STREAM REAL-TIME A LANGUAGE FOR => Machine Learning Meetup •
Nubank • May 24th 2017 PROCESSING -
JUAN LOPES R&D software engineer @ INTELIE Ph.D. student @
COPPE/UFRJ twitter.com/juanplopes github.com/juanplopes -
STREAM PROCESSING ALSO KNOWN AS • REACTIVE PROGRAMMING In the
context of programming paradigms; • DATA STREAM MINING In the context of machine learning; • DATA FLOW PROGRAMMING In the context of programming languages. • EVENT STREAM PROCESSING In the context of systems monitoring and data analysis. -
THE FASTEST ANSWER A PROGRAM CAN GIVE IS THE ONE
ALREADY COMPUTED -
“NOTIFY ME WHEN THE REGRESSION SLOPE OF THE LAST HOUR
BECOMES NEGATIVE” -
STREAM PROCESSING ENGINES THEY REALLY LOVE SQL SELECT count(*) as
fails, timestamp, local, description, FROM HttpMonitor(type = "error" OR description ="Timeout::Error") .std:groupwin(description) .win:time(15 minutes) var forward = inputStream.AlterEventStartTime( s => s.StartTime.AddSeconds(1)); var query = from evt in inputStream from prev in forward where prev.Value < threshold && evt.Value > threshold select new { Time = evt.Time, Low = prev.Value, High = evt.Value }; -
STREAM PROCESSING ENGINES THEY REALLY LOVE SQL SELECT STREAM "SuspectLoginFailures"."accountNumber",
"loginFailureCount", "transactionType", "amount" FROM "SuspectLoginFailures" OVER "lastFew" JOIN "Transactions" OVER "lastFew" ON "SuspectLoginFailures"."accountNumber" = "Transactions"."accountNumber" WHERE ("transactionType" = 'isDebit') WINDOW "lastFew" AS (RANGE INTERVAL '1' MINUTE PRECEDING); CREATE OUTPUT STREAM TickStats AS SELECT openval() AS StartOfTimeSlice, avg(NumberTicks) AS AvgTicksPerSecond, stdev(NumberTicks) AS StdevTicksPerSecond, lastval(NumberTicks) AS LastTicksPerSecond, FeedName FROM TicksPerSecond [ SIZE 20 ADVANCE 1 ON StartOfTimeSlice PARTITION BY FeedName ] GROUP BY FeedName; -
STREAM PROCESSING ENGINES THEY REALLY LOVE SQL SELECT T.firstc, T.lastc,
T.Ac1, T.Bc1, T.avgCc1, T.Dc1 FROM S0 MATCH_RECOGNIZE ( MEASURES first(C.c2) as firstc, last(C.c2) as lastc, avg(C.c1) as avgCc1, A.c1 as Ac1, B.c1 as Bc1, D.c1 as Dc1 PATTERN(A B C* D) DEFINE A as A.c1 = 30, B as B.c2 = 10.0, C as C.c1 = 7, D as D.c1 = 40 ) as T declare Sale @role( event ) end declare window Ticks Sale() over window:length(5) from entry-point MyEntryPoint end rule "More than 2 sale suceess in 5 events" when Number($cnt : intValue,intValue > 2) from accumulate( Sale (saleHappened == "Y") from window Ticks, count(1) ) then System.out.println( "A sale has happened over " + $cnt +" events" ); end -
CHAINED COMPUTATION MODEL SIMILAR TO UNIX... [juanplopes ~]$ find .
-name *.conf -print0 | xargs -0 grep -l -Z mem_limit | xargs -0 -i cp {} {}.bak PIPELINES! -
CHAINED COMPUTATION MODEL AN EXAMPLE QUERY Sales product:Pampers* size:(G|XG|XXG) =>
sum(value#) as sales every minute => sales:regression->slope as slope over last hour => @filter slope < 0 -
FILTER AUTOMATON MINIMIZES STRING COMPARISONS ?? field: type field: status
http 2 3 404 ?? and 00 and or and type:http status:404 type:http status:200 type:http status:(2?? | 3??) -
PROBABILISTIC DATA STRUCTURES LESS RESOURCES, SOME ERROR BLOOM FILTER Cardinality
testing, probabilistic counting; COUNT-MIN SKETCH Multiset frequency, stream quantiles, scalar product; MINHASH Locality sensitive hashing, set similarity; HYPERLOGLOG Probabilistic counting with ridiculously low memory usage. -
PROBABILISTIC DATA STRUCTURES LESS RESOURCES, SOME ERROR 1970 1990 1980
2000 2010 BLOOM FILTERS [Blo70] FM-SKETCH [FM85] MINHASH [Bro97] KMV-SKETCH [BYJK+02] LSH THEORY [IM98] SIMHASH [Cha02] LOGLOG [DF03] AMS PAPER [AMS96] CM-SKETCH [CM05] HYPERLOGLOG [FFGM08] SPECTRAL BLOOM [CM03] HYPERLOGLOG++ [HNH13] -
[Blo70] Burton H Bloom. Space/time trade-offs in hash coding with
allowable errors.Communications of the ACM, 13(7):422–426, 1970. [FM85] Philippe Flajolet and G Nigel Martin. Probabilistic counting algorithms for data base applications. Journal of computer and system sciences, 31(2):182–209, 1985. [AMS96] Noga Alon, Yossi Matias, and Mario Szegedy. The space complexity of approximating the frequency moments. In Proceedings of the twenty-eighth annual ACM symposium on Theory of computing, pages 20–29. ACM, 1996. [Bro97] Andrei Z Broder. On the resemblance and containment of documents. In Compression and Complexity of Sequences 1997. Proceedings, pages 21–29. IEEE, 1997. [IM98] Piotr Indyk and Rajeev Motwani. Approximate nearest neighbors: towards removing the curse of dimensionality. In Proceedings of the thirtieth annual ACM symposium on Theory of computing, pages 604–613. ACM, 1998. [Cha02] Moses S Charikar. Similarity estimation techniques from rounding algorithms. In Proceedings of the thiry-fourth annual ACM symposium on Theory of computing, pages 380–388. ACM, 2002. [BYJK+02] Ziv Bar-Yossef, TS Jayram, Ravi Kumar, D Sivakumar, and Luca Trevisan. Counting distinct elements in a data stream. In Randomization and Approximation Techniques in Computer Science, pages 1–10. Springer, 2002. [CM03] Saar Cohen and Yossi Matias. Spectral bloom filters. In Proceedings of the 2003 ACM SIGMOD international conference on Management of data, pages 241–252. ACM, 2003. [DF03] Marianne Durand and Philippe Flajolet. Loglog counting of large cardinalities. In Algorithms-ESA 2003, pages 605–617. Springer, 2003. [CM05] Graham Cormode and S Muthukrishnan. An improved data stream summary: the count-min sketch and its applications. Journal of Algorithms, 55(1):58–75, 2005. [FFGM08] Philippe Flajolet, Éric Fusy, Olivier Gandouet, and Frédéric Meunier. Hyperloglog: the analysis of a near-optimal cardinality estimation algorithm. DMTCS Proceedings, 2008. [HNH13] Stefan Heule, Marc Nunkesser, and Alexander Hall. Hyperloglog in practice: Algorithmic engineering of a state of the art cardinality estimation algorithm. In Proceedings of the 16th International Conference on Extending Database Technology, pages 683–692. ACM, 2013. -
“NOTIFY ME WHEN THE 99th PERCENTILE OF ALL RESPONSE TIMES
TODAY BECOMES GREATER THAN 1 SECOND?” -
IT IS PROVED IMPOSSIBLE TO COMPUTE QUANTILES IN A SINGLE
PASS, WITH LESS THAN O(N) MEMORY Munro, J. I., & Paterson, M. S. (1980). Selection and sorting with limited storage. Theoretical computer science, 12(3), 315-323. http://wrap.warwick.ac.uk/46321/1/WRAP_Munro_cs-rr-024.pdf -
0.01 0.02 0.02 0.35 0.39 0.42 1.25 48 0 1
2 N/2-1 N/2 N/2+1 99N 100 N-1 ... ... ... MEDIAN 99th PERCENTILE -
0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 COUNT-MIN SKETCH TO THE RESCUE -
0 0 0 0 0 3 0 0 0 0
3 0 0 0 0 0 COUNT-MIN SKETCH TO THE RESCUE A[“some value”] += 3 h 1 (“some value”) = 5 h 2 (“some value”) = 2 -
0 5 0 0 0 3 0 0 0 0
3+5 0 0 0 0 0 COUNT-MIN SKETCH TO THE RESCUE A[“another value”] += 5 h 1 (“another value”) = 1 h 2 (“another value”) = 2 -
1 5 0 10 4 3 7 9 1 0
8 3 1 0 0 1 COUNT-MIN SKETCH TO THE RESCUE A[“some value”]? h 1 (“some value”) = 5 h 2 (“some value”) = 2 -
4 9 4 1 2 3 9 0 5 1
5 3 3 3 8 5 FENWICK TREES I TOLD YOU THERE WOULD BE TREES -
4 9 4 1 2 3 9 0 5 1
5 3 3 3 8 5 13 5 5 9 6 8 6 13 18 14 14 19 32 33 65 -
4 9 4 1 1 3 5 0.01 0.02 0.03
0.04 0.35 0.99 42 ... ... ... ... -
4 9 4 1 2 3 9 0 5 1
5 3 3 3 8 5 -
IT IS POSSIBLE TO ESTIMATE QUANTILES IN A SINGLE PASS,
WITH LESS THAN O(N) MEMORY Munro, J. I., & Paterson, M. S. (1980). Selection and sorting with limited storage. Theoretical computer science, 12(3), 315-323. http://wrap.warwick.ac.uk/46321/1/WRAP_Munro_cs-rr-024.pdf -
+ 1 5 0 10 4 3 7 9 1
0 8 3 1 0 0 1 COUNT-MIN SKETCH IT IS THAT GOOD 2 3 9 1 0 0 2 4 9 4 4 11 13 7 0 1 + -
“HOW MANY DISTINCT USERS CLICKED IN OUR AD TODAY?” DID
I HEAR HYPERLOGLOG? -
0 0 3 0 0 0 0 0 01000101… ρ(x)
= 3 PARTITION #2 0 1 2 3 4 5 6 7 -
1 8 3 12 9 1 0 7 0 1
2 3 4 5 6 7 HARMONIC MEAN -
3 1 8 9 15 12 14 2 0 1
2 3 4 5 6 7 1 8 3 12 9 1 0 7 0 1 2 3 4 5 6 7 max -
THANKS => Machine Learning Meetup • Nubank • May 24th
2017 twitter.com/juanplopes github.com/juanplopes
