Better Living Through Control Flow Graph Generation

Thunderplainsconf 2014

Transcript

1. THUNDER PLAINS CONF 2014 @isntitvacant better living through! control flow graph! generation
2. THUNDER PLAINS CONF 2014 @isntitvacant OR: use JS to build a JS! runtime to analyze JS
3. THUNDER PLAINS CONF 2014 @isntitvacant hi, I’m chris.
4. THUNDER PLAINS CONF 2014 @isntitvacant hi, I’m chris. I work for WM labs
5. THUNDER PLAINS CONF 2014 @isntitvacant hi, I’m chris. I’d like to talk to you about how we think about our code. I work for WM labs
6. THUNDER PLAINS CONF 2014 @isntitvacant what is a program?
7. THUNDER PLAINS CONF 2014 @isntitvacant what is a program? is it text?
8. THUNDER PLAINS CONF 2014 @isntitvacant what is a program? is it text? is it what runs on the CPU?
9. THUNDER PLAINS CONF 2014 @isntitvacant what is a program? is it text? is it what runs on the CPU? is it an idea?
10. THUNDER PLAINS CONF 2014 @isntitvacant function compare(lhs, rhs) {
 return lhs - rhs > 0 } the treachery of text
11. THUNDER PLAINS CONF 2014 @isntitvacant function compare(lhs, rhs) {
 return lhs - rhs > 0 }
12. THUNDER PLAINS CONF 2014 @isntitvacant function compare(lhs, rhs) {
 return lhs - rhs > 0 }
13. THUNDER PLAINS CONF 2014 @isntitvacant function compare(lhs lhs rhs rhs , ) { > - 0 } return
14. THUNDER PLAINS CONF 2014 @isntitvacant function compare ( lhs lhs rhs rhs , ) { > - 0 } return
15. THUNDER PLAINS CONF 2014 @isntitvacant function compare ( lhs lhs rhs rhs , ) { > - 0 } return
16. THUNDER PLAINS CONF 2014 @isntitvacant function compare ( lhs lhs rhs rhs , ) { > - 0 } return
17. THUNDER PLAINS CONF 2014 @isntitvacant function compare ( lhs lhs rhs rhs , ) { > - 0 } return
18. THUNDER PLAINS CONF 2014 @isntitvacant function compare ( lhs lhs rhs rhs , ) { > - 0 } return
19. THUNDER PLAINS CONF 2014 @isntitvacant function compare ( lhs lhs rhs rhs , ) { > - 0 } return
20. THUNDER PLAINS CONF 2014 @isntitvacant function compare lhs lhs rhs rhs > - 0 return
21. THUNDER PLAINS CONF 2014 @isntitvacant function compare lhs lhs rhs rhs > - 0 return name parameters body
22. THUNDER PLAINS CONF 2014 @isntitvacant Abstract Syntax Trees one syntax tree can represent multiple different input texts.
23. THUNDER PLAINS CONF 2014 @isntitvacant function compare lhs lhs rhs rhs > - 0 return name parameters body
24. THUNDER PLAINS CONF 2014 @isntitvacant function a b b c c > - return name parameters body 0
25. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs
26. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs CFGs represent the flow between operations in a program.
27. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs CFGs are directed graphs. ! A directed graph has edges that go from one node to another. ! In a CFG's case, nodes are operations, and edges are flows between operations.
28. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs function <id> <id> <id> <id> <id> > - literal return name parameters body
29. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs <id> <id> > - literal return
30. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs <id> <id> > - literal return
31. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs <id> <id> > - literal return
32. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs <id> <id> > - literal return
33. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs <id> <id> > - literal return
34. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs <id> <id> > - literal return
35. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs <id> <id> > - literal return operation: "load <id>"
36. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs <id> <id> > - literal return then transfer control to..
37. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs <id> <id> > - literal return another load,
38. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs <id> <id> > - literal return then transfer control to..
39. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs <id> <id> > - literal return a subtraction operation!
40. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs importantly: one control flow graph can represent multiple different input syntax trees. for example...
41. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs while(x > 3) {
 x -= 2 } B1 B2 B3
42. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs for(;x > 3;) {
 x -= 2 } B1 B2 B3
43. THUNDER PLAINS CONF 2014 @isntitvacant control flow graphs function f(x) { if(x > 3) f(x - 2) } x = f(x) B1 B2 B3
44. THUNDER PLAINS CONF 2014 @isntitvacant goals and obstacles
45. THUNDER PLAINS CONF 2014 @isntitvacant goals if we can build CFGs, we open the door to neat optimizations ! * dead code elimination * splitting polymorphic functions into multiple monomorphic functions * extreme minification * generating SSA graphs (like V8's Crankshaft!)
46. THUNDER PLAINS CONF 2014 @isntitvacant goals (cont'd) and we can also do some neat mad-science-y stuff: ! * diffing CFGs — did that commit add a new exception edge to the program? * taint checking * if the IR is advanced enough, we could project JS into different languages.
47. THUNDER PLAINS CONF 2014 @isntitvacant obstacles BUT FIRST: ! * We need to accurately represent every (wonky) JS control structure * And for best results, we want to have as many "linear" blocks as possible.
48. THUNDER PLAINS CONF 2014 @isntitvacant obstacles (wonky control structures) B1: { if (x > 2) break B1 }
49. THUNDER PLAINS CONF 2014 @isntitvacant obstacles (wonky control structures) B2: { B1: { try { break B1 } finally {
 break B2 } } console.log('???') }
50. THUNDER PLAINS CONF 2014 @isntitvacant obstacles (linear blocks) what is a linear block? ! when a given operation has only one possible exit edge, and the next operation has one possible entry, we can say that:
51. THUNDER PLAINS CONF 2014 @isntitvacant obstacles (linear blocks) what is a linear block? ! "If control ever enters this block, it must perform all of these operations before exiting this block"
52. THUNDER PLAINS CONF 2014 @isntitvacant obstacles (linear blocks) what is a linear block? ! and thus we can simplify! load x load 3 less-than test less-than test load 3 load x ===
53. THUNDER PLAINS CONF 2014 @isntitvacant obstacles (linear blocks) in other words: ! anything that conditionally executes code is not linear ! that includes anything that throws an exception
54. THUNDER PLAINS CONF 2014 @isntitvacant obstacles (linear blocks) pop quiz: ! what operators in JavaScript are guaranteed to not throw exceptions?
55. THUNDER PLAINS CONF 2014 @isntitvacant obstacles (linear blocks) pop quiz (answered): ! well, there's void
56. THUNDER PLAINS CONF 2014 @isntitvacant obstacles (linear blocks) pop quiz (answered): ! * delete, in, instanceof, and new can all throw * all mathematical operators can all throw * all lookups can throw
57. THUNDER PLAINS CONF 2014 @isntitvacant obstacles (linear blocks) pop quiz (really answered): ! no* operators are safe. ! it's only combinations of operators and operand types that are safe. ! * except for void but hey, it's kind of difficult to write a useful program with just void
58. THUNDER PLAINS CONF 2014 @isntitvacant obstacles (linear blocks) solution: ! * track values through the program
59. THUNDER PLAINS CONF 2014 @isntitvacant tracking values
60. THUNDER PLAINS CONF 2014 @isntitvacant tracking values How do we track values in a JS program? What should a value look like?
61. THUNDER PLAINS CONF 2014 @isntitvacant tracking values Values might be: ! * Undefined or null * Primitives (strings, booleans, or numbers) * Objects * Functions * Unknown
62. THUNDER PLAINS CONF 2014 @isntitvacant tracking values (unknowns) Unknowns are values that are present in the program, but either aren't available from the code OR aren't deducible statically.
63. THUNDER PLAINS CONF 2014 @isntitvacant tracking values (unknowns) For instance, if you use a variable declared globally in another script, we would mark that "Unknown".
64. THUNDER PLAINS CONF 2014 @isntitvacant tracking values (unknowns) We can make deductions based on their use: ! * are they defined? (i.e., not null/undefined) * are they functions?
65. THUNDER PLAINS CONF 2014 @isntitvacant tracking values (unknowns) We track values using a stack.
66. THUNDER PLAINS CONF 2014 @isntitvacant tracking values We track values using a stack. load x subtract load 3
67. THUNDER PLAINS CONF 2014 @isntitvacant tracking values We track values using a stack. load x subtract load 3 Value<x> push 1
68. THUNDER PLAINS CONF 2014 @isntitvacant tracking values We track values using a stack. load x subtract load 3 Value<x> Value<3> push 1
69. THUNDER PLAINS CONF 2014 @isntitvacant tracking values We track values using a stack. load x subtract load 3 Value<x> Value<3> pop 2, push 1
70. THUNDER PLAINS CONF 2014 @isntitvacant tracking values We track values using a stack. load x subtract load 3 Value<x-3> pop 2, push 1
71. THUNDER PLAINS CONF 2014 @isntitvacant tracking values names Values are only half of the battle. ! We also care about names.
72. THUNDER PLAINS CONF 2014 @isntitvacant tracking values names Names are variable names and property names. ! An object is a collection of names. A scope is an object whose names represent variables.
73. THUNDER PLAINS CONF 2014 @isntitvacant tracking values names Operations can determine whether a name is pushed onto the stack, or a value. x = x + 3 This is called an LValue.
74. THUNDER PLAINS CONF 2014 @isntitvacant tracking values names x = x + 3
75. THUNDER PLAINS CONF 2014 @isntitvacant tracking values names x = x + 3 get x Name<x>
76. THUNDER PLAINS CONF 2014 @isntitvacant tracking values names x = x + 3 load x Value<x> get x Name<x>
77. THUNDER PLAINS CONF 2014 @isntitvacant tracking values names x = x + 3 load x load 3 Value<x> Value<3> get x Name<x>
78. THUNDER PLAINS CONF 2014 @isntitvacant tracking values names x = x + 3 load x add load 3 Value<x+3> get x Name<x>
79. THUNDER PLAINS CONF 2014 @isntitvacant tracking values names x = x + 3 load x add load 3 get x Value<x+3> store
80. THUNDER PLAINS CONF 2014 @isntitvacant tracking values names Values only exist for as long as at least one name points to them. ! When we write JS, we grow and prune the object graph using names.
81. THUNDER PLAINS CONF 2014 @isntitvacant branches
82. THUNDER PLAINS CONF 2014 @isntitvacant branches Branching logic presents a problem: ! A value could be X or Y, depending on the branch taken!
83. THUNDER PLAINS CONF 2014 @isntitvacant branches x = 3 if (Math.random() > 0.5) { x = "hi" y = x + ' world' } What is x's type? What is y's?
84. THUNDER PLAINS CONF 2014 @isntitvacant branches solution: ! * inject a proxy into the scope chain. * wrap names and values that are accessed from outside of scope * when a value changes, split it
85. THUNDER PLAINS CONF 2014 @isntitvacant branches after that point: ! * accesses inside the branch get the updated name+value. * accesses outside the branch get an Either object.
86. THUNDER PLAINS CONF 2014 @isntitvacant branches x = 3 if (Math.random() > 0.5) { x = "hi" y = x + ' world' } x = Either<Number, String> y = Either<Undefined, String>
87. THUNDER PLAINS CONF 2014 @isntitvacant demo time! github.com/chrisdickinson/escontrol.git npm.im/escontrol
