Automated workflows for materials discovery
Talk given at the International Workshop on Vienna Ab-initio Simulation Package (VASP) and Applications, 2024
Alex Ganose
February 14, 2024
Transcript
34 slides
-
Automated workflows for materials discovery Alex Ganose Imperial College London
VASP and Applications 2024 virtualatoms.org -
Computational materials design VASP and Applications Workshop 2024 virtualatoms.org Structure
DFT outputs Descriptors XW K L U W LK UX 6 4 2 0 2 4 6 Energy (eV) HΨ = EΨ 1 1.5 2 2.5 Energy (eV) DFT AM1.5G Absorption (cm–1) 104 103 102 101 0.5 〈Ψ | M | Ψ〉 -
High-throughput DFT is useful for screening VASP and Applications Workshop
2024 virtualatoms.org Phonons Petretto et al., Sci. Data 2018 5, 180065 Raman spectra Bagheri & Komsa, Sci. Data 2023, 10, 80 Hybrid band gaps Kim et al., Sci. Data 2020, 7, 387 Elastic tensors De Jong et al. Sci. Data 2015, 2, 150009 Battery electrolytes Spotte-Smith et al., Sci. Data 2021, 8, 203 Transport properties Ricci et al., Sci. Data 2017, 4, 170085 1k 5k 10k 10k 17k 48k -
HT DFT typically run by materials databases VASP and Applications
Workshop 2024 virtualatoms.org -
The Materials Project registered users crystalline compounds molecular compounds band
structures elastic tensors dielectric tensors 250k 150k 31k 52k 13k 6k VASP and Applications Workshop 2024 virtualatoms.org -
Materials Discovery Apps Crystal toolkit Structure visualisation and modifications Phase
diagrams DFT compositional phase diagrams MOF explorer Search for metal–organic frameworks & coordinate polymers Interface reactions Predict reaction products of two solid substances … and many more VASP and Applications Workshop 2024 virtualatoms.org -
Pymatgen materials science analysis code VASP and Applications Workshop 2024
virtualatoms.org Make, transform, and analyse materials science objects ┌──────┐ │ core │ └┬─────┘ ┌────┘ ├─ manipulate │ structures/molecules │ ├─ periodic table │ └─ electronic structure ┌────┐ │ io │ └┬───┘ ┌────┘ ├─ read/write input │ & output files │ └─ supports VASP, CP2K, FHI-aims, Lobster, Gaussian, QChem, XTB, and more... ┌──────────┐ │ analysis │ └┬─────────┘ ┌────┘ ├─ symmetry │ ├─ phase diagrams │ ├─ surfaces │ └─ magnetic ordering -
Open-source enables reliable software VASP and Applications Workshop 2024 virtualatoms.org
project started git commits individual contributors issues closed pull requests software dependents 2011 25,222 235 1,069 2,346 1,521 -
Goal: make high- throughput easy for everyone VASP and Applications
Workshop 2024 virtualatoms.org -
what is the PBE elastic tensor of GaAs? results “something”
researcher A black-box view of calculations VASP and Applications Workshop 2024 virtualatoms.org -
how to fix ZPOTRF?? The reality what is the PBE
elastic tensor of GaAs? results tedious low- level work researcher VASP and Applications Workshop 2024 virtualatoms.org -
An ideal approach what is the PBE elastic tensor of
GaAs? results researcher workflows ├─ band structure ├─ surface energies ├─ elastic tensor ├─ raman spectrum └─ free energy workflow engine VASP and Applications Workshop 2024 virtualatoms.org -
The method should scale take all binary oxides, replace O
with S, run several properties results researcher workflows ├─ band structure ├─ surface energies ├─ elastic tensor ├─ raman spectrum └─ free energy workflow engine VASP and Applications Workshop 2024 virtualatoms.org -
Atomate2 makes this process easy run many different properties of
many materials results database researcher VASP and Applications Workshop 2024 virtualatoms.org -
Workflows Executor Database VASP and Applications Workshop 2024 virtualatoms.org Definitions
of computing jobs and how they connect together The service that submits jobs on computing resources The collection of calculation results and derived properties -
│ ├─ point defects ├─ magnetic ordering ├─ electron-phonon coupling
├─ lobster analysis ├─ electron mobility ├─ ab initio molecular dynamics ├─ ferroelectric properties ├─ electrode properties ├─ surface absorption ├─ thermal expansion ├─ lattice thermal conductivity └─ ...and more │ single-point─┤ geometry optimisation ─┤ band structure ─┤ density of states─┤ spin-orbit coupling ─┤ hybrid functionals ─┤ SCAN functionals ─┤ elastic tensor ─┤ dielectric tensor ─┤ piezoelectric tensor ─┤ harmonic phonons ─┤ free energy ─┘ Workflow library VASP and Applications Workshop 2024 virtualatoms.org atomate2 -
Workflows translate into a series of low-level tasks VASP and
Applications Workshop 2024 virtualatoms.org Example: electronic transport with VASP and AMSET structure, dir_name structure, dir_name dir_name, structure structure dir_name, structure stress, structure dir_name, structure dir_name, structure dir_name dir_name output output raw normalmode_frequencies, structure, 'born', normalmode_eigenvecs epsilon_ionic, epsilon_static epsilon_static 'frequency' 'ibands' 'dir_name' dir_name, structure dir_name output 'dir_name' output hse tight relax 1 hse tight relax 2 hse static dense uniform generate_elastic_deformations run_elastic_deformations fit_elastic_tensor dielectric bulk static deformation generate_wavefunction_coefficients amset calculate_polar_phonon_frequency sum calculate_deformation_potentials run_amset_deformations -
Jobs automatically handle VASP errors VASP and Applications Workshop 2024
virtualatoms.org Relaxation 1. Write inputs 2. Run VASP 3. Validate 4. Store outputs -
VASP and Applications Workshop 2024 virtualatoms.org Relaxation 1. Write inputs
2. Run VASP 3. Validate 4. Store outputs Run VASP 1. Start VASP executable 2. Monitor for convergence and other VASP errors 3. On error: apply fixes to input files -> resubmit calculation Jobs automatically handle VASP errors -
Supported DFT packages VASP and Applications Workshop 2024 virtualatoms.org Most
workflows are “code agnostic” and support multiple DFT software calculators -
Machine learning force fields VASP and Applications Workshop 2024 virtualatoms.org
Universal MACE_MP CHGNET M3GNET Bespoke GAP/Quippy VASP MLFF Many workflows can be run directly with machine learning force fields -
Scale from one material to thousands VASP and Applications Workshop
2024 virtualatoms.org Run a single workflow Run many with FireWorks -
Building the database VASP and Applications Workshop 2024 virtualatoms.org Material:
GaAs Calc: Relaxation Material: ZnSe Calc: Relaxation Material: GaAs Calc: DOS Material: ZnSe Calc: Surface Material: GaAs Properties: - Relaxed structure – Total energy – Density of states Material: ZnSe Properties: - Relaxed structure – Surface energies – Ionisation potential structured database much easier to explore -
Full operation diagram VASP and Applications Workshop 2024 virtualatoms.org crystal
structure computational workflow submit & execute results database -
Atomate2 standardises knowledge VASP and Applications Workshop 2024 virtualatoms.org All
past and present knowledge, from everyone in the group, everyone previously in the group, and our collaborators, about how to run calculations … and many more -
Atomate2 powers the Materials Project VASP and Applications Workshop 2024
virtualatoms.org + -
Try atomate2 today VASP and Applications Workshop 2024 virtualatoms.org Installation
pip install atomate2 Code github.com/ materialsproject/atomate2 Support matsci.org/atomate -
4-day workshop Automated ab initio workflows with jobflow, FireWorks, and
atomate2 17-20 March 2025 EPFL, Lausanne, Switzerland cecam.org/workshop-details/1276 VASP and Applications Workshop 2024 virtualatoms.org -
Conclusions VASP and Applications Workshop 2024 virtualatoms.org High-throughput is now
possible for everyone Atomate2 makes it easy by integrating with common DFT packages Standardising computational workflows reduces mistakes and accelerates your research -
Acknowledgements VASP and Applications Workshop 2024 virtualatoms.org Andrew Rosen Janine
George Janosh Riebesell Guido Petretto David Waroquiers Gian-Marco Rignanese Anubhav Jain Jimmy-Xuan Shen Nick Winner Aaron Kaplan Thomas Purcell Aakash Ashok Naik Christina Ertural Matt McDermott Matthew Evans Mingjian Wen Matthew Horton …and many more Atomate2 & jobflow contributors Funding EPSRC US Department of Energy Compute ARCHER2 NERSC MMMHub -
Acknowledgements VASP and Applications Workshop 2024 virtualatoms.org Andrew Rosen Janine
George Janosh Riebesell Guido Petretto David Waroquiers Gian-Marco Rignanese Anubhav Jain Jimmy-Xuan Shen Nick Winner Aaron Kaplan Thomas Purcell Aakash Ashok Naik Christina Ertural Matt McDermott Matthew Evans Mingjian Wen Matthew Horton …and many more Atomate2 & jobflow contributors Funding EPSRC US Department of Energy Compute ARCHER2 NERSC MMMHub And you for your attention!
