Custom Views for Profit and Pleasure (Big Android BBQ)

All about custom Views and their uses.

Extended and revised from the original talk given in the Twin Cities.

Transcript

1. Custom Views for Profit and Pleasure October 18, 2014 Dan Lew
2. Custom Views (as viewed by me, years ago) Image source: http://goo.gl/JLdYHW
3. Framework Views are huge! View Lines View 20,992 TextView 9,477 ImageView 1,423 ViewGroup 7,285 LinearLayout 1,931 RelativeLayout 1,822 AdapterView 1,212 AbsListView 7,314 ListView 3,905 (Data as of API 21)
4. Too Many Methods! Category Methods Creation Constructors onFinishInflate() Layout onMeasure() onLayout() Drawing onSizeChanged() onDraw() Event processing onKeyDown() onKeyUp() onTrackballEvent() onTouchEvent() Focus onFocusChanged() onWindowFocusChanged() Attaching onAttachedToWindow() onDetachedFromWindow() onWindowVisibilityChanged()
5. Library Views != Custom Views
6. Why custom Views?
7. • View reuse
8. • View reuse • Encapsulation
9. • View reuse • Encapsulation • Compound Views
10. • View reuse • Encapsulation • Compound Views • XML styling <net.danlew.app.FontTextView          android:layout_width="wrap_content"          android:layout_height="wrap_content"          app:font="comicSans"  />   ! <net.danlew.app.FontTextView          android:layout_width="wrap_content"          android:layout_height="wrap_content"          app:font="papyrus"  />
11. • View reuse • Encapsulation • Compound Views • XML styling • Custom drawing
12. • View reuse • Encapsulation • Compound Views • XML styling • Custom drawing • Performance
13. • View reuse • Encapsulation • Compound Views • XML styling • Custom drawing • Performance • Awesomeness
14. A Simple Custom View
15. Step 1: Subclass public  class  CustomView  extends  View  {   ! ! ! }
16. Step 2: Constructor public  class  CustomView  extends  View  {          public  CustomView(Context  context)  {                  super(context);          }   }
17. Step 3: Add CustomView  customView  =  new  CustomView(context);   viewGroup.addView(customView);
18. You’re done!
19. UserView Our brave illustrative warrior
20. Without Custom Views
21. Without Custom Views <LinearLayout          android:layout_width="wrap_content"          android:layout_height="wrap_content"          android:gravity="center"          android:orientation="vertical">   !        <ImageView                  android:id="@+id/icon"                  android:layout_width="128dp"                  android:layout_height="128dp"  />   !        <TextView                  android:id="@+id/name"                  android:layout_width="wrap_content"                  android:layout_height="wrap_content"                  android:layout_marginTop="4dp"                  android:textSize="22sp"  />   ! </LinearLayout>
22. Without Custom Views View  userView  =  LayoutInflater.from(context)          .inflate(R.layout.user_view,  parent,  false);   ! TextView  nameView  =  (TextView)  view.findViewById(R.id.name);   nameView.setText(user.getName());   ! ImageView  iconView  =  (ImageView)  view.findViewById(R.id.icon);   iconView.setImageResource(user.getIcon());
23. Compound Views public  class  UserView  extends  LinearLayout  {   !        private  ImageView  mIconView;          private  TextView  mNameView;   !        public  UserView(Context  context)  {                  super(context);   !                setOrientation(LinearLayout.VERTICAL);                  setGravity(Gravity.CENTER);   !                LayoutInflater.from(context).inflate(R.layout.user_view_merge,  this);                  mIconView  =  (ImageView)  findViewById(R.id.icon);                  mNameView  =  (TextView)  findViewById(R.id.name);          }   !        public  void  setIcon(int  drawable)  {                  mIconView.setImageResource(drawable);          }   !        public  void  setName(CharSequence  name)  {                  mNameView.setText(name);          }   }
24. Compound Views <merge>   !      <ImageView                  android:id="@+id/icon"                  android:layout_width="128dp"                  android:layout_height="128dp"  />   !        <TextView                  android:id="@+id/name"                  android:layout_width="wrap_content"                  android:layout_height="wrap_content"                  android:layout_marginTop="4dp"                  android:textSize="22sp"  />   ! </merge>
25. Compound Views UserView  userView  =  new  UserView(context);   userView.setName(user.getName());   userView.setIcon(user.getIcon());
26. Encapsulation public  class  UserView  extends  LinearLayout  {   !        /*  ...same  code  as  before...  */       !        public  void  bind(User  user)  {                  mIconView.setImageResource(user.getIcon());                  mNameView.setText(user.getName());          }   }
27. Encapsulation UserView  userView  =  new  UserView(this);   userView.bind(user);
28. XML Styling
29. XML Styling <resources>          <declare-­‐styleable  name="UserView">                  <attr  name="tint"  format="color"  />          </declare-­‐styleable>   </resources>
30. XML Styling <net.danlew.customviews.view.UserView          xmlns:android="http://schemas.android.com/apk/res/android"          xmlns:app="http://schemas.android.com/apk/res-­‐auto"          android:layout_width="wrap_content"          android:layout_height="wrap_content"          app:tint="#500F"  />
31. Reading Styles in Code public  class  UserView  extends  LinearLayout  {   !        public  UserView(Context  context,  AttributeSet  attrs)  {                  super(context,  attrs);   !                /*  ...Same  constructor  code  as  before...  */   !                TypedArray  ta  =  context.obtainStyledAttributes(attrs,                            R.styleable.UserView);                  setTint(ta.getColor(R.styleable.UserView_tint,                          Color.TRANSPARENT));                  ta.recycle();          }   !        public  void  setTint(int  color)  {                  mIconView.setColorFilter(color);          }   }
32. Note on Constructors • Code constructor: !        public  View(Context  context)   • XML constructor: !        public  View(Context  context,  AttributeSet  attrs)   • XML w/ styled defaults (rarely necessary): !        public  View(Context  context,  AttributeSet  attrs,  int  defStyleAttr)          public  View(Context  context,  AttributeSet  attrs,  int  defStyleAttr,                                          int  defStyleRes)
33. Code + XML Constructors public  class  UserView  extends  LinearLayout  {   !        public  UserView(Context  context)  {                  this(context,  null);          }   !        public  UserView(Context  context,  AttributeSet  attrs)  {                  super(context,  attrs);   !                LayoutInflater.from(context).inflate(R.layout.user_view_merge,  this);   !                //  Etc...          }   }
34. Custom Drawing
35. Custom Drawing public  class  CircleView  extends  View  {   !        @Override          protected  void  onDraw(Canvas  canvas)  {                  Paint  paint  =  new  Paint();   !                /*                        ...Configure  paint  here  to  draw  icon...                      ...yadda  yadda  yadda...                  */   !                int  radius  =  getWidth()  /  2;                  canvas.drawCircle(radius,  radius,  radius,  paint);          }   } yadda: http://goo.gl/W8d17V
36. Advanced Practices • Measure / Layout • Saving state • Touch events • Custom animations
37. Measurement vs. Layout
38. onMeasure() View size
39. onLayout() Child View location/size
40. Measurement and Layout Pro-Tip Don’t bother! (most of the time)
41. onMeasure() • onMeasure() signature ! ! void  onMeasure(int  widthMeasureSpec,  int  heightMeasureSpec)   • measureSpec - packed integer ! int  widthMode  =  MeasureSpec.getMode(widthMeasureSpec);   int  widthSize  =  MeasureSpec.getSize(widthMeasureSpec);   int  heightMode  =  MeasureSpec.getMode(heightMeasureSpec);   int  heightSize  =  MeasureSpec.getSize(heightMeasureSpec);
42. Measure Modes • MeasureSpec.EXACTLY - Must be that size • MeasureSpec.AT_MOST - Maximum width • MeasureSpec.UNDEFINED - Ideal width
43. onMeasure() protected  void  onMeasure(int  widthMeasureSpec,  int  heightMeasureSpec)  {          int  widthMode  =  MeasureSpec.getMode(widthMeasureSpec);          int  widthSize  =  MeasureSpec.getSize(widthMeasureSpec);   !        int  width;          if  (widthMode  ==  MeasureSpec.EXACTLY)  {                  width  =  widthSize;          }          else  {                  int  desiredWidth  =  500;  //  Whatever  calculation  you  want   !                if  (widthMode  ==  MeasureSpec.AT_MOST)  {                          width  =  Math.min(desiredWidth,  widthSize);                  }                  else  {                          width  =  desiredWidth;                  }          }   !        //  ...to  be  continued...   }
44. onMeasure() @Override   protected  void  onMeasure(int  widthMeasureSpec,                  int  heightMeasureSpec)  {          int  width;          int  height;   !        //  ...Calculate  width  and  height...   !        setMeasuredDimension(width,  height);   }
45. onLayout() • Seriously, don’t bother! • For each child, call: child.layout()
46. onLayout() @Override   protected  void  onLayout(boolean  changed,  int  l,  int  t,                  int  r,  int  b)  {   !        for  (int  a  =  0;  a  <  getChildCount();  a++)  {                  View  child  =  getChildAt(a);   !                //  ...Calculate  left,  top,  right,  bottom…                  //  (This  should  be  easy,  right?)   !                child.layout(left,  top,  right,  bottom);          }   ! }
47. Detecting Size Changes • Update config based on size • onLayout() • onSizeChanged()
48. Saving State • Encapsulate state in Views • onSaveInstanceState() / onRestoreInstanceState() • Uses Parcelables • Parcelables - harder (but fast) • Bundles - easy (but a bit slower)
49. Saving State private  String  mValue;   ! @Override   protected  Parcelable  onSaveInstanceState()  {          Bundle  bundle  =  new  Bundle();          bundle.putString("Key",  mValue);          return  bundle;   }   ! @Override   protected  void  onRestoreInstanceState(Parcelable  state)  {          Bundle  bundle  =  (Bundle)  state;          mValue  =  bundle.getString("Key");   }
50. Parent State • View parent has state, too! • Must wrap/unwrap parent state • Still simple with Bundles
51. Parent State @Override   protected  Parcelable  onSaveInstanceState()  {          Bundle  bundle  =  new  Bundle();          bundle.putParcelable("SuperState",  super.onSaveInstanceState());          //  ...Put  whatever  you  want  in  the  Bundle...          return  bundle;   }   ! @Override   protected  void  onRestoreInstanceState(Parcelable  state)  {          Bundle  bundle  =  (Bundle)  state;          super.onRestoreInstanceState(bundle.getParcelable("SuperState"));          //  ...Restore  whatever  you  put  into  the  Bundle...   }
52. Touch Events • Hard mode: onTouchEvent() • Easy mode: GestureDetector • Handles complex logic (e.g. touch slop) • If you want to know everything, Dave Smith Talk: http://goo.gl/CtzHaN
53. GestureDetector • Step 1: Create OnGestureListener ! ! private  OnGestureListener  mListener  =  new  SimpleOnGestureListener()  {   !        @Override          public  boolean  onDoubleTap(MotionEvent  e)  {                  Log.i("Tag",  "Double  tap  detected!");                  return  true;          }   ! };
54. GestureDetector • Step 2: Create GestureDetector ! ! public  class  CustomView  extends  View  {   !        private  GestureDetector  mGestureDetector;   !        public  CustomView(Context  context,  AttributeSet  attrs)  {                  super(context,  attrs);                  mGestureDetector  =  new  GestureDetector(context,  mListener);          }   ! }
55. GestureDetector • Step 3: Hook up GestureDetector in onTouchEvent() ! ! public  class  CustomView  extends  View  {   !        //  ...Previous  code...   !        @Override          public  boolean  onTouchEvent(MotionEvent  event)  {                  return  mGestureDetector.onTouchEvent(event)                          ||  super.onTouchEvent(event);          }   ! }
56. Custom Animation
57. Custom Draw Property public  class  ColorView  extends  View  {   !        private  int  mColor;   !        @Override          protected  void  onDraw(Canvas  canvas)  {                  canvas.drawColor(mColor);          }   }
58. What I Want //  Animate  the  alpha   ObjectAnimator.ofFloat(myView,  "alpha",  1.0f).start();   ! //  Change  color  as  it  fades  in   ObjectAnimator.ofInt(myView,  "color",  Color.RED).start();
59. Property Setter/Getter public  class  ColorView  extends  View  {   !        private  int  mColor;   !        public  int  getColor()  {                  return  mColor;          }   !        public  void  setColor(int  color)  {                  mColor  =  color;                  invalidate();          }   !        @Override          protected  void  onDraw(Canvas  canvas)  {                  canvas.drawColor(mColor);          }   }
60. Invalidate vs. Layout • invalidate() - View needs to redraw contents • requestLayout() - View needs to change its size • Rubbish for animation • Animation talk: http://goo.gl/uwRBso • …By yours truly, Dan Lew
61. One downside…
62. …no custom View composition
63. Avoid Custom Views • …when hooks exist already: !        view.setOnClickListener(new  OnClickListener()  {  ...  });   • …when you could just use a custom Drawable: !        imageView.setImageDrawable(new  CustomDrawable());   See “Mastering Android drawables”: http://goo.gl/ENfzW6 • …when Google is doing tricky stuff (e.g. widget tinting in appcompat)
64. Summary • Custom Views can be simple! • Encapsulating logic makes your code simpler. • Custom Views can help you fine tune your app. • …But don’t go crazy with them.
65. Thank you! • Samples: https://github.com/dlew/android-custom- views-sample • http://danlew.net/ • @danlew42 • +DanielLew
