Shooting a “Glance” at Android App Widgets

The Android community adopts Jetpack Compose more and more every day. But what about our app widgets?

In this talk, we will see how we can use “Glance” library to create app widgets. We will briefly talk about how to create “glanceable” UI using composables. We will also see how to use actions for user interactions and create widgets with different size modes. Moreover, we will touch upon the internal state of the Glance app widget and how to update this state outside of the widget process. Finally, we will discuss how to apply theming and use dynamic colors in the app widgets.

Transcript

1. FATIH GIRIS ANDROID LEAD @DNB SHOOTING A “GLANCE” AT ANDROID APP WIDGETS @fatih_grs
2. APP WIDGETS https://developer.android.com/guide/topics/appwidgets App widgets o ffi cial documentation
3. APP WIDGETS https://developer.android.com/guide/topics/appwidgets App widget processing fl ow
4. • What is Glance? • Actions • Size modes • State • Theming AGENDA
5. • Library to create App Widgets & Wear Tiles • Uses compose runtime GLANCE
6. Convert COMPOSABLES REMOTEVIEWS
7. Convert GLANCEABLES REMOTEVIEWS
8. Any Composable inside Glance is called Glanceable.
9. • Library to create App Widgets & Wear Tiles • Uses compose runtime • Converts Composables to RemoteViews & Tiles • Android 12 widget improvements • Backward compatible (API 23) GLANCE
10. SHOW ME THE CODE!
11. GLANCE class MyAppWidgetReceiver : GlanceAppWidgetReceiver() { override val glanceAppWidget: GlanceAppWidget get() = MyAppWidget() }
12. GLANCE class MyAppWidgetReceiver : GlanceAppWidgetReceiver() { override val glanceAppWidget: GlanceAppWidget get() = MyAppWidget() } AppWidgetReceiver
13. GLANCE class MyAppWidgetReceiver : GlanceAppWidgetReceiver() { override val glanceAppWidget: GlanceAppWidget get() = MyAppWidget() } BroadcastReceiver
14. GLANCE class MyAppWidget : GlanceAppWidget() { @Composable override fun Content() { // Write your App Widget composable } }
15. GLANCE class MyAppWidget : GlanceAppWidget() { @Composable override fun Content() { Text( text = "Hello from a Glance widget!" ) } }
16. GLANCE
17. GLANCE class MyAppWidget : GlanceAppWidget() { @Composable override fun Content() { Text( text = "Hello from a Glance widget!" ) } }
18. GLANCE class MyAppWidget : GlanceAppWidget() { @Composable override fun Content() { androidx.compose.material.Text( text = "Hello from a Glance widget!" ) } }
19. GLANCE class MyAppWidget : GlanceAppWidget() { @Composable override fun Content() { androidx.glance.text.Text( text = "Hello from a Glance widget!" ) } }
20. GLANCE class MyAppWidget : GlanceAppWidget() { @Composable override fun Content() { androidx.glance.text.Text( modifier = androidx.compose.ui.Modifier, text = "Hello from a Glance widget!" ) } }
21. GLANCE class MyAppWidget : GlanceAppWidget() { @Composable override fun Content() { androidx.glance.text.Text( modifier = androidx.glance.GlanceModifier, text = "Hello from a Glance widget!" ) } }
22. ACTIONS
23. • Use actions in response to user interactions • 4 types of actions - actionStartActivity - actionSendBroadcast - actionStartService - actionRunCallback ACTIONS
24. ACTIONS class MyAppWidget : GlanceAppWidget() { @Composable override fun Content() { Text( modifier = GlanceModifier.clickable( actionStartActivity<MyActivity>() ), text = "Hello from a Glance widget!" ) } }
25. ACTIONS class MyAppWidget : GlanceAppWidget() { @Composable override fun Content() { Text( modifier = GlanceModifier.clickable( actionStartActivity<MyActivity>() ), text = "Hello from a Glance widget!" ) } }
26. ACTIONS
27. ACTIONS class MyAppWidget : GlanceAppWidget() { @Composable override fun Content() { Text( modifier = GlanceModifier.clickable( actionStartActivity<MyActivity>() ), text = "Hello from a Glance widget!" ) } }
28. ACTIONS class MyAppWidget : GlanceAppWidget() { @Composable override fun Content() { Text( modifier = GlanceModifier.clickable( actionRunCallback<MyCustomActionCallback>() ), text = "Hello from a Glance widget!" ) } }
29. GLANCE WIDGETS ARE STATEFUL 🤩
30. • Provides a composition local LocalState • Uses DataStore under the hood • Default state de fi nition supports: Boolean, Int, Long, Float, String, Set • Get the current state using currentState() STATE
31. LET’S MAKE A CLICK COUNTER 🧮
32. STATE
33. STATE class MyAppWidget : GlanceAppWidget() { // The key for the data store private val COUNTER_KEY = intPreferencesKey("MY_COUNTER_KEY") // The key for the custom action parameter private val COUNTER_ACTION_PARAMETER_KEY = ActionParameters.Key<Int>( “COUNTER_INCREMENT_ACTION” ) @Composable override fun Content() { // Get the saved number of clicks from the current state val numberOfClicks = currentState(key = COUNTER_KEY) ?: 0 Text( modifier = GlanceModifier.clickable( actionRunCallback<CounterIncrementActionCallback>( parameters = actionParametersOf( COUNTER_ACTION_PARAMETER_KEY to numberOfClicks + 1 ) ) ), text = numberOfClicks.toString() ) } }
34. STATE class MyAppWidget : GlanceAppWidget() { // The key for the data store private val COUNTER_KEY = intPreferencesKey("MY_COUNTER_KEY") // The key for the custom action parameter private val COUNTER_ACTION_PARAMETER_KEY = ActionParameters.Key<Int>( “COUNTER_INCREMENT_ACTION” ) @Composable override fun Content() { // Get the saved number of clicks from the current state val numberOfClicks = currentState(key = COUNTER_KEY) ?: 0 Text( modifier = GlanceModifier.clickable( actionRunCallback<CounterIncrementActionCallback>( parameters = actionParametersOf(
35. class MyAppWidget : GlanceAppWidget() { // The key for the data store private val COUNTER_KEY = intPreferencesKey("MY_COUNTER_KEY") // The key for the custom action parameter private val COUNTER_ACTION_PARAMETER_KEY = ActionParameters.Key<Int>( “COUNTER_INCREMENT_ACTION” ) @Composable override fun Content() { // Get the saved number of clicks from the current state val numberOfClicks = currentState(key = COUNTER_KEY) ?: 0 Text( modifier = GlanceModifier.clickable( actionRunCallback<CounterIncrementActionCallback>( parameters = actionParametersOf( COUNTER_ACTION_PARAMETER_KEY to numberOfClicks + 1 ) ) ), text = numberOfClicks.toString() STATE
36. // The key for the custom action parameter private val COUNTER_ACTION_PARAMETER_KEY = ActionParameters.Key<Int>( “COUNTER_INCREMENT_ACTION” ) @Composable override fun Content() { // Get the saved number of clicks from the current state val numberOfClicks = currentState(key = COUNTER_KEY) ?: 0 Text( modifier = GlanceModifier.clickable( actionRunCallback<CounterIncrementActionCallback>( parameters = actionParametersOf( COUNTER_ACTION_PARAMETER_KEY to numberOfClicks + 1 ) ) ), text = numberOfClicks.toString() ) } } STATE
37. // The key for the custom action parameter private val COUNTER_ACTION_PARAMETER_KEY = ActionParameters.Key<Int>( “COUNTER_INCREMENT_ACTION” ) @Composable override fun Content() { // Get the saved number of clicks from the current state val numberOfClicks = currentState(key = COUNTER_KEY) ?: 0 Text( modifier = GlanceModifier.clickable( actionRunCallback<CounterIncrementActionCallback>( parameters = actionParametersOf( COUNTER_ACTION_PARAMETER_KEY to numberOfClicks + 1 ) ) ), text = numberOfClicks.toString() ) } } STATE
38. private val COUNTER_ACTION_PARAMETER_KEY = ActionParameters.Key<Int>( “COUNTER_INCREMENT_ACTION” ) @Composable override fun Content() { // Get the saved number of clicks from the current state val numberOfClicks = currentState(key = COUNTER_KEY) ?: 0 Text( modifier = GlanceModifier.clickable( actionRunCallback<CounterIncrementActionCallback>( parameters = actionParametersOf( COUNTER_ACTION_PARAMETER_KEY to numberOfClicks + 1 ) ) ), text = numberOfClicks.toString() ) } } STATE
39. “COUNTER_INCREMENT_ACTION” ) @Composable override fun Content() { // Get the saved number of clicks from the current state val numberOfClicks = currentState(key = COUNTER_KEY) ?: 0 Text( modifier = GlanceModifier.clickable( actionRunCallback<CounterIncrementActionCallback>( parameters = actionParametersOf( COUNTER_ACTION_PARAMETER_KEY to numberOfClicks + 1 ) ) ), text = numberOfClicks.toString() ) } } STATE
40. “COUNTER_INCREMENT_ACTION” ) @Composable override fun Content() { // Get the saved number of clicks from the current state val numberOfClicks = currentState(key = COUNTER_KEY) ?: 0 Text( modifier = GlanceModifier.clickable( actionRunCallback<CounterIncrementActionCallback>( parameters = actionParametersOf( COUNTER_ACTION_PARAMETER_KEY to numberOfClicks + 1 ) ) ), text = numberOfClicks.toString() ) } } STATE
41. @Composable override fun Content() { // Get the saved number of clicks from the current state val numberOfClicks = currentState(key = COUNTER_KEY) ?: 0 Text( modifier = GlanceModifier.clickable( actionRunCallback<CounterIncrementActionCallback>( parameters = actionParametersOf( COUNTER_ACTION_PARAMETER_KEY to numberOfClicks + 1 ) ) ), text = numberOfClicks.toString() ) } } STATE
42. STATE class CounterIncrementActionCallback : ActionCallback { override suspend fun onRun( context: Context, glanceId: GlanceId, parameters: ActionParameters ) { // Get the incremented value from the parameters since // we are sending it from the composable val counter = parameters[MyAppWidget.COUNTER_ACTION_PARAMETER_KEY] ?: 0 // Save the counter into the data store updateAppWidgetState( context = context, definition = PreferencesGlanceStateDefinition, glanceId = glanceId ) { it.toMutablePreferences().apply { this[MyAppWidget.COUNTER_KEY] = counter } } // Need to update the widget as well in order // to invoke the content function again MyAppWidget().update(context, glanceId) } }
43. STATE class CounterIncrementActionCallback : ActionCallback { override suspend fun onRun( context: Context, glanceId: GlanceId, parameters: ActionParameters ) { // Get the incremented value from the parameters since // we are sending it from the composable val counter = parameters[MyAppWidget.COUNTER_ACTION_PARAMETER_KEY] ?: 0 // Save the counter into the data store updateAppWidgetState( context = context, definition = PreferencesGlanceStateDefinition, glanceId = glanceId ) { it.toMutablePreferences().apply { this[MyAppWidget.COUNTER_KEY] = counter
44. class CounterIncrementActionCallback : ActionCallback { override suspend fun onRun( context: Context, glanceId: GlanceId, parameters: ActionParameters ) { // Get the incremented value from the parameters since // we are sending it from the composable val counter = parameters[MyAppWidget.COUNTER_ACTION_PARAMETER_KEY] ?: 0 // Save the counter into the data store updateAppWidgetState( context = context, definition = PreferencesGlanceStateDefinition, glanceId = glanceId ) { it.toMutablePreferences().apply { this[MyAppWidget.COUNTER_KEY] = counter STATE
45. class CounterIncrementActionCallback : ActionCallback { override suspend fun onRun( context: Context, glanceId: GlanceId, parameters: ActionParameters ) { // Get the incremented value from the parameters since // we are sending it from the composable val counter = parameters[MyAppWidget.COUNTER_ACTION_PARAMETER_KEY] ?: 0 // Save the counter into the data store updateAppWidgetState( context = context, definition = PreferencesGlanceStateDefinition, glanceId = glanceId ) { it.toMutablePreferences().apply { this[MyAppWidget.COUNTER_KEY] = counter } } // Need to update the widget as well in order // to invoke the content function again STATE
46. context: Context, glanceId: GlanceId, parameters: ActionParameters ) { // Get the incremented value from the parameters since // we are sending it from the composable val counter = parameters[MyAppWidget.COUNTER_ACTION_PARAMETER_KEY] ?: 0 // Save the counter into the data store updateAppWidgetState( context = context, definition = PreferencesGlanceStateDefinition, glanceId = glanceId ) { it.toMutablePreferences().apply { this[MyAppWidget.COUNTER_KEY] = counter } } // Need to update the widget as well in order // to invoke the content function again MyAppWidget().update(context, glanceId) } } STATE
47. // Get the incremented value from the parameters since // we are sending it from the composable val counter = parameters[MyAppWidget.COUNTER_ACTION_PARAMETER_KEY] ?: 0 // Save the counter into the data store updateAppWidgetState( context = context, definition = PreferencesGlanceStateDefinition, glanceId = glanceId ) { it.toMutablePreferences().apply { this[MyAppWidget.COUNTER_KEY] = counter } } // Need to update the widget as well in order // to invoke the content function again MyAppWidget().update(context, glanceId) } } STATE
48. val counter = parameters[MyAppWidget.COUNTER_ACTION_PARAMETER_KEY] ?: 0 // Save the counter into the data store updateAppWidgetState( context = context, definition = PreferencesGlanceStateDefinition, glanceId = glanceId ) { it.toMutablePreferences().apply { this[MyAppWidget.COUNTER_KEY] = counter } } // Need to update the widget as well in order // to invoke the content function again MyAppWidget().update(context, glanceId) } } STATE
49. STATE
50. WHAT ABOUT THE SIZING?
51. • LocalSize to keep the size of a widget • 3 di ff erent size modes - SizeMode.Single - SizeMode.Exact - SizeMode.Responsive SIZING
52. SizeMode.Single • Content is called once with minimum size • LocalSize does not change
53. SizeMode.Single class MyAppWidget : GlanceAppWidget() { override val sizeMode: SizeMode get() = SizeMode.Single @Composable override fun Content() { Box { Text( text = "I am a using SizeMode.Single" + "Content will be called only once" + "${LocalSize.current}" ) } } }
54. SizeMode.Single class MyAppWidget : GlanceAppWidget() { override val sizeMode: SizeMode get() = SizeMode.Single @Composable override fun Content() { Box { Text( text = "I am a using SizeMode.Single" + "Content will be called only once" + "${LocalSize.current}" ) } } }
55. SizeMode.Single
56. SizeMode.Exact • Content is called every time size changes • LocalSize always has the latest size
57. SizeMode.Exact class MyAppWidget : GlanceAppWidget() { override val sizeMode: SizeMode get() = SizeMode.Exact @Composable override fun Content() { Box { Text( text = "I am a using SizeMode.Single" + "Content will be called only once" + "${LocalSize.current}" ) } } }
58. SizeMode.Exact class MyAppWidget : GlanceAppWidget() { override val sizeMode: SizeMode get() = SizeMode.Exact @Composable override fun Content() { Box { Text( text = "I am a using SizeMode.Single" + "Content will be called only once" + "${LocalSize.current}" ) } } }
59. SizeMode.Exact
60. NEED TO UPDATE THE WIDGET AFTER EVERY RESIZE?
61. SizeMode.Responsive • Content is called for the de fi ned sizes • LocalSize has one of the de fi ned sizes
62. SizeMode.Responsive class MyAppWidget : GlanceAppWidget() { companion object { // Responsive sizes val SMALL_BOX = DpSize(100.dp, 100.dp) val LARGE_BOX = DpSize(200.dp, 200.dp) } override val sizeMode: SizeMode get() = SizeMode.Responsive( setOf(SMALL_BOX, LARGE_BOX) ) @Composable override fun Content() { when (LocalSize.current) { SMALL_BOX -> SmallBox() LARGE_BOX -> LargeBox() } } }
63. SizeMode.Responsive class MyAppWidget : GlanceAppWidget() { companion object { // Responsive sizes val SMALL_BOX = DpSize(100.dp, 100.dp) val LARGE_BOX = DpSize(200.dp, 200.dp) } override val sizeMode: SizeMode get() = SizeMode.Responsive( setOf(SMALL_BOX, LARGE_BOX) ) @Composable override fun Content() { when (LocalSize.current) { SMALL_BOX -> SmallBox() LARGE_BOX -> LargeBox() } } }
64. SizeMode.Responsive class MyAppWidget : GlanceAppWidget() { companion object { // Responsive sizes val SMALL_BOX = DpSize(100.dp, 100.dp) val LARGE_BOX = DpSize(200.dp, 200.dp) } override val sizeMode: SizeMode get() = SizeMode.Responsive( setOf(SMALL_BOX, LARGE_BOX) ) @Composable override fun Content() { when (LocalSize.current) { SMALL_BOX -> SmallBox() LARGE_BOX -> LargeBox() } } }
65. SizeMode.Responsive class MyAppWidget : GlanceAppWidget() { companion object { // Responsive sizes val SMALL_BOX = DpSize(100.dp, 100.dp) val LARGE_BOX = DpSize(200.dp, 200.dp) } override val sizeMode: SizeMode get() = SizeMode.Responsive( setOf(SMALL_BOX, LARGE_BOX) ) @Composable override fun Content() { when (LocalSize.current) { SMALL_BOX -> SmallBox() LARGE_BOX -> LargeBox() } } }
66. SizeMode.Responsive
67. THEMING 🌈
68. • MaterialTheme THEMING
69. MaterialTheme
70. androidx.compose.material.MaterialTheme
71. • Not possible to use MaterialTheme ❌ THEMING
72. Starting from Android 12, we can use dynamic colors 🤩
73. THEMING Box( modifier = GlanceModifier .background( com.google.android.material.R.color.m3_sys_color_dynamic_dark_primary ), contentAlignment = Alignment.Center ) { Text(text = "🙈") }
74. THEMING Box( modifier = GlanceModifier .background( com.google.android.material.R.color.m3_sys_color_dynamic_dark_primary ), contentAlignment = Alignment.Center ) { Text(text = "🙈") }
75. THEMING The widget background using the dark dynamic color from the system color pallet
76. THEMING Box( modifier = GlanceModifier .background( com.google.android.material.R.color.m3_sys_color_dynamic_dark_primary ), contentAlignment = Alignment.Center ) { Text(text = "🙈") }
77. What about day & night con fi guration?
78. THEMING <resources> <color name=“dynamic_color_ref">@color/m3_sys_color_dynamic_light_primary</color> </resources> values/color.xml
79. THEMING <resources> <color name=“dynamic_color_ref">@color/m3_sys_color_dynamic_light_primary</color> </resources> values-v31/color.xml
80. THEMING <resources> <color name=“dynamic_color_ref”>@color/my_color</color> </resources> values/color.xml
81. THEMING <resources> <color name=“dynamic_color_ref”>@color/m3_sys_color_dynamic_dark_primary</color> </resources> values-night-v31/color.xml
82. THEMING Box( modifier = GlanceModifier .background(R.color.dynamic_color_ref), contentAlignment = Alignment.Center ) { Text(text = "🙈") }
83. THEMING Box( modifier = GlanceModifier .background(R.color.dynamic_color_ref), contentAlignment = Alignment.Center ) { Text(text = "🙈") }
84. THEMING Dynamic color reference in light mode Dynamic color reference in dark mode
85. • Not possible to use MaterialTheme ❌ • Dynamic colors THEMING
86. ColorProvider
87. ColorProvider Docs: “Provider of colors for a glance composable's attributes.”
88. ColorProvider FixedColorProvider ResourceColorProvider DayNightColorProvider
89. ColorProvider FixedColorProvider ResourceColorProvider DayNightColorProvider internal 🤔
90. ColorProvider function that provides day & night colors ColorProvider function
91. THEMING Box( modifier = GlanceModifier .background( ColorProvider( day = Color.White, night = Color.Yellow ) ), contentAlignment = Alignment.Center ) { Text(text = "🙈") }
92. THEMING Box( modifier = GlanceModifier .background( ColorProvider( day = Color.White, night = Color.Yellow ) ), contentAlignment = Alignment.Center ) { Text(text = "🙈") }
93. THEMING White background color in light mode Yellow background color in dark mode
94. • Not possible to use MaterialTheme ❌ • Dynamic colors • Use ColorProvider for day & night con fi guration THEMING
95. • Glance converts Composables to RemoteViews (and Tiles) • Not possible to use the composables from the app • Actions: • actionStartActivity • actionStartService • actionSendBroadcast • actionRunCallback • Size modes: Single, Exact and Responsive TL;DR
96. • currentState() provides the current state of the widget • Dynamic colors on Android 12 and above • ColorProvider()supports day & night colors • Remember that it’s still in alpha TL;DR
97. THANKS!
98. QUESTIONS @fatih_grs
