Lecture #7 1G & 2G TDMA Mobile Systems Instructor: Dr.
Ahmad El-Banna November 2014 E-716-A Mobile Communications Systems Integrated Technical Education Cluster At AlAmeeria © Ahmad El-Banna
Agenda Zero Generation (Pre cellular ) First Generation Second Generation
TDMA 2 E-716-A, Lec#7 , Nov 2014 © Ahmad El-Banna
PRE CELLULAR (ZERO GENERATION) 3 © Ahmad El-Banna E-716-A, Lec#7
, Nov 2014
0G • They are the mobile radio telephone systems preceded
modern cellular mobile telephony technology. • These systems are sometimes referred to as pre cellular (or sometimes zero generation) systems. • Technologies used in pre cellular systems included • Push to Talk (PTT or manual), • Mobile Telephone System (MTS), • Improved Mobile Telephone Service (IMTS), and • Advanced Mobile Telephone System (AMTS) systems. • These mobile telephones were usually mounted in cars or trucks, though briefcase models were also made. • Typically, the transceiver (transmitter-receiver) was mounted in the vehicle trunk and attached to the "head" (dial, display, and handset) mounted near the driver seat. 4 © Ahmad El-Banna E-716-A, Lec#7 , Nov 2014
FIRST GENERATION 5 © Ahmad El-Banna E-716-A, Lec#7 , Nov
2014
Mobile/Cellular System Evolution 6 © Ahmad El-Banna E-716-A, Lec#7 ,
Nov 2014
1G Analog • Original cellular telephone networks • Analog traffic
channels • Early 1980s in North America • Advanced Mobile Phone Service (AMPS) • AT&T • Also common in South America, Australia, and China 7 © Ahmad El-Banna E-716-A, Lec#7 , Nov 2014
Spectral Allocation in North America • Two 25-MHz bands are
allocated to AMPS • One from BS to mobile unit (869–894 MHz) • Other from mobile to base station (824–849 MHz) • Bands is split in two to encourage competition • In each market two operators can be accommodated • Operator is allocated only 12.5 MHz in each direction • Channels spaced 30 kHz apart • Total of 416 channels per operator • Twenty-one channels allocated for control • 395 to carry calls • Control channels are 10 kbps data channels • Conversation channels carry analog using frequency modulation • Control information also sent on conversation channels in bursts as data • Number of channels inadequate for most major markets • For AMPS, frequency reuse is exploited 8 © Ahmad El-Banna E-716-A, Lec#7 , Nov 2014
AMPS Architecture & Parameters 9 © Ahmad El-Banna E-716-A, Lec#7
, Nov 2014
Operation • AMPS-capable phone has numeric assignment module (NAM) in
read-only memory • NAM contains number of phone • Assigned by service provider • Serial number of phone • Assigned by the manufacturer • When phone turned on, transmits serial number and phone number to MTSO • MTSO has database of mobile units reported stolen • Uses serial number to lock out stolen units • MTSO uses phone number for billing • If phone is used in remote city, service is still billed to user's local service provider 10 © Ahmad El-Banna E-716-A, Lec#7 , Nov 2014
Call Sequence 1. Subscriber initiates call by keying in number
and presses send 2. MTSO validates telephone number and checks user authorized to place call • Some service providers require a PIN to counter theft 3. MTSO issues message to user's phone indicating traffic channels to use 4. MTSO sends ringing signal to called party • All operations, 2 through 4, occur within 10 s of initiating call 5. When called party answers, MTSO establishes circuit and initiates billing information 6. When one party hangs up MTSO releases circuit, frees radio channels, and completes billing information 11 © Ahmad El-Banna E-716-A, Lec#7 , Nov 2014
AMPS Control Channels • 21 full-duplex 30-kHz control channels •
Transmit digital data using FSK • Data are transmitted in frames • Control information can be transmitted over voice channel during conversation • Mobile unit or the base station inserts burst of data • Turn off voice FM transmission for about 100 ms • Replacing it with an FSK-encoded message • Used to exchange urgent messages • Change power level • Handoff 12 © Ahmad El-Banna E-716-A, Lec#7 , Nov 2014
SECOND GENERATION TDMA 13 © Ahmad El-Banna E-716-A, Lec#7 ,
Nov 2014
Development of Mobile Telecommunication Systems 14 © Ahmad El-Banna E-716-A,
Lec#7 , Nov 2014
Popular 2G Systems 15 © Ahmad El-Banna E-716-A, Lec#7 ,
Nov 2014
Differences Between 1G and 2G Systems • Digital traffic channels
– first-generation systems are almost purely analog; second-generation systems are digital • Encryption – all second generation systems provide encryption to prevent eavesdropping • Error detection and correction – second-generation digital traffic allows for detection and correction, giving clear voice reception • Channel access – second-generation systems allow channels to be dynamically shared by a number of users 16 © Ahmad El-Banna E-716-A, Lec#7 , Nov 2014
TDMA Design Considerations • Number of logical channels (number of
time slots in TDMA frame): 8 • Maximum cell radius (R): 35 km • Frequency: region around 900 MHz • Maximum vehicle speed (Vm ):250 km/hr • Maximum coding delay: approx. 20 ms • Maximum delay spread (m ): 10 s • Bandwidth: Not to exceed 200 kHz (25 kHz per channel) 17 © Ahmad El-Banna E-716-A, Lec#7 , Nov 2014
TDMA Design 18 © Ahmad El-Banna E-716-A, Lec#7 , Nov
2014 Steps in Design of TDMA Time Slot TDMA Time Slot
GSM Network Architecture 19 © Ahmad El-Banna E-716-A, Lec#7 ,
Nov 2014 BSS MS NS MSC
MS & BSS • Mobile station communicates across Um interface
(air interface) with base station transceiver in same cell as mobile unit • Mobile equipment (ME) – physical terminal, such as a telephone or PCS • ME includes radio transceiver, digital signal processors and subscriber identity module (SIM) • GSM subscriber units are generic until SIM is inserted • SIMs roam, not necessarily the subscriber devices • BSS consists of base station controller and one or more base transceiver stations (BTS) • Each BTS defines a single cell • Includes radio antenna, radio transceiver and a link to a base station controller (BSC) • BSC reserves radio frequencies, manages handoff of mobile unit from one cell to another within BSS, and controls paging 20 © Ahmad El-Banna E-716-A, Lec#7 , Nov 2014
NS & MSC • NS provides link between cellular network
and public switched telecommunications networks • Controls handoffs between cells in different BSSs • Authenticates users and validates accounts • Enables worldwide roaming of mobile users • Central element of NS is the mobile switching center (MSC) • MSC components: • Home location register (HLR) database – stores information about each subscriber that belongs to it • Visitor location register (VLR) database – maintains information about subscribers currently physically in the region • Authentication center database (AuC) – used for authentication activities, holds encryption keys • Equipment identity register database (EIR) – keeps track of the type of equipment that exists at the mobile station 21 © Ahmad El-Banna E-716-A, Lec#7 , Nov 2014
TDMA Format – Time Slot Fields • Trail bits –
allow synchronization of transmissions from mobile units • Encrypted bits – encrypted data • Stealing bit - indicates whether block contains data or is "stolen" • Training sequence – used to adapt parameters of receiver to the current path propagation characteristics • Strongest signal selected in case of multipath propagation • Guard bits – used to avoid overlapping with other bursts 22 © Ahmad El-Banna E-716-A, Lec#7 , Nov 2014
GSM Frame Format 23 © Ahmad El-Banna E-716-A, Lec#7 ,
Nov 2014
GSM Speech Signal Processing 24 © Ahmad El-Banna E-716-A, Lec#7
, Nov 2014
GSM Signaling Protocol Architecture 25 © Ahmad El-Banna E-716-A, Lec#7
, Nov 2014
Functions Provided by Protocols • Protocols above the link layer
of the GSM signaling protocol architecture provide specific functions: • Radio resource management • Mobility management • Connection management • Mobile application part (MAP) • BTS management 26 © Ahmad El-Banna E-716-A, Lec#7 , Nov 2014
• For more details, refer to: • Chapter 4, J.
Chiller, Mobile Communications, 2003. • Chapter 10, W. Stallings, Wireless Communications and Networks, 2005. • The lecture is available online at: • https://speakerdeck.com/ahmad_elbanna • For inquires, send to: •
[email protected]
27 E-716-A, Lec#7 , Nov 2014 © Ahmad El-Banna
