Managed Containers, Open Source, and Google

Joe Beda
August 21, 2014

Managed Containers, Open Source, and Google

Talking about Kubernetes at LinuxCon/CloudOpen in Chicago, August 21, 2014.

Joe Beda

August 21, 2014
Tweet

More Decks by Joe Beda

Other Decks in Programming

Transcript

  1. Why Containers*? 1. Packaging 2. Efficiency and Speed 3. Security

    (?) (*) Container = Docker flavor container
  2. Static application environment No stress deployment and update Repeatable portable

    artifact Develop here, run there Pick your cloud solely on its merits Loosely coupled = easier to build and manage Easier to build and manage Compose applications from micro-services Packaging
  3. Everything at Google runs in a container. • Resource isolation

    • Predictability • Quality of service • Efficient overcommit • Resource accounting Google starts over 2 billion containers per week. Images by Connie Zhou Efficiency
  4. Kubernetes Inspired by Google's systems and experience Manage Containers, not

    Machines Efficient: optimized packing, better scaling Performant: active environment tuning Robust: active monitoring, self healing Organizationally Scalable: • Split sys ops and app ops • Enable micro-services Modern Open Source: • Extensible & portable, can run anywhere • Apache 2.0 licensed • Written in Go • Hosted on github
  5. Node Container Manager Scheduled Containers Managed Base OS Managed Base

    OS Node Container Manager Scheduled Containers Cluster Scheduler Simplified Cluster Management Stack
  6. Managed Base OS kubelet Scheduled Containers Managed Base OS kubelet

    + Docker Scheduled Containers Kubernetes Master etcd Kubernetes Container Stack
  7. Kubernetes Master/Scheduler Kubernetes Machine Host Machine Host Machine Host Machine

    Host Machine Host Machine Host Machine Host Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent
  8. Log Roller Web Server Machine Host Machine Host Machine Host

    Machine Host Machine Host Machine Host Machine Host Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Kubernetes Master/Scheduler Pods
  9. FE FE FE FE FE FE BE BE BE BE

    BE BE BE BE BE Machine Host Machine Host Machine Host Machine Host Machine Host Machine Host Machine Host Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Kubernetes - Master/Scheduler Too Many Pods
  10. labels: role: frontend FE FE FE FE FE FE BE

    BE BE BE BE BE BE BE BE Machine Host Machine Host Machine Host Machine Host Machine Host Machine Host Machine Host Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Kubernetes - Master/Scheduler Labels
  11. labels: role: frontend stage: production Machine Host Machine Host Machine

    Host Machine Host Machine Host Machine Host Machine Host Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Kubernetes - Master/Scheduler FE FE FE FE FE FE BE BE BE BE BE BE BE BE BE Labels
  12. Declarative Over Imperative Imperative: "for pod in pod{001..100} ; start

    $pod Declarative: "Run 100 copies of this pod with a target of <= 2 tasks down at any time" Pros: • Repeatable • "Set it and forget it" • Eventually consistent • Easily updatable Con: • Tracing action/reaction can be difficult. "I made a change, is it done?" Image: "Space Needle under construction, 1961" seattlemunicipalarchives CC-BY-2.0 http://www.flickr. com/photos/seattlemunicipalarchives/6847114249
  13. FE FE FE FE replicas: 4 template: ... labels: role:

    frontend stage: production Machine Host Machine Host Machine Host Machine Host Machine Host Machine Host Machine Host Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Kubernetes - Master/Scheduler Replication Controller
  14. FE replicas: 1 template: ... labels: role: frontend stage: production

    Machine Host Machine Host Machine Host Machine Host Machine Host Machine Host Machine Host Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Kubernetes - Master/Scheduler Replication Controller
  15. FE FE FE replicas: 3 template: ... labels: role: frontend

    stage: production Machine Host Machine Host Machine Host Machine Host Machine Host Machine Host Machine Host Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Kubernetes - Master/Scheduler Replication Controller
  16. id: backend-service port: 9000 labels: role: backend stage: production Backend

    Service BE BE BE BE Machine Host Machine Host Machine Host Machine Host Machine Host Machine Host Machine Host Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Container Agent Kubernetes - Master/Scheduler Service
  17. We’re taking lessons we’ve learned and open sourcing them Kubernetes

    is evolving We’re eager to hear from you! 1 2 3 Summing Up
  18. We are just getting started... Clone Kubernetes at: github.com/GoogleCloudPlatform/kubernetes IRC:

    #google-containers on Freenode Google group: google-containers Reach out: [email protected] Twitter: @jbeda
