Alerting with Time Series

Transcript

1. Alerting with Time Series github.com/fabxc @fabxc Fabian Reinartz, CoreOS
2. Stream of <timestamp, value> pairs associated with an identifier http_requests_total{job="nginx",instance="1.2.3.4:80",path="/status",status="200"} 1348 @ 1480502384 1899 @ 1480502389 2023 @ 1480502394 http_requests_total{job="nginx",instance="1.2.3.1:80",path="/settings",status="201"} http_requests_total{job="nginx",instance="1.2.3.5:80",path="/",status="500"} ... Time Series
3. Stream of <timestamp, value> pairs associated with an identifier sum by(path) (rate(http_requests_total{job="nginx"}[5m])) {path="/status",status="200"} 32.13 @ 1480502384 {path="/status",status="500"} 19.133 @ 1480502394 {path="/profile",status="200"} 44.52 @ 1480502389 Time Series
4. Prometheus Targets Service Discovery (Kubernetes, AWS, Consul, custom...) Grafana HTTP API UI
5. A lot of traffic to monitor Monitoring traffic should not be proportional to user traffic
6. A lot of targets to monitor A single host can run hundreds of machines/procs/containers/...
7. Targets constantly change Deployments, scaling up, scaling down, and rescheduling
8. Need a fleet-wide view What’s my 99th percentile request latency across all frontends?
9. Drill-down for investigation Which pod/node/... has turned unhealthy? How and why?
10. Monitor all levels, with the same system Query and correlate metrics across the stack
11. Translate that to Meaningful Alerting
12. Anomaly Detection Automated Alert Correlation Self-Healing Machine Learning
13. Anomaly Detection If you are actually monitoring at scale, something will always correlate. Huge efforts to eliminate huge number of false positives. Huge chance to introduce false negatives.
14. Prometheus Alerts != = current state desired state alerts
15. Symptom-based pages Urgent issues – Does it hurt your user? system user dependency dependency dependency dependency
16. Latency Four Golden Signals system user dependency dependency dependency dependency
17. Traffic Four Golden Signals system user dependency dependency dependency dependency
18. Errors Four Golden Signals system user dependency dependency dependency dependency
19. Cause-based warnings Helpful context, non-urgent problems system user dependency dependency dependency dependency
20. Saturation / Capacity Four Golden Signals system user dependency dependency dependency dependency
21. etcd_has_leader{job="etcd", instance="A"} 0 etcd_has_leader{job="etcd", instance="B"} 0 etcd_has_leader{job="etcd", instance="C"} 1
22. Prometheus Alerts ALERT <alert name> IF <PromQL vector expression> FOR <duration> LABELS { ... } ANNOTATIONS { ... } <elem1> <val1> <elem2> <val2> <elem3> <val3> ... Each result entry is one alert:
23. requests_total{instance="web-1", path="/index", method="GET"} 8913435 requests_total{instance="web-1", path="/index", method="POST"} 34845 requests_total{instance="web-3", path="/api/profile", method="GET"} 654118 requests_total{instance="web-2", path="/api/profile", method="GET"} 774540 … request_errors_total{instance="web-1", path="/index", method="GET"} 84513 request_errors_total{instance="web-1", path="/index", method="POST"} 434 request_errors_total{instance="web-3", path="/api/profile", method="GET"} 6562 request_errors_total{instance="web-2", path="/api/profile", method="GET"} 3571 …
24. Prometheus Alerts ALERT EtcdNoLeader IF etcd_has_leader == 0 FOR 1m LABELS { severity=”page” } {job=”etcd”,instance=”A”} 0.0 {job=”etcd”,instance=”B”} 0.0 {job=”etcd”,alertname=”EtcdNoLeader”,severity=”page”,instance=”A”} {job=”etcd”,alertname=”EtcdNoLeader”,severity=”page”,instance=”B”}
25. ALERT HighErrorRate IF sum(rate(request_errors_total[5m])) > 500 {} 534
26. ALERT HighErrorRate IF sum(rate(request_errors_total[5m])) > 500 {} 534 WRONG Absolute threshold alerting rule needs constant tuning as traffic changes
27. ALERT HighErrorRate IF sum(rate(request_errors_total[5m])) > 500 {} 534 traffic changes over days
28. ALERT HighErrorRate IF sum(rate(request_errors_total[5m])) > 500 {} 534 traffic changes over months
29. ALERT HighErrorRate IF sum(rate(request_errors_total[5m])) > 500 {} 534 traffic when you release awesome feature X
30. ALERT HighErrorRate IF sum(rate(request_errors_total[5m])) / sum(rate(requests_total[5m])) > 0.01 {} 1.8354
31. ALERT HighErrorRate IF sum(rate(request_errors_total[5m])) / sum(rate(requests_total[5m])) > 0.01 {} 1.8354
32. ALERT HighErrorRate IF sum(rate(request_errors_total[5m])) / sum(rate(requests_total[5m])) > 0.01 {} 1.8354 WRONG No dimensionality in result loss of detail, signal cancelation
33. ALERT HighErrorRate IF sum(rate(request_errors_total[5m])) / sum(rate(requests_total[5m])) > 0.01 {} 1.8354 high error / low traffic low error / high traffic total sum
34. ALERT HighErrorRate IF sum by(instance, path) (rate(request_errors_total[5m])) / sum by(instance, path) (rate(requests_total[5m])) > 0.01 {instance=”web-2”, path=”/api/comments”} 0.02435 {instance=”web-1”, path=”/api/comments”} 0.01055 {instance=”web-2”, path=”/api/profile”} 0.34124
35. ALERT HighErrorRate IF sum by(instance, path) (rate(request_errors_total[5m])) / sum by(instance, path) (rate(requests_total[5m])) > 0.01 {instance=”web-2”, path=”/api/v1/comments”} 0.022435 ... WRONG Wrong dimensions aggregates away dimensions of fault-tolerance
36. ALERT HighErrorRate IF sum by(instance, path) (rate(request_errors_total[5m])) / sum by(instance, path) (rate(requests_total[5m])) > 0.01 {instance=”web-2”, path=”/api/v1/comments”} 0.02435 ... instance 1 instance 2..1000
37. ALERT HighErrorRate IF sum without(instance) (rate(request_errors_total[5m])) / sum without(instance) (rate(requests_total[5m])) > 0.01 {method=”GET”, path=”/api/v1/comments”} 0.02435 {method=”POST”, path=”/api/v1/comments”} 0.015 {method=”POST”, path=”/api/v1/profile”} 0.34124
38. ALERT DiskWillFillIn4Hours IF predict_linear(node_filesystem_free{job='node'}[1h], 4*3600) < 0 FOR 5m ... 0 now -1h +4h
39. ALERT DiskWillFillIn4Hours IF predict_linear(node_filesystem_free{job='node'}[1h], 4*3600) < 0 FOR 5m ANNOTATIONS { summary = “device filling up”, description = “{{$labels.device}} mounted on {{$labels.mountpoint}} on {{$labels.instance}} will fill up within 4 hours.” }
40. Alertmanager Aggregate, deduplicate, and route alerts
41. Prometheus Targets Service Discovery (Kubernetes, AWS, Consul, custom...) Alertmanager Email, Slack, PagerDuty, OpsGenie, ...
42. Alerting Rule Alerting Rule Alerting Rule Alerting Rule ... 04:11 hey, HighLatency, service=”X”, zone=”eu-west”, path=/user/profile, method=GET 04:11 hey, HighLatency, service=”X”, zone=”eu-west”, path=/user/settings, method=GET 04:11 hey, HighLatency, service=”X”, zone=”eu-west”, path=/user/settings, method=GET 04:11 hey, HighErrorRate, service=”X”, zone=”eu-west”, path=/user/settings, method=POST 04:12 hey, HighErrorRate, service=”X”, zone=”eu-west”, path=/user/profile, method=GET 04:13 hey, HighLatency, service=”X”, zone=”eu-west”, path=/index, method=POST 04:13 hey, CacheServerSlow, service=”X”, zone=”eu-west”, path=/user/profile, method=POST . . . 04:15 hey, HighErrorRate, service=”X”, zone=”eu-west”, path=/comments, method=GET 04:15 hey, HighErrorRate, service=”X”, zone=”eu-west”, path=/user/profile, method=POST
43. Alerting Rule Alerting Rule Alerting Rule Alerting Rule ... Alert Manager Chat JIRA PagerDuty ... You have 15 alerts for Service X in zone eu-west 3x HighLatency 10x HighErrorRate 2x CacheServerSlow Individual alerts: ...
44. Inhibition {alertname=”LatencyHigh”, severity=”page”, ..., zone=”eu-west”} ... {alertname=”LatencyHigh”, severity=”page”, ..., zone=”eu-west”} {alertname=”ErrorsHigh”, severity=”page”, ..., zone=”eu-west”} ... {alertname=”ServiceDown”, severity=”page”, ..., zone=”eu-west”} {alertname=”DatacenterOnFire”, severity=”huge-page”, zone=”eu-west”} if active, mute everything else in same zone
45. Anomaly Detection
46. Practical Example 1 job:requests:rate5m = sum by(job) (rate(requests_total[5m])) job:requests:holt_winters_rate1h = holt_winters( job:requests:rate5m[1h], 0.6, 0.4 )
47. Practical Example 1 ALERT AbnormalTraffic IF abs( job:requests:rate5m - job:requests:holt_winters_rate1h offset 7d ) > 0.2 * job:request_rate:holt_winters_rate1h offset 7d FOR 10m ...
48. Practical Example 2 instance:latency_seconds:mean5m > on (job) group_left() ( avg by (job)(instance:latency_seconds:mean5m) + on (job) 2 * stddev by (job)(instance:latency_seconds:mean5m) )
49. Practical Example 2 ( instance:latency_seconds:mean5m > on (job) group_left() ( avg by (job)(instance:latency_seconds:mean5m) + on (job) 2 * stddev by (job)(instance:latency_seconds:mean5m) ) ) > on (job) group_left() 1.2 * avg by (job)(instance:latency_seconds:mean5m)
50. Practical Example 2 ( instance:latency_seconds:mean5m > on (job) group_left() ( avg by (job)(instance:latency_seconds:mean5m) + on (job) 2 * stddev by (job)(instance:latency_seconds:mean5m) ) ) > on (job) group_left() 1.2 * avg by (job)(instance:latency_seconds:mean5m) and on (job) avg by (job)(instance:latency_seconds_count:rate5m) > 1
51. Self Healing
52. Prom Alert manager wh node scrape notify alert action
53. Conclusion - Symptom-based pages + cause based warnings provide good coverage and insight into service availability - Design alerts that are adaptive to change, preserve as many dimensions as possible, aggregate away dimensions of fault tolerance - Use linear prediction for capacity planning and saturation detection - Advanced alerting expressions allow for well-scoped and practical anomaly detection - Raw alerts are not meant for human consumption - The Alertmanager aggregates, silences, and routes groups of alerts as meaningful notifications
