Ruby meets WebAssembly

RubyKaigi 2022 Keynote https://rubykaigi.org/2022/presentations/kateinoigakukun.html#day1

Transcript

1. Ruby meets WebAssembly Yuta Saito / @kateinoigakukun 1
2. About this talk 1. Introduction to Ruby on WebAssembly 1. Motivation 2. Live demo: “on-browser” usage 3. About WebAssembly and WASI 4. Live demo: “non-web” usage 2. Technical details: How to port the Ruby Interpreter 1. Explore missing pieces for porting: Exceptions, Fiber, Conservative GC 2. A magic technique Asyncify 3. FAQ & Recap 2
3. About me • Yuta Saito / @kateinoigakukun • Waseda University B4 • Working at • A newbie CRuby / Swift / LLVM committer • Porting languages to WebAssembly 3
4. Introduction to Ruby on WebAssembly Motivation On-browser Demo Motivation non-Web Demo About
 Wasm and WASI
5. What's Good about Ruby • Designed to make programmers happy • Fast to write a program • Well-developed Gem Ecosystem 5
6. What's Dif fi cult in Ruby? 1. Some platforms can’t run Ruby easily • Some restricted platforms can’t install Ruby interpreter (e.g. Web browser, Mobile device) • Hard to run your Ruby program on user machine • Run on server? Need to maintain server? 2. Installation battle 💥 • Making the fi rst step easy is important for beginners • How many times have you seen BUILD FAILED ? 6
7. 🤔 How can we solve them? 7
8. Ruby 🤝 WebAssembly 8
9. WebAssembly is a game changer • A binary instruction format for a stack-based machine • Designed to be • Portable • Language agnostic • Size- and Load-time ef fi cient • Secure by Sandbox • and more… 9
10. What WebAssembly solves 1. Some platforms can’t run Ruby easily → ✅ Now browser is everywhere 🌐 2. Installation battle 💥 → ✅ Beginners can try Ruby on browser without installation
11. Execution Flow of WebAssembly C / C++ Swift Rust Go … .wasm Web browsers 11
12. Ruby on WebAssembly Ruby Interpreter (CRuby) ruby.wasm app.rb Web browsers 12
13. Introduction to Ruby on WebAssembly Live demo: On browser Ruby About
 Wasm and WASI On-browser Demo Motivation non-Web Demo
14. github.com/ruby/ruby.wasm
 packages/npm-packages/ruby-wasm-wasi/example/README.md
15. https://irb-wasm.vercel.app
16. Introduction to Ruby on WebAssembly About WebAssembly and WASI About
 Wasm and WASI On-browser Demo Motivation non-Web Demo
17. https://emscripten.org/ Musl libc CRuby .wasm How WebAssembly works • Vanilla WebAssembly has: • No fi le system • No system clock • No networks • … • Time.now returns … what? ? 17
18. Musl libc CRuby JS Glue code .wasm .js Web API syscall emulation How WebAssembly works MemFS … JS provides functions to the WebAssembly Time.now clock_gettime Date.now() 18
19. • Secure by sandbox, architecture portability, many language support are useful for other area • Serverless platforms • Plugin systems • and more… • WebAssembly is not always on JavaScript WebAssembly is not only for Web 19
20. Overview of WASI User Application .wasm WASI interface Host Application Web Poly fi ll Bare Metal Serverless platform Musl libc … WASI (WebAssembly System Interface) WASI standardize platform independent system call interface 20
21. WASI compatible things Platforms • Node.js / Deno / Wasmtime • Fastly Compute@Edge • Cloud fl are Workers • VSCode Extensions • Fluent Bit • Etc… Languages • C / C++ • Rust • Swift • Ruby (NEW) • Etc… 21
22. • CRuby program itself is now portable everywhere! • However • Need to distribute .rb fi les also • Most Wasm integrated tools requires “One Binary” WASI + VFS = Portable Ruby App WASI interface WASI Implementation app.rb lib.rb Host User Application Musl libc .wasm 22
23. WASI + VFS = Portable Ruby App User Application .wasm WASI interface WASI Implementation Musl libc Host wasi-vfs app.rb lib.rb • wasi-vfs • A VFS layer backed by WASI • Read-only in-memory FS 23
24. Introduction to Ruby on WebAssembly Live demo: Serverless About
 Wasm and WASI On-browser Demo Motivation non-Web Demo github.com/kateinoigakukun/ruby-compute-runtime
25. https://ruby-compute-runtime- demo.edgecompute.app/
26. Ruby 3.2 will support WebAssembly and WASI
27. What’s new around WebAssembly in Ruby 3.2 • Support WebAssembly / WASI target • ruby/ruby.wasm provides npm packages and pre-compiled rubies • Let’s fi nd interesting use cases! 27
28. How to Port CRuby to
 WebAssembly with WASI 28 Technical details Introduction FAQ & Recap
29. Port CRuby to WebAssembly with WASI Me: OK, we already have C to WebAssembly compiler,
 so it’s easy to port! 29
30. Port CRuby to WebAssembly with WASI CRuby has many internal dragons… • 🐲 Exceptions • Heavily depend on setjmp/longjmp, which cannot be implemented on WebAssembly itself • 🐲 Fiber • WebAssembly itself doesn’t support context-switching • 🐲 Conservative GC • Need to inspect WebAssembly VM 30
31. Technical details Exception implementation 🐲 Conservative GC 🐲 Fiber 🐲 Exception ⚔ Asyncify
32. raise rb_raise_jump ... #define EC_EXEC_TAG() \ (ruby_setjmp(_tag.buf) ? rb_ec_tag_state(VAR_FROM_MEMORY(_ec)) : (EC_REPUSH_TAG(), 0)) VALUE vm_exec(rb_execution_context_t *ec, bool mjit_enable_p) { enum ruby_tag_type state; VALUE result = Qundef; VALUE initial = 0; EC_PUSH_TAG(ec); _tag.retval = Qnil; if ((state = EC_EXEC_TAG()) == TAG_NONE) { if (!mjit_enable_p || (result = mjit_exec(ec)) == Qundef) { result = vm_exec_core(ec, initial); } goto vm_loop_start; /* fallback to the VM */ } else { result = ec->errinfo; rb_ec_raised_reset(ec, RAISED_STACKOVERFLOW | RAISED_NOMEMORY); while ((result = vm_exec_handle_exception(ec, state, result, &initial)) == Qundef) { /* caught a jump, exec the handler */ result = vm_exec_core(ec, initial); vm_loop_start: VM_ASSERT(ec->tag == &_tag); /* when caught `throw`, `tag.state` is set. */ if ((state = _tag.state) == TAG_NONE) break; _tag.state = TAG_NONE; } } EC_POP_TAG(); return result; } CRuby implements exceptions by setjmp/longjmp static void rb_raise_jump(VALUE mesg, VALUE cause) { rb_execution_context_t *ec = GET_EC(); ... rb_vm_pop_frame(ec); ... rb_longjmp(ec, TAG_RAISE, mesg, cause); } raise “You got an error” setjmp saves the current program state longjmp restores the saved program state #define EC_EXEC_TAG() \ (ruby_setjmp(_tag.buf) ? rb_ec_tag_state(VAR_FROM_MEMORY(_ec)) : (EC_REPUSH_TAG(), 0)) if ((state = EC_EXEC_TAG()) == TAG_NONE) { if (!mjit_enable_p || (result = mjit_exec(ec)) == Qundef) { result = vm_exec_core(ec, initial); } goto vm_loop_start; /* fallback to the VM */ } #define EC_EXEC_TAG() \
33. setjmp/longjmp on x86_64 musl-libc src/setjmp/x86_64/setjmp.s src/setjmp/x86_64/longjmp.s /* Copyright 2011-2012 Nicholas J. Kain, licensed under standard MIT license */ setjmp: mov %rbx,(%rdi) /* rdi is jmp_buf, move registers onto it */ mov %rbp,8(%rdi) mov %r12,16(%rdi) mov %r13,24(%rdi) mov %r14,32(%rdi) mov %r15,40(%rdi) lea 8(%rsp),%rdx /* this is our rsp WITHOUT current ret addr */ mov %rdx,48(%rdi) mov (%rsp),%rdx /* save return addr ptr for new rip */ mov %rdx,56(%rdi) xor %eax,%eax /* always return 0 */ ret longjmp: xor %eax,%eax cmp $1,%esi /* CF = val ? 0 : 1 */ adc %esi,%eax /* eax = val + !val */ mov (%rdi),%rbx /* rdi is the jmp_buf, restore regs from it */ mov 8(%rdi),%rbp mov 16(%rdi),%r12 mov 24(%rdi),%r13 mov 32(%rdi),%r14 mov 40(%rdi),%r15 mov 48(%rdi),%rsp jmp *56(%rdi) /* goto saved address without altering rsp */ longjmp: jmp *56(%rdi) /* goto saved address without altering rsp */ /* Copyright 2011-2012 Nicholas J. Kain, licensed under standard MIT license */ setjmp: mov (%rsp),%rdx /* save return addr ptr for new rip */ Save and Restore • Machine stack position • Machine registers • Program counter
 (Return address) 33
34. WebAssembly Execution Model WebAssembly VM Code Functions[0] Functions[1] Functions[2] Functions[3] Push (Call) Pop (Return) Protected Stack Call Frame i32(0x42) i64(0xffff0a) Call Frame Return Address Return Address 🙅 🙅 Can’t jump! Can’t read/write! Control- fl ow is protected by WebAssembly VM Only goto/call/return are allowed 34
35. Missing pieces for porting 1. Save the current execution state 2. Unwind to the saved execution state 35
36. Technical details Fiber Implementation 🐲 Conservative GC 🐲 Fiber 🐲 Exception ⚔ Asyncify
37. Fiber in CRuby Main Fiber fi b Main Fiber fi b fib.resume Fiber.yield • Semi-coroutine • Suspend/Resume programs fib = Fiber.new do Fiber.yield x = 0 Fiber.yield y = 1 loop do x, y = y, x + y Fiber.yield y end end 3.times { puts fib.resume } fib.resume Fiber.yield ... 37
38. Fiber context-switch • Fiber#resume / Fiber.yield / Fiber#transfer switches “context” • Context • Ruby VM stack • Machine stack • Machine registers • Program counter Fiber 1 Fiber 2 Context Context Current Context Program Architecture Speci fi c 38
39. Missing pieces for porting 1. Save the current execution state 2. Unwind to the saved execution state
 → Restore an execution state from arbitrary execution state
 (not limited to being within the call stack) 39
40. Technical details Conservative GC Implementation 🐲 Conservative GC 🐲 Fiber 🐲 Exception ⚔ Asyncify
41. Conservative GC in CRuby • Scan data space to fi nd object-like values • CRuby scans: • Machine Registers • Machine Stack Registers VALUE VALUE non- VALUE Machine Stack VALUE non-VALUE VALUE VALUE non-VALUE (?) 41
42. WebAssembly Execution Model WebAssembly VM Code Functions[0] Functions[1] Functions[2] Functions[3] Push (Call) Pop (Return) Protected Stack (Current) Call Frame Write Read Linear Memory C Stack Data Heap Can’t read! Space for putting
 address referenced
 local values Call Frame Return Address Locals[1] Locals[2] Locals[0] Return Address Value Stack Value Stack i32(0x42) i64(0xffff0a) i32(0x42) 🙅 Can’t scan! 🙅 OK! 🙆 Machine Stack = C Stack + Value Stack Machine Register = Locals 42
43. Missing pieces for porting 1. Save the current execution state 2. Restore an execution state from arbitrary execution state
 (not limited to being within the call stack) 3. Inspect the Locals and Value Stack of all call frames 43
44. Technical details Asyncify 🐲 Conservative GC 🐲 Fiber 🐲 Exception Asyncify
45. Asyncify fi lls the missing pieces 🧙 • Provides low-level support for pausing and resuming programs • Designed to call async JS function from sync C code by Alon Zakai • Works by instrumenting .wasm binaries • wasm-opt input.wasm --asyncify -o output.wasm 45
46. Asyncify Example sleep Rewind sleep Call stack main main foo Unwind • Unwind: Serialize execution state
 and return the control to root • Rewind: Call entrypoint function again
 and rebuild call stack void sleep(void) { static bool is_sleeping = false; if (!is_sleeping) { is_sleeping = true; asyncify_start_unwind(); } else { is_sleeping = false; asyncify_stop_rewind(); } } void foo(void) { puts("before"); sleep(); puts("after"); } int main(void) { foo(); asyncify_stop_unwind(); puts("sleeping"); asyncify_start_rewind(); foo(); foo foo 46
47. Asyncify Example void sleep(void) { int main(void) { foo(); foo foo 47
48. void sleep(void) { puts("before"); } foo foo 48
49. void sleep(void) { static bool is_sleeping = false; if (!is_sleeping) { is_sleeping = true; asyncify_start_unwind(); } } sleep(); foo Asyncify Example 49
50. void sleep(void) { sleep(); } foo Asyncify Example 50
51. void sleep(void) { puts("before"); sleep(); puts("after"); // skipped } int main(void) { foo(); asyncify_stop_unwind(); foo Asyncify Example 51
52. void sleep(void) { puts("sleeping"); asyncify_start_rewind(); foo(); foo Asyncify Example 52
53. void sleep(void) { asyncify_start_rewind(); foo(); foo Asyncify Example 53
54. void sleep(void) { static bool is_sleeping = false; if (!is_sleeping) { } else { is_sleeping = false; asyncify_stop_rewind(); } } void foo(void) { // skipped sleep(); } foo Asyncify Example 54
55. void sleep(void) { puts("after"); } Asyncify Example 55
56. How Asyncify instruments program 1. Spill out Wasm stack values into Wasm registers 2. Instrument control fl ow, around calls and adding skips for rewinding 3. Instrument Wasm registers saving/restoring. 56
57. Asyncify: Instrument program static VALUE sym_length(VALUE sym) { return rb_str_length(rb_sym2str(sym)); } C code Wasm stack machine code (local.get $sym) (call $rb_sym2str) (call $rb_str_length) (return) 57
58. 1. Spill out Wasm stack values into Wasm registers Guarantee that each statement doesn’t pop previous results static VALUE sym_length(VALUE sym) { register VALUE v1 = rb_sym2str(sym); register VALUE v2 = rb_str_length(v1); return v2; } (local.get $sym) (call $rb_sym2str) (local.set $v1) (local.get $v1) (call $rb_str_length) (local.set $v2) (local.get $v2) (return) C code Wasm stack machine code 58
59. 2. Instrument control fl ow, around calls
 and adding skips for rewinding static VALUE sym_length(VALUE sym) { register VALUE v1; register VALUE v2; if (__asyncify_state == REWINDING) { __asyncify_get_call_index(); } if (__asyncify_state == NORMAL || __asyncify_check_call_index(0)) { v1 = rb_sym2str(sym); if (__asyncify_state == UNWINDING) { __asyncify_unwind(0); } } if (__asyncify_state == NORMAL || __asyncify_check_call_index(1)) { v2 = rb_str_length(v1); if (__asyncify_state == UNWINDING) { __asyncify_unwind(1); } } return v2; } 59
60. static VALUE sym_length(VALUE sym) { register int __asyncify_call_index; register VALUE v1; register VALUE v2; if (__asyncify_state == REWINDING) { __asyncify_call_index = *(__asyncify_data--); v1 = *(__asyncify_data--); v2 = *(__asyncify_data--); } if (__asyncify_state == NORMAL || __asyncify_check_call_index(0)) { v1 = rb_sym2str(sym); if (__asyncify_state == UNWINDING) { goto __asyncify_unwind(0); } } if (__asyncify_state == NORMAL || __asyncify_check_call_index(1)) { v2 = rb_str_length(v1); if (__asyncify_state == UNWINDING) { goto __asyncify_unwind(1); } } return v2; __asyncify_unwind(int call_index): *(__asyncify_data++) = v2; *(__asyncify_data++) = v1; *(__asyncify_data++) = call_index; return 0; } 3. Instrument Wasm registers saving/restoring. 60
61. Missing pieces for porting 1. Save the current execution state → ✅ Asyncify serializes the execution state into memory space 2. Restore an execution state from arbitrary execution state
 (not limited to being within the call stack) → ✅ Asyncify deserializes the execution state from memory space 3. Inspect the Locals and Value Stack of all call frames → ✅ Asyncify spills Value Stack to Locals,
 and Locals are serialized to execution state 61
62. CRuby now runs on WebAssembly 👏 62
63. FQA & Recap 63 FAQ & Recap Technical details Introduction
64. FAQ • No Thread related API • Wasm and WASI don’t have thread spawning API yet. • Throw NotImplementedError • C Extension library must be linked statically • Dynamic-linking ABI is not yet well-supported What are the limitations of Ruby on WebAssembly? 64
65. FAQ How large is the .wasm binary? raw gzip Brotli minimal No standard extensions 8.1M 2.9M 1.7M full All standard extensions (like json, yaml, or stringio) 10M 3.4M 2.0M full+stdlib With stdlib .rb fi les 25M 7.3M 5.0M 65
66. FAQ How fast is CRuby on WebAssembly? • Near mruby speed • Asyncify adds much overheads • Environment • Node.js v17.9.0 • Ubuntu 20.04 • AMD Ryzen 9 5900HX Optcarrot FPS (bigger is better) master (native) mruby master (wasm32-wasi) Opal 0 15 30 45 60 1.51 18 21.6 54.6 66
67. Acknowledgements • @mame, @ko1, and other Ruby committers gave me a lot of advice • Ruby Association supported the project as a grant project • And thanks for all contributors and users 67
68. Recap • Ruby 3.2 will support WebAssembly and WASI • ruby.wasm provides npm packages and pre-compiled rubies • Try your favorite gems on https://irb-wasm.vercel.app/ • Welcome your feedback! 68
69. FAQ WebAssembly is designed for the mixed goals of them Why not use JVM / .NET CLI / NaCL / eBPF / Lua … ? Wasm design goal Similar with Portability JVM / .NET CLI Language independency .NET CLI Secure sandbox NaCL, eBPF Embeddable runtime Lua 69
