Mobile Vision API

Mobile Vision API

DroidUp 3.0 talk about Google Mobile Vision API

Merab Tato Kutalia

December 27, 2016
Tweet

More Decks by Merab Tato Kutalia

Other Decks in Programming

Transcript

  1. What is Vision API? Find objects in photos and video,

    using real-time on-device vision technology. • detect faces • scan barcodes • recognize text
  2. Face Detection • not recognition, just detection • The Face

    API finds human faces in photos, videos, or live streams. It also finds and tracks positions of facial landmarks such as the eyes, nose, and mouth • classification
  3. Landmarks Landmark detection is not done by default, since it

    takes additional time to run. You can optionally specify that landmark detection should be done.
  4. Classification Classification determines whether a certain facial characteristic is present.

    The Android Face API currently supports two classifications: eyes open and smiling. but iOS Face API currently supports only smiling classification. note: “eyes open” and “smiling” classification only works for frontal faces, that is, faces with at most about +/- 18 degrees.
  5. Face tracking extends face detection to video sequences. Any face

    appearing in a video for any length of time can be tracked. That is, faces that are detected in consecutive video frames can be identified as being the same person. Note: This is not face recognition
  6. Operational Status The first time that an app using the

    Face API is installed on a device, GMS will download a native library to the device in order to do face detection. A detector’s isOperational method can be used to check if the required native library is currently available
  7. Some weird things • detect nose base • scale bitmap

    • calculate Y for external bitmap • action
  8. Barcode • 1D barcodes: EAN-13, EAN-8, UPC-A, UPC-E, Code-39, Code-93,

    Code-128, ITF, Codabar • 2D barcodes: QR Code, Data Matrix, PDF-417, AZTEC Android 4.2.2
  9. Text Recognition • The Text API can recognize text in

    any Latin based language Real-Time, on device
  10. Text Recognition The Text Recognizer segments text into blocks, lines,

    and words. a Block is a contiguous set of text lines, such as a paragraph or column, a Line is a contiguous set of words on the same vertical axis, and a Word is a contiguous set of alphanumeric characters on the same vertical axis.
