Rapid Web Prototyping with Lightweight Tools

Rapid Web Prototyping with Lightweight Tools

Tutorial presentation given at PyCon US 2013.

Meant for Python programmers who don't typically do web or front-end programming, this provides a whirlwind introduction to rapid HTML + CSS + JavaScript iteration with static clickables, and the conversion of static UIs into working web applications with Flask, Jinja2, and a simple single-node object database.

In a way, it's the slides accompanying the long-form blog post, "Build a web app fast: Python, HTML & JavaScript resources", which has been updated over the years.

https://amontalenti.com/2012/06/14/web-app

At the end, also discusses how to deploy your web application to a real server that you own (e.g. EC2 or DigitalOcean) using fabric, nginx, uWSGI, and supervisord.

Slide source code:

https://github.com/amontalenti/rapid-web-slides/

Example project on Github:

https://github.com/amontalenti/rapid-web/

(Update from the future: Though these slides are from 2013, a lot of the concepts hold up, even as of a quick scan of all the slides from a 2021 vantage point.)

Andrew Montalenti

March 13, 2013
Tweet

More Decks by Andrew Montalenti

Other Decks in Programming

Transcript

  1. Meta Information Me: I've been using Python for >10 years.

    I use Python full-time, and have for the last 4 years. Startup: I'm co-founder/CTO of Parse.ly ❏, a tech startup in the digital media space. E-mail me: [email protected] ❏ Follow me on Twitter: amontalenti ❏ Connect on LinkedIn: http://linkedin.com/in/andrewmontalenti ❏
  2. Requirements The main requirements for this course are: • Google

    Chrome (recent version) • Python 2.7.x • Git 1.7/1.8 • virtualenv (described elsewhere) • basic UNIX shell usage (e.g. bash, zsh) • basic programming text editor usage (e.g. TextMate/SublimeText, emacs/ vim, Komodo) • a UNIX-like operating system (OS X, Linux VM, or Linux on raw hardware) Already done with these steps? Skip ahead! ❏
  3. Programming Newbies: Beginner Track If you aren't familiar with the

    command-line, programming text editors, UNIX, and/ or don't have a good comfort level with basic usage of Python/Git already, then you can take the "beginner track" in this course. Rather than setting up your local computer, you will simply follow along what I'm doing on the screen, and optionally connect to a server I have set up where you can experiment with an IPython Notebook and CodeMirror HTML Editor. You can also download the code to follow along: http://pixelmonkey.org/pub/rapid-web-code.zip ❏
  4. Is my OS already set up? Open terminal and... run

    python -V and make sure you're on Python 2.7.x. run git --version to make sure you have git 1.7/1.8 installed.
  5. Python / Git Setup A recent Python version (2.7.3) can

    be installed from Python.org ❏. A recent Git version (1.8.1) can be downloaded from git-scm.com ❏.
  6. UNIX basics This course assumes you can walk around the

    command line a bit. A quick cheat sheet: • ls: list files in current directory • pwd: print working directory path • cd <path>: change directory • mkdir <path>: create a directory • cat <file>: show contents of file • nano <file>: open file in nano text editor
  7. Repo setup Make a work area: mkdir ~/repos Clone the

    code respository: git clone git://github.com/amontalenti/rapid-web.git cd rapid-web Inspect the tags: git tag -l Look at Github web interface ❏. Feel free to fork!
  8. Browse all the additions All the changes from the initial

    check-in to the last on Github. https://github.com/amontalenti/rapid-web/compare/v0.2-static...v2.0-fin ❏
  9. virtualenv pre-reqs easy_install command may not be available in some

    borked Python versions on Linux and OS X. Try easy_install --version to check. If not available, use this script: curl -O http://python-distribute.org/distribute_setup.py python distribute_setup.py
  10. Set up virtualenv Run this virtualenv setup: $ sudo easy_install

    pip $ sudo pip install virtualenv Then: $ cd rapid-web $ virtualenv rapid-env This will create a self-contained Python installation for use with this tutorial.
  11. IPython One of the first Python development tools I'll use

    in hour 2 is IPython. It lets us test code at the command-line easily. Prototyping code at the command-line is one of the core ways to do effective prototyping beyond the HTML / CSS / JavaScript phase.
  12. IPython Setup You should now have a virtualenv folder called

    rapid-env. For convenience, let's make it easy to activate: $ ln -s rapid-env/bin/activate Activate it with the "magic incantation": $ source activate And then, install IPython: (rapid-env)$ pip install ipython ... lots of output ... (rapid-env)$ ipython -V 0.13.1
  13. IPython and Flask installation Install the requirements with pip: $

    cat requirements.txt ipython Flask $ pip install -r requirements.txt ... Then, confirm that you can import all the libraries: $ ipython >>> import flask >>> import jinja2 >>> import werkzeug >>> <CTRL+D> Do you really want to exit ([y]/n)? y $
  14. Advanced Prototyping If you install some optional requirements, you can

    get: • IPython Notebook: browser-based Python editor and prototyping environment • LiveReload: browser plugin and server for auto reloading on page changes
  15. IPython Notebook and LiveReload Installation These are in dev-requirements.txt, which

    you can install with pip: $ cat dev-requirements.txt # for live code updates livereload # for ipython notebook tornado pyzmq $ pip install -r dev-requirements.txt ... $ ipython notebook <CTRL+C to quit> $ livereload -p 8000 <CTRL+C to quit>
  16. LiveReload Chrome Plugin To actually use LiveReload, you need a

    browser extension for chrome which can be downloaded here: https://chrome.google.com/webstore/detail/livereload/ jnihajbhpnppcggbcgedagnkighmdlei ❏
  17. SSH Config We're going to ssh into a remote server

    in the final hour of the course for deployment. To do this, we're going to need to add your public key to the server's list of "authorized keys". If you are already a Github user or remotely manage servers with SSH, then you probably don't need to generate a new public key, but I've included these instructions here for those of you who don't already have public keys.
  18. Do I have a public key? Try: cat ~/.ssh/id_*.pub Do

    you get output like: ssh-rsa AAAAB3NzaC1yc2EAAAABIwAAAQE... If so, you do already have a public key.
  19. SSH Public Key Setup SSH has a small configuration file

    at ~/.ssh/config that allows you to specify hostnames that ssh will use. Upon connecting to a server, ssh looks for an identity file for public key authentication. This is typically ~/.ssh/id_rsa. This private key has a matching public key, which is typically ~/.ssh/id_rsa.pub and must be listed in the remote host's ~/.ssh/authorized_keys file. ssh-keygen can create the public/private key for you. Then you need to share the public key with me.
  20. ssh-keygen $ ssh-keygen Generating public/private rsa key pair. Enter file

    in which to save the key (/home/user1/.ssh/id_rsa): Your identification has been saved in /home/user1/.ssh/id_rsa. Your public key has been saved in /home/user1/.ssh/id_rsa.pub. The key fingerprint is: 43:55:f0:cc:1a:9f:ff:2e:3a:a8:94:8c:f1:62:d3:b1 user1@hacknode ...
  21. .ssh/config example Edit the file: $ nano ~/.ssh/config And insert

    contents: Host hacknode User shared HostName hacknode.alephpoint.com Then: $ ssh hacknode It'll prompt you for a password right, but that's OK -- just CTRL+C to abort.
  22. Rapid Web Prototyping Thesis: the most important skill that a

    modern web developer can have today is prototyping. Most web developers lack this skill due to a number of biases: • Computer Science Backend Bias • Fear of Unskilled Design Bias • Web Framework SQL Bias • Polyglot Complexity Bias Let's take each of these in turn.
  23. Computer Science Backend Bias Myth: The most interesting problems in

    computing are algorithmic and backend systems oriented: e.g. data structures, natural language processing, operating systems, distributed systems, cryptography. Reality: These are simply the most interesting problems to introverted CS PhDs. The most widely used software is not solving fundamental computing problems (think Twitter, Facebook, GMail, Reddit) but is instead solving user experience problems.
  24. Fear of Unskilled Design Bias Myth: Only a trained graphic

    designer can create usable and functional user interfaces. Reality: Anyone can create these interfaces; a skilled designer will promote these interfaces from the kind you merely use daily to the kind you share excitedly to friends.
  25. Web Framework SQL Bias Myth: The purpose of a web

    framework is to unify web technologies with backend (database) technologies, specifically a SQL database. Building a web app consists of building a SQL model, then building the interfaces on that model. Reality: SQL isn't necessary in the early stages of a project; it may not be necessary at all during the entire lifetime of the project. Traditional web frameworks focus on the wrong thing.
  26. Polyglot Complexity Bias Myth: The web requires knowledge of a

    slew of complex technologies: a backend programming language, a database query language, a templating language, JavaScript, HTML, and CSS. That's messy; I prefer to simply code in Java, Ruby, Python, etc. Reality: This is partially true. The web is messy, but all that's necessary to build a web app is some basic knowledge of JavaScript and HTML. Much of the rest can be abstracted via modern toolkits like jQuery and Bootstrap. You also need a way to render that JavaScript/HTML code, but this isn't as tough as it seems.
  27. Beat the Backend Bias Back! Together, all of these biases

    form a general software engineering "backend bias" that I observe in the real world. The typical Python software engineer has no problem with: • writing and testing a database schema • implementing pure Python classes / functions • thinking about scale and performance • building a command-line interface This is a kind of "comfort zone" for typical programmers.
  28. Free From Frontend Fear? Same engineers exhibit a real fear

    when confronted with: • creating hand-drawn or digital wireframes • prototyping entire clickable user interfaces • experimenting with a user interface concept in isolation • testing variations of a user interface on a live population I'm not really concerned with why this split exists, but I definitely observe it.
  29. Premature Optimization "Premature optimization is the root of all evil."

    Don't overcomplicate your code with optimizations before you've measured whether those optimizations are actually necessary for acceptable runtime performance. "Premature backend is the root of all evil." Don't start to build the backend of your web app until you've determined what user experience your application will enable.
  30. Discussion: Is This Fair? Do you think backends deserve to

    be built first? I'd like opinions from the class!
  31. Fake It Till We Make It Now that you have

    a sense of the theory behind this course, I'll take you through three phases of rapid web prototyping: • "First Fake": a JavaScript & HTML web clickable with jQuery and Bootstrap • "Get Real": introduce Flask & Jinja2, the front-end / back-end split • "Ship It!": add a database and deployment, store your first data
  32. Why Fake? (1) Traditional software process: 1. Someone has an

    idea 2. Idea elaborated into "Requirements Document" 3. Requirements enriched with Wireframes (optional, "product lead") 4. Wireframes enriched into Mockup (optional, "design lead") 5. Backend engineer builds Requirements into API, database schema, or somesuch
  33. Why Fake? (2) 6. Frontend engineer builds Mockup into user

    interface 7. Some engineer "wires frontend to backend" 8. Feature is tested on users 9. Feedback from users leads to bug reports / revisions / rewrites
  34. Why Fake? (3) Problem: between steps 1 and 9, MONTHS

    can pass. Related problem: when building fundamentally new & innovative products, step 9 (feedback from real users) is the most important.
  35. First Fake Can we skip from step 1 to step

    9? Yes: this is the essence of "rapid web prototyping". We need to fake a test user into thinking a working system exists.
  36. Light Bulb Idea: "Reddit for clickstreams!" Reddit is cool, but

    the explicit "voting" process is annoying. People don't mind submitting links, but who wants to take time to upvote/downvote them? How about implicit voting based on users clicking on or re-submitting the same article? Insight: click is "implicit upvote"; re-submit is "explicit upvote". No vote buttons necessary!
  37. Now What? Do you start building a database? Frontpage, Article,

    and Link classes w/ ORM bindings? Hell, no! Do you start researching high-concurrency web frameworks for your millions of potential users? Screw that! Do you write a really detailed requirements document and complicated technical architecture? What good will that do!? Let's prototype this idea.
  38. Pen and Paper Even before diving into code, let's think

    about how to sketch out this idea using the old pen and paper. Quick discussion about wireframes: • hand-drawn vs digital • low-fidelity vs high-fidelity • information, heirarchy, flow
  39. Goal of Sketch Answer key questions: • what does she

    see? • what can she do? • why does she care?
  40. Wireframe to Static In my version of this wireframe, I

    have three main screens: • Links: shows recently posted articles that are most popular • Submit: form for submitting a new article to the site • Search: variation of links screen that lets you find links by keyword
  41. Static HTML <!DOCTYPE html> <html> <head> <meta charset="utf-8"> <title>Rapid News

    Static</title> <link rel="stylesheet" href="css/main.css"> </head> <body> <div class="container"> <!-- fun stuff --> </div> <script src="js/main.js"></script> </body> </html>
  42. HTML for Prototypers An HTML document is like a little

    "envelope for your site." In <head>, you describe the document itself. The <title> of the document, some metadata about the document, and links to relevant to stylesheets (CSS). In the <body>, you put the "main entree": the content itself, or the site structural elements. At the bottom of the <body>, you install <script> tags for any JavaScript you want to make the page behave in a dynamic way.
  43. HTML Element Flow There are a few core HTML elements

    that our framework will use (and we'll describe later), but you should know a couple things about HTML / CSS first. First, any element can have a name (id) and any number of styles (class). This will be important later. <div id="container" class="on"> Rapid Web <span id="course" class="smallcaps">Prototyping</span> </div> Second, though there are many kinds of elements for different browser interface components, there are two special kinds of HTML elements with nearly limitless flexibility: <div> and <span>.
  44. div element The div element creates a "block" element, which

    means, it is sized like a rectangle inside the browser. Used to mark off "divisions" of your site page, e.g. distinguish a "header area" from the "content area" from the "footer area". div elements can contain other div elements, creating a parent/child site structure.
  45. span element The span tag creates an "inline" element, which

    means, it's used to wrap around text and images. This is typically used for things like labels, in-text annotations, captions, etc. Importantly, a span cannot contain a block element (like a div), but can be contained by one.
  46. div and span On their own, div and span are

    "meaningless containers" other than the above description. They are therefore typically the tool used for all your CSS styling. And with the framework we are using, they are relied upon heavily, as well.
  47. jQuery / Bootstrap Intro <html> <head> <link rel="stylesheet" href="css/lib/bootstrap.css"> <link

    rel="stylesheet" href="css/lib/bootstrap-responsive.css"> <link rel="stylesheet" href="css/main.css"> </head> <body> <div class="container"> <!-- <bootstrap> --> <!-- </bootstrap> --> </div> <script src="js/lib/jquery.js"></script> <script src="js/lib/bootstrap.js"></script> <script src="js/main.js"></script> </body> </html>
  48. Why Bootstrap? • We are not designers • HTML's default

    styling is ugly! • Modern HTML & CSS involves a lot of "boilerplate" • CSS is especially tricky for novices to get right • Component toolkit built mostly with pre-canned CSS classes
  49. Scaffolding Smooths out the differences between different browser default HTML

    / CSS styling. Provides a "grid" and "layout" system. Supports responsive design approaches (auto scale down for mobile/tablet).
  50. Base CSS Improves typically-used HTML elements with some reasoanble default

    stylings. • h1 through h6 • body and p • table • form and input • button (with links) • img • glyphicons
  51. Components Adds other commonly-used UI components that are "missing" from

    HTML. • dropdowns • navigation bars • pagination bars • labels • alerts • "media objects"
  52. JavaScript plugins Richer interactive components that require JavaScript. • modal

    windows • typeahead search • image carousels • tab panels • tooltips & popovers
  53. Let's build the fake! We'll start with the navigation area

    and header. We'll then add a simple listing of fake links in a table.
  54. Navigation Area <div class="navbar"> <div class="navbar-inner"> <a class="brand hidden-phone">Rapid News</a>

    <a class="brand visible-phone">RN</a> <ul class="nav"> <li class="active"><a href="#">Links</a></li> <li><a href="#">Submit</a></li> </ul> <form class="navbar-search pull-right hidden-phone" action="/search"> <small><i class="icon-search"></i> Search</small> <input name="query" type="text" class="search-query" placeholder=""> </form> </div> </div>
  55. Simple Table <table class="table table-hover table-striped"> <thead> <tr> <th>Score</th> <th>Link</th>

    <th>Published</th> </tr> </thead> <tbody> <tr> <td><span class="label label-important">150</span></td> <td><a href="#">The Meditations of Marcus Aurelius</a></td> <td><span class="label">3 hours ago</span></td> </tr> ... </tbody> </table>
  56. What have we learned? HTML isn't that hard. With Bootstrap,

    you don't need to be a designer to get from wireframe to clickable. Problems: • app is not very interactive • list of links hard-coded
  57. Simple Animation Example function animateRows() { // simple animation to

    fade in all but the top story $("tbody tr").each(function(i, row) { if (i === 0) { // skip 1st row return; } // capture current row var elm = $(row); // schedule it to fade in setTimeout(function() { elm.fadeIn(); }, i * 500); }); };
  58. Organizing JS Code // module.js (function() { // anonymous function

    creates namespace // prevents global leakage function myPrivateFunction() { // private function created in namespace }; function myPublicFunction() { var elements = myPrivateFunction(); elements.each(function() { ... } ); // public function must be exported }; // export as RAPID.myPublicFunction RAPID.myPublicFunction = myPublicFunction; })();
  59. First Visit Experience Use browser cookie to detect whether user

    has visited before. Show a modal dialog on first visit to explain concept, and then hide it on future visits.
  60. Static file limitations When first prototyping, the easiest approach is

    "pure static" -- just open your HTML file in your browser. This has some limitations though: • cookies don't work • localStorage doesn't work • referencing static JSON/CSV files doesn't work • relative links won't work
  61. Python SimpleHTTPServer Here is our first "Python backend". A simple

    HTTP web server built into Python itself. Just run: cd static python -m SimpleHTTPServer Now open http://localhost:8000 ❏ in your browser.
  62. Bootstrap Modal HTML <div id="first-visit-dialog" class="modal hide fade in"> <div

    class="modal-header"> <a class="close" data-dismiss="modal">×</a> <h3>Welcome to Rapid News!</h3> </div> <div class="modal-body"> <h4>Rapid News connects you with the latest links</h4> <p>Links are prioritized on this page based on clicks and submits. Simply click a link or submit a story and you're instantly a part of the community.</p> </div> <div class="modal-footer"> <a href="#" class="btn" data-dismiss="modal">Close</a> </div> </div>
  63. Scripting the Modal function showFirstVisitDialog() { var cookie = RAPID.readCookie("visited");

    if (cookie === "true") { // do nothing, user has visited before return; } var modal = $("#first-visit-dialog"); modal.on("hide", function() { RAPID.createCookie("visited", "true", 30); }); modal.modal(); };
  64. Use a JSON-P API with jQuery http://hndroidapi.appspot.com /best/format/json/page/ ?appid=RAPID& callback=

    var apiroot = "http://hndroidapi.appspot.com"; var path = "/best/format/json/page/"; var params = "?appid=RAPID&callback=?"; var url = [apiroot, path, params].join(""); $.getJSON(url, function(data) { $.each(data.items, function(i, item) { console.log(item.title); }); console.dir(data); });
  65. Dynamic Element Modification $.getJSON(url, function(data) { var rows = $("table

    tr"); $.each(data.items, function(i, item) { var row = rows.get(i+1); if (typeof row !== "undefined") { row = $(row); var score = row.find("span.label:first"); var pubdate = row.find("span.label:last"); var link = row.find("a"); link.attr("href", item.url); link.html(item.title); score.html(item.score.replace(" points", "")); pubdate.html(item.time); } }); });
  66. Implementing the Submit Page • what she sees: a form

    for submitting content • why she cares: share a story with the community Copypasta time!
  67. Review Template <html> <head> <meta charset="utf-8"> <title>RN: Submit News</title> <!--

    ... --> </head> <body> <div class="container"> <!-- <bootstrap> --> <!-- </bootstrap> --> </div> <script src="js/lib/jquery.js"></script> <script src="js/lib/bootstrap.js"></script> <script>window.RAPID = {};</script> <script src="js/submit.js"></script> </body> </html>
  68. Link Wiring On main page: <ul class="nav"> <li><a class="active" href="#">Links</a></li>

    <li><a href="/submit.html">Submit</a></li> </ul> On submit page: <ul class="nav"> <li><a href="/">Links</a></li> <li class="active"><a href="#">Submit</a></li> </ul>
  69. Create a Form <div id="submit-form"> <form action="/new"> <fieldset> <legend>Submit some

    news!</legend> <label>Link</label> <input type="text" placeholder="http://..."> <label>Title</label> <input type="text" placeholder="news headline or description"> <div class="control-group"> <button type="submit" class="btn">Submit!</button> </div> </fieldset> </form> </div>
  70. Reviewing the Carnage Two pages: index.html and submit.html. Using several

    Bootstrap components: navigation, table, form, modal. JSON-P API calls to some fake data and jQuery for element manipulation. Still no backend built. Can be used to gather useful user feedback.
  71. What's Missing from our Prototype? No server means no way

    to handle the submit form. No way to track clicks (no link redirector). No real scoring algorithm yet (data faked from HN).
  72. What's Wrong with Our Prototype? Nothing! With very little code,

    we're providing a clickable UI. De-risking some of our core assumptions about the product. However, we can already see some code duplications (header/footer, nav). Starting to hit the limits of no backend. Time for Python to save the day!
  73. Onward to "Getting Real!" Let's take a 5m break to

    answer questions / reflect a bit.
  74. Build a Web Server from werkzeug.wrappers import Request, Response @Request.application

    def app(request): print request.path print request.headers return Response("hello, world!") from werkzeug.serving import run_simple run_simple("localhost", 4000, app)
  75. Debug a Web Server from werkzeug.wrappers import Request, Response from

    werkzeug.debug import DebuggedApplication @Request.application def app(request): raise ValueError("testing debugger") return Response("hello, world!") app = DebuggedApplication(app, evalex=True) from werkzeug.serving import run_simple run_simple("localhost", 4000, app)
  76. Inspecting the Request >>> request.headers EnvironHeaders([('Cookie', 'csrftoken=ETXzOTz6zqbQYt0o... >>> request.headers.keys() ['Cookie',

    'Content-Length', 'Accept-Charset', 'User-Agent', 'Connection', 'Host', 'Cache-Control', 'Accept', 'Accept-Language', 'Content-Type', 'Accept-Encoding'] >>> request.headers["User-Agent"] 'Mozilla/5.0 (X11; Linux x86_64) AppleWebKit/537.17 (KHTML, like Gecko)' 'Chrome/24.0.1312.68 Safari/537.17'
  77. Inspecting the Request from Chrome We can look at both

    sides of this request to really understand it.
  78. Flask "microframework" overview • Werkzeug provides the web server and

    HTTP utility libraries • Jinja2 provides the templating language • Flask wires these two together conveniently
  79. Why do we need a programmable web server? To do

    anything "dynamic" in response to user requests. For our Rapid News app, we need the server to: • validate the news submission form • store recently submitted stories • calculate the scoring algorithm • implement a link redirector (for tracking clicks) • implement keyword search
  80. Why do we need a templating language? Remember copypasta? We

    want to avoid duplicating code between index.html and submit.html. As this app grows, we may add new pages, and we'd like to maintain a common look-and- feel (template heirarchy). We want to render pages "dynamically" using data we've stored on the server (control flow and interpolation). We want to enable HTML code re-use within pages (macros).
  81. Template Example from jinja2 import Template tmpl = Template(u'''<table> <tr>

    <td><strong>Number</strong></td> <td><strong>Square</strong></td> </tr> {%- for item in rows %} <tr> <td>{{ item.number }}</td> <td>{{ item.square }}</td> </tr> {%- endfor %} <table> ''') data = [{"number": number, "square": number*number} for number in range(10)] print tmpl.render(rows=data)
  82. Template Output <table> <tr> <td><strong>Number</strong></td> <td><strong>Square</strong></td> </tr> ... <tr> <td>3</td>

    <td>9</td> </tr> <tr> <td>4</td> <td>16</td> </tr> ... <tr> <td>9</td> <td>81</td> </tr> <table>
  83. Template Loaders import os import sys import json from jinja2

    import Environment, FileSystemLoader args = sys.argv env = Environment(loader=FileSystemLoader(os.getcwd())) data = json.load(open(args[2])) print env.get_template(args[1]).render(data)
  84. Template as File <table> <tr> <td><strong>Number</strong></td> <td><strong>Square</strong></td> </tr> {%- for

    item in rows %} <tr> <td>{{ item.number }}</td> <td>{{ item.square }}</td> </tr> {%- endfor %} <table> Saved in squares.jinja2.html.
  85. Template Tester $ python render.py squares.jinja2.html {"rows": [{"number": 3, "square":

    9}]} <table> <tr> <td><strong>Number</strong></td> <td><strong>Square</strong></td> </tr> <tr> <td>3</td> <td>9</td> </tr> </table>
  86. Flask App Structure from flask import Flask, render_template from rapid

    import top_articles app = Flask(__name__) @app.route('/') def index(): articles = top_articles() return render_template('index.jinja2.html', rows=articles) if __name__ == "__main__": app.run(debug=True)
  87. Flask Goodies • request "context" • URL routing • template

    "context" • sessions • redirects • app configuration • filesystem handling
  88. Request Context (1) In plain Python code, you tend to

    avoid global state like the plague. In web applications, there is some implicit global state: the currently running "application", and the currently-being-handled "request". Flask makes dealing with these easier than it would otherwise be.
  89. Request Context (2) app = Flask(__name__) # the "application context"

    ... and... from flask import request @app.route('/') def index(): # the "request context" print request.headers
  90. Handling Shared State Core Idea: your Python functions / classes

    get "bound to a context". Flask calls your code and sets appropriate shared state (e.g. current request via flask.request and the current session via flask.session). You can also share arbitrary data in-process via flask.g (global).
  91. Code Coupling In this way, Flask makes coupling between your

    code and the web server very explicit. (Insight: Flask can create a "thin web layer" for plain Python code.)
  92. URL Routing URL Routing lets you bind HTTP paths and

    arguments to Python functions easily. This is the "design of your URLs". Let's look at an example of Flickr's URL design.
  93. URL Routing at Flickr @app.route("/explore") def explore_photos(): pass @app.route("/photos") def

    most_recent_photos(): pass @app.route("/photos/<username>") def user_photos(username): pass @app.route("/photos/<username>/<int:photo_id>") def photo_detail(username, photo_id): pass
  94. URL Routing with Rapid News @app.route('/') def index(): pass @app.route('/search/<query>')

    def search(query): pass @app.route('/submit', methods=["GET", "POST"]) def submit(): pass
  95. Porting Static Design to Templates {# example layout.html #} {#

    header #} <html> <head> <title>{% block title %}{% endblock %}</title> </head> <body> {# /header #} {% block body %} {% endblock %} {# footer #} </body> </html> {# /footer #}
  96. Simplified Index Template {# example index.html #} {% extends 'layout.html'

    %} {% block title %}Latest News{% endblock %} {% block body %} <table> <thead> ... </thead> <tbody> .... </tbody> </table> {% endblock %}
  97. Simplified Submit Template {# example submit.html #} {% extends 'layout.html'

    %} {% block title %}Submit News{% endblock %} {% block body %} <form> <fieldset> ... </fieldset> </form> {% endblock %}
  98. Static Code Generation $ cd templates $ python render.py index.jinja2.html

    data.json <html> ... <table> ... </html> $ python render.py submit.jinja2.html data.json <html> ... <form> ... </html>
  99. Template Context (1) In the render.py calls from before, data.json

    was a file with an empty JSON object. {} We can populate variables in here to create a "template context".
  100. Template Context (2) {"rows": [ {"title": "Google", "score": 150, "link":

    "http://google.com"}, {"title": "Yahoo", "score": 75, "link": "http://yahoo.com"}, {"title": "Bing", "score": 50, "link": "http://bing.com"} ] }
  101. Template Context (3) {% for row in rows %} <tr>

    <td>{{ row.score }}</td> <td><a href="{{ row.link }}">{{ row.title }}</a></td> <td>just now</td> </tr> {% endfor %}
  102. Template Context (4) $ python render.py index.jinja2.html articles.json <html> ...

    <body> ... <tr> <td>150</td> <td><a href="http://google.com">Google</a></td> <td>just now</td> </tr> ... </body> </html>
  103. Wire Templates to Flask from flask import render_template, Flask app

    = Flask(__name__) def top_articles(): articles = [ {"title": "Google", "score": 150, "link": "http://google.com"}, {"title": "Yahoo", "score": 75, "link": "http://yahoo.com"}, {"title": "Bing", "score": 50, "link": "http://bing.com"} ] return articles @app.route('/') def index(): articles = top_articles() return render_template("index.jinja2.html", rows=articles) if __name__ == "__main__": app.run(debug=True)
  104. Frontend / Backend Recap Backend: • browser makes request to

    specific URL • Flask server routes URL to appropriate view function • "does something useful" during request context • stashes results into template context Frontend: • server renders HTML / JavaScript in response to request • rendering happens within a "template context", via Jinja2 • template context provides "dynamic" data from server • JavaScript executed within client browser, after page rendering
  105. Simplified Backend thru Frontend Browser Request --> WSGI Server -->

    Flask App Context --> View Function --> Request Context --> Python Code / Data Access --> Template Context --> Render Template --> Response to Browser Browser Response Parsing --> Download & Parse CSS / JavaScript --> Render DOM --> Execute JavaScript --> Register Event Handlers --> Remote Requests (AJAX) --> Dynamic Element Modification --> Full Page Loaded
  106. What Goes Where? This request/response lifecycle is what makes web

    programming a little complex. Paradox of choice re: where to put your logic. Should core logic be in the browser (JavaScript), templates (Jinja2), in the request context (Flask) or just on the server (plain Python)? The answer is, "it depends".
  107. Single Page Apps There has been a bit of a

    craze recently about "single-page web apps". The idea is that for many web apps, almost all of the application logic can live in the browser. The server only speaks an API (HTTP/JSON) and does not do things like template rendering. Proponents of this approach say that it makes the applications more performant and unifies the codebase (mostly JavaScript). JavaScript interpreters in modern browsers are fast enough for this now, whereas in e.g. 2004-2008, this would have been infeasible.
  108. Multi-Page Apps Multi-page apps tend to be more "web-friendly". They

    also tend to be simpler to implement and debug. Easy to selectively use single-page app techniques in a multi-page app. Original "AJAX" craze was about this.
  109. Rapid News As Single-Page Browser Request to '/' --> Flask

    Renders Static HTML --> Flask Returns Static JavaScript Application Browser Response --> jQuery API call to /frontpage.json --> New Flask Request --> Python Logic to get top articles --> Data Rendered as JSON --> API data used to template/render client-side User Sees Front Page User Clicks "Submit" --> JavaScript alters DOM User Sees Submit Form User Submits New Article --> jQuery API call to /submit.json for validation User Sees Validation Errors or Success
  110. Rapid News as Multi-Page Browser Request to '/' --> New

    Flask Request --> Python Logic to get Top Articles --> New Template Context with Data --> Template Rendered with Jinja2 Browser Response User Sees Front Page User Clicks "Submit" --> New Flask Request --> New (Empty) Template Context for Submission Form --> Template Rendered with Jinja2 User Sees Submit Form User Submits New Article --> New Flask Request --> Python Form Validation Logic --> New Template Context with Errors (or Empty) --> Template Rendered with Jinja2 User Sees Validation Errors or Success
  111. Macros {%- macro link_tag(location) -%} <link rel="stylesheet" href="static/css/{{ location }}.css">

    {%- endmacro -%} {%- macro script_tag(location) -%} <script src="static/js/{{ location }}.js"></script> {%- endmacro -%}
  112. Macro Imports (1) {# layout.jinja2.html #} {% from 'util.jinja2.html' import

    link_tag, script_tag %} ... <head> <title>(RN) {% block title %}{% endblock %}</title> {{ link_tag('lib/bootstrap') }} {{ link_tag('lib/bootstrap-responsive') }} {% block css %} {% endblock %} </head> <body> ...
  113. Macro Imports (2) {% from 'util.jinja2.html' import link_tag, script_tag %}

    ... {{ script_tag('lib/jquery') }} {{ script_tag('lib/bootstrap') }} <script>window.RAPID = {};</script> {% block js %} {% endblock %}
  114. Using Static Assets app = Flask(__name__, static_folder="../static", static_url_path="/static") Will now

    look in "../static" and serve all static files there under "/static" URL, thus matching our macros.
  115. New Template Layout {% extends 'layout.jinja2.html' %} {% block title

    %}My Page{% endblock %} {% block css %} {{ link_tag('my-page') }} {% endblock %} {% block body %} <div class="my-page"></div> {% endblock %} {% block js %} {{ script_tag('my-page') }} {% endblock %}
  116. Server Side vs Client Side (1) One of the original

    limitations of our Rapid News "fake" prototype is that the "Submit" page wasn't functional. You might ask: why couldn't I implement that page 100% client-side? Technically, you could, but there are a slew of reasons you don't want to do so.
  117. Server Side vs Client Side (2) • Misplaced Trust in

    Client. • No Access to Secrets. • Minimal Standard Library. • Keyhole Access to Database. • JavaScript Interpreter Performance.
  118. Bottom Line on Client vs Server All user data must

    be validated server-side. Optionally, can "convenience check" on client side. JavaScript code must run under the "hostile environment" assumption that an attacker can change any aspect of DOM, functions, classes, etc. Where dynamism is needed, it's preferable to do HTTP/JSON requests to server via XMLHTTPRequest or JSON-P.
  119. HTML Forms for Server Interaction Now that we understand why

    we need the server to validate data coming from the user, let's make our original "Submit" form server-enabled. <div id="submit-form"> <form method="POST"> <fieldset> <!-- ... --> </fieldset> </form> </div>
  120. Fieldset with Control Groups <div class="control-group "> <label class="control-label" for="link">Link</label>

    <div class="controls"> <input type="text" name="link" id="link" value="" placeholder="http://..."> </div> </div> <div class="control-group "> <label class="control-label" for="title">Title</label> <div class="controls"> <input type="text" name="title" id="title" value="" placeholder="headline or description"> </div> </div>
  121. Macro'izing an Input Component {% macro input(name, desc, type='text', placeholder=None)

    -%} <div class="control-group {{ error(name) }}"> <label class="control-label" for="{{ name }}">{{ desc }}</label> <div class="controls"> <input type="{{ type }}" name="{{ name }}" id="{{ name }}" value="{{ request.form[name] }}" placeholder="{{ placeholder }}"> {{ errorhelp(name) }} </div> </div> {%- endmacro %}
  122. Macro'izing (2) {% macro error(name) -%} {% if errors and

    errors[name] -%} error {% endif -%} {% endmacro -%} {% macro errorhelp(name) -%} {% if errors and errors[name] -%} <span class="help-inline">{{ errors[name] }}</span> {% endif -%} {% endmacro -%}
  123. Using Macros as Form Components <div id="submit-form"> <h2>Submit a new

    article!</h2> <form method="POST"> <fieldset> {{ input("link", "Link", placeholder="http://...") }} {{ input("title", "Title", placeholder="headline or description") }} <div class="form-actions"> {{ button("Submit") }} </div> </fieldset> </form> </div>
  124. Implement Validation def validate_submission(params): errors = {} def err(id, msg):

    errors[id] = msg title = params["title"].strip() if len(title) < 2: err("title", "title must be > 2 characters") if len(title) > 150: err("title", "title may not be > 150 characters") link = params["link"].strip() try: opened = urlopen(link) link = opened.geturl() except (URLError, ValueError): err("link", "link could not be reached") if len(errors) > 0: return (False, errors) else: return (True, errors)
  125. Using the Validation Function def do_submit(): form = request.form submission

    = dict( title=form["title"], link=form["link"] ) valid, errors = validate_submission(submission) if valid: article = insert_article(submission) return render_template("success.jinja2.html", page_submit="active") else: return render_template('submit.jinja2.html', page_submit="active", errors=errors)
  126. Filters Filters, like macros, are a form of code re-use

    in your templates. Unlike macros, they are typically written as Python code (rather than Jinja code) and then bound to your template context. They are typically used for "value conversions".
  127. Commonly Used Built-In Filters • default, e.g. {{ value|default("N/A") }}

    • escape, e.g. {{ user_html|escape }} • sort, e.g. {% for article in articles|sort(attribute="pub_date") %} • dictsort, e.g. {% for pub_date, article in articles|dictsort %} • truncate, e.g. {{ title|truncate(length=100) }}
  128. Our Own Filter def val_ago(value, unit="unit"): if value == 1:

    return "{} {} ago".format(value, unit) else: return "{} {}s ago".format(value, unit)
  129. Filter Usage Example Template: {% for second in range(60) %}

    {{ second|val_ago(unit="second") }} {% endfor %} Output: 0 seconds ago 1 second ago <-- notice 2 seconds ago ... 59 seconds ago
  130. Registering the Filter from filters import val_ago @app.template_filter() def seconds_ago(val):

    return val_ago(val, unit="second") @app.route('/experiment') def experiment(): return render_template('seconds.jinja2.html', seconds=range(60)) ... and ... <ul> {% for second in seconds %} <li>{{ second|seconds_ago }} {% endfor %} </ul>
  131. A Complex Filter Filters are very powerful since they can

    boil down some complex processing logic into a simple front-end value transformation. The example we're going to work through now involves converting absolute datetime objects into human-readable relative dates, such as "10 seconds ago", and "3 days ago". We'll implement this with a pure Python function we'll then bind as a template filter.
  132. Test Cases jan1 = dt.datetime(2013, 1, 1) def test_case(expected, **kwargs):

    #** val = jan1 - dt.timedelta(**kwargs) #** human = human_date(val, nowfunc=lambda: jan1) assert human == expected, human test_case("1 day ago", days=1) test_case("2 days ago", days=2) test_case("5 seconds ago", seconds=5) test_case("2 minutes ago", seconds=60*2) test_case("3 hours ago", seconds=60*60*3) test_case("12/25/2012", days=7)
  133. Filter Implementation def human_date(dateval, nowfunc=dt.datetime.now): now = nowfunc() delta =

    now - dateval days = delta.days if days == 0: seconds = delta.seconds minutes = seconds / 60 hours = minutes / 60 if hours > 0: return val_ago(hours, unit="hour") if minutes > 0: return val_ago(minutes, unit="minute") return val_ago(seconds, unit="second") elif 0 < days < 7: return val_ago(days, unit="day") else: return dateval.strftime("%m/%d/%Y")
  134. Using the New Complex Filter import datetime as dt from

    filters import human_date app.add_template_filter(human_date) def _example_dates(): now = dt.datetime.now() deltas = [ dt.timedelta(seconds=5), dt.timedelta(seconds=60*60), dt.timedelta(days=5), dt.timedelta(days=60)] dates = [now - delta for delta in deltas] return dates @app.route('/datetest') def datetest(): dates = _example_dates() return render_template('dates.jinja2.html', dates=dates)
  135. Template Usage of Complex Filter <ul> {% for date in

    dates %} <li>{{ date }} ({{ date|human_date }}) {% endfor %} </ul> with output: <ul> <li>2013-02-18 09:40:18.713401 (5 seconds ago) <li>2013-02-18 08:40:23.713401 (1 hour ago) <li>2013-02-13 09:40:23.713401 (5 days ago) <li>2012-12-20 09:40:23.713401 (12/20/2012) </ul>
  136. Filter Usage in Rapid News {% for row in rows|sort(attribute="date",

    reverse=True) %} <tr> <td><span class="label label-important">{{ row.score }}</span></td> <td><a href="{{ row.link }}">{{ row.title }}</a></td> <td><span class="label">{{ row.date|human_date }}</span></td> </tr> {% endfor %}
  137. Click Redirector Brainstorm Last piece of the server puzzle for

    this app is the click redirector. We'll be able to measure re-submit upvotes by instrumenting insert_article. But to measure clickthroughs, we need to replace our links in the app with something else. Shall we brainstorm ideas?
  138. Click Redirector Implementation A Flask Route called "/click" that takes

    a single parameter, url, and tracks a click to that URL. This will utilize a database call called track_click that tracks this URL in our database. Then, directs the user to the appropriate URL via an HTTP redirect. A Jinja macro called "tracked_link()" that takes a title and URL and generates a link tag to our "/click" route.
  139. Click Tracking Macro {%- macro tracked_link(title, url) -%} <a href="{{

    url_for("click", url=url) }}">{{ title }}</a> {%- endmacro -%} ... and its usage: <tr> <td><span class="label label-important">{{ row.score }}</span></td> <td>{{ tracked_link(row.title, row.link) }}</td> <td><span class="label">{{ row.date|human_date }}</span></td> </tr>
  140. Onward to "Shipping It!" Let's take a 5m break to

    answer questions / reflect a bit.
  141. Server Setup So far, all of our development has been

    "local". This has lots of benefits: • Simplicity • Speed • Instantaneous feedback loop However, eventually, you want to have a server for your web app -- even if it is only a prototype.
  142. Lots of Choices We have no shortage of choices when

    it comes to where to deploy our Python application. • "Shared" Hosting Environments, like Webfaction and Dreamhost. • "Cloud" Environments, like Rackspace Cloud and Amazon Web Services. • "Platforms", like Heroku and Google App Engine.
  143. Rackspace Cloud Environment For simplicity, I'm going to walk you

    through the deployment of our app on Rackspace Cloud. Unlike "Shared" hosting environments, Rackspace gives you full control of your deployment Linux operating system, aka "root access". And unlike "Platforms", you are not locked into using any proprietary deployment tooling or process. My other worry with "Platforms" is that you don't learn anything about how the web really works. Basically, Rackspace gives you a "virtual private server".
  144. What is a server, anyway? • Typically a Linux machine.

    • Typically some fixed base resources, such as CPU, Memory, Disk. • A stable public IP address. • Usually a stable private IP address, too.
  145. hacknode Our Rackspace Nextgen Cloud Server. • RAM: 512MB of

    RAM • Disk: 20GB Attached • OS: Ubuntu 12.04 LTS • Location: Rackspace Chicago (ORD) • Host: hacknode.alephpoint.com • Public IP: 198.101.146.50 • Private IP: 10.177.128.157
  146. Access via SSH Initial access to the server is granted

    via a "root" account, with a pre-determined password. From that moment on, most people switch to SSH connections via public/private key pairs. This has the side benefit of obviating the need for password entry at the command- line. (Github uses this same trick for read+write Git access.)
  147. "shared" user account In the case of hacknode, I've created

    a non-root account called shared which will be shared by every person in the class. We'll add your public keys to this account, and you'll do your deployments in its home directory (/home/shared).
  148. Control via SSH Once you have SSH access, you can

    use the ssh command as a simple remote job runner. e.g. ssh hacknode ls /tmp will list the contents of the /tmp directory on the server. e.g. ssh hacknode ps aux will list all running processes on the server.
  149. Introducing Fabric Once you have SSH set up correctly and

    can connect to / run remote commands on a remote server, you are all ready to start scripting deployment. In the Python community, we use a simple tool called Fabric for this. Fabric installs a little program called fab into your PATH. fab looks for a file called fabfile.py, which is written using Fabric's core library. You define tasks that correspond to command-line arguments. Tasks can actually do pretty much anything, but are typically used for scripting remote machines, e.g. copying files onto the remote machine and executing remote commands.
  150. Set up new dependencies In requirements.txt: ipython Flask Flask-Script Fabric

    And re-install with pip install -r requirements.txt.
  151. Set up Flask-Script Manager This will help us with deployment

    later. from flask.ext.script import Manager app = Flask(...) app.debug = True manager = Manager(app) if __name__ == "__main__": manager.run()
  152. Running Flask-Script $ python app.py Please provide a command: runserver

    Runs the Flask development server i.e. app.run() shell Runs a Python shell inside Flask application context. So, e.g., to run on all IPs and port 8000: $ python app.py runserver --host=0.0.0.0 --port=8000 * Running on http://0.0.0.0:8000/
  153. Our First fabfile from fabric.api import * env.use_ssh_config = True

    env.hosts = ["shared@hacknode"] @task def list_home(): """List files in home directory.""" run("ls -lha")
  154. Running fab (2) $ fab list_home [shared@hacknode] Executing task 'list_home'

    [shared@hacknode] run: ls -lha [shared@hacknode] out: total 40K [shared@hacknode] out: drwxr-xr-x 6 shared shared 4.0K Feb 20 23:33 . [shared@hacknode] out: drwxr-xr-x 4 root root 4.0K Feb 20 21:19 .. [shared@hacknode] out: -rw------- 1 shared shared 159 Feb 20 23:17 .bash_history [shared@hacknode] out: -rw-r--r-- 1 shared shared 220 Feb 20 21:19 .bash_logout [shared@hacknode] out: -rw-r--r-- 1 shared shared 3.5K Feb 20 21:19 .bashrc [shared@hacknode] out: drwx------ 2 shared shared 4.0K Feb 20 21:20 .cache [shared@hacknode] out: drwxrwxr-x 2 shared shared 4.0K Feb 20 23:33 .pip [shared@hacknode] out: -rw-r--r-- 1 shared shared 675 Feb 20 21:19 .profile [shared@hacknode] out: drwxr-xr-x 2 shared shared 4.0K Feb 20 21:20 .ssh [shared@hacknode] out: Done. Disconnecting from [email protected]... done.
  155. Setting Up a Deploy from fabric.contrib.project import rsync_project def unique_id():

    def sh(cmd): return local(cmd, capture=True) return "{}__{}".format(sh("whoami"), sh("hostname")) @task def print_my_id(): """Print your unique identifier.""" puts("UNIQUE ID: " + unique_id()) @task def deploy(): """Deploy project remotely.""" run("mkdir -p deploys") rsync_project(remote_dir="deploys/" + unique_id(), local_dir="./", exclude=(".git", "rapid-env", "steps", "activate"))
  156. Setting up a Virtualenv def virtualenv_run(cmd): run("source rapid-env/bin/activate && {}".format(cmd))

    @task def setup_virtualenv(): """Set up virtualenv on remote machine.""" with cd("deploys/" + unique_id()): run("virtualenv rapid-env") virtualenv_run("pip install -r requirements.txt")
  157. Setting up a Remote Run @task def run_devserver(): """Run the

    dev Flask server on remote machine.""" with cd("deploys/" + unique_id()): virtualenv_run("cd app && python app.py runserver --host=0.0.0.0 --port=8000")
  158. Dev Server Setup, Fully Automated $ fab -l Available commands:

    deploy Deploy project remotely. list_deploys List deployment directories. list_home List files in home directory. print_my_id Print your unique identifier. run_devserver Run the dev Flask server on remote machine. setup_virtualenv Set up virtualenv on remote machine. $ fab deploy ... $ fab setup_virtualenv ... $ fab run_devserver [shared@hacknode] * Running on http://0.0.0.0:8000/ Now, we navigate over to http://hacknode1.alephpoint.com:8000/ ❏.
  159. Dev vs Prod Deployment Server Running a development server is

    good enough for our early prototyping, but when we ship our app, we want to run in a "real" web server. Why? • dev server shuts down when you log out • dev server may be insecure • prod server is more scalable and resilient • prod server will give us better sysadmin / monitoring options
  160. uwsgi A lightweight bridge between programming languages and web servers.

    Originally built just for Python (due to WSGI standard), but now even being used by other languages. One command and your web application is ready to be plugged into any web server.
  161. uwsgi command uwsgi # enable HTTP and Python plugins --plugins=http,python

    # use this socket -s /tmp/uwsgi-hacknode1.sock # find the Python web app module in this file --file /home/shared/servers/hacknode1/app/app.py # look for the variable "app" for the server to run --callable app # set the PYTHONHOME directory to our virtualenv -H /home/shared/servers/hacknode1/rapid-env
  162. supervisor supervisor is the most lightweight service runner. Allows us

    to run a "long-lived" task, like our web server. Handles auto-healing, logging, and a simple start/stop/restart user interface. We'll use it to run our uwsgi instance.
  163. supervisor config Lives in /etc/supervisor/conf.d/hacknode1.conf: [program:hacknode1] command=\ uwsgi \ --plugins=http,python

    \ -s /tmp/uwsgi-hacknode1.sock \ --file /home/shared/servers/hacknode1/app/app.py --callable app \ -H /home/shared/servers/hacknode1/rapid-env directory=/home/shared/servers/hacknode1/app autostart=true autorestart=true stdout_logfile=/home/shared/logs/hacknode1.log redirect_stderr=true stopsignal=QUIT
  164. nginx nginx is the most lightweight web server available. Built

    to support highly concurrent workloads (e.g. 10,000 concurrents). Simple configuration system. Python integration outsourced to uwsgi.
  165. nginx config Lives in /etc/nginx/sites-enabled/hacknode1: server { listen 80; server_name

    hacknode1.alephpoint.com; location / { try_files $uri @hacknode1; } location @hacknode1 { include uwsgi_params; # notice: same socket from uwsgi command uwsgi_pass unix:/tmp/uwsgi-hacknode1.sock; } }
  166. Lightweight Deployment Stack Overview Web Request --> nginx --> supervisor

    --> uwsgi --> Flask Your Application Code Y SO MANY LAYERS?
  167. Layers of Deployment Stack Lightweight means "right tool for the

    job", and in this case: • nginx only knows about serving and proxying HTTP requests • supervisor only knows about managing long-lived processes • uwsgi only knows about forwarding HTTP requests to WSGI app servers • Flask is an app server So, there may be a lot of layers, but each piece is small and well-understood.
  168. hacknode Team Setup Overview For our team development benefit, I've

    already configured our hacknode server with this nginx, supervisor, and uwsgi setup (yay sysadmin!) There are nine identical setups, hacknode{1-9}: {% for num in range(1, 10) %} {% set team_name = "hacknode" + num %} mkdir /home/shared/servers/{{ team_name}}; make_nginx_config {{ team_name }}; make_supervisor_config {{ team_name }}; start_service {{ team_name }}; {% endfor %} (not actual code, but it's what I did, roughly)
  169. Small fabfile changes TEAM_NAME = "hacknode2" # ... @task def

    setup_virtualenv(): """Set up virtualenv on remote machine.""" with cd("servers/" + TEAM_NAME): # <-- changed run("virtualenv rapid-env") virtualenv_run("pip install -r requirements.txt") @task def deploy(): """Deploy project remotely .""" run("mkdir -p servers") # <-- changed rsync_project(remote_dir="servers/" + TEAM_NAME, # <-- changed local_dir="./", exclude=(".git", "rapid-env", "steps", "activate"))
  170. Set up prod First, we set up the deployment directory.

    $ fab setup_virtualenv ... $ fab deploy ... We should now have /home/shared/servers/hacknode2/app/app.py for the app. We should also have /home/shared/servers/hacknode2/rapid-env for the env.
  171. Add restarter to fabfile def supervisor_run(cmd): sudo("supervisorctl {}".format(cmd), shell=False) @task

    def restart(): """Restart supervisor service and view some output of log file.""" supervisor_run("restart {}".format(TEAM_NAME)) run("sleep 1") supervisor_run("tail -800 {}".format(TEAM_NAME))
  172. Run prod $ fab restart [shared@hacknode] Executing task 'restart' [shared@hacknode]

    sudo: supervisorctl restart hacknode1 [shared@hacknode] out: hacknode1: stopped [shared@hacknode] out: hacknode1: started # ... [shared@hacknode] sudo: supervisorctl tail -800 hacknode1 # ... [shared@hacknode] out: uwsgi socket 0 bound to UNIX address /tmp/uwsgi-hacknode1.sock fd 3 [shared@hacknode] out: Python version: 2.7.3 (default, Apr 20 2012, 23:04:22) [GCC 4.6.3] [shared@hacknode] out: Set PythonHome to /home/shared/servers/hacknode1/rapid-env [shared@hacknode] out: Python main interpreter initialized at 0x1f06940 [shared@hacknode] out: your server socket listen backlog is limited to 100 connections [shared@hacknode] out: *** Operational MODE: single process *** [shared@hacknode] out: WSGI application 0 (mountpoint='') ready on interpreter 0x1f06940 pid [shared@hacknode] out: *** uWSGI is running in multiple interpreter mode *** [shared@hacknode] out: spawned uWSGI worker 1 (and the only) (pid: 6265, cores: 1) # ...
  173. Onward to Databases! Now that we have our web prototype,

    and a place where we can run our server in production, the last piece that is necessary is to think about where to put our glorious datas. There are various database types: • SQL • NoSQL • Search • Dynamo
  174. Database Styles Even within these types, there are multiple database

    styles! • Schema vs Schema-less • Distributed vs Single-Node • Dev-friendly vs Sysadmin friendly We'll do a quick "speed dating" right now.
  175. NoSQL: Redis "Data structures database." Key-value store. In-memory storage with

    optional backups to disk. strings, sets, sorted sets, hashes Good for: high-performance, low-importance data.
  176. NoSQL: MongoDB "Document database." Stores JSON documents, both flat and

    compound. Supports indexing for fast queries by using memory. Has a good replication / sharding story and a great out-of-box experience for developers. Good for: simple data storage use cases and some high-performance use cases.
  177. SQL: SQLite "World's simplest SQL database." Supports full SQL standard,

    but runs as an "embedded" server. Good for: development environments, learning SQL, desktop applications. Not good for servers; no concurrency story.
  178. SQL: Postgres "World's most advanced open source SQL database." Supports

    full SQL standard, "and then some". Has a great replication story, lots of developer tooling, and tons of performance optimization. Good for: detailed reporting needs, transactional systems, and also many "common" web app use cases. Only downsides: some sysadmin burden, some complex tooling/configuration, and you must know SQL.
  179. Search: Solr "World's most advanced open source search engine." Supports

    full-text search and complex filtering and faceting. Recently, has a good replication story, decent developer tooling, and tons of performance optimization. Good for: any use case where you're dealing with large amounts of text, or where you need to offer a "search" or "drill-down" (filter/refine) interface to users.
  180. Search: ElasticSearch "New contender in search engine space." Supports much

    of the same functionality as Solr, but was written from ground-up to have a better replication/sharding story. Good for: large-scale search use cases, e.g. searching the Twitter firehose.
  181. Dynamo: Cassandra and Riak Just don't worry about these databases.

    They are for "big data" use cases that are way beyond the needs of your prototype. They are part of the "upgrade path" for really big apps like Facebook, Advertising Systems, Finance Applications, etc.
  182. Picking One: MongoDB Why MongoDB? Doesn't require me to teach

    you anything about SQL -- "documents" are an intuitive and even Python-friendly concept. Awesome developer experience: you install it, and with zero configuration, you're basically ready to store data. pymongo driver lets you use Python dicts as MongoDB documents: simple! mongo "shell" is actually a JavaScript shell. Scales pretty well. We even use it at Parse.ly!
  183. Installing MongoDB There are pretty straightforward instructions for every operating

    system at: http://mongodb.org/downloads ❏ But I have also pre-installed it on our hacknode server to save us some time!
  184. Storing our first datum $ ssh shared@hacknode ... $ mongo

    ... > use hacknode1 switched to db hacknode1 > db.articles.insert({"title": "Google", "link": "http://google.com"}) > db.articles.find().pretty() { "_id" : ObjectId("51277ff21aba565f2bc54c5e"), "title" : "Google", "link" : "http://google.com" }
  185. Using pymongo >>> import pymongo >>> pymongo.MongoClient() MongoClient('localhost', 27017) >>>

    client = pymongo.MongoClient() >>> client.hacknode1 Database(MongoClient('localhost', 27017), u'hacknode1') >>> client.hacknode1.articles Collection(Database(MongoClient('localhost', 27017), u'hacknode1'), u'articles')
  186. Querying pymongo >>> coll = client.hacknode1.articles >>> coll.find() <pymongo.cursor.Cursor at

    0x2b1b350> >>> list(coll.find()) [{u'_id': ObjectId('51277ff21aba565f2bc54c5e'), u'link': u'http://google.com', u'title': u'Google'}]
  187. MongoDB query module from pymongo import MongoClient TEAM_NAME = "hacknode1"

    def get_collection(): return MongoClient()[TEAM_NAME].articles
  188. Storing data upon article submit def insert_article(article): coll = get_collection()

    article["score"] = 0 article["date"] = dt.datetime.now() print "Inserting ->", article coll.insert(article) return True
  189. Handling Submit "Explicit Upvoting" def insert_article(article): coll = get_collection() existing

    = coll.find_one({"link": article["link"]}) if existing is not None: print "Found existing, explicit upvoting ->", existing # updates the document server-side, incrementing score by 5 coll.update({"link": existing["link"]}, {"$inc": {"score": 5} }) return True else: article["score"] = 0 article["date"] = dt.datetime.now() print "Inserting ->", article # inserts a fresh document coll.insert(article) return True
  190. Handling Click "Implicit Upvoting" def track_click(url): coll = get_collection() print

    "Tracking ->", url # updates document server-side, incrementing by 1 coll.update({"link": url}, {"$inc": {"score": 1} }) return True
  191. Handling "Basic" Search def search_articles(query): print "Searching ->", query #

    does a regular expression match server-side # good for a hacky v1 articles = coll.find({"title": {"$regex": query} }) return list(articles)
  192. Architecture Review Web Request --> nginx --> uwsgi / supervisor

    --> Flask --> Python / MongoDB --> Jinja2 Templates --> Web Response --> HTML Browser --> Requests for Bootstrap CSS/JS --> Requests for jQuery JS --> Dynamic Element Modification
  193. Growing Up with Frameworks Flask is a "microframework" in that

    it lets you keep the technology small and wire pieces together as you need them. Larger projects might need to "grow up" into other Python web frameworks. We'll discuss two: Tornado and Django.
  194. Tornado and API Servers Tornado is like a "programmable nginx".

    Meant for handling 10,000 concurrent requests. Good for: high-performance API servers. Difficulties: • completely different programming model (callback-driven) • not compatible with all Python libraries
  195. Django and SaaS Apps Django is Python's most popular open

    source web framework. Deployment is similar to Flask, so performance is similar. Very popular for software-as-a-service web apps.
  196. Django Difficulties Has its own template engine that is less

    intuitive / powerful vs Jinja2 Built around an ORM (Object-Relational Mapper) that assumes you will use SQL Even if you use SQL, their ORM is under-powered vs e.g. SQLAlchemy IMO, a lot of "magic" in the framework that doesn't need to be there
  197. Django Pros Awesome admin interface built with the ORM Lots

    of open source plugins via "middleware" Good pattern for large applications with multiple "subapps" Has a built-in "users" and "groups" model for multi-user web apps More widely used in production, analyzed for security etc.
  198. Thoughts on SOA Service-Oriented Architecture (SOA) allows you to mix-and-match

    services by defining how they talk to one another. HTTP and JSON provide a low-cost and easy-to-understand communication protocol between these services. As your web app grows up, it might make sense to think about it as a "few small apps communicating with well-defined interfaces." This will allow you to use the best tool for the job. e.g. use Flask for your main app, and Tornado for your API server.
  199. Recap You've learned a lot! Rapid Web Prototyping doesn't mean

    jumping right into code. Static HTML / CSS / JavaScript can short-circuit the user feedback process. Good-looking UIs can be built by non-designers. Lightweight tools, like Bootstrap and Flask, can get you to working web app in record time. Web development isn't magic! It's just putting a few pieces together.
  200. Your New Lightweight Web Dev Stack (1) Building a Fake

    HTML, CSS, and JavaScript for static clickables, enhanced by Bootstrap and jQuery. Python SimpleHTTPServer and/or livereload for prototyping the UI. Fake a backend using public JSON-P services or local .json files as necessary.
  201. Your New Lightweight Web Dev Stack (2) Getting Real Build

    a local web application with Flask and design your URL routes. Convert your static clickables to Jinja2 templates. Use Macros and Filters for code duplication on the front-end.
  202. Your New Lightweight Web Dev Stack (3) Shipping It Set

    up a remote server in the cloud, e.g. Rackspace Cloud. Use Fabric to deploy your code to nginx, uwsgi, and supervisor. Store your first "real" data with MongoDB.
