PICO-SDK1.5.0 ZEPHYR V3.3.0 が出ました。 TOKITA Hiroshi
PICO-SDK 1.5.0 • RaspberryPi PicoのSDK • https://github.com/raspberrypi/pico-sdk/releases/tag/1.5.0 • Divider/DMA/I2C/Timerの改善 •
CYW43(Pico W のBT/WIFI)の大幅改善 • TinyUSB 1.3.0→1.5.0 • Pico W の BTサポート(ベータ版) • ドライバ層の方は小幅な修正。API層がメイン。 • BT/Wifiの方はFreeRTOSを使ったサンプル。 • さすがにこの辺になるとベアメタルはしんどい。
ZEPHYR V3.3.0 • https://docs.zephyrproject.org/3.3.0/releases/release-notes-3.3.html • Newlib-Nano C-Libraryが標準に。 • プロセス間通信の「ZBus」が導入された。 •
他はあまり変わり映えせず。例によって対応デバイスがたくさん増えた
RASPBERRYPI DEBUG PROBE
RASPBERRYPI DEBUG PROBE • 従来よりRasPiPicoを使ったpicoprobeの ファームウェアが提供されていたが、 これの製品版。 • PicoprobeはRaspberryPi Picoのドキュメント
でも言及があり、RaspiPicoを2個使ってデバッ ガとターゲットを用意する形。 • JSTのSH 1mmピッチ 3pin で接続。 • 既に発売されているPico H (ピンヘッダ実装済 み版)にはこのコネクタがついていた。 ので勘のいい人は発売予定になっていたことは 気づいていたはず。
SCHEMATICS ダンピング抵抗 なんだこれ? バッファのICでレベ ルシフトしている?
コミットログから • https://github.com/raspberrypi/picoprobe/tree/debugprobe • 特別版ファームウェアあり。 • https://github.com/raspberrypi/picoprobe/commit/724e5de6c8a42c2dd0f9 00a0ebfacced8327f691 probe: if
we have a separate SWDIO input, use it For boards with a level-shifter on SWDIO for compatibility with 1.8V VDDIO. • 入出力共用のSWDIOから、入力だけ分けているっぽい
多分こんな感じ。 行き?(OUT) 帰り?(IN) 帰りは無視?(IN)
疑問 • なんで入力だけ分けたのかがよくわからん。 • http://nemuisan.blog.bai.ne.jp/?eid=214764 • 昔からこの辺で苦労している先人がいる…
