Make it SOLID. Software Architecture for System Administrators

Gave this talk at OSDC 2014 in Berlin, Germany on April 9th, 2014
Follow me on Twitter: @CodeStars or Sönke @s0enke

Starting with Chef or Puppet as a System Administrator will lead you to a problem where you are not sure what's the best solution of a problem in terms of software architecture. We will give you a brief overview of general well known and battle tested software patterns, which also applies to infrastructure management code. In addition, we'll also show Antipatterns, and best practices.

Ole Michaelis

April 09, 2014
Tweet

More Decks by Ole Michaelis

Other Decks in Technology

Transcript

  1. Ole Michaelis & Sönke Ruempler | Jimdo Make it SOLID

    Software Architecture for System Administrators
  2. OSDC 2014 node web-1 { $role = 'web-app-a' $has_apache =

    true; include php5 } node web-2 { $role = 'web-app-b' $has_fcgi=true include php5 } # has both enabled, but needs a special config node web-3 { $role = 'web-app-c' $has_fcgi=true $has_apache=true include php5 } Web App 1 Web App 2 Web App 3
  3. OSDC 2014 class php5 { if ($::has_fcgi) package { 'php5-cli'

    : ensure => installed } } if ($::has_apache) { package { 'php5-apache' : ensure => installed } } if ($::role == 'web-app-c') package { 'php5-web-app-c-special-module' } file { '/etc/php5/php.ini' : source => 'puppet:///modules/php5/php.ini-web-app-c' } } } Global variable! Out of Context! No abstraction
  4. OSDC 2014 class php5( $has_fcgi = false, $has_apache = false,

    $role = undef ) { if ($has_fcgi) package { 'php5-cli' : ensure => installed } } if ($has_apache) { package { 'php5-apache' : ensure => installed } } if ($role == 'web-app-c') { package { 'php5-web-app-c-special-module' } file { '/etc/php5/php.ini' : source => 'puppet:///modules/php5/php.ini-web-app-c' , require => Package[php-fcgi] } }
  5. OSDC 2014 node 'web-1' { $role = 'web-app-a' $has_apache =

    true class { 'php5' : has_apache => true, role => 'web-app-a' } } node 'web-2' { $role = 'web-app-b' $has_fcgi = true class { 'php5' : has_fcgi => true, role => 'web-app-b' } } Injection! Injection!
  6. OSDC 2014 Would you solder a lamp directly to the

    electrical wiring in a wall? Dependency Inversion
  7. OSDC 2014 class php5( $has_fcgi = false, $has_apache = false,

    $role = undef ) { if ($has_fcgi) package { 'php5-cli' : ensure => installed } } if ($has_apache) { package { 'php5-apache' : ensure => installed } } if ($role == 'web-app-c') { package { 'php5-web-app-c-special-module' } file { '/etc/php5/php.ini' : source => 'puppet:///modules/php5/php.ini-web-app-c' require => Package[php-fcgi] } } }
  8. OSDC 2014 if ($lighttpd) { package { 'php5-cgi': } configdir

    { '/etc/php5/cgi': require => Package['php5-cgi'] } configdir { '/etc/php5/cgi/conf.d': require => Package['php5-cgi'] } if ($testserver) { configfile { '/etc/php5/cgi/php.ini': sourcename => 'php5/cgi/php.ini-testserver', require => Package['php5-cgi'] } } else { if ($cms ) { configfile { '/etc/php5/cgi/php.ini': sourcename => 'php5/cgi/php.ini-cms', require => Package['php5-cgi'] } } else { if ($mgmt ) { configfile { '/etc/php5/cgi/php.ini': sourcename => 'php5/cgi/php.ini-mgmt', require => Package['php5-cgi'] } } else { if ($lc ) { configfile { '/etc/php5/cgi/php.ini': sourcename => 'php5/cgi/php.ini-lc. jimdo.com', require => Package['php5-cgi'] } } else { configfile { '/etc/php5/cgi/php.ini': sourcename => 'php5/cgi/php.ini', require => Package['php5-cgi'] } } } } } configfile { '/etc/php5/cgi/conf.d/pdo.ini': sourcename => 'php5/cgi/conf.d/pdo.ini', require => Package['php5-cgi'] } }
  9. OSDC 2014 describe :node => 'web-1' do it { should

    contain_package ('php5-fcgi') } end describe :node => 'web-2' do it { should contain_package ('php5-apache2' ) } end describe :node => 'web-3' do it { should contain_package ('php5-fcgi') } it { should contain_package ('php5-apache2' ) } end Test php5 class: Install Package ?
  10. OSDC 2014 describe :class => 'php5::fcgi' do it { should

    contain_package('php5-cli') } end describe :class => 'php5::apache' do it { should contain_package('php5-apache2') } end class php5::fgci { package { 'php5-cgi' : ensure => installed } } class php5::apache { package { 'php5-apache' : ensure => installed } }
  11. OSDC 2014 describe :node => 'web-1' do it { should

    include_class('php5::fcgi') } it { should contain_package('php5-fcgi') } end describe :node => 'web-2' do it { should include_class('php5::apache') } it { should contain_package('php5-apache2') } end node web-1 { include php5::apache } node web-2 { include php5::fcgi } Tests Code
  12. OSDC 2014 “programs […] are changed by adding new code,

    rather than by changing existing code” Open Close Principle
  13. OSDC 2014 new requirements... now web app 1 needs a

    second node node web-1 { $role = 'web-app-a' include php5::apache } node web-1a { $role = 'web-app-a' include php5::apache }
  14. OSDC 2014 class role::web-app-a { include php5::apache } node web-1

    { include role::web-app- a } node web-1a { include role::web-app- a } Our new role! And nodes just include it!
  15. OSDC 2014 ? class php5::fcgi($role = undef) { if ($role

    == 'web-app-c') { package { 'php5-web-app-c-special-module' } file { '/etc/php5/php.ini' : source => 'puppet:///modules/php5/php.ini-web-app-c', require => Package[php-fcgi] } } }
  16. OSDC 2014 class role::web-app-c::special-php-stuff { package { 'php5-web-app-c-special-module' } file

    { '/etc/php5/php.ini' : source => 'puppet:///modules/php5/php.ini-web-app-c' } } 1. Split out the special case into its own class.
  17. OSDC 2014 class php5::fcgi($include_after_package_install = undef) { package { 'php5-fcgi'

    : ensure => installed } if ($include_after_package_install) include $include_after_package_install Package['php5-fcgi'] -> Class[$include_after_package_install] } } 2. Make the special case pluggable and reusable. 2a. And name it abstract.
  18. OSDC 2014 class role::web-app-c { include php5::apache class { 'php5::fcgi'

    : include_after_package_install => 'profile::web-app-c::special-php-stuff' } } 3. Pass the special case as dependency in our web-app-c.
  19. OSDC 2014 class profile::web-app-c::special-php-stuff { package { 'php5-web-app-c-special-module' } file

    { '/etc/php5/php.ini' : source => 'puppet:///modules/php5/php.ini-web-app-c' } } ?
  20. OSDC 2014 define php5::specialconfig( $ensure = present, $sapi, $module, $key,

    $value, $section = undef, $path = '/etc/php5/%s/conf.d/%s.ini' ) { ini_setting { $title: ensure => $ensure, path => sprintf($path, $sapi, $module), section => $section, setting => $key, value => $value, require => Package["php5-${sapi}"] } }
  21. OSDC 2014 # /etc/puppet/hieradata/web1.yaml --- classes: - profile::web-app-a # /etc/puppet/hieradata/web1a.yaml

    --- classes: - profile::web-app-a # /etc/puppet/hieradata/web2.yaml --- classes: - profile::web-app-c # /etc/puppet/hieradata/web3.yaml --- classes: - profile::web-app-c puppet-hiera example in YAML
  22. OSDC 2014 node default { hiera_include('classes') } node web-1 {

    include role::web-app-a } node web-1a { include role::web-app-a } node web-2 { include role::web-app-b } node web-3 { include role::web-app-c }
  23. OSDC 2014 If it looks like a duck, quacks like

    a duck, but need batteries - you probably have the wrong abstraction! Liskov Substitution
  24. OSDC 2014 Sources • http://www.slideshare.net/PuppetLabs/garethrushgrove-puppetconf • http://www.slideshare.net/PuppetLabs/alessandro-franceschi-new • https://github.com/jedi4ever/stop-the-fork •

    http://lostechies.com/derickbailey/2009/02/11/solid-development-principles-in-motivational- pictures/ • https://speakerdeck.com/jfryman/refactoring-puppet • http://www.clker.com/cliparts/e/2/a/d/1206574733930851359Ryan_Taylor_Green_Tick.svg.med. png • http://www.craigdunn.org/2012/05/239/ • http://cdn.slashgear.com/wp-content/uploads/2012/10/google-datacenter-tech-13.jpg • http://deviq.com/Media/Default/Article/Dont-Call-Us-Well-Call-You-Jun-2013.png • http://www.timeshighereducation.co.uk/Pictures/web/g/q/g/copy_paste_keyboard_button_450.jpg • http://sanremo.com.au/wp-content/uploads/2013/05/lasagna.jpg • http://4.bp.blogspot. com/_9kQQgQD35rY/SaV5p8YBGhI/AAAAAAAAAkg/HOvlhIo7yGI/s400/06_Red_Green_Refactor. JPG • http://www.thelolshop.com/wp-content/uploads/2012/11/20121126-101937.jpg •
