Transcript
kube-vipで作るお手軽 高可用クラスター ~外出しHAProxyからの卒業~ Presented by @_inductor_
じこしょうかい apiVersion: inductor.apps/v1 kind: Person metadata: name: “Kohei Ota” Twitter:
“@_inductor_” GitHub: “@inductor” org: “HPE” role: “Solutions Architect” community: “CNCF Ambassador, CloudNative Days organizer, Docker Meetup Tokyo organizer” spec: replicas: 1
免責事項 - 今回作成するクラスターはkubeadmの利用を前提としています - kube-vip v0.3.1時点での要求 - kube-vipについて説明をしますが、HAProxyやKeepalivedについての説明はLTな ので省略します -
kube-vipはまだバージョンが若いので、今回の手順や構成図は今後変更される可 能性があります
HAProxyからの卒業?
これまでのオンプレKubernetesにおける 高可用性クラスターの基本構成
None
Kubernetesのノード Kubernetes外リソース
HAProxy+Keepalivedによるロードバランシング - ふつーにオンプレでサーバー建てるのと同じHAProxy構成 - バックエンドにKubernetes Control planeを複数台配置 - HAProxyはVM/ベアメタルで配置するのでKubernetesとは別で管理 -
Kubernetes上でHAProxyの管理はしない ※このHAProxyはIngressとは違い、kube-apiserverを冗長化するための ロードバランサーです
HAProxy+Keepalivedによるロードバランシング - ふつーにオンプレでサーバー建てるのと同じHAProxy構成 - バックエンドにKubernetes Control planeを複数台配置 - HAProxyはVM/ベアメタルで配置するのでKubernetesとは別で管理 -
Kubernetes上でHAProxyの管理はしない ※このHAProxyはIngressとは違い、kube-apiserverを冗長化するための ロードバランサーです Kubernetesで全部管理したい!!!! ・・・したくない???
そこでkube-vip
kube-vip
kube-vip - kube-vipはKubernetesの「中と外」に負荷分散機能を与える OSS - api-serverの負荷分散 - HAProxyの代替 - Type:
LoadBalancer機能の提供(with Plunder Cloud Provider) - MetalLBなどの代替 これらの機能が「ハイブリッドに」提供できるのが便利
kube-vip - kube-vipはKubernetesの「中と外」に負荷分散機能を与える OSS - api-serverの負荷分散 - HAProxyの代替 - Type:
LoadBalancer機能の提供(with Plunder Cloud Provider) - MetalLBなどの代替 これらの機能が「ハイブリッドに」提供できるのが便利
kube-vip - kube-vipはKubernetesの「中と外」に負荷分散機能を与える OSS - api-serverの負荷分散 - HAProxyの代替 - Type:
LoadBalancer機能の提供(with Plunder Cloud Provider) - MetalLBなどの代替 これらの機能が「ハイブリッドに」提供できるのが便利 Tanzu Kubernetes Grid(🥚かけ🍚)でも バージョン1.2から採用
kube-vipの構成
kube-vipの構成
192.168.0.100 (VIP) 192.168.0.201 192.168.0.202 192.168.0.203 Kubernetes control plane nodes Incoming
traffic Global Endpoint 192.168.0.204 192.168.0.205 192.168.0.206 Kubernetes control worker nodes kubectl https://global-endpoint:6443 https://192.168.0.100:6443 Static Pod or DaemonSet
kube-vipの構成 - Static Pod - 単一の構成なら一番簡単 - kubeadmでクラスターを作るときに Pod manifestを/etc/kubernetes/manifests配下に配置
- 各コントロールプレーンノードに配置もできるっぽいけどやり方がよく分からない() - DaemonSet(推奨) - コントロールプレーンごとに LB Podが立ち上がってVIPでやりとりするので本番向け 他にも、APIのLBだけ構成するかServiceでも使うようにしたいか、LBの構成にBGPを 使うかARPを使うかや、DDNS、DHCPなど様々な動的設定もできるようになっている (詳細はドキュメント参照)
さいごに - 使ってみた記事を英語で上げてます https://inductor.medium.com/say-good-bye-to-haproxy-and-keepalived-with-k ube-vip-on-your-ha-k8s-control-plane-bb7237eca9fc - 説明の都合上一番シンプルなStatic Pod + API
LBのみにしましたが、実際にPod で立ち上がってきたので面白かったです(小並感)
手軽におうちで 高可用クラスター生活が 捗りますね!!!!!
ご清聴ありがとうございました
