1. Collect distributed application logging using Fluentd (EFK stack) Marco Pas Philips Lighting Software geek, hands on Developer/Architect/DevOps Engineer @marcopas
2. Some stuff about me... • Mostly doing cloud related stuff ◦ Java, Groovy, Scala, Spring Boot, IOT, AWS, Terraform, Infrastructure • Enjoying the good things • Chef leuke dingen doen == “trying out cool and new stuff” • Currently involved in a big IOT project • Wannabe chef, movie & Netflix addict
3. Agenda • Logging • Distributed Logging • Fluentd Overview including demo’s: ◦ Run Fluentd ◦ Capture input from docker container ◦ Capture HTTP access logs ◦ Capture HTTP access logs and store in MongoDB ◦ Capture HTTP access logs and store in EFK stack ◦ Capture SpringBoot logs and store in EFK stack including in_tail ◦ HA Setup
4. Logging
5. • Providing useful information, seems hard! • Common Log Formats ◦ W3C, Common Log Format, Combined Log Format ◦ used for: ▪ Proxy & Web Servers • Agree upon Application Log Formats ◦ Do not forget -> Log levels! • Data security ◦ Do not log passwords or privacy related data Generate Collect Transport Store Analyze Alert
6. Some seriously useful log message :) • “No need to log, we know what is happening” • “Something happened not sure what” • “Empty log message” • “Lots of sh*t happing” • “It works b****” • “How did we end up here?” • “Okay i am getting tired of this error message” • “Does this work?” • “We hit a bug, still figuring out what” • “Call 911 we have a problem”
7. Logging considerations • Logging means more code • Logging is not free • Consider feedback to the UI instead of logging • The more you log, the less you can find • Consider to log only the most evil scenarios (log exceptions) • Agree on levels like FATAL, ERROR, WARN, DEBUG, INFO, TRACE …
8. • Syslog / Syslog-ng • Files -> multiple places (/var/log) ◦ Near realtime replication to remote destinations • Stdout ◦ Normally goes to /dev/null Generate Collect Transport Store Analyze Alert In container based environments logging to “Stdout” has the preference
9. • Specialized transporters and collectors available using frameworks like: ◦ Logstash, Flume, Fluentd • Accumulate data coming from multiple hosts / services ◦ Multiple input sources • Optimized network traffic ◦ Pull / Push Generate Collect Transport Store Analyze Alert
10. Generate Collect Transport Store Analyze Alert • Where should it be stored? ◦ Short vs Long term ◦ Associated costs ◦ Speed of data ingestion & retrieval ◦ Data access policies (who needs access) • Example storage options: ◦ S3, Glacier, Tape backup ◦ HDFS, Cassandra, MongoDB or ElasticSearch
11. • Batch processing of log data ◦ HDFS, Hive, PIG → MapReduce Jobs • UI based Analyses ◦ Kibana, GrayLog2 Generate Collect Transport Store Analyze Alert
12. • Based on patterns or “calculated” metrics → send out events ◦ Trigger alert and send notifications • Logging != Monitoring ◦ Logging -> recording to diagnose a system ◦ Monitoring -> observation, checking and recording Generate Collect Transport Store Analyze Alert http_requests_total{method="post",code="200"} 1027 1395066363000 127.0.0.1 - frank [10/Oct/2000:13:55:36 -0700] "GET /apache_pb.gif HTTP/1.0" 200 2326
13. “In a containerized world, we must think differently about logging.” Label data at the source Push data and parse it as soon as possible
14. Distributed Logging
15. Logging
16. Distributed Logging
18. Need for a Unified Logging Layer
19. Fluentd Overview
21. Fluentd • Open source log collector written in Ruby • Reliable, scalable and easy to extend ◦ Pluggable architecture ◦ Rubygem ecosystem for plugins • Reliable log forwarding
22. Example
23. Event structure • Tag ◦ Where an event comes from, used for message routing • Time ◦ When an event happens, Epoch time ◦ Parsed time coming from the datasource • Record ◦ Actual log content being a JSON object ◦ Internally MessagePack
24. Event example 192.168.0.1 - - [28/Feb/2013:12:00:00 +0900] "GET / HTTP/1.1" 200 777 tag:: apache.access # set by configuration time: 1362020400 # 28/Feb/2013:12:00:00 +0900 record: {"user":"-","method":"GET","code":200,"size":777,"host":"192.168.0.1","path":"/"}
25. Pluggable Architecture http://www.fluentd.org/plugins
26. Configuration • Driven by a simple text based configuration file ◦ fluent.conf → Tell where the data comes from (input) → Tell fluentd what to do (output) → Event processing pipeline → Groups filter and output for internal routing <source><source/> <match></match> <filter></filter> source -> filter 1 -> ... -> filter N -> output <label></label>
27. # receive events via HTTP <source> @type http port 9880 </source> # read logs from a file <source> @type tail path /var/log/httpd.log format apache tag apache.access </source> # save alerts to a file <match alert.**> @type file path /var/log/fluent/alerts </match> # save access logs to MongoDB <match apache.access> @type mongo database apache collection log </match> # forward other logs to servers <match **> type forward <server> host 192.168.0.11 weight 20 </server> <server> host 192.168.0.12 weight 60 </server> </match>
28. # add a field to an event <filter myapp.access> @type record_transformer <record> host_param "#{Socket.gethostname}" </record> </filter> # grouping and internal routing <source> @type forward port 24224 bind 0.0.0.0 @label @SYSTEM </source> <label @SYSTEM> <filter var.log.middleware.**> @type grep # ... </filter> <match **> @type s3 # ... </match> </label>
29. Generate Collect Transport Store Analyze Alert Collect & Transport Store & Analyze Demo Setup
30. Demo: Run Fluentd
31. # file: docker-compose.yml version: '2' services: fluentd: container_name: fluentd image: fluentd-demo → Docker image used for fluentd (container the plugins) volumes: - $PWD/:/fluentd/etc → Mounting local filesystem that contains the config file ports: - "24220:24220" → portmapping 24220 on host to 24220 in Docker container
32. # file: fluent.conf # monitoring agent: # check http://localhost:24220/api/plugins.json for healthcheck <source> @type monitor_agent port 24220 → Run the monitor agent on port 24220 bind 0.0.0.0 → Bind to all network interfaces </source>
33. Demo
34. Demo: Capture input from Docker container
35. # file: docker-compose.yml version: '2' services: fluentd: container_name: fluentd # code intentionally omitted echo: container_name: echo image: debian command: bash -c 'for((i=1;i<=1000;i+=1)); do echo -e "Welcome $${i} times"; sleep 2; done;' links: - fluentd logging: driver: "fluentd" → Use the fluentd logging driver options: fluentd-address: localhost:24224 → Where can we find fluentd? tag: echo → Tag used for event routing
36. # file: fluent.conf # input forward plugin <source> @type forward → Bind to all network interfaces port 24224 → Run the in_forward plugin on port 24220 bind 0.0.0.0 → Bind to all network interfaces </source>
37. Demo
38. Demo: Capture HTTP Access Logs
39. # file: docker-compose.yml version: '2' services: fluentd: container_name: fluentd # code intentionally omitted httpd: container_name: httpd image: httpd-demo ports: - "80:80" → Run our Http server on port 80 serving “/” links: - fluentd logging: driver: "fluentd" → Use the fluentd logging driver options: fluentd-address: localhost:24224 → Where can we find fluentd? tag: httpd.access → Tag used for event routing You get the idea :)
40. # file: fluent.conf # input forward plugin <source> @type forward → Bind to all network interfaces port 24224 → Run the in_forward plugin on port 24220 bind 0.0.0.0 → Bind to all network interfaces </source> # filter httd access logs <filter httpd.access> → Notice the filter tag! *, *.*, **, {a.b,a.*,a.*.b}, ... @type parser → Parse the data and create fields using the regex pattern format /^some regex pattern$/ # code intentionally omitted </filter> # match all and print <match **> @type stdout </match> m a t c h o r d e r
41. Demo
42. Demo: Capture HTTP Access Logs -> MongoDB
43. # file: fluent.conf # code intentionally omitted <match httpd.access> @type copy → Copy to multiple destinations <store> @type stdout → Console output </store> <store> @type mongo → MongoDB output host mongodb port 27017 database fluentd collection test flush_interval 5s include_time_key true </store> </match>
44. Demo
45. Demo: Capture HTTP Access Logs -> ELK stack
46. # file: fluent.conf # code intentionally omitted <match httpd.access> @type copy → Copy to multiple destinations <store> @type stdout → Console output </store> <store> @type elasticsearch → Elasticsearch output host elasticsearch port 9200 flush_interval 5 logstash_format true include_tag_key true </store> <store> @type file path /fluentd/etc/logs/ → File output </store> </match>
47. Demo
48. Demo: Capture Spring Boot Logs
49. # file: fluent.conf # code intentionally omitted <filter springboot.**> @type parser key_name log reserve_data true reserve_time true <parse> @type grok grok_failure_key grokfailure <grok> → Parsing done based on GROK Patterns pattern %{TIMESTAMP_ISO8601:time_stamp}%{SPACE}%{LOGLEVEL:log_level}...*) </grok> </parse> </filter>
50. Demo
51. Demo: HA Setup
52. Demo
53. That’s a wrap! Question? https://github.com/mpas/collect-distributed-application-logging-using-fluentd-efk-stack Marco Pas Philips Lighting Software geek, hands on Developer/Architect/DevOps Engineer @marcopas
