1. Software Engineer, 10gen @brandonmblack Brandon Black #MongoDBDays Introduction to Sharding
2. Agenda •  Scaling Data •  MongoDB's Approach •  Architecture •  Configuration •  Mechanics
3. Scaling Data
4. Examining Growth •  User Growth –  1995: 0.4% of the world’s population –  Today: 30% of the world is online (~2.2B) –  Emerging Markets & Mobile •  Data Set Growth –  Facebook’s data set is around 100 petabytes –  4 billion photos taken in the last year (4x a decade ago)
5. Read/Write Throughput Exceeds I/O
6. Working Set Exceeds Physical Memory
7. Vertical Scalability (Scale Up)
8. Horizontal Scalability (Scale Out)
9. Data Store Scalability •  Custom Hardware –  Oracle •  Custom Software –  Facebook + MySQL –  Google
10. Data Store Scalability Today •  MongoDB Auto-Sharding •  A data store that is –  Free –  Publicly available –  Open source (https://github.com/mongodb/mongo) –  Horizontally scalable –  Application independent
11. MongoDB's Approach to Sharding
12. Partitioning •  User defines shard key •  Shard key defines range of data •  Key space is like points on a line •  Range is a segment of that line -∞ +∞ Key Space
13. Data Distribution •  Initially 1 chunk •  Default max chunk size: 64mb •  MongoDB automatically splits & migrates chunks when max reached Node 1 Secondary Config Server Shard 1 Mongos Mongos Mongos Shard 2 Mongod
14. Routing and Balancing •  Queries routed to specific shards •  MongoDB balances cluster •  MongoDB migrates data to new nodes Shard Shard Shard Mongos 1 2 3 4
15. MongoDB Auto-Sharding •  Minimal effort required –  Same interface as single mongod •  Two steps –  Enable Sharding for a database –  Shard collection within database
16. Architecture
17. What is a Shard? •  Shard is a node of the cluster •  Shard can be a single mongod or a replica set Shard Primary Secondary Secondary Shard or Mongod
18. •  Config Server –  Stores cluster chunk ranges and locations –  Can have only 1 or 3 (production must have 3) –  Not a replica set Meta Data Storage or Node 1 Secondary Config Server Node 1 Secondary Config Server Node 1 Secondary Config Server Node 1 Secondary Config Server
19. Routing and Managing Data •  Mongos –  Acts as a router / balancer –  No local data (persists to config database) –  Can have 1 or many App Server Mongos Mongos App Server App Server App Server Mongos or
20. Sharding infrastructure Node 1 Secondary Config Server Node 1 Secondary Config Server Node 1 Secondary Config Server Shard Shard Shard Mongos App Server Mongos App Server Mongos App Server
21. Configuration
22. Example Cluster •  Don’t use this setup in production! -  Only one Config server (No Fault Tolerance) -  Shard not in a replica set (Low Availability) -  Only one mongos and shard (No Performance Improvement) -  Useful for development or demonstrating configuration mechanics Node 1 Secondary Config Server Mongos Mongod Mongod
23. Node 1 Secondary Config Server Starting the Configuration Server •  mongod --configsvr •  Starts a configuration server on the default port (27019)
24. Node 1 Secondary Config Server Mongos Start the mongos Router •  mongos --configdb <hostname>:27019! •  For 3 configuration servers: mongos --configdb <host1>:<port1>,<host2>:<port2>,<host3>:<port3>! •  This is always how to start a new mongos, even if the cluster is already running
25. Start the shard database •  mongod --shardsvr! •  Starts a mongod with the default shard port (27018) •  Shard is not yet connected to the rest of the cluster •  Shard may have already been running in production Node 1 Secondary Config Server Mongos Mongod Shard
26. Add the Shard •  On mongos: -  sh.addShard(‘<host>:27018’)! •  Adding a replica set: -  sh.addShard(‘<rsname>/<seedlist>’)! Node 1 Secondary Config Server Mongos Mongod Shard
27. Verify that the shard was added •  db.runCommand({ listshards:1 })! { "shards" :
 ![{"_id”: "shard0000”,"host”: ”<hostname>:27018” } ],! "ok" : 1
 }! Node 1 Secondary Config Server Mongos Mongod Shard
28. Enabling Sharding •  Enable sharding on a database ! sh.enableSharding(“<dbname>”)! •  Shard a collection with the given key ! sh.shardCollection(“<dbname>.people”,{“country”:1})! •  Use a compound shard key to prevent duplicates ! sh.shardCollection(“<dbname>.cars”,{“year”:1, ”uniqueid”:1})!
29. Tag Aware Sharding •  Tag aware sharding allows you to control the distribution of your data •  Tag a range of shard keys –  sh.addTagRange(<collection>,<min>,<max>,<tag>) •  Tag a shard –  sh.addShardTag(<shard>,<tag>)
30. Mechanics
31. Partitioning •  Remember it's based on ranges -∞ +∞ Key Space
32. Chunk is a section of the entire range minKey maxKey minKey maxKey minKey maxKey {x: -20} {x: 13} {x: 25} {x: 100,000} 64MB
33. Chunk splitting •  A chunk is split once it exceeds the maximum size •  There is no split point if all documents have the same shard key •  Chunk split is a logical operation (no data is moved) minKey maxKey minKey 13 14 maxKey
34. Balancing •  Balancer is running on mongos! •  Once the difference in chunks between the most dense shard and the least dense shard is above the migration threshold, a balancing round starts Node 1 Secondary Config Server Shard 1 Mongos Mongos Mongos Shard 2 Mongod
35. Acquiring the Balancer Lock •  The balancer on mongos takes out a “balancer lock” •  To see the status of these locks: use config! db.locks.find({ _id: “balancer” })! Node 1 Secondary Config Server Mongos Shard 1 Mongos Mongos Shard 2 Mongod
36. Moving the chunk •  The mongos sends a moveChunk command to source shard •  The source shard then notifies destination shard •  Destination shard starts pulling documents from source shard Node 1 Secondary Config Server Mongos Shard 1 Shard 2 Mongod
37. Committing Migration •  When complete, destination shard updates config server -  Provides new locations of the chunks Node 1 Secondary Config Server Mongos Shard 1 Shard 2 Mongod
38. Cleanup •  Source shard deletes moved data -  Must wait for open cursors to either close or time out -  NoTimeout cursors may prevent the release of the lock •  The mongos releases the balancer lock after old chunks are deleted Node 1 Secondary Config Server Shard 1 Shard 2 Mongod Mongos Mongos Mongos
39. Routing Requests
40. Cluster Request Routing •  Targeted Queries •  Scatter Gather Queries •  Scatter Gather Queries with Sort
41. Cluster Request Routing: Targeted Query Shard Shard Shard Mongos
42. Routable request received Shard Shard Shard Mongos 1
43. Request routed to appropriate shard Shard Shard Shard Mongos 1 2
44. Shard returns results Shard Shard Shard Mongos 1 2 3
45. Mongos returns results to client Shard Shard Shard Mongos 1 2 3 4
46. Cluster Request Routing: Non-Targeted Query Shard Shard Shard Mongos
47. Non-Targeted Request Received Shard Shard Shard Mongos 1
48. Request sent to all shards Shard Shard Shard Mongos 1 2 2 2
49. Shards return results to mongos Shard Shard Shard Mongos 1 2 2 2 3 3 3
50. Mongos returns results to client Shard Shard Shard Mongos 1 2 2 2 3 3 3 4
51. Cluster Request Routing: Non-Targeted Query with Sort Shard Shard Shard Mongos
52. Non-Targeted request with sort received Shard Shard Shard Mongos 1
53. Request sent to all shards Shard Shard Shard Mongos 1 2 2 2
54. Query and sort performed locally Shard Shard Shard Mongos 1 2 2 2 3 3 3
55. Shards return results to mongos Shard Shard Shard Mongos 1 2 2 2 4 4 4 3 3 3
56. Mongos merges sorted results Shard Shard Shard Mongos 1 2 2 2 4 4 4 3 3 3 5
57. Mongos returns results to client Shard Shard Shard Mongos 1 2 2 2 4 4 4 3 3 3 6 5
58. Shard Key
59. Shard Key •  Shard key is immutable •  Shard key values are immutable •  Shard key must be indexed •  Shard key limited to 512 bytes in size •  Shard key used to route queries –  Choose a field commonly used in queries •  Only shard key can be unique across shards –  `_id` field is only unique within individual shard
60. Shard Key Considerations •  Cardinality •  Write Distribution •  Query Isolation •  Reliability •  Index Locality
61. { _id: ObjectId(), user: 123, time: Date(), subject:
    ..., recipients: [], body:
    ..., attachments: [] } Example: Email Storage Most common scenario, can be applied to 90% cases Each document can be up to 16MB Each user may have GBs of storage Most common query: get user emails sorted by time Indexes on {_id}, {user, time}, {recipients}
62. Example: Email Storage Cardinality! Write Scaling! Query Isolation! Reliability! Index! Locality!
63. Example: Email Storage Cardinality! Write Scaling! Query Isolation! Reliability! Index! Locality! _id! Doc level! One shard! Scatter/ gather! All users affected! Good!
64. Example: email storage Cardinality! Write scaling! Query isolation! Reliability! Index! locality! _id! Doc level! One shard! Scatter/ gather! All users affected! Good! hash(_id)! Hash level! All Shards! Scatter/ gather! All users affected! Poor!
65. Example: Email Storage Cardinality! Write Scaling! Query Isolation! Reliability! Index! Locality! _id! Doc level! One shard! Scatter/ gather! All users affected! Good! hash(_id)! Hash level! All Shards! Scatter/ gather! All users affected! Poor! user! Many docs! All Shards! Targeted Some users affected Good!
66. Example: Email Storage Cardinality! Write Scaling! Query Isolation! Reliability! Index! Locality! _id! Doc level! One shard! Scatter/ gather! All users affected! Good! hash(_id)! Hash level! All Shards! Scatter/ gather! All users affected! Poor! user! Many docs! All Shards! Targeted Some users affected Good! user, time! Doc level! All Shards! Targeted! Some users affected Good!
67. Conclusion
68. Read/Write Throughput Exceeds I/O
69. Working Set Exceeds Physical Memory
70. Sharding Enables Scale •  MongoDB’s Auto-Sharding –  Easy to Configure –  Consistent Interface –  Free and Open Source
71. •  What’s next? –  Webinar: Technical Overview of MongoDB (March 7th) –  MongoDB User Group •  Resources https://education.10gen.com/ http://www.10gen.com/presentations http://github.com/brandonblack/presentations
72. Software Engineer, 10gen @brandonmblack Brandon Black #MongoDBDays Thank You
