Droidcon Boston 2017: Cool ConstraintLayout

Droidcon Boston 2017: Cool ConstraintLayout

Huyen's presentation at Droidcon Boston 2017 on some of the cool things that you can do with ConstraintLayout.

Huyen Tue Dao

April 11, 2017
Tweet

More Decks by Huyen Tue Dao

Other Decks in Programming

Transcript

  1. CONSTRAINTS EQUATIONS SOLVER POSITION FIXED WRAP CONTENT MATCH CONSTRAINT RATIO

    EDGE CENTER BASELINE DIMENSION HELPERS/GROUPINGS GUIDELINE CONSTRAINTSET CHAINS 8 HOW DOES IT WORK?
  2. <android.support.constraint.Guideline
 android:layout_width="wrap_content"
 android:layout_height="wrap_content"
 android:id="@+id/guideline_start"
 android:orientation="vertical"
 app:layout_constraintGuide_begin="16dp" />


 <android.support.constraint.Guideline


    android:layout_width="wrap_content"
 android:layout_height="wrap_content"
 android:id="@+id/horizontal"
 android:orientation="horizontal"
 app:layout_constraintGuide_percent="0.37" /> #DROIDCONBOS
  3. public class SquareImageView extends ImageView { @Override
 protected void onMeasure(int

    widthMeasureSpec, int heightMeasureSpec) {
 super.onMeasure(widthMeasureSpec, heightMeasureSpec);

 final int size = Math.min(getMeasuredWidth(), getMeasuredHeight());
 setMeasuredDimension(size, size);
 } #DROIDCONBOS
  4. private fun updateManualAnchors() {
 val size = anchorMinSize + seekBar.progress


    val halfSize = Math.round(size * 0.5f)
 val horizontalMargin = resources.getDimensionPixelSize(R.dimen.content_margin_horizontal) - halfSize
 val verticalMargin = resources.getDimensionPixelSize(R.dimen.alignment_rectangle_margin_vertical) - halfSize
 updateManualAnchor(frameAnchorTop, size, verticalMargin, 0, 0, 0)
 updateManualAnchor(frameAnchorStart, size, 0, horizontalMargin, 0, 0)
 updateManualAnchor(frameAnchorBottom, size, 0, 0, verticalMargin, 0)
 updateManualAnchor(frameAnchorEnd, size, 0, 0, 0, horizontalMargin)
 }

 private fun updateManualAnchor(anchor: View, size: Int,
 marginTop: Int, marginStart: Int,
 marginBottom: Int, marginEnd: Int) {
 val layoutParams = anchor.layoutParams as FrameLayout.LayoutParams layoutParams.width = size
 layoutParams.height = size
 layoutParams.topMargin = marginTop
 layoutParams.bottomMargin = marginBottom
 layoutParams.marginStart = marginStart
 layoutParams.marginEnd = marginEnd anchor.layoutParams = layoutParams
 } WITH CONSTRAINTLAYOUT JUST CHANGE THE SIZE…
  5. <TextView
 android:id=“@+id/weighted_chain_head
 android:layout_width="0dp"
 android:layout_height="wrap_content"
 app:layout_constraintHorizontal_chainStyle="spread"
 app:layout_constraintHorizontal_weight=“1" /> <TextView
 android:id=“@+id/next android:layout_width="0dp"


    android:layout_height="wrap_content"
 app:layout_constraintHorizontal_weight="2" /> <TextView
 android:id=“@+id/last
 android:layout_width="0dp"
 android:layout_height="wrap_content"
 app:layout_constraintHorizontal_weight="1" /> 32 WEIGHTED CHAIN
  6. CONSTRAINT SET #DROIDCONBOS DEFINE SET OF CONSTRAINTS PROGRAMMATICALLY CREATE/SAVE/APPLY CREATE

    MANUALLY CLONE A LAYOUT FILE CLONE A CONSTRAINT LAYOUT AWESOME WITH TRANSITIONS
  7. // Inflate initial layout as usual. setContentView(R.layout.activity_constraintset_01) // Get references

    to controls
 constraintLayout = findViewById(R.id.constraint_layout) as ConstraintLayout

 // Load ConstraintSets.
 constraintSet01.clone(constraintLayout)
 constraintSet02.clone(this, R.layout.activity_constraintset_02) …some time later… // Toggle ConstraintSets. TransitionManager.beginDelayedTransition(constraintLayout)
 if (original) constraintSet02.applyTo(constraintLayout)
 else constraintSet01.applyTo(constraintLayout)
 original = !original 38
  8. CUSTOM VIEW GROUP #DROIDCONBOS LAYOUT IS LOW-LEVEL (X, Y) LOTS

    OF CODE TO ACCOMPLISH A SIMPLE LAYOUT ADVANCED LAYOUTS… WOAH
  9. @Override
 protected void onLayout(boolean changed, int left, int top, int

    right, int bottom) {
 MarginLayoutParams layoutParams = (MarginLayoutParams) icon.getLayoutParams();

 // Figure out the x-coordinate and y-coordinate of the icon.
 int x = getPaddingLeft() + layoutParams.leftMargin;
 int y = getPaddingTop() + layoutParams.topMargin;

 // Layout the icon.
 icon.layout(x, y, x + icon.getMeasuredWidth(), y + icon.getMeasuredHeight());

 // Calculate the x-coordinate of the title: icon's right coordinate +
 // the icon's right margin.
 x += icon.getMeasuredWidth() + layoutParams.rightMargin;

 // Add in the title's left margin.
 layoutParams = (MarginLayoutParams) titleView.getLayoutParams();
 x += layoutParams.leftMargin;

 // Calculate the y-coordinate of the title: this ViewGroup's top padding +
 // the title's top margin
 y = getPaddingTop() + layoutParams.topMargin;

 // Layout the title.
 titleView.layout(x, y, x + titleView.getMeasuredWidth(), y + titleView.getMeasuredHeight());

 // The subtitle has the same x-coordinate as the title. So no more calculating there.

 // Calculate the y-coordinate of the subtitle: the title's bottom coordinate +
 // the title's bottom margin.
 y += titleView.getMeasuredHeight() + layoutParams.bottomMargin;
 layoutParams = (MarginLayoutParams) subtitleView.getLayoutParams();

 // Add in the subtitle's top margin.
 y += layoutParams.topMargin;

 // Layout the subtitle.
 subtitleView.layout(x, y,
 x + subtitleView.getMeasuredWidth(), y + subtitleView.getMeasuredHeight());
 }
  10. private fun addRow(view: View) {
 constraintLayout.addView(view)

 val id =

    view.id
 constraintSet.constrainWidth(id, MATCH_CONSTRAINT)
 constraintSet.constrainHeight(id, rowHeight)

 // Constrain new view vertically.
 val target = if (lastRowId  PARENT_ID) TOP else BOTTOM
 constraintSet.connect(id, TOP, lastRowId, target) // Constrain new view horizontally.
 constraintSet.connect(id, START, PARENT_ID, START)
 constraintSet.connect(id, END, PARENT_ID, END)

 // Toggle elevation to elevate last added view.
 constraintSet.setElevation(id, resources.getDimension(R.dimen.elevation_content))
 constraintSet.setElevation(lastViewId, 0f)

 // Apply constraints.
 constraintSet.applyTo(constraintLayout) 43
  11. private fun addRowItem(view: View) {
 …
 constraintLayout.addView(view)

 val id

    = view.id

 // Initialize width and height of new view.
 constraintSet.constrainWidth(id, MATCH_CONSTRAINT)
 constraintSet.constrainHeight(id, rowHeight)

 // Constrain new view vertically.
 val target = if (lastRowId  PARENT_ID) TOP else BOTTOM
 constraintSet.connect(id, TOP, lastRowId, target) 44
  12. // Update current row.
 currentRow.add(id)
 // Re-create horizontal chain with

    other row items.
 constraintSet.createHorizontalChainRtl(
 PARENT_ID, START,
 PARENT_ID, END,
 currentRow.toIntArray(), FloatArray(currentRow.size, { 1f }),
 CHAIN_SPREAD_INSIDE)

 // Toggle elevation to elevate last added view.
 constraintSet.setElevation(id, resources.getDimension(R.dimen.elevation_content))
 constraintSet.setElevation(lastViewId, 0f)

 // Apply constraints.
 constraintSet.applyTo(constraintLayout) 45
  13. REFERENCES 50 CONSTRAINT LAYOUT APIS DOCUMENTATION https://developer.android.com/reference/android/support/constraint/package-summary.html BUILD A RESPONSIVE

    UI WITH CONSTRAINTLAYOUT developer.android.com/training/constraint-layout/index.html ANDROID DEVELOPERS BACKSTAGE: EPISODE 50: CONSTRAINT LAYOUT androidbackstage.blogspot.com/2016/06/episode-50-constraint-layout.html USING CONSTRAINTLAYOUT TO DESIGN YOUR VIEWS | CODE LABS codelabs.developers.google.com/codelabs/constraint-layout/index.html ANDROID LAYOUTS: A NEW WORLD | GOOGLE I/O 2016 https://youtu.be/sO9aX87hq9c CONSTRAINTLAYOUT https://speakerdeck.com/writtmeyer/constraintlayout-1 ADVANCED CONSTRAINTLAYOUT http://cfp.devoxx.us/2017/talk/XOD-8930/Advanced_ConstraintLayout
  14. REFERENCES 51 CONSTRAINTLAYOUT – PART 1 blog.stylingandroid.com/constraintlayout-part-1/ CONSTRAINTLAYOUT, INSIDE AND

    OUT: PART 1 http://wiresareobsolete.com/2016/07/constraintlayout-part-1/ SOME THOUGHTS ON ANDROID’S NEW CONSTRAINTLAYOUT AND ANDROID STUDIO’S NEW DESIGN EDITOR http://www.grokkingandroid.com/thoughts-on-constraintlayout-and-design-editor/ BUILD A UI WITH LAYOUT EDITOR developer.android.com/studio/write/layout-editor.html WHAT'S NEW IN ANDROID DEVELOPMENT TOOLS | GOOGLE I/O 2016 https://youtu.be/csaXml4xtN8 THE EXPERTS' GUIDE TO ANDROID DEVELOPMENT TOOLS | GOOGLE I/O 2016 https://youtu.be/hHnTIMjd1Y8
