Implementation and Verification of a Consensus Protocol in Erlang

A talk about implementing and testing rafter, an erlang implementation of the raft consensus protocol.

Talk given at Erlang Factory Lite Berlin, Oct 16 2013.
http://www.erlang-factory.com/conference/Berlin2013

https://github.com/andrewjstone/rafter

Transcript

1. Implementation and Verification of a Consensus Protocol in
2. Andrew Stone
3. I about your
4. Distributed Systems are HARD
5. Many ways to skin a
7. Asynchronous Replication client Master Slave a
8. Asynchronous Replication client a Master Slave
9. Asynchronous Replication client a Master Slave ok
10. Asynchronous Replication client a Master Slave a
11. Asynchronous Replication client a Master a Slave
12. Asynchronous Replication client a Master a Slave b
13. Asynchronous Replication client a b Master a Slave
14. Asynchronous Replication client a b Master a Slave ok
15. Asynchronous Replication client a b Master a Slave b X
16. Consistent or Available
17. if (promote_secondary){ stderr(“possible data loss”); }else{ stderr(“system unavailable”); }
18. (›°□°ʣ›ớ ᵲᴸᵲ
19. Yep, you just traded safety for latency
20. Synchronous Replication client Master Slave a
21. Synchronous Replication client a Master Slave
22. Synchronous Replication client a Master Slave a
23. Synchronous Replication client a Master a Slave
24. Synchronous Replication client a Master a Slave ok
25. Synchronous Replication client a Master a Slave ok
26. Synchronous Replication client a Master a Slave b
27. Synchronous Replication client a b Master a Slave
28. Synchronous Replication client a b Master a b Slave b X
29. Synchronous Replication client a b Master a b Slave X timeout
30. Safety vs. Liveness
31. Goal: Maintain Safety while tolerating failure
32. Quorums
33. 0 0.75 1.5 2.25 3 1 2 3 4 5 6 7 Cluster Size Node Failures Allowed while Available
34. Problems • Who coordinates writes and reads? • What interleavings are ‘safe’?
35. Consensus
36. RAFT
37. • Distributed State Machine Replication • Designed to facilitate understanding • John Ousterhout and Diego Ongaro
38. izability
39. • All nodes agree on an identical sequence of operations • Monotonic ‘Term’ acts as a logical clock to prevent time from going backwards • Operations are committed when written to a log on majority of nodes AND the term of the entry is the current term • Once committed an operation cannot be removed from the log
40. Replicated Log v4 v3 v2 v1 v6 v5 Index Term 1 1 2 3 4 5 6 1 1 3 3 3 Committed Uncommitted
41. Replicated Log v4 v3 v2 v1 v5 Index Term 1 1 2 3 4 5 1 1 3 4 Committed Uncommitted
42. Leader Election
43. • All nodes start in follower state • After a random timeout, one becomes candidate • Candidate increments term, requests a vote • Followers vote for the candidate if the candidate log and term are up to date
45. Log Replication
46. • Leader sends Append Entries calls to each follower • If previous log entry and term agree with the follower log contents, follower replies with success • Leader keeps track of follower log indexes, decrements index on failure and sends older data • If Majority replies with success, leader commits entry, responds to client and tells followers the latest commit index on next heartbeat
47. Heartbeats =:= Append Entries
48. • Prevent followers from becoming candidates unnecessarily • Allow followers to detect failed leader or network partition and start a new election • Leader replays log to followers who are behind due to either prior failure or netsplit
49. Rafter
50. • A Library for building strongly consistent distributed systems in Erlang • Implements Raft in Erlang • Isolates the application developer from the intricacies of consensus
51. Why Raft? • I wanted to fully grok consensus • Easier to understand than Paxos • Every day someone tries to implement consensus in an ad-hoc manner
52. Why Erlang? • Erlang is terrific for building reliable distributed systems • I currently spend > 90% of my coding time in Erlang • Consensus is NOT solved in Erlang • mnesia, gen_leader, gproc don’t tolerate netsplits
53. Core Abstractions
54. Peers • Each peer is made up of 2 supervised processes • A gen_fsm implements the raft protocol • A gen_server wraps the persistent log • An API module hides the implementation
55. -include_lib("rafter/lib/rafter_opts.hrl"). start_node() -> Name = peer1, Me = {Name, node()}, Opts = #rafter_opts{state_machine=rafter_backend_ets, logdir="./data"}, rafter:start_node(Me, Opts). set_config(Peer, NewServers) -> rafter:set_config(Peer, NewServers). put(Peer, Table, Key, Value) -> rafter:op(Peer, {put, Table, Key, Value}). get(Peer, Table, Key) -> rafter:read_op(Peer, {get, Table, Key}).
56. Replicated Log • API operates on Log Entries • Log Entries contain commands • Commands transparent to rafter • Cmds encoded with term_to_binary/1
57. File Header Format ----------------------- <<Version:8>> Entry Format ---------------- <<Sha1:20/binary, Type:8, Term:64, Index:64, Size:32, Cmd/binary>> Entry Trailer Format ---------------- <<Crc:32, ConfigStart:64, EntryStart:64, ?MAGIC/64>>
58. Backend State Machine • OTP behaviour • Operates on commands via callbacks from consensus fsm • Callbacks run on each node when commands are committed or read quorum achieved
59. -module(rafter_backend). -export([behaviour_info/1]). behaviour_info(callbacks) -> [{init, 0}, {read, 1}, {write, 1}]; behaviour_info(_) -> undefined.
60. read({get, Table, Key}) -> try case ets:lookup(Table, Key) of [{Key, Value}] -> {ok, Value}; [] -> {ok, not_found} end catch _:E -> {error, E} end; write({put, Table, Key, Value}) -> try ets:insert(Table, {Key, Value}), {ok, Value} catch _:E -> {error, E} end;
61. Consensus Module • Implements Raft protocol in gen_fsm • 3 states - follower, candidate, leader • Logs persistent data via rafter_log gen_server • Pure functions handling dynamic reconfiguration and quorums abstracted out to rafter_config
62. %% API -export([start/0, stop/1, start/1, start_link/3, leader/1, op/2, set_config/2, send/2, send_sync/2, get_state/1]). %% States -export([follower/2, follower/3, candidate/2, candidate/3, leader/2, leader/3]).
63. %% Election timeout has expired. Go to candidate state iff we are a voter. follower(timeout, #state{config=Config, me=Me}=State) -> case rafter_config:has_vote(Me, Config) of false -> Duration = election_timeout(), {next_state, follower, State, Duration}; true -> {next_state, candidate, State, 0} end; follower({read_op, _}, _From, #state{leader=Leader}=State) -> Reply = {error, {redirect, Leader}}, {reply, Reply, follower, State, ?timeout()};
64. %% We are out of date. Go back to follower state. candidate(#vote{term=VoteTerm, success=false}, #state{term=Term}=State) when VoteTerm > Term -> NewState = step_down(VoteTerm, State), {next_state, follower, NewState, NewState#state.timer_duration}; %% Sweet, someone likes us! Do we have enough votes to get elected? candidate(#vote{success=true, from=From}, #state{responses=Responses, me=Me, config=Config}=State) -> NewResponses = dict:store(From, true, Responses), case rafter_config:quorum(Me, Config, NewResponses) of true -> NewState = become_leader(State), {next_state, leader, NewState, 0}; false -> NewState = State#state{responses=NewResponses}, {next_state, candidate, NewState, ?timeout()} end.
65. leader(timeout, State) -> Duration = heartbeat_timeout(), NewState = State#state{timer_start=os:timestamp(), timer_duration=Duration}, send_append_entries(State), {next_state, leader, NewState, Duration}; leader({op, {Id, Command }}, From, #state{term=Term}=State) -> Entry = #rafter_entry{type=op, term=Term, cmd=Command}, NewState = append(Id, From, Entry, State, leader), {next_state, leader, NewState, ?timeout()}.
66. Implementation Tradeoffs • Distributed Erlang • Single FSM for the consensus algorithm • Separating read path from write path • Rolling my own log file format
67. What isn’t done? • Handling of exactly-once semantics for non-idempotent commands • Log compaction • A nice DB built on top of rafter • More tests, More documentation • Performance
68. Testing
69. Property Based Testing prop_reverse() -> ?FORALL(L, list(int()), L == lists:reverse(lists:reverse(L))). eqc:quickcheck(eqc:numtests(1000, prop_reverse())). -include_lib("eqc/include/eqc.hrl").
70. • eqc_statem behaviour • Create a model of what your testing • Verify that model Stateful Property Tests
71. eqc_statem callbacks • initial_state/0 • precondition/2 • command/1 • postcondition/3 • next_state/3 • invariant/1 (optional)
72. command(_State) -> frequency([ {10, {call, rafter_backend_ets, write, [{new, table_gen()}]}}, {3, {call, rafter_backend_ets, write, [{delete, table_gen()}]}}, {100, {call, rafter_backend_ets, write, [{delete, table_gen(), key_gen()}]}}, {200, {call, rafter_backend_ets, read, [{get, table_gen(), key_gen()}]}}, {200, {call, rafter_backend_ets, write, [{put, table_gen(), key_gen(), value_gen()}]}}, {20, {call, rafter_backend_ets, read, [list_tables]}}, {20, {call, rafter_backend_ets, read, [{list_keys, table_gen()}]}}]).
73. next_state(#state{tables=Tables}=S, _Result, {call, rafter_backend_ets, write, [{new, Table}]}) -> S#state{tables={call, sets, add_element, [Table, Tables]}}; postcondition(#state{}, {call, rafter_backend_ets, write, [{new, Table}]}, {ok, Table}) -> true; postcondition(#state{tables=Tables}, {call, rafter_backend_ets, write, [{new, Table}]}, {error, badarg}) -> sets:is_element(Table, Tables);
74. invariant(State) -> tables_are_listed_in_ets_tables_table(State) andalso tables_exist(State) andalso data_is_correct(State). tables_exist(#state{tables=Tables}) -> EtsTables = sets:from_list(ets:all()), sets:is_subset(Tables, EtsTables). data_is_correct(#state{data=Data}) -> lists:all(fun({{Table, Key}, Value}) -> [{Key, Value}] =:= ets:lookup(Table, Key) end, Data).
75. An Actual Bug %% This should only happen if two machines are configured differently during %% initial configuration such that one configuration includes both proposed leaders %% and the other only itself. Additionally, there is not a quorum of either %% configuration's servers running. %% %% (i.e. rafter:set_config(b, [k, b, j]), rafter:set_config(d, [i,k,b,d,o]). %% when only b and d are running.) %% candidate(#vote{term=VoteTerm, success=false}, #state{term=Term, init_config=[_Id, From]}=State) when VoteTerm > Term -> gen_fsm:reply(From, {error, invalid_initial_config}), State2 = State#state{init_config=undefined, config=#config{state=blank}}, NewState = step_down(VoteTerm, State2), {next_state, follower, NewState, NewState#state.timer_duration};
76. Model Checking =/= Proof of correctness
77. Other Test Tools • Pulse - http://quviq.com • Concuerror - http://concuerror.com/ • PropEr - http://proper.softlab.ntua.gr/
