Room - The blessed persistence library

Hugo Visser
October 06, 2017

Room - The blessed persistence library

Slides from my presentation at Mobile Era 2017

Hugo Visser

October 06, 2017
Tweet

More Decks by Hugo Visser

Other Decks in Technology

Transcript

  1. Knowing SQL • SQL Delight: everything is SQL → little

    or no abstractions, source of truth • Room → Queries and migrations are SQL • Cupboard → SQL as fallback
  2. Key points Part of Architecture Components → opinionated app architecture

    Does not support entity relations by design (e.g. no lazy loading) Database operations use SQL, no abstractions. Current version: 1.0.0-beta2 Created by Google
  3. Getting started (Java) android { defaultConfig { javaCompileOptions { annotationProcessorOptions

    { arguments = ["room.schemaLocation": "$projectDir/schemas".toString()] } } } } dependencies { implementation "android.arch.persistence.room:runtime:1.0.0-beta2" annotationProcessor "android.arch.persistence.room:compiler:1.0.0-beta2" // 26.1.+ implements LifecyleOwner for LiveData and friends implementation 'com.android.support:appcompat-v7:26.1.0' // For LiveData & Lifecycle support implementation "android.arch.lifecycle:extensions:1.0.0-beta2" annotationProcessor "android.arch.lifecycle:compiler:1.0.0-beta2" }
  4. Getting started (Kotlin) apply plugin: 'kotlin-kapt' kapt { arguments {

    arg("room.schemaLocation", "${projectDir}/schemas") } } dependencies { implementation "android.arch.persistence.room:runtime:1.0.0-beta2" kapt "android.arch.persistence.room:compiler:1.0.0-beta2" // 26.1.+ implements LifecyleOwner for LiveData and friends implementation 'com.android.support:appcompat-v7:26.1.0' // For LiveData & Lifecycle support implementation "android.arch.lifecycle:extensions:1.0.0-beta2" kapt "android.arch.lifecycle:compiler:1.0.0-beta2" }
  5. Room main ingredients Entities → your objects DAO’s → how

    you persist and retrieve entities RoomDatabase → where everything is persisted
  6. Entities @Entity public class User { @PrimaryKey(autoGenerate = true) public

    Long id; public String firstName; public String lastName; }
  7. Entities @Entity public class User { @PrimaryKey(autoGenerate = true) public

    String id; public String firstName; public String lastName; } error: If a primary key is annotated with autoGenerate, its type must be int, Integer, long or Long.
  8. Entities @Entity public class User { @PrimaryKey public String id;

    public String firstName; public String lastName; } error: You must annotate primary keys with @NonNull. SQLite considers this a bug and Room does not allow it.
  9. Entities @Entity public class User { @PrimaryKey @NonNull private final

    String id; public String firstName; public String lastName; public User(@NonNull String id) { this.id = id; } @Ignore public User() { this.id = UUID.randomUUID().toString(); } @NonNull public String getId() { return id; } }
  10. Entities @Entity public class User { @PrimaryKey @NonNull private final

    String id; @NonNull private final String firstName; private final String lastName; public User(@NonNull String id, @NonNull String firstName, String lastName) { this.id = id; this.firstName = firstName; this.lastName = lastName; } @Ignore public User(String firstName, String lastName) { this(UUID.randomUUID().toString(), firstName, lastName); } // getters --> } @NonNull public String getId() { return id; } @NonNull public String getFirstName() { return firstName; } public String getLastName() { return lastName; }
  11. Entities @Entity data class User(@PrimaryKey val id: String = UUID.randomUUID().toString(),

    val firstName: String, val lastName: String?) val user = User(firstName = "Hugo", lastName = "Visser")
  12. Entities @Entity(tableName = "k_user", primaryKeys = arrayOf("firstName", "lastName")) data class

    User(val id: String = UUID.randomUUID().toString(), val firstName: String, val lastName: String)
  13. Entities @Entity(indices = arrayOf(Index("firstName", "lastName", unique = true))) data class

    User(@PrimaryKey val id: String = UUID.randomUUID().toString(), @ColumnInfo(index = true) val firstName: String, @ColumnInfo(name = "last_name", typeAffinity = ColumnInfo.TEXT, collate = ColumnInfo.NOCASE) val lastName: String?)
  14. Entities Annotated Java or Kotlin classes Must specify a non-null

    primary key Database representation is controlled by annotations
  15. Entities vs POJOs Distinction is made in the Room documentation

    @Entity → Object that has a table in the database POJO → any object that a result can be mapped to
  16. Data access objects (DAOs) Define methods of working with entities

    interface or abstract class marked as @Dao One or many DAOs per database
  17. DAO @Query @Dao interface UserDao { @Query("select * from User

    limit 1") fun firstUser(): User @Query("select * from User") fun allUsers(): List<User> @Query("select firstName from User") fun firstNames(): List<String> @Query("select * from User where firstName = :fn") fun findUsersByFirstName(fn: String): List<User> @Query("delete from User where lastName = :ln") fun deleteUsersWithLastName(ln: String): Int @Query("select firstName as first, lastName as last from User where lastName = :ln") fun findPersonByLastName(ln: String): List<Person> }
  18. Map result on any POJO data class Person(val first: String,

    val last:String) Room matches column names Must be able to convert column to type
  19. @Insert @Insert(onConflict = OnConflictStrategy.REPLACE) fun addUser(user: User) @Insert fun addUsers(users:

    List<User>): List<Long> @Insert fun addUserWithBooks(user: User, books: List<Book>)
  20. User with books @Entity data class User @Ignore constructor(@PrimaryKey val

    id: String, val firstName: String, val lastName: String?, @field:Ignore val books: List<Book>) { constructor(id: String = UUID.randomUUID().toString(), firstName: String, lastName: String?) : this(id, firstName, lastName, listOf()) } Needs @field:Ignore on books Primary constructor is @Ignored for Room
  21. Abstract DAO class @Dao abstract class UserBookDao { @Insert protected

    abstract fun insertSingleUser(user: User) @Insert protected abstract fun insertBooks(books: List<Book>) @Query("select * from User where id = :id") protected abstract fun findUserById(id: String) : User? @Query("select * from Book where userId = :userId") protected abstract fun findUserBooks(userId: String) : List<Book> @Transaction open fun insertUser(user: User) { insertBooks(user.books) insertSingleUser(user) } fun findUser(id: String) : User { val user = findUserById(id) return user?.copy(books = findUserBooks(id)) ?: throw IllegalArgumentException("No user with id $id") } }
  22. The database @Database(entities = arrayOf(User::class, Book::class), version = 1) abstract

    class MyDatabase : RoomDatabase() { abstract fun getUserDao(): UserDao companion object { private var instance: MyDatabase? = null fun getInstance(context: Context): MyDatabase { return instance ?: Room.databaseBuilder(context, MyDatabase::class.java, "my.db"). build().also { instance = it } } } } Annotated with @Database abstract class that extends RoomDatabase Room.databaseBuilder() → create singleton (use DI, or other means)
  23. Let’s do this! val dao = MyDatabase.getInstance(context).getUserDao() val users =

    dao.allUsers() java.lang.IllegalStateException: Cannot access database on the main thread since it may potentially lock the UI for a long period of time.
  24. It was never okay to do database ops on the

    main thread! (but we all did it)
  25. @Insert, @Delete and @Update Nothing provided by Room to run

    off the main thread Run in an executor, AsyncTask, RxJava, Kotlin co-routines For testing only: allowMainThreadQueries() on the database builder
  26. Observable queries Using LiveData or RxJava 2 Delivers result async

    with updates @Query("select * from User") fun allUsers(): List<User>
  27. Observable queries Using LiveData → android.arch.lifecycle:extensions RxJava 2 → android.arch.persistence.room:rxjava2

    Delivers result async with updates @Query("select * from User") fun allUsers(): LiveData<List<User>> @Query("select * from User") fun allUsersRx(): Flowable<List<User>>
  28. Observable queries override fun onCreate(savedInstanceState: Bundle?) { super.onCreate(savedInstanceState) val dao

    = MyDatabase.getInstance(this).getUserDao() dao.allUsers().observe(this, Observer { it?.let { showUsers(it) } }) } private fun showUsers(users: List<User>) { }
  29. TypeConverter Convert a field (object) to column and vice versa

    Can be scoped from field, entity, ..., Database No default converters for things like Date or enums :(
  30. TypeConverter object MyTypeConverters { @TypeConverter @JvmStatic fun dateToLong(date: Date?) :

    Long? { return date?.time } @TypeConverter @JvmStatic fun longToDate(value: Long?) : Date? { return if (value == null) { null } else { Date(value) } } }
  31. TypeConverter @Entity data class User(@PrimaryKey val id: String, val firstName:

    String, val lastName: String, @field:TypeConverters(MyTypeConverters::class) val birthDate: Date) @Entity @TypeConverters(MyTypeConverters::class) data class User(@PrimaryKey val id: String, val firstName: String, val lastName: String, val birthDate: Date) @TypeConverters(MyTypeConverters::class) @Database(...) abstract class MyDatabase : RoomDatabase() { }
  32. Complex objects Flatten objects onto a table using @Embedded data

    class Address(val street: String, val houseNumber: String, val city: String) @Entity class User(@PrimaryKey(autoGenerate = true) val id: Long, val name: String, val address: Address)
  33. @Embedded User table will now have a street, houseNumber and

    city column too data class Address(val street: String, val houseNumber: String, val city: String) @Entity class User(@PrimaryKey(autoGenerate = true) val id: Long, val name: String, @Embedded val address: Address)
  34. Migrations When adding, changing, removing entities: schema updates Database version

    number Migrate from version x to version y Missing migration will crash your app, but save user data
  35. Creating & using migrations class UserBirthDayMigration : Migration(1, 2) {

    override fun migrate(database: SupportSQLiteDatabase) { // execute the statements required database.execSQL("ALTER TABLE User ADD COLUMN `birthDate` INTEGER") } } Room.databaseBuilder(context, MyDatabase::class.java, "mydatabase.db"). addMigrations(UserBirthDayMigration(), MyOtherMigration()). build()
  36. Migrations Tip: use exported schema definitions 1.json, 2.json etc Testing

    migrations https://d.android.com/topic/libraries/architecture/room.html#db-migration-testing fallbackToDestructiveMigration() discards data
  37. Large result sets w/ Paging Cursors (+ CursorAdapter) have their

    problems https://medium.com/google-developers/large-database-queries-on-android-cb043a e626e8 Room integrates with Paging architecture component https://developer.android.com/topic/libraries/architecture/paging.html
  38. Data sources for PagedLists // this might be a huge

    list @Query("select * from User") fun allUsers():List<User> // Generates a TiledDataSource (not observable) @Query("select * from User") fun allUsers(): TiledDataSource<User> // Generates a LivePagedListProvider (observable) that uses LIMIT and OFFSET @Query("select * from User") fun allUsers(): LivePagedListProvider<Integer, User>
  39. More stuff Foreign key support (cascading deletes, integrity checks) SupportSQLiteDatabase

    allows for alternative SQLite implementations @Relation annotation to eager fetch relations in POJOs only Testing support
