Introduction to regular expressions
The slides of my brown-bag session dedicated to introducing regular expressions.
Gianluca Costa
April 24, 2014
Transcript
67 slides
-
Before starting Regular expressions are a tool: it's up to
you to use them wisely. Like every tool, they require: Practice Tests Patience -
Why “regular expressions”? • 1956: mathematical definition of regular sets
by Stephen Cole Kleen • 1968: “Regular Expression Search Algorithm” - by Ken Thompson. Description of a regular expression compiler. • Regular expressions employed in text editors. Introduction of the grep command. -
Examples of text matching • Given an IIS log, keep
just the requests to the web app “/PicnicAPI” • Perform LIKE queries on MongoDB • Get the dir and basename of a file path • Get the src attribute of an <img> tag • Read a key-value file having “\” line continuations -
Generalized problems • Determine if a pattern is contained (matches)
a given string • Extract substrings from a matching string • Replace one or more substrings • Generalizable to files and streams -
Regular expressions Regular expressions describe text patterns. For example: “At
least 3 digits, but not more than 5”. -
How to apply regexes • Functions/classes provided by programming languages/frameworks
• Command-line tools (sed, awk, egrep, …) • Other interfaces (eg: MongoDB queries) -
Interactive testing • http://regex101.com/ - currently provides a free multi-engine
test environment, explaining your regex and showing the matches on a text. • http://rubular.com/ - another regex test environment, targeting Ruby's flavour. -
The dualism regex-target The regular expression is applied to a
string, to check for a match. Both the regex and the string have their own cursor. Which cursor drives the matching process? T h e q u i c k b r q u i Text: Regex: -
Engine types • DFA • Traditional NFA • POSIX NFA
• Hybrid solutions -
DFA • Matching is driven by the cursor on the
text • Very fast matching • Takes longer to compile • Takes more memory • Declarative regex • Always returns the longest possible match. -
Traditional NFA • Matching is driven by the cursor on
the regex • Creates a stack of states, and performs backtracking • Supports more language constructs • Imperative regex • Usually returns the first match found • Employed by standard Java, .NET, Python, PHP, Perl, Ruby, … -
POSIX NFA • Very, very similar to traditional NFA, but
returns the longest possible match. • Further performance issues! -
Hybrid solutions Double engine: first-scan with DFA, then scan with
NFA if required by the pattern. Further implementations are possible. -
Our target: NFAs • DFAs are less common than NFAs,
their syntax is almost a subset and they are generally simpler. • We will concentrate on NFA regexes -
Know your engine There are common rules, but several engines.
Every engine has its own implementation. You must know your engine. And write tests. -
Regex basics Literal text, such as /rain/ matches if and
only if the string contains, somewhere, that sequence, matching character after character. -
The first rule of matching Matching starts from the leftmost
character. Therefore: “The rainbow shines after the rain” /rain/ -
The second rule of matching The engine returns a success
if and only if the regex cursor reaches the end of the regex. -
Escaping characters • Some characters (\, *, ?, +, .,
(, ), [, ], {, }, |, ^, $, #) must be escaped when they are used literally • Escape is performed by prepending “\”. For example: /\?/ to represent a literal “?” • Where raw strings are not supported, a double escape might be required. In Java, the regex /\\\+/ becomes: “\\\\\\+”. -
Escape sequences • \r • \n • \v • \f
• \t • They work just like in C -
Character classes • [abc] = “a, b or c in
this position” • [a-z] = “a, b, c, …, z here” • [A-Za-z] = “A, B, …, Z, a, b, …, z here” • [A-Za-z0] = “A, …, Z, a, …, z, 0 here” • [A-Z\-] = [-A-Z] = “A, …, Z or – here” • What about accents? (é, è, …) And cedilla? • Know your engine. -
Negated character classes • [^ab] = “Something not a and
not b here” • [^a-z] = “Something not a, b, c, …, z here” • [^A-Za-c] = “Something not “A, …, Z, a, …, c here” • Negating a character set requires the existence of a character in that position, not belonging to the specified class. -
Common character classes • \d = a digit • \D
= [^\d] • \w = a letter, a digit or “_” • \W = [^\w] • \s = a space character • \S = [^\s] • . = any character except newline -
What are letters and spaces? • The answer depends on
the encoding and on your engine. • In ASCII, usually: – \w = [A-Za-z0-9_] – \s = [\r \n\t\f\v] (includes ASCII-32 common space) • But what about Latin-1 or Unicode? • Know your engine -
Unicode character classes • \uXXXX: matches the Unicode code point
whose hex value is XXXX • There should also be support for Unicode's categories and scripts, especially via \p • Much more Unicode-related, non-standard features • Know your engine -
Capturing groups • ( and ) define a capturing group
• Capturing groups are assigned a 1-based index, according to the position of their ( • /(\w+)bet/ tries to match a string and, if successful, creates a capturing group for the text matching \w+, having index 1 • If the above regex is applied to “alphabet”, it matches and its group 1 is “alpha” -
Non-capturing groups • Groups can just be used to clarify
precedence: capturing is not always needed • Skipping capturing can save memory and speed up the matching process • To define a non-capturing group, use (?: and ). • Therefore, /(?:\w+)bet/ is just like /\w+bet/, as no capturing is performed and this grouping alters precedence without effects. -
Backreferences • Backreference = the content of a capturing group
that becomes part of the regex • Use \N in your regex, replacing N with the index of the captured group in question • For example: /(['”])\w+\1/ to pair single and double quotes • Some engines support named capturing and backreferences -
Alternation • Alternatives are separated by | • For example:
/alpha|beta/ means “alpha” or “beta” • Alternation has very low precedence; its scope is the current group: use grouping to force precedence. • For example: /A(?:pril|ugust)/ means “A, followed by “pril” or “ugust”. -
Alternation VS char classes • A character class (asserted or
negated) always matches one and only one character • The branches of an alternation can be strings of any length (at least one character, to be consistent) -
Matching in a DFA /nice|cute/ applied to: “Pandas are cute
animals” It scans the string, starting from P, and, at every character, tries to apply the regex. In a DFA regex, the engine only chooses which regex components remain valid at a given position of the text cursor. -
Matching in NFA • NFA also keeps a stack of
states! • Each decision point saves a state in the stack • State = position of the 2 cursors • If a choice in the regex leads to no match, the engine backtracks (=pops a state from the stack and makes a different choice) -
Backtracking S1 S2 S5 S3 S4 S6 S7 S8 1
2 4 7 8 10 11 3 5 6 9 -
Performance implications • In NFA, a failure is returned only
when all the regex paths have been explored • NFA regexes must be written with performances in mind. -
Alternation in NFA • Ordered in most implementations. • Affects
what is matched and performances. • Know your engine -
Greedy quantifiers • All quantifiers can be applied to single
characters, classes or even groups • * = any number of occurrences (even 0) • ? = 0 or 1 occurrencies • + = 1 or infinite occurrencies • {n} = exactly n occurrencies • {m, n} = m to n occurrencies (included) • {m,} = at least m occurrencies -
First example of greedy quantifiers • Let's consider the regex
/be?(er|ar)/ • How is it applied to “I'd like a chocolate bar” ? • The regex cursor stays on “b” until the text cursor reaches its “b” too • Then, the following regex paths are tried: – be => b(er) => b(ar) -
Greedy quantifiers and backtracking • Consider the regex /.* are/
• Applied to: “Pandas are cute animals” • .* will consume the whole text at first • However, when reaching the end of the text, it stops matching and the regex cursor goes on. -
Greedy quantifiers and backtracking (2) • Now, “ “ can't
match (no more text is available), so the engine backtracks! • Some backtracking is performed, until the first available space is reached (between “cute” and “animals”) • The regex cursor moves on to “a”, that matches the “a” in “animals”. But “r” doesn't match “n” => more backtracking! -
Greedy quantifiers and backtracking (3) • The failures and backtracking
go on until the space between “are” and “cute”... “a” doesn't match the “c” in “cute” => backtracking, again! • The next space is ok: it is followed by “are”, that matches the rest of the regex. -
Lazy quantifiers • Quantifiers become lazy if followed by a
? • *? • ?? • +? • {m, n}? • {m, }? • {n} cannot be lazy: it indicates a precise n -
Lazy quantifiers and backtracking • When applying /.*? are/ to
“Pandas are cute animals”, what happens? • The engine must choose whether to apply .*? to “P”. But it's lazy, so the engine chooses to move the regex cursor forward • The regex cursor goes on to “ “, but it doesn't match “P” so the engine backtracks • The engine must now take the remaining path – applying .*? to “P”, which is viable -
Lazy quantifiers and backtracking (2) • This goes on until
the first space in the text is reached: it matches the space in the regex, so the regex cursor can go on • The matching process continues until the regex ends • In this case, the match of greedy and lazy evaluation was the same – but the lazy quantifiers required less backtracking -
Apply or skip? Greedy VS Lazy • When a quantifier
is encountered, the regex engine must choose whether to apply its element to the text or not • Greedy quantifiers prefer the “apply” path whenever possible • Lazy quantifiers prefer the “skip” path whenever possible • Choosing greedy VS lazy quantifiers can impact performances and what is matched, but not the presence/absence of a match. -
Greedy VS Lazy: an example • Given the text “987”:
– /\d{1,3}/ matches the whole “987”: the greedy quantifier tries to consume as much as possible – /\d{1,3}?/ matches just “9”: the lazy quantifier must honour the constraints (at least 1 match), but chooses to skip application whenever possible -
Atomic grouping • (?> and ) define an atomic group
• All the states created within an atomic group are removed from the engine's stack as soon as the group closes • Atomic groups are non-capturing, but can have capturing groups • Atomic grouping can alter the match/failure result of a regex, as well as affecting performances -
Possessive quantifiers • Obtained by adding a “+” to greedy
quantifiers • Possessive quantifiers are equivalent to greedy quantifiers wrapped within an atomic group. • For example: /\d++/ = /(?>\d+)/ -
Regex flags • Regex engines can turn on/off features, for
customized behaviour • Enabling and disabling flags usually affects the whole regex, but some engines support flags on just regions. • Flag manipulation is engine- and API- dependent • Every engine has its own flags, but some are definitely common. -
Most common regex flags • Case insensitive • Dot-all: .
matches any character, including \n • Multiline anchors: ^ and $ (see later) work on lines instead of the whole text • Extended: spaces – including newlines - are ignored unless escaped or within a character class; lines starting with # are comments. More readable regexes. -
Anchors • Anchors do not consume text: they are basic
conditions on the text cursor. • They must be verified for the regex to match -
Common anchors • ^: the cursor is at the beginning
of the text (of a line, in multiline mode) • $: the cursor is at the end of the text (of a line, in multiline mode. And before or after \n? Know your engine). • \A: the cursor is at the beginning of the text • \Z: the cursor is at the end of the text • \b: the cursor is at a word boundary (what's a word boundary? Know your engine) -
Lookaround • Lookaround = a regex-based condition on the text
cursor. Can be positive (the regex must match) or negative (the regex must fail). • Lookahead = a lookaround on the text following the cursor • Lookbehind = a lookaround on the text preceding the cursor. -
Lookaround notation Lookbehind Lookahead Positive (?<= regex) (?= regex )
Negative (?<! regex) (?! regex ) -
Lookaround basics • Their position in the regex matters, as
the other characters in the regex consume the text and make the text cursor shift forward. • On the other hand, lookarounds do not consume text • Juxtaposed lookarounds all apply, bound by a logic and, to the position marked by the text cursor -
Lookaround limitations • Lookarounds behave like nested regexes having their
own stack • They are also called zero-length assertions • Lookahead can be full-fledged regexes • Lookbehinds are usually much more restricted, depending on the engine -
Lookarounds and the stack • Each lookaround maintains its own
stack, that gets deleted at the end of the lookaround. • An important detail: capturing groups within lookarounds are considered capturing groups of the whole regex => their result is saved. -
Lookahead + Backreference = Atomic group • Lookaheads are full-fledged
regexes with their own stack, which is thrown away. • This is exactly like an atomic group, but the lookahead does not consume text • However, capturing groups in a lookahead are stored by the regex => use a backreference to capture that text • Therefore, for example: /(?=(\d+))\1/ = /(?>\d+)/ -
Regexes and C# • .NET encapsulates regexes in a class,
System.Text.RegularExpressions.Regex • Its constructor accepts the regex and, optionally, global flags • C# supports raw strings (preceded by @), to avoid over-escaping, that can be found in Java. -
Regexes and Java • Java's regex class is java.util.regex.Pattern •
In lieu of a constructor, it's a static method, Pattern.compile(), that creates a regex • It takes the regex and, optionally, the global flags • In Java, the regex /\\test/ becomes “\\\\test”, because each “\” in the regex must be escaped in Java, too, for a total of 4 “\”. -
Regexes in MongoDB • MongoDB supports regexes • Just use
/regex/ (with slashes and without double quotes) as the right side of an equality assertion in your query • Important: a regex could hit indexes on a field, but the best results are achieved when the regex starts with ^ -
Regexes in Python • Python provides the standard module re
• To create a regex, just use re.compile(), that takes, as usual, the regex string and the optional global flags -
Regexes in JavaScript • In JavaScript, it's quite common to
use this notation to create a regex object: var regex = /regexPattern/ var regexWithFlags = /regexPattern/flags • Alternatively, the RegExp class can be used -
Final notes • Don't forget that regexes must be kept
simple, just like any other construct • To achieve this result, a good knowledge of the text, as well as of the requirements, is needed. • Write tests for your regexes -
Further references • “Mastering Regular Expressions” - by Jeffrey E.
F. Friedl, published by O'Reilly Media • http://regex101.com/ • http://rubular.com/ • http://www.regular-expressions.info/
