1. Qemu bananaapple
2. Qemu • QEMU is a generic and open source machine emulator and virtualizer • Two modes • System (target-softmmu) • User (target-linux-user) • Targets • i386 • x86_64 • arm Kvm support could be used accelerate the system emulation
3. Qemu
4. TCG (Tiny Code Generator) • After version 0.9.1, Qemu use TCG as replacement of DynGen and GCC • TCG (Tiny Code Generator) is a code generator which translates code fragments ("basic blocks") from target code (any of the targets supported by QEMU) to a code representation which can be run on a host. • Translation Block -> TCG Operations -> Host Code
5. Main loop • cpu_exec() at /cpu-exec.c called each time around main loop • Using sigsetjmp and siglongjmp
6. Translation Block • Defined in include/exec/exec-all.h • pc, cs_base, flags • tc_ptr: a pointer to the translated code of this TB • jmp_list_next[2]: jump to next TB in a list • jmp_list_first: pointer to the first TB jumping to this one
7. Translation Block • Since each TB can have two jumps, it can participate in two lists. jmp_list_first and jmp_list_next are 4-byte aligned pointers to a TranslationBlock structure, but the two least significant bits of them are used to encode which data field of the pointed TB should be used to traverse the list further from that TB: • 0 => jmp_list_next[0], 1 => jmp_list_next[1], 2 => jmp_list_first
8. Translation Block • Block exit point: • encounter branch(modify PC) • reach page boundary 000081ac<abort>: 81ac: add $sp, $sp #-24 81b0: str $fp, [$sp+#20] … 81c2: beq $lr 81c6: mov $sp, $fp … 81d0: ret $lr Branch occur Block 1 Block 2 YODO Lab -8-
9. Block Chaining • Jump directly between basic blocks YODO Lab -9-
10. Chaining Steps • tb_add_jump() in “cpu-exec.c” YODO Lab -10-
11. TCG (Tiny Code Generator)
12. TCG (Tiny Code Generator)
13. TCG (Tiny Code Generator)
14. Codebase
15. Codebase • /vl.c: Setup virtual machine specification such as size of ram…… • /hw/: Emulated Hardware • /target-xxx/: Guest (Target) Specific • /target-xxx/translate.c: Guest Specific ISA is converted into TCG ops • /tcg/: Host (TCG) Specific • /tcg/*/tcg-target.c: TCG ops to Host Code • /cpu-exec.c: cpu-exec() finds the next translation block to translate and execute • /tci.c: tcg_qemu_tb_exec() real function execute code
16. Reference • https://lists.gnu.org/archive/html/qemu-devel/2011- 04/pdfhC5rVdz7U8.pdf • https://dl.dropboxusercontent.com/u/8976842/TCG.pdf • http://www.slideshare.net/RampantJeff/qemu-binary-translation • http://lugatgt.org/content/qemu_internals/downloads/slides.pdf
