Building a Task Queue System with GenStage, Ecto, and PostgreSQL

Most applications have background jobs that require managing. While a basic queue implementation is simple to write, it could riddle your system with tight coupling, and straddle the developers with multiple nearly-duplicate implementations.

In this talk, I will explain our design constraints for such a task queue system, and present an implementation, taking into account Elixir’s strengths in concurrency, state management, and node clustering. I will also examine the performance characteristics of such an implementation.

Transcript

1. Building a Task Queue
 with GenStage, Ecto & PostgreSQL Evadne Wu Faria Education Group ev@radi.ws; twitter.com/evadne; github.com/evadne revision date 17 April 2018
2. Outline Use Cases Basic Scheduling Concepts Designing Task Systems Regulating Resource Use Monitoring Task Systems Scaling Task Systems Future State
3. Expected Benefits You will have a generic understanding of how to design Tasks and Executors, with focus on their use within Web applications. You will receive some anecdotal evidence on performance and operational characteristics of particular solutions or components, that you may use. You will see some code snippets that may be of use, but things that are more or less standard will not be repeated in this deck.
4. 1 Use Cases
5. Our Use Cases Ingest Documents and send them out for pre-processing ➤ Another service takes the Conversion Requests and feeds results back asynchronously Import Documents and Annotations from external services ➤ Migrations, done in batches Broadcast Events regarding newly created Annotations and Comments ➤ To live user sessions, and Services that have subscribed for these Events …and many other uses for Job Queues
6. My Team Commercial ➤ Embeddable Document Previews & Annotation for Web Applications ➤ Coursework Collection System with Deep Content Introspection ➤ System operations for things we built (exposed as “Managed Services”) ➤ Other Java, Ruby, C pixie dust as required Non-Commercial ➤ Various OSS Pull Requests and Projects
7. 2 Basic Scheduling Concepts
8. Task Deadlines Type If Missed Applicable? Soft e.g. Send Emails ☹ People unhappy Yes Firm e.g. Compute Balances ☹ Results useless Yes Hard e.g. Guide Missiles Very bad things No
9. Task Scheduling: Approaches Type Scheduling Efficiency Schedule Driven Hardcoded N/A Time Sharing % of CPU Time Slice Depending on # of
 Context Switches Priority Driven By Task Priority 70% – 100%
10. Task Scheduling Approaches Clock-Driven: based on hardcoded schedules Processor-Sharing: Based on preemptive time-boxes Priority-Driven: based on priorities ➤ Priorities determined by programmer (Fixed Priority) ➤ Priorities determined dynamically by the program (Dynamic Priority)
11. Clock-Driven All tasks are arranged on a schedule by the programmer Scheduler runs tasks, and sleeps in between Not adaptive and there are no good ways to recover from faults ➤ Potentially solved by implementing watchdog process
12. Time Sharing (Processor-Sharing) Each task is given a certain fraction of time slices to execute ➤ Quite similar to preemptive multi-tasking. ➤ However context-switching is not zero-cost. ➤ The smaller time slices are, the more time is spent context-switching
13. Priority Driven Each task is given a priority. ➤ Highest priority task runs. Dynamic Priority Example ➤ Earliest Deadline First (EDF): task with least time left to run first. Fixed Priority Examples ➤ Rate-Monotonic (RM): Tasks with smallest period first. ➤ Deadline-Monotonic (DM): Tasks with closest deadline first.
14. Task Scheduling: In Practice Aspect Non-Web Web Slowdowns Taken seriously. Systems reworked. #YOLO (Probably no SLA). Breaches Taken seriously. Avoid lawsuits. Apologise on Twitter. Validation Check all tasks run and completed by deadline. Check if app feels snappy on dev laptop.
15. Trickling Down of Robustness Observation: We operate in a world with drastically higher tolerance for faults, and drastically lower cost of recovering from errors. ➤ Hug Ops works when there is no loss of human life involved ➤ Our worst case scenario is mere inconvenience or embarrassment Hypothesis: This should make it quite easy to do an acceptable job. ➤ We can therefore aim for a well done job.
16. Old vs. New World Mindset Aspect Old World New World Place On-Premises mostly capex Cloud mostly opex Capacity Mostly Fixed not without costs Mostly Elastic to a certain point Intervention Optimise Code try to fit code in servers Autoscale get more servers to run code
17. Old vs. New World Mindset Cheap and on-demand compute makes most problems solvable with money. ➤ Solution caters to the “rest of us” with a reasonable amount of resources. Externalities of poor software architecture and performance are greatly deferred. ➤ Once painfully expensive at an early stage, these problems are now deferred further ➤ They are almost invisible for more use cases that previously required larger investment. Conclusion: We are now freely able to achieve greater scale. ➤ Caveat: until it is no longer feasible.
18. 3 Designing Task Systems
19. 3 Designing Task Systems a Classifying and Designing Tasks
20. Basic Classification of Tasks Type Example Can Parallelise? One-Off Unordered Send Email Easily One-Off Serial Publish Changes By Entity Periodic (Batch) Rubbish Removal Probably
21. One-Off Unordered Tasks Tasks either do not have side effects, or are idempotent. ➤ Validity not coupled to state. ➤ Failures can be retried without extensive eligibility checks. ➤ Good candidate for first attempts. Tasks do not need to be executed in-order. ➤ Easily parallelised.
22. One-Off Serial Tasks Tasks may have side effects or build upon each other. ➤ May require ordered execution. ➤ Retrying a single task out-of-order may cause issues. Not easily parallelised, but partially amenable to partitioning. ➤ Perhaps by unit of absolute isolation, e.g. Customer Account. ➤ Probably the same unit of isolation used in multi-tenant applications.
23. Periodic Tasks Often operate on a large number of entities at once. ➤ May not be feasible to identify the underlying entities ahead-of-time. ➤ May be too expensive to enqueue one-off tasks (due to context switching costs). ➤ May require all-or-nothing among the entire batch. Probably parallelised by batch. ➤ Depending on whether partial completion is acceptable. ➤ Depending on expected rollback behaviour as well.
24. Other Considerations Cancellation: can a task be cancelled in the future? ➤ These tasks may need to be One-Off Ordered. Repetition: should a task repeat itself? ➤ Repetitive One-Off Tasks can probably be simplified, and re-implemented as Periodic. Retrying: should a task be re-run if it fails the first time? ➤ What happens if retries never succeeded?
25. 3 Designing Task Systems B Creating One-Off Tasks
26. Creating One-Off Tasks Approach Scalability Consistency Robustness Application after transaction commit ☠ Application within transaction Database with trigger function
27. One-Off Tasks: No Transaction Exactly what happens if you store jobs outside your RDBMS: ➤ Changes committed to database from application. ➤ Job enqueued to queue from application. You can lose jobs to unhandled crashes ➤ Could mitigate with nonces and tight retries. ➤ Could sacrifice best case latency to delay processing. ➤ These are ugly workarounds at most, and should be designed away.
28. One-Off Tasks: No Transaction Example: Insert a Job outside of a Transaction def MyApp.Web.DocumentController do def create(conn, params) do with {:ok, document} <- Document.ingest(params) do spawn(&(DocumentProcessor.perform(document))) end end end
29. One-Off Tasks: With Transaction Implies that jobs are stored in the same RDBMS as the changes. ➤ Either use Repo.multi or custom code in Repo.transaction. Easy to copy and paste, but very difficult to simplify. ➤ Copy and paste is not good, as it can introduce unwanted errors. ➤ More unwanted complexity does not solve the issue of code duplication.
30. One-Off Tasks: With Transaction Example: Insert a Job within a Transaction Repo.transaction(fn -> with {:ok, document} <- Document.process(params) do Repo.insert(%DocumentJob{document_id: document.id}) end end)
31. One-Off Tasks: From Application Avoid creating One-Off Tasks from application code. ➤ No matter whether tasks are enqueued within the same transaction or not. ➤ They can be missed if direct changes were made to the database. ➤ They might be missed if the application crashes. Do not treat databases as exclusive, untyped, dumb data stores ➤ People will try to integrate your databases directly, regardless of design intent. ➤ Try to encode essential constraints directly into the database.
32. One-Off Tasks: From Database Use a trigger function, which writes to the jobs table upon mutation. ➤ Good for jobs that can not be inferred, or requires retrying. ➤ See Transactionally Staged Job Drain, by @brandur. Guaranteed to run in most cases, but can be skipped if needed. ➤ SET session_replication_role = replica;
33. One-Off Tasks: From Database Example 1: Remove Remote Objects CREATE FUNCTION jobs.enqueue_remove_objects() RETURNS trigger AS $$ BEGIN INSERT INTO jobs.remove_objects (id, object_reference) VALUES (OLD.id, OLD.object_reference); RETURN OLD; END; $$ LANGUAGE plpgsql;
34. One-Off Tasks: From Database Example 1: Remove Remote Objects CREATE TRIGGER enqueue_cleanup_job AFTER DELETE ON documents FOR EACH ROW WHEN old.object_reference IS NOT NULL EXECUTE PROCEDURE jobs.enqueue_remove_objects();
35. One-Off Tasks: From Database Example 2: Issue Charges CREATE FUNCTION jobs.enqueue_process_charges() RETURNS trigger AS $$ BEGIN INSERT INTO jobs.process_charges (id) VALUES (OLD.id); RETURN OLD; END; $$ LANGUAGE plpgsql;
36. One-Off Tasks: From Database Example 2: Issue Charges CREATE TRIGGER enqueue_process_charges AFTER UPDATE ON purchases FOR EACH ROW WHEN NEW.status = 'processing' EXECUTE PROCEDURE jobs.enqueue_process_charges();
37. 3 Designing Task Systems C Designing the Executor
38. Deciding the Concurrency Model Single Executor, Single Priority ➤ Each Consumer takes work; easiest implementation Single Executor, Multiple Priorities ➤ Can be controlled by Weighted Polling of Tasks ➤ Can also be controlled by latency, to avoid lower priority tasks not being run under load ➤ Possibly a better fit than Weighted Polling in some cases
39. Deciding the Concurrency Model Multiple Executor, each having Single Priority ➤ Each Executor takes work; basically many copies of Single Priority Executors. Multiple Executor, each having Multiple Priorities ➤ A bit more tricky
40. Levels of Sharing: Overview Approach Complexity Isolation Contention Robustness No Sharing task tables split by type High High Low OK Share Everything all tasks in same table Low Low High Meh
41. Levels of Sharing: No Sharing Each Task type has its own dedicated Executor. ➤ Isolated and easy to monitor, as any metric would already be split by relevant dimensions. ➤ Each Executor can be scaled independently, as needed. Each One-Off Task can be represented precisely. ➤ Arguments represented with correct, dedicated types (or domains). ➤ Eliminates runtime casting to/from JSONB, JSON or HStore representations.
42. Levels of Sharing: Share Everything All tasks held in the same table ➤ Need to be conscious of page churn ➤ Any schema change or full vacuum blocks all tasks No typing support from database ➤ All task arguments will need to be serialised to/from JSONB, etc. ➤ Application upgrades that cause task definition changes are now harder to do
43. Proposed Architecture One GenStage pipeline for each Executor ➤ Multiple Executors, each Single Priority ➤ Clear and defined data flow Pipelines to dynamically scale, as required ➤ Orchestrator to observe queue lengths and sojourn time ➤ Each Pipeline to scale according to suggestions made by Flow Orchestrator ➤ Allows offloading of decisions that can not be made with only local information
44. Proposed Architecture Each Pipeline to expose a load determination function ➤ Returns total amount of workload (normalised) and latency ➤ Also return expected reduction in latency per workload processed Orchestrator to start with weighted presets and re-adjust over time ➤ Initial preset determined by relative priority constant, set at startup ➤ Takes in observations from Pipelines ➤ Tells each Pipeline what the target buffer size (normalised) should be
45. 3 Designing Task Systems D Populating the Executor
46. Fulfilling Initial Demand Each GenStage Consumer start with a fixed demand size ➤ Usually scales with number of cores in the system, by default. Initial demand can easily be fulfilled (in full, in part, or not at all) by queries ➤ Select up to N jobs (with obligatory SKIP LOCKED) then update their states. Unmet demand needs to be fulfilled at a later time when work is available ➤ Producer must be made aware of additional work that has become available.
47. Fulfilling Unmet Demand Unmet Demand must be fulfilled at a later time when more work is available. ➤ Schedule a tick after N seconds. ➤ On tick, run a query to grab up to J jobs. ➤ If J jobs were returned, fulfil all demand and re-schedule a tick after N seconds. ➤ Otherwise, fulfil any demand outstanding and re-schedule a tick after N + P seconds. Jobs that were created between Polling Intervals will be processed late ➤ Worst case latency = MAX(processing time) + MAX(jitter) + polling interval
48. Async Notifications Postgres exposes LISTEN and NOTIFY commands. ➤ Can be used to make the Producer aware of incoming jobs between Polling Intervals ➤ Supported in Postgrex. Asynchronous Notifications are exposed as (Topic, Payload) tuples. ➤ It can also be used in lieu of polling for new jobs. ➤ Payload can be useful as well.
49. Async Notifications: Example Aspect 1: Trigger Function, which sends Notifications with the NEW row in Payload CREATE FUNCTION new_job_notify() RETURNS trigger AS $$ BEGIN PERFORM pg_notify('new_job', row_to_json(NEW)::text); RETURN NEW; END; $$ LANGUAGE plpgsql;
50. Async Notifications: Example Aspect 2: Trigger Definition, which calls the Trigger Function on Job creation CREATE TRIGGER notify AFTER INSERT ON jobs FOR EACH ROW WHEN NEW.status = 'pending' EXECUTE PROCEDURE new_job_notify();
51. Async Notifications: Example Aspect 3: Listening for Notifications with Postgrex config = Repo.config |> Keyword.merge(pool_size: 1) channel = "new_jobs" {:ok, pid} = Postgrex.Notifications.start_link(config) {:ok, ref} = Postgrex.Notifications.listen(pid, channel) receive do {:notification, connection_pid, ref, channel, payload} -> # ? end
52. Async Notifications: Caveats PostgreSQL uses a single global queue for all Async Notifications. ➤ See src/backend/commands/async.c for implementation details. ➤ Single global queue, backed by disk, with hot pages mapped in memory. All listening backends get all notifications and filter out the ones they don’t want ➤ Performance degrades as listeners are added. Maximum payload size is capped by SLRU (Simple Least-Recently Used) page size ➤ Probably don’t want to send large messages in payloads this way, anyway.
53. Async Notifications: Caveats Example: Testing Maximum Notification Payload Size evadne=# select pg_notify('test', string_agg(substr('a', 1), '')) from generate_series(1, 7999); pg_notify ----------- (1 row)
54. Async Notifications: Caveats Example: Testing Maximum Notification Payload Size evadne=# select pg_notify('test', string_agg(substr('a', 1), '')) from generate_series(1, 8000); ERROR: payload string too long
55. 3 Designing Task Systems E Handling Errors & Timeouts
56. Errors, Timeouts, etc Things can go wrong ➤ Usually we want to capture stack traces on error (exceptions) ➤ We may also want to see what the Task is waiting on, causing the timeout Task timeouts can be implemented with Task.yield ➤ On timeout, grab stack trace, kill Task, and have the Task retried later Stack traces available from Process.info ➤ Many other pieces of information also available
57. Errors, Timeouts, etc Aspect 1: Starting a linked Task which runs and monitors the actual Task Task.start_link(fn -> task = Task.Supervisor.async_nolink(TaskSupervisor, &(run(event))) result = Task.yield(task, @timeout) handle_result(event, task, result) end)
58. Errors, Timeouts, etc Aspect 2: Utility function to get Current Stacktrace for a given PID defp stacktrace_for(pid) do {_, entries} = Process.info(pid, :current_stacktrace) Enum.map(entries, &Exception.format_stacktrace_entry/1) end
59. Consumer & Runner Supervision Worker Task runs actual code Runner Task monitors worker Producer generates events Consumer processes events Runner Task monitors worker Task Supervisor holds worker tasks Worker Task runs actual code
60. 3 Designing Task Systems F Maintaining Periodic Tasks
61. Periodic Tasks: Characteristics They frequently depend on driving queries ➤ They impact a large amount of entities ➤ They may also generate a large amount of data They have looser deadlines, and their results may be all-or-nothing in nature ➤ Faster availability of partial results may or may not be welcomed
62. Periodic Tasks: Examples Example 1: Remove Rubbish ➤ Clean up soft-deleted objects past their retention periods Example 2: Generate Reports ➤ Month end reporting, CARR rollups, etc. Example 3: Restart Services ➤ Hopefully not necessary
63. Periodic Tasks: Considerations Handling Schedule Overruns ➤ Kill and restart task ➤ Postpone next period Thundering Herd Problem ➤ Causes of hourly peaks, especially observable when running at scale ➤ Either vary start time within period, or vary wait time between runs
64. Periodic Tasks: Implementation GenServer manages periodic task GenServer manages periodic task Worker Task runs actual code Supervisor Task Supervisor holds worker tasks Worker Task runs actual code Runner Task spawns/monitors worker Runner Task spawns/monitors worker
65. 4 Regulating Resource Use
66. Regulation: Contentious Things Resource Type Exhaustion Consequences Host Resources CPU, Memory, Disk Service Degradation heightened latency and/or error rate Service Rate Limits first- or third-party Service Degradation and/or Monetary charges Upstream Capacity first-party, expensive processes Service Degradation and/or Monetary charges Users’ Patience e.g. notifications/day Unhappy Users and/or churn (long-term)
67. Regulation: Approaches The proper approach depends on whether level of resource usage is dynamic ➤ Sometimes this can be inferred before running the task ➤ Pre-processing of a file will require the same space on disk as the HTTP request indicates ➤ May need to spend cycles teasing the origin for appropriate boundaries Sometimes the Pipeline does not need changing ➤ Pooling results is enough in these cases ➤ Example: 1-Click Ordering holds the cart in read/write state, rollup email of updates, etc.
68. Regulation: External Processes External OS Processes can be limited using OS tools ➤ Use nice to control prioritisation ➤ Use cpulimit to pin a process to a particular CPU ➤ Use Control Groups to impose hard limit on resources Some External Processes naturally degrade over time ➤ Memory leaks due to bugs or natural fragmentation ➤ Recycled every X runs or when memory usage exceeds expectations
69. Regulation: Discrete Resources Some Resources are discrete ➤ Number of concurrent database connections ➤ Number of concurrent sessions to other systems ➤ … They can be regulated by use of a Pool and/or a Regulator ➤ Each Resource is represented by one Process ➤ The Process is actually used to communicate with the Resource
70. Regulation: Non-Discrete Resources Some Resources are not discrete ➤ CPU time, memory, disk… They can still be regulated in the same manner ➤ Each Resource is segmented into X smaller chunks, each represented by one Process. ➤ The Process is checked out, but just as a placeholder. This is a Bin Packing Problem in disguise ➤ Find most efficient way to pack workloads together, minimising overall latency.
71. Regulation: With poolboy Worker Consumer Worker Worker Consumer Consumer poolboy
72. Regulation: With sbroker Resource Consumer Resource Resource Consumer Consumer sbroker
73. Regulation: With sbroker Resource Consumer Resource Resource Consumer sbroker
74. 5 Monitoring Task Systems
75. Monitoring: Motivation Identify Executors that are experiencing delays. ➤ The number of tasks in each queue is a poor proxy metric. ➤ Queue Length, Latency and Sojourn Time are different aspects although inter-related. Need to be able to do both just-in-time monitoring and post-facto analysis. ➤ Some patterns only emerge over time and can advise preemptive up/down scaling. Auto-scaling depends on good metrics. ➤ Good monitoring begets good metrics.
76. Monitoring: Suggested Approach Report from every Task Executor. ➤ One time series per (Task Executor, Host) tuple. ➤ Can be further aggregated in upstream monitoring systems. Use Exometer. ➤ :histogram type for task duration and latency; :spiral type for task count. Push metrics to CloudWatch and/or other Monitoring Solutions, like WombatOAM. ➤ Allows visibility of Infrastructure and Application in the same place.
77. Monitoring: Suggested Key Metrics Metrics to Watch Intently: ➤ Latency ➤ Queue Time ➤ Processing Time ➤ Error Rates ➤ Number of Retries ➤ Throughput probably matters
78. 6 Scaling Task Systems
79. 6 Scaling Task Systems a Scaling Elixir
80. Scaling Elixir: Motivation Desired Attribute Protection Against Expected Benefits Resiliency Host Failures Application not dying
 when a single server dies. Scalability Resource Exhaustion Application not limited to resources of a single server. Consistent QoS Large Customers Single customer unable to degrade service for all. Easy Deployment Mutable Hosts Higher quality of life with Rolling Updates.
81. Scaling Elixir: Aspects Preparing Infrastructure ➤ Needs to allow intra-BEAM networking (as well as epmd). Establishing Cluster ➤ Needs to be dynamic if auto-scaling is in place, may require service discovery. Distributing Work ➤ Easy for One-Off Unordered tasks but a bit more fiddly for the rest. ➤ However it is eminently possible.
82. Scaling Elixir: Infrastructure Prep Allow traffic to flow correctly ➤ Probably best to leave epmd in place. ➤ Ports used by BEAM intra-node communication configurable. ➤ Assuming EC2 deployment, this is easy to do. ➤ Assuming ECS deployment, awsvpc task network mode attaches ENI to each container.
83. Scaling Elixir: Clustering Establish Peers ➤ The gossip-based mechanism in libcluster can be used. ➤ Many other ways to get an idea of which nodes to connect to. ➤ Can also write a custom strategy to query ECS for running jobs in service. ➤ Also possible via Route 53 private hosted zones. ➤ Select the approach which is suitable for your organisation.
84. Scaling Elixir: Distributing Work Expected Benefits ➤ Server A runs tasks for Customers A, B, C; server B runs tasks for Customers D, E, etc, and they do not require any manual configuration when nodes were added or removed. Sample Scenarios ➤ You want to have more than one server without doing the same jobs twice. ➤ You have One-Off Ordered Tasks that can’t be split between 2 Executors. ➤ You have other forms contention which requires even allocation of Periodic Tasks.
85. Scaling Elixir: Distributing Work Work can be scheduled by abusing (repurposing) Swarm. ➤ Standing on the shoulders of @bitwalker. ➤ In short, Swarm distributes processed based on a consistent hashing algorithm. ➤ Each name is hashed to a particular segment in the ring. ➤ Each node is responsible for parts of the ring, which is partitioned across all nodes. ➤ Each server runs the relevant processes accordingly. ➤ These processes do not necessarily need to do any work, their presence is sufficient.
86. Scaling Elixir: Distributing Work Node Startup Sequence ➤ Each node is to run the whole GenStage pipeline ➤ Producers pull nothing. ➤ Producers are to be told which Accounts to pull down work for. ➤ Each node is assumed to be in an Erlang Cluster, which requires Clustering to be done. ➤ Each node boots up, starts, gains membership in Swarm and wait. ➤ Each node also runs the Enforcer (custom process)
87. Scaling Elixir: Distributing Work The Enforcer ➤ Solves the cold boot problem in case of system hard down: there will be no existing state ➤ Tells Swarm which Workers are supposed to be running ➤ The missing Workers are then created by Swarm somewhere in the cluster. ➤ Essentially runs SELECT id FROM accounts; in a loop
88. Scaling Elixir: Distributing Work Aspect 1: Enforcer polls for Accounts that should have Workers periodically defp poll(interval) do Enum.each(account_ids(), &(enforce(:account, &1))) to_interval = round(:rand.uniform * interval + interval) Process.send_after(self(), :poll, to_interval) end
89. Scaling Elixir: Distributing Work Aspect 2: Enforcer queries Swarm status to determine whether to start a Worker defp enforce(scope, value) do name = {scope, value} case Swarm.whereis_name(name) do :undefined -> register(name) _ -> :ok end end
90. Scaling Elixir: Distributing Work Aspect 3: Enforcer starts a Worker somewhere in the cluster via Swarm defp register(name) do supervisor = MyApp.Swarm.Supervisor case Swarm.register_name(name, supervisor, :register, [name]) do {:ok, _} -> :ok {:error, {:already_registered, _}} -> :ok end end
91. Scaling Elixir: Distributing Work The Swarm Supervisor ➤ Holds all Swarm Workers ➤ Supervisor with :simple_one_for_one strategy
92. Scaling Elixir: Distributing Work Example: The Swarm Supervisor is a Simple One-For-One Supervisor defmodule MyApp.Swarm.Supervisor do def init(_) do [worker(MyApp.Swarm.Worker, [], restart: :temporary)] |> supervise([strategy: :simple_one_for_one]) end def register(name), do: Supervisor.start_child(__MODULE__, [name]) end
93. Scaling Elixir: Distributing Work The Swarm Worker ➤ Represents an Account; purely a conduit to various Producers ➤ Adds the Account to all Producers during init. ➤ Removes the Account from all Producers during handoff.
94. Scaling Elixir: Distributing Work Example: The Swarm Worker monitors and messages the Producer on init def init({scope, id}) do target_name = target(scope) target_ref = Process.monitor(target_name) _ = GenServer.cast(target_name, {:add, scope, id}) Process.send_after(self(), :join, 0) {:ok, {scope, id, target_ref}} end
95. Scaling Elixir: Distributing Work Example: The Swarm Worker calls Swarm.join asynchronously def handle_info(:join, {scope, _, _} = state) do Swarm.join(scope, self()) {:noreply, state} end
96. Scaling Elixir: Distributing Work Example: The Swarm Worker handles Handoffs def handle_call({:swarm, :begin_handoff}, _from, {scope, id, ref}) do _ = GenServer.cast(target(scope), {:remove, scope, id}) {:reply, :restart, {scope, id, ref}} end def handle_call({:swarm, :end_handoff}, state), do: {:noreply, state}
97. Scaling Elixir: Distributing Work Example: The Swarm Worker does no conflict resolution whatsoever def handle_cast({:swarm, :resolve_conflict, _delay}, state), do: {:noreply, state}
98. Scaling Elixir: Distributing Work Example: The Swarm Worker prefers to die quickly def handle_info({:swarm, :die}, state), do: {:stop, :shutdown, state} def handle_info({:DOWN, ref, :process, _, _}, {_, _, ref} = state), do: {:stop, :shutdown, state} def handle_info({:EXIT, _, _}, _), do: Process.exit(self(), :kill)
99. Scaling Elixir: Distributing Work The Producers ➤ Each Producer holds a MapSet which contains Account IDs. ➤ The MapSet determines which Tasks the Producer pulls down. ➤ So far so good.
100. 6 Scaling Task Systems B Scaling Postgres
101. Scaling Postgres: Motivation Vertical Scaling Still Limited ➤ There are still global bottlenecks that get worse with usage ➤ Notifications are dealt with globally for example The Maximum Concentration Ratio is fixed ➤ Number of Application Servers ÷ Number of Database Servers ➤ Essentially a Single Point of Failure, even if clustered with failover ➤ Jesus Nut of Software Engineering
102. Scaling Postgres: Motivation Effort put into Horizontal Scaling pays dividends ➤ Allows isolated A/B testing of new database engines ➤ Obviates global outages that accompany even a minor version bump ➤ Postgres only guarantees on-disk representation stability among minor versions ➤ Obviates even partial outages if data is quietly migrated ahead of time ➤ Allows adding additional resources dedicated for specific Accounts ➤ One of many ways of achieving Enterprise-tier SLA
103. Scaling Postgres: Ready Solutions Project Type Approach xDB MMR EnterpriseDB Commercial free trial available Multi-Master Postgres-XL NTT OSS Multi-Master pg_partman keithf4 OSS Partitioning Postrgres 10 native partitioning OSS Partitioning
104. Scaling Postgres: Single Repo Postgres upstream server Repo Postgres upstream server Postgres upstream server Postgres view with rules
105. Scaling Postgres: Single Repo All tables are actually views, backed by foreign tables ➤ Parent table can be built with a view that uses UNION + INSTEAD OF update/delete rules. ➤ Caution: FDWs forward per session, so N sessions per shard, with M shards = M*N connections from master instance. Other Problems (~Postgres 10) ➤ Views are not really backed by shards and the solution is really wonky. ➤ DDL operations (migrations) are not run against shards so this is even more wonky.
106. Scaling Postgres: Single Repo The Future of Postgres Sharding [March 2018] ➤ Shard management will be added to the partitioning syntax,
 which was added in Postgres 10. Suggestion ➤ Buy some time until native support for shard management is added to Postgres. ➤ Wait until RDS also supports it and the right number of support cases have been filed. ➤ Don’t try to hide the fact that data is now stored across shards.
107. Scaling Postgres: Many Repos Postgres upstream server Application Postgres upstream server Postgres upstream server Repo Repo Repo
108. Scaling Postgres: Many Repos Each repo corresponds to a separate Postgres instance. ➤ You can still tie them together with FDWs. ➤ Useful if you want a single access point for debugging purposes. You may want to also add a “master” repo for data that is global in nature ➤ Each shard can still refer to it via FDWs. ➤ Useful if you have globally defined truths that unfortunately differ, but not per-customer. ➤ Per-customer data can always be stored in their own shards.
109. 6 Scaling Task Systems c Scaling Infrastructure
110. Scaling Infrastructure: Motivation Servers can scale to fit workload ➤ Not only up but also down (to save money) Sometimes an extra server buys weeks of engineering time for rework ➤ Outages are not only annoying, they have technical and human cost ➤ Fixes made in the heat of the moment are seldom good
111. Scaling Infrastructure: Approach Scaling should be based on Host Resource utilisation ➤ Utilising Upstream Capacity will also raise utilisation of Host Resources. Scaling should not be based on Executor metrics ➤ Retain alarms on Executor metrics but don‘t scale based on it. Scaling should not be used without Resource Use Regulation ➤ Calling a service from more servers can leave more concurrent sessions opened.
112. Scaling Infrastructure: Suggestion Base Scaling Decisions on Saturation ➤ i.e. how many normalised hosts remain free (total free % ÷ total %) Suggested Approach ➤ Assuming ECS deployment, adjust Desired Count on the Service based on this metric. ➤ Target Tracking Scaling Policy + Metric Math, as needed. ➤ Assuming EC2 target type, adjust Desired Count for ASG or Spot Fleet. ➤ Based on Reservation %.
113. 7 Future State
114. 8 References
115. Reference: Elixir/Erlang Code Alex Kira & co.: exq Mike Buhot & co.: ecto_job Basho: sidejob Michael Shapiro & co.: honeydew James Fish & co.: sbroker Bernard Duggan: Exometer to CloudWatch (gist)
116. Reference: Articles @brandur: Transactionally Staged Job Drains in Postgres @brandur: Implementing Stripe-like Idempotency Keys in Postgres Chris Hanks: Turning PostgreSQL into a queue serving 10,000 jobs per second Craig Ringer: What is SKIP LOCKED for in PostgreSQL 9.5? Robert Haas: Did I Say 32 Cores? How about 64? Michael Schaefermeyer: Monitoring Phoenix Hamidreza Soleimani: Erlang Scheduler Details
117. Reference: Other References Paper: Real-Time Scheduling Analysis (PDF) Paper: Errata: A New Algorithm for Scheduling Periodic, Real-Time Tasks (PDF) Postgres Wiki: Built-In Sharding, Distributed Transaction Manager, Table Partitioning Postgres Mailing List: Transactions Involving Multiple Postgres Foreign Servers Bruce Momjian: The Future of PostgreSQL Sharding (PDF; Video)
