1. RubyGems on ruby.wasm Yuta Saito (@kateinoigakukun) RubyKaigi 2024 1
3. About me • Yuta Saito / @kateinoigakukun • Master's student at Waseda University • Newbie commi>er of CRuby and SwiB • Creator of ruby.wasm 3
4. Overview 1. Introduc+on to ruby.wasm 2. Challenges of RubyGems support 3. Demo 4. Technical details 5. Future vision 4
5. 1. Introduc,on: ruby.wasm • Introduced in RubyKaigi 2022 • Enables running Ruby on everywhere by WebAssembly • This project consists of: 1. CRuby interpreter compiled to WebAssembly 2. Packaging system for interpreter + .rb files 3. JS interop library ( require 'js') 5
6. <html> <script src="https://cdn.jsdelivr.net/.../dist/browser.script.iife.js"></script> <script type="text/ruby" data-eval="async"> require 'js' button = JS.global[:document].createElement("button") button[:textContent] = "Click me!" button.addEventListener("click") do puts "Hello~" end response = JS.global.fetch("https://example.com/data.json").await puts response.json.await </script> </html> 6
7. $ wasmtime run ruby.wasm hello.rb Hello, world! 7
8. But, what about RubyGems? 8
9. 2. Challenges of RubyGems support RubyGems has two main components: 1. Installer: gem install 2. Run:me loader: require 'gem_name' 9
10. 2. Challenges of RubyGems support Run$me loader ✅ • Supported from early versions • require 'gem_name' works as expected 10
11. 2. Challenges of RubyGems support Gem installer ! When to install gems? • On-the-fly installa/on • Pre-installa/on 11
12. 2. Challenges of RubyGems support On-the-fly installa.on Install Gems at run-.me • Convenient way for daily scrip4ng • Run gem install on Wasm • Requires network access at 12
13. 2. Challenges of RubyGems support On-the-fly installa.on • I showed on-the-fly installa2on demo at RubyKaigi 2022. • Network access is passed through the browser's fetch API. • You can try it now on runruby.dev by Svyatoslav • No built-in support 13
14. 2. Challenges of RubyGems support Pre-installa+on Install Gems in advance before running the Ruby program. • No network access at Run- 1me • "build" step before running the Ruby program. 14
15. Today's focus Pure-Ruby Gems C-Extension Gems On-the-fly installa.on ⚠ ❌ Pre-installa.on ❌ ❌ 15
16. Today's focus Pure-Ruby Gems C-Extension Gems On-the-fly installa.on ⚠ ❌ Pre-installa6on # # 16
17. 3. Demo: Mastodon in the browser 17
19. h"ps:/ /mastodon-in-browser.vercel.app/boot.html Mastodon in the browser Inspired by 19
20. 3. Demo - Mastodon in the browser 20
21. Possible use case? "Serverless Staging": Host Rails app as a sta3c site • Low-cost • Low security risk • e.g. Preview environments for Pull Requests 21
22. 4. Technical details 22
23. 4. Technical details 1. Package Gems 2. Cross-compile C-Extensions 3. Pre-link C-Extension shared libraries 23
24. 4.1. Package Gems Package gem source files into the WebAssembly binary by VFS # WARNING: Still Experimental $ bundle add ruby_wasm --group=development $ bundle add rainbow $ bundle exec rbwasm build -o ruby.wasm (snip) INFO: Packaging gem: rainbow-3.1.1 INFO: Size: 51.17 MB 24
25. 4.1. Package Gems 25
26. 4.2. Cross-compile C-Extensions Cross-compila,on support in mkmf • mkmf is the core of the C-extension build system in Ruby • 3 major mkmf users (extconf.rb consumers in in other words): • CRuby build system • rake-compiler • RubyGems 26
27. 4.2. Cross-compile C-Extensions Cross-compila,on support status in major mkmf users • CRuby build system & rake-compiler: • Fake rbconfig.rb trick • RubyGems: " • Does not support cross-compila<on at all 27
28. 4.2. Cross-compile C-Extensions Exis%ng rbconfig.rb trick • Overwrite top-level RbConfig constants • Does not work for some corner cases $ ruby -rrbconfig -rwasm32-wasi-fake extconf.rb # ./rbconfig.rb module RbConfig # For target platform ... end # ./wasm32-wasi-fake.rb class Object remove_const :CROSS_COMPILING if defined?(CROSS_COMPILING) CROSS_COMPILING = RUBY_PLATFORM constants.grep(/^RUBY_/) {|n| remove_const n} RUBY_VERSION = "3.4.0" RUBY_RELEASE_DATE = "2024-05-11" RUBY_PLATFORM = "wasm32-wasi" ... end 28
29. # From https://github.com/rake-compiler/rake-compiler/blob/v1.2.7/lib/rake/extensiontask.rb # Pre-load resolver library before faking, in order to avoid error # "cannot load such file -- win32/resolv" when it is required later on. # See also: https://github.com/tjschuck/rake-compiler-dev-box/issues/5 require 'resolv' require 'rbconfig' ... 29
30. 4.2. Cross-compile C-Extensions Cross-compila,on support without trick ✅ Feature #20345: Add --target-rbconfig op3on to mkmf2 h9ps:/ /bugs.ruby-lang.org/issues/20345 $ ruby extconf.rb --target-rbconfig=path/to/rbconfig.rb creating Makefile $ make $ file nokogiri.so nokogiri.so: WebAssembly (wasm) binary module version 0x1 (MVP) 2 Will be available in Ruby 3.4 and later 30
31. 4.2. Cross-compile C-Extensions Cross-compila,on support in RubyGems ! PR #7628: Add --target-rbconfig op.on to gem install h"ps:/ /github.com/rubygems/rubygems/pull/7628 $ gem install nokogiri --target-rbconfig=path/to/rbconfig.rb $ bundle install --target-rbconfig=path/to/rbconfig.rb 31
32. 4.3. Pre-link C-Extension shared libraries 32
33. 4.3. Pre-link C-Extension shared libraries Why not sta*c linking? • We already support sta/cally-linked C-extensions • But, the build model is not suitable for the RubyGems ecosystem • Take a long linking /me (especially due to Asyncify) • Need to /ghtly integrate with the CRuby build system 33
34. Sta$c linking Dynamic linking 34
35. 4.3. Pre-link C-Extension shared libraries Why not dynamic linking so far? • WebAssembly does not have a standard dynamic linking ABI • If we do our bespoke dynamic linking3, the binary will be incompa?ble with standard WebAssembly run?mes 3 Emscripten does dynamic linking by its own loader 35
36. 4.3. Pre-link C-Extension shared libraries Breakthrough: Component Model • A new layer of WebAssembly standard • Consists of: • WIT (WebAssembly Interface Types) IDL • Module linking • ... and more 36
37. 4.3. Pre-link C-Extension shared libraries Module Linking 37
38. 4.3. Pre-link C-Extension shared libraries Dynamic Linking upon Component Model • Each module has its metadata for dynamic linking • "AOT" linker encapsulates "how to link modules" into Component 38
39. 4.3. Pre-link C-Extension shared libraries AOT dynamic linking A new concept of dynamic linking in WebAssembly • Done at the build /me • The final binary is a Component • The linker is originally developed by Joel Dice in wit-component • Adjusted for Ruby use case 39
40. 4.3. Pre-link C-Extension shared libraries Difference from the tradi0onal dynamic linking • The final binary, a Component, contains all the dependencies • No file-based shared library search at run:me • dlopen is available only for libraries known at build-:me 40
41. Current status Pure-Ruby Gems C-Extension Gems On-the-fly installa.on ⚠ ❌ Pre-installa6on ✅ ✅ (soon) 41
42. 5. Future vision 42
43. Roadmap 43
44. Interpreter size 44
45. Summary • RubyGems support will be available soon on ruby.wasm • Ruby is leveraging the state-of-the-art WebAssembly technology including the Component Model 45
46. Acknowledgements • Supported by the Ruby Associa4on Grant Program • Advised by @mame and @ko1 46
