The Bleeding Edge of HTML5
An overview of the most bleeding of edges to HTML, CSS and JavaScript. Featuring: JS Speech, CSS Custom Filters, Responsive Images, Web Components and more!
Brandon Satrom
November 15, 2012
Transcript
55 slides
-
Meanwhile, back in the Enterprise... So, to use Geolocation, I’ll
need to add feature detection. Then I need a polyfill for IE6, 7 and 8, which will triple the size of the feature... -
Meanwhile, back in the Enterprise... So, to use Geolocation, I’ll
need to add feature detection. Then I need a polyfill for IE6, 7 and 8, which will triple the size of the feature... HOLY CHRISTIAN HEILMANN, BATMAN! -
If you’d rather be practical, you can watch: http:/ /bit.ly/HTML5-TechEd
Forget practical... ... let’s have some fun!* -
Notice! Cutting-Edge Browsers Only! Chrome Canary - bit.ly/Chrome-Canary Firefox Nightly
- nightly.mozilla.org -
JavaScript is like this really big fish I caught once...
brendaneich.com/2012/10/ harmony-of-dreams-come- true/ Default & Rest Parameters for-of iteration Map & Set Proxy Modules And more... -
Default and Rest Parameters function f(a = 0, b =
a*a) { return [a, b]; } var ret = f(2); // Returns [2, 4] function f(a, b, ...others) { return others.concat(a, b); } ret = f(1, 2, 3, 4); // Returns [3, 4, 1, 2]; -
Modules module EventAggregator { export function sub() { /*
… */ } export function pub() { /* … */ } } import {sub, pub} from EventAggregator; import $ from “//code.jquery.comjquery-‐1.8.2.min.js”; var el = $(‘#main’); // No Script include! -
Classes //Extend a ThreeJS Mesh with an //overloaded ctor
and extra properties class SkinnedMesh extends THREE.Mesh { constructor(geometry, materials) { super(geometry, materials); this.idMatrix = new THREE.Matrix4(); this.bones = []; this.boneMatrices = []; ... } update(camera) { ... super.update(); } } -
CSS Regions <!-‐-‐ HTML -‐-‐> <div id="source">
<p> [ Really long article goes here ] </p> </div> <div class="container"> <div id="region1" class="region"></div> <div id="region2" class="region"></div> <div id="region3" class="region"></div> </div> /* CSS */ #source { -‐webkit-‐flow-‐into: main; } .region { -‐webkit-‐flow-‐from: main; width: 250px; float: left; margin-‐right: 10px; background: #eee; width: 30%; padding: 1%; margin-‐right: 1%; height: 400px; } -
CSS Filter Effects img.sepia { -‐webkit-‐filter: sepia(100%);
-‐moz-‐filter: sepia(100%); -‐o-‐filter: sepia(100%); -‐ms-‐filter: sepia(100%); filter: sepia(100%); } img.hue { -‐webkit-‐filter: hue-‐rotate(50deg); -‐moz-‐filter: hue-‐rotate(50deg); -‐o-‐filter: hue-‐rotate(50deg); -‐ms-‐filter: hue-‐rotate(50deg); filter: hue-‐rotate(50deg); } -
CSS Custom Filters .shader { -webkit-filter: custom(none mix(url(shaders/grayscale.fs) normal source-atop),
amount 0); -webkit-transition: -webkit-filter linear 1s; } .shader:hover{ -webkit-filter: custom(none mix(url(shaders/grayscale.fs) normal source-atop), amount 1); } -
CSS Custom Filters - Shaders precision mediump float; // Uniform
values from CSS uniform float amount; // Varyings passed in from vertex shader varying vec2 v_uv; varying float v_height; varying float v_light; // Main void main() { ! const float a = 1.0; ! float r, g, b; ! // Depth variant ! /* ! float n = 1.0 - v_height; ! float v = mix(1.0, n, amount); ! r = g = b = v; ! */ ! // Light variant ! float n = v_light; ! float v = mix(1.0, n * n, amount); ! r = g = b = sqrt(v); ! // Set color matrix ! css_ColorMatrix = mat4(r, 0.0, 0.0, 0.0, ! ! ! ! ! ! ! 0.0, g, 0.0, 0.0, ! ! ! ! ! ! ! 0.0, 0.0, b, 0.0, ! ! ! ! ! ! ! 0.0, 0.0, 0.0, a); } -
CSS Custom Filters - Shaders precision mediump float; // Uniform
values from CSS uniform float amount; // Varyings passed in from vertex shader varying vec2 v_uv; varying float v_height; varying float v_light; // Main void main() { ! const float a = 1.0; ! float r, g, b; ! // Depth variant ! /* ! float n = 1.0 - v_height; ! float v = mix(1.0, n, amount); ! r = g = b = v; ! */ ! // Light variant ! float n = v_light; ! float v = mix(1.0, n * n, amount); ! r = g = b = sqrt(v); ! // Set color matrix ! css_ColorMatrix = mat4(r, 0.0, 0.0, 0.0, ! ! ! ! ! ! ! 0.0, g, 0.0, 0.0, ! ! ! ! ! ! ! 0.0, 0.0, b, 0.0, ! ! ! ! ! ! ! 0.0, 0.0, 0.0, a); } Holy C-like syntax, Batman! -
getUser Media & WebRTC navigator.getUserMedia = navigator.getUserMedia ||
navigator.webkitGetUserMedia || navigator.mozGetUserMedia || navigator.msGetUserMedia; var url = window.URL || window.webkitURL, createEl = document.CreateElement; function streamVideo(lStream) { var video = createEl("video"); video.autoplay = true; video.src = url.createObjectURL(lStream); document.body.appendChild(video); } navigator.getUserMedia( {video: true}, streamVideo, logError); -
WebGL var camera, scene, renderer; var geometry, material, mesh; camera
= new THREE.PerspectiveCamera(75,500,1, 10000 ); camera.position.z = 1000; scene = new THREE.Scene(); geometry = new THREE.CubeGeometry( 200, 200, 200 ); material = new THREE.MeshBasicMaterial( { color: 0xff0000, wireframe: true } ); mesh = new THREE.Mesh( geometry, material ); scene.add( mesh ); renderer = new THREE.WebGLRenderer(); renderer.setSize( window.innerWidth, window.innerHeight ); document.body.appendChild( renderer.domElement ); -
JavaScript Speech API var recognition = new SpeechRecognition(); recognition.maxAlternatives =
5; recognition.onresult = function(event) { // SpeechRecognitionEvent if (event.result.length > 0) { // SpeechRecognitionResult var q = document.querySelector('#query'); // SpeechRecognitionAlternative q.value = event.result[0].transcript; } }; var button = document.querySelector('#s'); button.onclick = function() { recognition.start(); }; -
Hixie vs. THE WORLD (a.k.a. srcset vs. <picture>) or (a
tale of two specifications) or (much ado about media) http:/ /responsiveimages.org/ http:/ /picture.responsiveimages.org/ http:/ /dev.w3.org/html5/srcset/ -
Responsive Images <picture> <!-‐-‐ picture-‐element -‐-‐> <picture> <source media="(max-‐width:
479px)" src="[email protected]"> <source media="(min-‐width: 480px) and (max-‐width: 639px)" src="[email protected]"> <source media="(min-‐width: 640px)" src="[email protected]"> <source media="monochrome" src="[email protected]"> <!-‐-‐ fallback img if picture is not supported -‐-‐> <img src="[email protected]"> <!-‐-‐ providing alternate text -‐-‐> <p>Nymphenburg Castle in Munich during sunset</p> </picture> -
Responsive Images “srcset” <h1> <img alt="The Breakfast Combo"
src="banner.jpeg" srcset="banner-‐HD.jpeg 2x, banner-‐phone.jpeg 100w, banner-‐phone-‐HD.jpeg 100w 2x"> </h1> <figure> <img src="pear-‐tablet.jpeg" srcset="pear-‐min0.jpeg 720w, pear-‐min721.jpeg 1280w, pear-‐min1281.jpeg 1x" alt="The pear is juicy."> <figcaption>Awesome Pear</figcaption> </figure> -
<picture> & “srcset”, so happy together... <picture width="500" height="500">
<source media="(min-‐width: 45em)" srcset="large-‐1.jpg 1x, large-‐2.jpg 2x"> <source media="(min-‐width: 18em)" srcset="med-‐1.jpg 1x, med-‐2.jpg 2x"> <source srcset="small-‐1.jpg 1x, small-‐2.jpg 2x"> <img src="small-‐1.jpg"> <p>Accessible text</p> </picture> -
Web Components webcomponents.github.com/ Custom Elements / x-tags Templates Decorators Shadow
DOM or (“Subverting the W3C, one x-tag at a time”) -
Templates <template id="cmmTmpl"> <div> <img src=""> <div class="comment"></div> … </div>
</template> var t = document.querySelector("#cmmTmpl"); // Populate the template. // … // Add Node to DOM someElement.appendChild( t.content.cloneNode()); -
Custom Elements <element extends="button" name="x-fancybutton"> <template> <style scoped> :host {
display: contents; } div.fancy { … } </style> <div class="fancy"> <content></content> <div id="t"></div> <div id="l"></div> <div id="b"></div> <div id="r"></div> </div> </template> </element> <button is=”x-fancybutton” onclick=”showTime();”> Show Time </button> -
CSS Decorators <decorator id="fade-to-white"> <template> <div style="position: relative;"> <style scoped>
#fog { position: absolute; background: rgba(255, 255, 255, 0); } </style> <content></content> <div id="fog"></div> </div> </template> </decorator> <div class="poem"> Two roads diverged in a yellow wood,<br> </div> .poem { decorator: url(#fade-to-white); font-variant: small-caps; } -
Shadow DOM <div> <content select="h1.cool"> <!-- all h1.cool children here
--> </content> <div class="cool"> <content select=".cool"> <!-- all .cool children (except h1.cool) appear here --> </content> </div> <div class="stuff"> <content> <!-- remaining children will appear here --> </content> </div> </div> <div> <shadow> <!-- range slider renders here --> </shadow> <div class="ticks"> … </div> </div> -
... like Mozilla’s WebAPI Initiative WebTelephony WebSMS Contacts API Battery
Status WebNFC WebPayment WebFM arewemobileyet.com -
I am the Web, hug me! So, what does it
all mean? Image by “dbking” From http://www.flickr.com/photos/65193799@N00/185094394/ -
Questions? Image From http:/ /www.freepixels.com/index.php?action=showpic&cat=22&pic=1223 Slides - bit.ly/bleeding-html5 Demos -
github.com/bsatrom/bleeding-html5
