Design System Adventures in React - ReactJS Day 2024
Gabriele Petronella
October 25, 2024
Transcript
80 slides
-
Context "Are you't that Scala / TypeScript dude who likes
functional programming?" Sure, but I spent the last 4 years working on Design Systems! -
Pedigree • Co-founder and CTO @ buildo • Built two
design systems for Big Enterprise ™ • Built several others for smaller companies • Distilled that knowledge in Bento, a general purpose design system for the web -
Bento • Design System for the web • React +
TypeScript for the dev library • Figma for the design library • OSS + commercial support • https:/ /bento-ds.com -
✋ Raise your hand if you are familiar with the
term "design system" -
✋ Raise your hand if you could explain it to
a colleague -
A design system is a set of standards to manage
design at scale by reducing redundancy while creating a shared language and visual consistency across different pages and channels. -- Nielsen Norman Group -
Design System shopping list • Foundations • Components • UX
patterns • Governance • ...whatever works for your context -
Today Let's talk about the technical side of building a
Design System with React -
Topics • Vanilla Extract • Testing • Accessibility • One
weird TypeScript technique -
Vanilla Extract • CSS-in-TS library • CSS fully extracted at
build time (no runtime overhead) • Similar to CSS modules in spirit • Originally created by Seek for their own DS (Braid) • Successor of treat (https:/ /seek-oss.github.io/treat/) -
Why Vanilla Extract (in general)? • Static CSS generation •
Fewer moving parts, CSS integrates well with any stack • No runtime overhead • Seems more future proof, for example when it comes to SSR (see https:/ /github.com/reactwg/react-18/discussions/108) -
Why Vanilla Extract (in general)? • Editor tooling integration •
It's just TypeScript, no need for special plugins • Styles are TypeScript objects, imports just work -
Why Vanilla Extract (for Design Systems)? • Opinionated towards encapsulated
components • No child selectors allowed const list = style({ padding: 8, selectors: { "& > li": { // ! a style cannot target its children color: "red", }, }, }); -
Why Vanilla Extract (for Design Systems)? • Styles are objects
• Easy to manipulate and compose (example: https:/ /github.com/ buildo/bento-design-system/blob/main/packages/bento-design- system/src/Layout/Column.css.ts) -
Why Vanilla Extract (for Design Systems)? • Recipes API •
maps perfectly to how UI components are represented in a design tool -
export const buttonRecipe = recipe({ base: { borderRadius: 6, },
variants: { color: { neutral: { background: "whitesmoke" }, accent: { background: "slateblue" }, }, size: { medium: { padding: 16 }, large: { padding: 24 }, }, }, }); -
import { buttonRecipe } from "./button.css.ts"; type Props = {
color: "neutral" | "accent"; size: "medium" | "large"; children: ReactNode; }; function Button({ color, size, children }: Props) { return <button className={buttonRecipe({ color, size })}>{children}</button>; } -
Why Vanilla Extract (for Design Systems)? • Sprinkles API •
generate utility CSS classes • basically a roll-your-own Tailwind... • ...but with a nice API -
import { defineProperties, createSprinkles } from "@vanilla-extract/sprinkles"; const space =
{ none: 0, small: "4px", medium: "8px" /*...*/ }; const responsiveProperties = defineProperties({ conditions: { mobile: {}, tablet: { "@media": "screen and (min-width: 768px)" }, desktop: { "@media": "screen and (min-width: 1024px)" }, }, defaultCondition: "mobile", properties: { paddingTop: space, paddingBottom: space, // ... }, }); export const sprinkles = createSprinkles(responsiveProperties); -
type Props = { children: ReactNode } function Card({ children
}: Props) { const className = sprinkles({ paddingTop: 'medium' }); return ( <div className={className}> {children} </div> ); -
type Props = { children: ReactNode } function Card({ children
}: Props) { const className = sprinkles({ paddingTop: { desktop: 'large', tablet: 'medium', mobile: 'small' } }); return ( <div className={className}> {children} </div> ); -
Why Vanilla Extract (for Design Systems)? • Sprinkles API •
nice to expose foundations to consumers -
Accessibility • Accessibility is hard • Accessibility is important •
Accessibility is being regulated at the European level • 2025: all new apps must be accessible • 2030: all existing apps must be accessible -
Accessibility and Design Systems Design Systems are well positioned to
centralize and prevent some common accessibility issues. However: accessibility is ultimately a concern of the final product. -
Examples where Design Systems doesn't help much • Tab order
(can keyboard and screen reader users jump around the content effectively?) • Link purpose <!-- Bad --> Go to Google by clicking <a href="google.com">this link</a> <!-- Good --> Click here to <a href="google.com">go to Google</a> -
Examples where Design Systems clearly help • Color contrast •
Ensuring text is readable wrt its background and size • Operating via mouse, keyboard, touch, screen reader • Ensuring the interactions work across difference devices -
Examples where Design Systems clearly help • Focus management •
Ensuring the focus is always visible • Ensuring modal content does not let the focus escape • Form interactions • Ensuring labels/errors are linked to fields • Ensuring error state is not only a color -
Using TypeScript for a greater good // ❌ <IconButton size="{16}"
icon="{IconPencil}" /> // ^^^^^^^^ // Property 'label' is missing // ✅ <IconButton size="{16}" icon="{IconPencil}" label="Edit user" /> Here label is used for screen readers, but it's also useful for mouse users (hover tooltip). -
react-aria A library of React Hooks that provides accessible UI
primitives for your design system. Immensely useful for building accessible components. If you think you can do this from scratch: good luck! -
Examples: building a Button import { useButton } from "react-aria";
import { useRef } from "react"; function Button(props) { const ref = useRef(); const { buttonProps } = useButton(props, ref); const { children } = props; return ( <button {...buttonProps} ref={ref}> {children} </button> ); } -
Examples: focus management FocusScope is a utility to manage the
focus of its descendants. This is crucial to implement focus traps (e.g. modals) correctly. <FocusScope contain restoreFocus> <!-- Modal content goes here --> </FocusScope> -
Examples: building a number field Have you every tried to
create a number field supporting multiple languages and locale? Yeah, I have PTSD too... useNumberField to the rescue! Why not <input type="number">? Let's take a look -
• Support for internationalized number formatting and parsing including decimals,
percentages, currency values, and units • Support for the Latin, Arabic, and Han positional decimal numbering systems in over 30 locales • Automatically detects the numbering system used and supports parsing numbers not in the default numbering system for the locale • Support for multiple currency formats including symbol, code, and name in standard or accounting notation -
• Validates keyboard entry as the user types so that
only valid numeric input according to the locale and numbering system is accepted • Handles composed input from input method editors, e.g. Pinyin • Automatically selects an appropriate software keyboard for mobile according to the current platform and allowed values • Supports rounding to a configurable number of fraction digits -
• Support for clamping the value between a configurable minimum
and maximum, and snapping to a step value • Support for stepper buttons and arrow keys to increment and decrement the value according to the step value • Supports pressing and holding the stepper buttons to continuously increment or decrement • Handles floating point rounding errors when incrementing, decrementing, and snapping to step -
• Supports using the scroll wheel to increment and decrement
the value • Exposed to assistive technology as a text field with a custom localized role description using ARIA • Follows the spinbutton ARIA pattern • Works around bugs in VoiceOver with the spinbutton role • Uses an ARIA live region to ensure that value changes are announced • Support for description and error message help text linked to the input via ARIA -
react-aria components Pre-made components, built on top of react-aria hooks,
ready to be styled. import { Button } from "react-aria-components"; <Button onPress={() => alert("Hello world!")}>Press me</Button>; -
The styling can happen in multiple ways: • className •
style • public CSS API via classes (e.g. .react-aria-Button) -
Why do we write tests? • To ensure the code
works as expected? • Because a book told me so? • So that I can feel good about test coverage reports? -
Why do we write tests? To prevent bugs that the
user perceives Preventing bugs != testing the code -
Which kind of bugs? The most common type of bugs
for a UI library is visual bugs. So, we write snapshot tests using Jest Vitest, right? -
Why not snapshot test? You're still testing the code, hoping
a code change will affect the UI. This may or may not be true. • Code changes may not affect the UI • The snapshot may not catch UI changes that indirectly affect other components Can we do better? -
Why? In our experience the most frequent bugs in a
DS library manifest as visual bugs. Other bugs can arise, but this is are by far the most common ones. You want a lot of visual tests, think of it as the base of the pyramid. -
Chromatic • visual regression tool by the same company behind
Storybook • (unsurprisingly) based on Storybook • not free (149$/m for the Starter plan, billed by the snapshot) -
Why Chromatic • real browser snapshots • cross-browser support •
multiple viewport support • integration with GitHub PRs • works well for design review -
Testing ! Development • Storybook is a helpful tool for
development • With Chromatic, Storybook is used for testing and CI • Aligned incentives in keeping Storybook healthy and up-to-date -
What about other kinds of tests? • Storybook and Chromatic
also support interaction testing • Write tests for stories using Storybooks' play function • It uses the testing-library API • Chromatic runs them automatically and reports failures alongside visual tests -
Getting to a specific state export const CalendarOpen = {
// ... play: async () => { const button = screen.getByRole("button"); await waitFor(() => button.click()); }, }; -
Test assertions export const NonDefaultType = { args: { value:
"[email protected]" type: "email", }, play: async ({ canvasElement }) => { const textField = within(canvasElement).getByRole("textbox"); await expect(textField).toHaveAttribute("type", "email"); }, }; -
Root cause A string is a string ! <MyComponent label="Foo
foo foo" /> <MyComponent label={t('Whatever.submitButtonLabel')} /> -
Can we do better? function MyComponent({ label }: { label:
string }) { // ... } ⬇ function MyComponent({ label }: { label: LocalizedString }) { // ... } -
LocalizedString? This doesn't work: type LocalizedString = string; // transparent
type alias We need something "more" than string: type LocalizedString = string & ??? -
LocalizedString as a branded type type LocalizedString = string &
{ readonly __brand: unique symbol }; The type is string but also something more. -
LocalizedString as a branded type declare const normalString: string; declare
const label: LocalizedString; declare function giveMeAString(s: string); declare function giveMeALocalizedString(s: LocalizedString); giveMeAString(normalString); // OK giveMeAString(label); // OK giveMeALocalizedString(label); // OK giveMeALocalizedString(normalString); // Error -
Back to our component function MyComponent({ label }: { label:
LocalizedString }) { // ... } <MyComponent label="Woops, not localized, TypeScript complains" /> <MyComponent label={t('Whatever.submitButtonLabel')} /> -
How do we create a LocalizedString? Well... by casting! Isn't
casting bad? In general, yes. In this case, it's fine if confined to a single function. In practice you wrap the localization function of a library like react- i18next or react-intl, to change the return type to LocalizedString instead of string. -
Ok, but I don't want any of this! What if
I'm a library and I don't want to force this mechanism on my users? Ideal scenario: • the library accepts string by default • the consume can opt-in into stricter type-safety via LocalizedString -
Declaration merging interface Box { height: number; } interface Box
{ width: number; } same as interface Box { height: number; width: number; } -
Declaration merging cannot override members interface Box { height: number;
} interface Box { height: string; // ❌ Subsequent property declarations // must have the same type } -
Module augmentation Imagine mymodule exports a Box interface like: interface
Box { height: number; } We can "augment it" with a module augmentation: declare module "mymodule" { // module augmentation interface Box { // declaration merging width: number; } } -
One typical example declare module global { interface Window {
logPageView: () => void; } } -
Putting it all together In our library we define an
empty interface meant to be "merged": export interface TypeOverrides {} we then define the "base" types: interface BaseTypes { LocalizedString: string; } -
Putting it all together We derive our final types as
import { O } from "ts-toolbelt"; type ConfiguredTypes = O.Overwrite<BaseTypes, TypeOverrides>; // This is the type we use in our library export type LocalizedString = BaseTypes["LocalizedString"] & ConfiguredTypes["LocalizedString"]; // Our beloved stricter type export type StrictLocalizedString = string & { readonly __brand: unique symbol; }; -
Putting it all together Now a consumer of the library
can opt-in into stricter type-safety by augmenting the TypeOverrides interface: import { StrictLocalizedString } from "mylibrary"; declare module "mylibrary" { interface TypeOverrides { LocalizedString: StrictLocalizedString; } } -
To recap • Branded type to avoid mixing strings and
localized strings • Declaration merging + module augmentation to allow configuring library type from outside -
Thank you ! Work with us " buildo.com ! Let's
chat " twitter.com/gabro27 QA and feedback! !
