Getting started with Kubernetes

Kubernetes is a very powerful container orchestration platform that is quickly gaining traction and gives you lots of benefits in deploying, running and scaling your microservice web application. But it has also a steep learning curve. In this talk I will introduce you to Kubernetes, why you would want to use it and all the tooling around Kubernetes with the help of practical examples.

Transcript

1. Introduction to Kubernetes @BastianHofmann
5. Container orchestration platform
6. Run and scale your services in isolated containers
7. Very Powerful
8. Large community
9. Lot’s of large company backers
10. No vendor lock in
11. Runs on
12. AWS
13. Azure
14. Google Cloud Platform
15. Bare metal
16. Your laptop
17. Minikube
18. Included in Docker Desktop Clients
19. Learning curve
20. This talk is supposed to get you started
21. I’m going to explain the basics
22. I’ll start with deploying a simple PHP Web App
23. look into some more ways to use Kubernetes
24. and cover things like Logging, Monitoring, Security, …
25. But first
26. Why containers?
27. Decouple Ops and Dev
28. Make things …
29. Easier to deploy
30. Easier to upgrade system dependencies
31. Easier to scale
32. Easier to develop
33. More performant than Virtual Machines
34. OK, sold
35. Let’s define some core concepts first
36. Kubernetes Cluster
37. Image • A docker image built from a Dockerfile that contains everything a service needs to run
38. • A container runs a docker image. • Only 1 process can run inside of a container Container
39. Pod • A group of 1 or more containers • Same port space • Ports are not accessible from outside of the pod
40. Replica Set • Defines and manages how many instances of a pod should run
41. Deployment • Manages updates and rollbacks of replica sets
42. Service • Makes a port of a pod accessible to other pods
43. Ingress • Makes a service accessible to the outside of Kubernetes
44. Node • A physical server • Containers get distributed automatically
45. ConfigMaps & Secrets • Configuration that can be mounted inside of a container
46. Volumes • Volumes can be mounted into a container to access a ConfigMap, Secret or a folder on the host
47. Namespaces • Dedicated environment to deploy services in
48. Example
49. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD
50. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD ReplicaSet: 2 instances PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD
51. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER ReplicaSet: 2 instances PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER CONFIG WEB :80 PHP Application POD PHP Application POD
52. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER ReplicaSet: 2 instances PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER CONFIG WEB :80 https://php-app.k8s.foo.com:443/ PHP Application POD PHP Application POD
53. To interact with Kubernetes
54. Tooling
55. kubectl
56. $ kubectl get pods
57. NAME READY STATUS RESTARTS AGE kubernetes-dashboard-5b5bf59977-t9xb9 1/1 Running 2 9d nginx-ingress-controller-5549f5597c-97kcw 0/1 Running 2 9d nginx-ingress-default-backend-564d9d9477-tmnnr 1/1 Running 4 9d mysql-556c9b5bcb-5jdrt 1/1 Running 1 8d symfony-demo-5b75f5fc6-c7wr9 1/1 Running 0 8d symfony-demo-5b75f5fc6-jg8n4 1/1 Running 23 8d
58. REST API
59. $ kubectl proxy --port=8080 $ curl http://localhost:8080/api/v1/namespaces/default/pods { "kind": "PodList", "apiVersion": "v1", "metadata": { "selfLink": "/api/v1/namespaces/default/pods", "resourceVersion": "336834" }, "items": [ { "metadata": { "name": "kubernetes-dashboard-5b5bf59977-t9xb9", "generateName": "kubernetes-dashboard-5b5bf59977-", …
60. kubernetes- dashboard https://github.com/kubernetes/dashboard
62. Helm The package manager for Kubernetes https://helm.sh/
63. $ helm install stable/wordpress
64. Practical example
65. Preparations
66. Install Docker Client
67. $ brew cask install docker
69. Install helm
70. $ brew install kubernetes-helm
71. $ helm init
72. Install kubernetes-dashboard
73. ingress: enabled: true hosts: - kubernetes-dashboard.local.k8s
74. $ helm install stable/kubernetes-dashboard -f kubernetes-dashboard.yaml
75. Install nginx-ingress-controller
76. rbac: create: true controller: hostNetwork: true
77. $ helm install stable/nginx-ingress -f ingress-controller.yaml
78. Let’s deploy the symphony demo app
79. https://github.com/symfony/demo
80. First the Dockerfile
81. PHP
82. Copy our code
83. Build the project
84. Composer install
85. yarn install
86. https://docs.docker.com/develop/develop-images/ multistage-build/
87. FROM kkarczmarczyk/node-yarn:latest WORKDIR /var/www/html COPY package.json /var/www/html/ COPY yarn.lock /var/www/html/ RUN yarn install
88. FROM php:7.2-apache WORKDIR /var/www/html # install packages RUN apt-get update -y && \ apt-get install -y --no-install-recommends \ curl git openssl \ less vim wget unzip rsync git mysql-client \ libcurl4-openssl-dev libfreetype6 libjpeg62-turbo libpng-dev libjpeg-dev libxml2-dev libxpm4 \ libicu-dev coreutils openssh-client libsqlite3-dev && \ apt-get clean && \ apt-get autoremove -y && \ rm -rf /var/lib/apt/lists/*
89. # install php extensions RUN docker-php-ext-configure gd --with-jpeg-dir=/usr/ local/ && \ docker-php-ext-install -j$(nproc) iconv intl pdo_sqlite curl json xml mbstring zip bcmath soap pdo_mysql gd # apache config RUN /usr/sbin/a2enmod rewrite && /usr/sbin/a2enmod headers && /usr/sbin/a2enmod expires COPY ./container/apache.conf /etc/apache2/sites- available/000-default.conf
90. ENV COMPOSER_HOME /tmp ENV COMPOSER_VERSION 1.6.3 RUN curl -s -f -L -o /tmp/installer.php https:// raw.githubusercontent.com/composer/getcomposer.org/ b107d959a5924af895807021fcef4ffec5a76aa9/web/installer \ && php -r " \ \$signature = '544e09ee996cdf60ece3804abc52599c22b1f40f4323403c44d44fd fdd586475ca9813a858088ffbc1f233e9b180f061'; \ \$hash = hash('SHA384', file_get_contents('/tmp/ installer.php')); \ if (!hash_equals(\$signature, \$hash)) { \ unlink('/tmp/installer.php'); \ echo 'Integrity check failed, installer is either corrupt or worse.' . PHP_EOL; \ exit(1); \ }" \ && php /tmp/installer.php --no-ansi --install-dir=/usr/ bin --filename=composer --version=${COMPOSER_VERSION} \ && composer --ansi --version --no-interaction \ && rm -rf /tmp/* /tmp/.htaccess
91. COPY composer.* /var/www/html/ RUN composer install COPY --from=0 /var/www/html/node_modules/ /var/www/html/ node_modules/ COPY . /var/www/html/ RUN chown -R www-data:www-data /var/www/html && composer dump-autoload
92. Command it runs
93. apache2 -DFOREGROUND
94. Build the image
95. docker build -t symfony-demo:2.0.0 .
96. Since it’s all local we don’t need to push it to a registry
97. Now we have to tell Kubernetes what to do with the image
98. Resources are defined in YAML or JSON
99. Deployment
100. kind: Deployment apiVersion: extensions/v1beta1 metadata: name: symfony-demo spec: revisionHistoryLimit: 3 template: metadata: labels: app: symfony-demo spec: containers: - name: symfony-demo image: symfony-demo:1.0.0 imagePullPolicy: Never ports: - containerPort: 80
101. containers: - name: symfony-demo image: symfony-demo:latest imagePullPolicy: Never ports: - containerPort: 80 livenessProbe: httpGet: path: / port: 80 timeoutSeconds: 1 initialDelaySeconds: 10 readinessProbe: httpGet: path: / port: 80 timeoutSeconds: 1
102. Many more options configurable
103. •Setting environment variables •Mounting volumes •Requesting resources •Defining upgrade strategies •Defining command •Configure networking •Configure affinities •LifeCycle events •…
104. Service
105. kind: Service apiVersion: v1 metadata: name: symfony-demo spec: ports: - name: http port: 80 targetPort: 80 protocol: TCP selector: app: symfony-demo
106. Ingress
107. kind: Ingress apiVersion: extensions/v1beta1 metadata: name: symfony-demo spec: rules: - host: symfony-demo.local.k8s http: paths: - path: / backend: serviceName: symfony-demo servicePort: 80
108. Creating everything
109. kubectl apply -f deployment/webapp.yaml
111. Rolling Deployments
112. kind: Deployment apiVersion: extensions/v1beta1 metadata: name: symfony-demo spec: revisionHistoryLimit: 3 template: metadata: labels: app: symfony-demo spec: containers: - name: symfony-demo image: symfony-demo:1.1.0 imagePullPolicy: Never ports: - containerPort: 80
113. kubectl apply -f deployment/webapp.yaml
114. These are the basics
115. Let’s talk about some other interesting and important aspects
116. There are other types of deploying things into Kubernetes
117. DaemonSets
118. Ensure that a pod runs once on every node
119. Log collection daemon
120. Monitoring agent
121. Service mesh containers
122. …
123. Basically works like deployments
124. But roll out strategy is different
125. https://kubernetes.io/docs/tasks/manage-daemon/update- daemon-set/
126. apiVersion: extensions/v1beta1 kind: DaemonSet metadata: name: kubernetes-ingress-nginx labels: k8s-app: kubernetes-ingress-nginx spec: updateStrategy: type: RollingUpdate rollingUpdate: maxUnavailable: 1 minReadySeconds: 5 template: …
127. CronJobs
128. Regularly repeating jobs
129. apiVersion: batch/v1beta1 kind: CronJob metadata: name: cron-job spec: schedule: "*/1 * * * *" jobTemplate: spec: template: spec: containers: - name: cron-job image: your-cron-job restartPolicy: OnFailure
130. How does Kubernetes work internally
131. Service Discovery
132. Within a pod
133. Shared port namespace
134. Everything behaves like localhost
135. Between pods
136. You have to expose ports with services
137. kind: Service apiVersion: v1 metadata: name: symfony-demo spec: ports: - name: http port: 80 targetPort: 80 protocol: TCP selector: app: symfony-demo
138. Every service has a virtual IP address
139. $ kubectl get service symfony-demo NAME TYPE CLUSTER-IP PORT(S) AGE symfony-demo ClusterIP 10.106.119.24 80/TCP 6d
140. Discoverable in other containers by
141. Environment Variables
142. SYMFONY_DEMO_SERVICE_HOST=10.106.119.24 SYMFONY_DEMO_SERVICE_PORT=80
143. DNS
144. $ nslookup symfony-demo Server: 10.0.0.10 Address 1: 10.0.0.10 Name: symfony-demo Address 1: 10.106.119.24
145. $ curl http://symfony-demo
146. Alternatively
147. Service Mesh
148. LinkerD https://linkerd.io/
149. Istio https://istio.io/
150. Conduit https://conduit.io/
151. Runs as
152. DaemonSet
153. Sidecar container
154. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD
155. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD NODEJS LINKERD STATSD Other service POD NODEJS LINKERD STATSD Other service POD
156. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD NODEJS LINKERD STATSD Other service POD NODEJS LINKERD STATSD Other service POD
157. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD NODEJS LINKERD STATSD Other service POD NODEJS LINKERD STATSD Other service POD
158. Benefits
159. Advanced routing
160. Prefer service in current namespace, fall back to default namespace
161. Advanced monitoring
163. Profiling
164. Zipkin https://zipkin.io/
166. Accessing Kubernetes from the outside
167. Port forwarding through kubectl
168. $ kubectl port-forward $POD_NAME 8080:80
169. The ingress controller
170. Nginx
171. haproxy
172. Istio
173. …
174. A controller listens to all ingresses and routes traffic from the outside to the correct service
175. kind: Ingress apiVersion: extensions/v1beta1 metadata: name: symfony-demo spec: rules: - host: symfony-demo.local.k8s http: paths: - path: / backend: serviceName: symfony-demo servicePort: 80
176. What about data?
177. Storage
178. Volumes
179. https://kubernetes.io/docs/concepts/storage/volumes/
180. apiVersion: v1 kind: Pod metadata: name: test-pd spec: containers: - image: k8s.gcr.io/test-webserver name: test-container volumeMounts: - mountPath: /cache name: cache-volume volumes: - name: cache-volume emptyDir: {}
181. Persistent Storage
182. You define a Persistent Volume, e.g. NFS
183. Each pod can specify a Persistent Volume Claim
184. And then mount the Claim into a Volume in a container
185. https://kubernetes.io/docs/concepts/storage/persistent- volumes/
186. Configuration
187. Less data, so either than Persistent Volumes
188. ConfigMap
189. Key/Value Store
190. kind: ConfigMap apiVersion: v1 metadata: name: special-config data: special-key: value bool-value: true
191. Can be accessed in a pod through environment variables
192. spec: containers: - name: test-container image: k8s.gcr.io/busybox command: [ "/bin/sh", "-c", "env" ] env: - name: SPECIAL_KEY valueFrom: configMapKeyRef: name: special-config key: special-key
193. spec: containers: - name: test-container image: k8s.gcr.io/busybox command: [ "/bin/sh", "-c", "env" ] envFrom: - configMapRef: name: special-config
194. Can be accessed through volumes
195. spec: containers: - name: test-container image: k8s.gcr.io/busybox command: [ "/bin/sh", "-c", "ls /etc/config/" ] volumeMounts: - name: config-volume mountPath: /etc/config volumes: - name: config-volume configMap: name: special-config
196. https://kubernetes.io/docs/tasks/configure-pod-container/ configure-pod-configmap/
197. Secret
198. Storage for sensitive information
199. https://kubernetes.io/docs/concepts/configuration/secret
200. How about complex init processes
201. Init Containers
202. Run a process in a container before the pod starts
203. Use cases
204. Database Migrations
205. Multiple containers need the same sources
206. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD
207. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD INIT
208. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD INIT The only image that contains the source code
209. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD INIT emptyDir Volume Mounts
210. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD INIT emptyDir Volume Copies source
211. PHP-FPM NGINX LINKERD STATSD MEM CACHED MONGO ROUTER PHP Application POD INIT emptyDir Volume with source Mounts and uses
212. Figuring out what’s going on inside Kubernetes
213. Monitoring
214. Heapster
215. https://github.com/kubernetes/heapster
216. Takes metrics from Kubernetes and stores them in a monitoring solution
217. InfluxDB
218. Prometheus
219. Grafana for displaying the data
222. https://blog.kublr.com/how-to-utilize-the-heapster-influxdb- grafana-stack-in-kubernetes-for-monitoring- pods-4a553f4d36c9
223. Logging
224. kubectl logs
225. $ kubectl logs symfony-demo-5b75f5fc6-c7wr9
226. Log to stdout & stderr
227. Automatically written to disk
228. DaemonSet Log collector
229. • Logstash • Fluentd • Filebeat
230. Central log management
232. https://www.elastic.co/blog/shipping-kubernetes-logs-to- elasticsearch-with-filebeat
233. Scaling
234. Manual Scaling
235. kubectl scale --replicas=3 deployment/my-app
236. AutoScaling
238. https://kubernetes.io/docs/user-guide/horizontal-pod- autoscaling/
239. Keeping services secure
240. Docker Container Security
241. https://kubernetes.io/docs/tasks/configure-pod-container/ security-context/
242. Role Based Access Control
243. Users
244. ServiceAccounts
245. https://kubernetes.io/docs/admin/authorization/rbac/
246. Summary
247. Powerful
248. Helpful
249. Fast paced development
250. https://gravitational.com/blog/kubernetes-release-cycle/
251. Keep up to date
252. Documentation
253. https://kubernetes.io/docs/
254. KubeCons
255. https://www.youtube.com/channel/UCvqbFHwN- nwalWPjPUKpvTA
256. http://speakerdeck.com/u/bastianhofmann
257. http://twitter.com/BastianHofmann http://lanyrd.com/people/BastianHofmann http://speakerdeck.com/u/bastianhofmann mail@bastianhofmann.de
