the view http://app?file=1 http://app?id=7d3J93 http://app?id=9182374 http://app?file=Report123.xls
  19. What is it? • Basically a capture-replay attack • Malicious

    code executes functions on your behalf while being authenticated • Deep links make this easier • JavaEE 6 affected: – UI technology of choice (e.g. JSF, JSP)
  20. How to spot it • A “secret Cookie” • Only

    POST requests • Wizard like transactions • Simple URL rewriting
  21. Best Practices • Add Unpredictability (tokens) – Hidden Field, Single-Use

    URLs – Request or Session Scope • CSRFPreventionForm (JSF 1.2 & 2) http://blog.eisele.net/2011/02/preventing-csrf-with-jsf-20.html • Use OWASP ESAPI http://www.jtmelton.com/2010/05/16/the-owasp-top-ten-and-esapi-part-6-cross- site-request-forgery-csrf/
  22. What is it? • Applies to – Operating System –

    Application Server – Databases – Additional Services • Includes (beside _many_ others) – All security relevant configuration – Missing Patches – Default accounts
  23. Worst Practices • Not restricting GlassFish user nor enabling security

    manager • Network interfaces/sockets access control • Relaxed File system access control • Using any defaults like: – Passwords: Admin, master password – Network interface binding: Listening on 0.0.0.0 – Certificates: Self signed certificate • Using a not hardened OS!
  24. Policy Files location • Global Policy File: java.home/jre/lib/security/java.policy • User

    Policy File: user.home/.java.policy • Domain Policy File: domain.home/config/server.policy • Application Policy File: domain.home/generated/policy/<app.name>/ <module.name>/granted.policy
  25. Running GlassFish in a Secure Environment • Use the latest

    version (3.1.2.2) • Enable secure admin (TLS/https) • Use password aliasing • Enable security manager and put forth a proper security policy file • Set correct file system permissions http://blog.eisele.net/2011/05/securing-your-glassfish-hardening-guide.html http://docs.oracle.com/cd/E18930_01/html/821-2435/gkscr.html
  26. Review the *.policy files • Policy files precedence order •

    Remove unused grants • Add extra permissions only to applications or modules that require them, not to all applications deployed to a domain. • Document your changes!
  27. What is it? • Presentation layer access control • Related

    to A4 – Insecure Direct Object References
  28. Worst Practice • Using home-grown security features instead of container

    provided ones • Assuming people wont know some URLs to try them • Assuming no one would misuse the extra permission and access they have
  29. Java EE 6 • What you do to prevent, A4

    plus: – Use Container security (security-constraint) – Use programmatic login of Java EE 6 if needed. – Properly configure security realms – Accurately map roles to principal/groups (auth- constraint / security-role-mapping) – Only allow supported/required HTTP methods – Accurately Categorize the URL patterns and permit the relevant roles for each
  30. Best Practices • Any none public URL should be protected

    • Use container authentication/authorization features or extend on top of them • If not enough use proven frameworks/ products to protect the resources • If user can get /getpic?id=1x118uf it does not mean you should show /getpic?id=1x22ug
  31. What is it? • Sensitive data kept unprotected • Sensitive

    data exposed to wrong persons • Could be: – Passwords – Financial/Health care data – Credit cards
  32. Worst Practices • Storing sensitive data unencrypted • Storing comparative

    data unhashed (passwords/security question answer…) • Keeping clear text copies of encrypted data • Not keeping the keys/passwords well guarded
  33. GlassFish • Protect the keystore • Protect GlassFish accounts –

    Use aliasing to protect the password and keep the master password safe to protect the aliases • Ignoring digest authentication/hashed password storage
  34. Prevention • Identify sensitive data • Wisely encrypt sensitive data

    – On every level (application, appserver, db) – with the right algorithm and – with the right mechanism • Don’t keep clear text copies • To decrypt and view clear text should be restricted to authorized personnel • Keep the keys as protected as possible (HSM) • Keep offsite encrypted backups in addition to on-site copies
  35. Worst Practice • Using basic/form authentication without SSL • Not

    using HTTPS for pages with private information • Using default self signed certificate • Storing unencrypted cookies • Not setting cookies to be securely transmitted Cookie.setSecure(true) • Forgetting about the rest of the infrastructure
  36. GlassFish • Properly configure HTTPS listener/s (set the right keystore)

    • Install the right server certificates to be used by SSL listeners • Properly configure the ORB over SSL listeners if needed (set the right keystore) • Enable auditing under Security and access log under HTTP Service
  37. Java EE • Group the resources in regard to transport

    sensitivity using web-resource-collection • Use user-data-constraint as widely as you need for data integrity and encryption needs • Ensure that login/logout pages (in case of form auth-type) are protected by <transport- guarantee>CONFIDENTIAL</transport- guarantee>
  38. Best Practice • Use TLS on all connections with sensitive

    data • Individually encrypt messages • Sign messages before transmission • Use standard strong algorithms • Use proven mechanisms when sufficient
  39. What is it? • Redirecting to another URL computed by

    user provided parameters • Forward to another URL computed by user provided parameters http://www.java.net/external?url=http://www.adam- bien.com/roller/abien/entry/conveniently_transactionally_a nd_legally_starting
  40. Worst Practices • Not using a proper access control mechanism

    (e.g container managed and proper security- constraint ) • Redirecting to a user provided parameter, e.g to an external website • Not to validate/verify the target with user’s access level before doing the forward
  41. Java EE 6 • Don’t use redirect or forward as

    much as possible • Accurately verify/validate the target URL before forwarding or redirecting • Redirects are safe when using container managed authentication/authorization properly • Forwards happen without authentication and thus requires triple check to prevent unauthorized access.
