Kubecon 2017: Storage Developments for Stateful Workloads

Covers two new Kubernetes storage features that will benefit stateful, distributed workloads: local persistent volumes, and raw block volumes.

Transcript

1. K8s Storage Developments for Stateful Workloads Erin Boyd, Software Engineer, Red Hat Michelle Au, Software Engineer, Google
2. Agenda •Background •Problem •Solution •Demo •Future
3. Expected Knowledge Kubernetes • Pods • Labels • Nodes • PersistentVolumeClaims • PersistentVolumes • StorageClasses • StatefulSets
5. Background Local Persistent Volumes & Raw Block Volumes Stateful, Distributed Workloads • Cassandra, MongoDB, GlusterFS, etc. • Replicate sharded data for high availability, fault tolerance • Critical infrastructure / applications • Data locality for performance • Data gravity • Execute on where the data is today • High performance tuning
6. Background Kubernetes Features that benefit stateful workloads • StatefulSets for stable identity and volumes • Pod Disruption Budget for controlled disruption • Pod Affinity, Anti-Affinity for co-location, spreading (1.6 beta) • Pod Priority and Preemption (1.8 alpha)
7. Problem Difficult to access high performance local storage Hostpath volumes have a lot of problems • Not portable • Security risk! apiVersion: v1 kind: Pod metadata: name: my-pod spec: nodeName: node-1 volumes: - name: data hostPath: path: /mnt/some-disk containers: ...
8. Problem Today’s workarounds • Manually maintain a Pod spec for each node • Custom scheduler and/or operator • Custom local disk reservation and lifecycle manager Consequences • Can’t leverage existing Kubernetes features • StatefulSets, scaling, rolling updates, etc. • High barrier to entry for adopting Kubernetes
9. Local Persistent Volumes Extend existing PersistentVolumeClaim, PersistentVolume model • PVC: User’s storage requests • “I need 100GB of fast storage” • PV: Cluster’s specific volume implementation • “I have a 100GB local volume available on node-1 at /mnt/disks/ssd0” User PVClaim Pod Cluster Admin PersistentVolumes
10. Example: User’s Pod and Claim apiVersion: v1 kind: Pod metadata: name: my-pod spec: nodeName: node-1 volumes: - name: data hostPath: persistentVolumeClaim: path: /mnt/some-disk claimName: my-pvc containers: ... apiVersion: v1 kind: PersistentVolumeClaim metadata: name: my-pvc spec: accessModes: - ReadWriteOnce resources: requests: storage: 100Gi storageClassName: my-class
11. Example: Admin apiVersion: v1 kind: PersistentVolume metadata: Name: local-volume-1 spec: accessModes: - ReadWriteOnce capacity: storage: 100Gi storageClassName: my-class local: path: /tmp/my-test1 nodeAffinity: requiredDuringSchedulingIgnoredDuringExecution: nodeSelectorTerms: - matchExpressions: - key: kubernetes.io/hostname operator: In values: - node-1 User PVClaim Pod Cluster Admin PersistentVolumes
12. Local Persistent Volumes 1.7 Alpha • “Local” PersistentVolume type with NodeAffinity • Scheduler logic for data gravity 1.9 Alpha • Perform PVC/PV binding during pod scheduling User PVClaim Pod Cluster Admin PersistentVolumes
13. Local Persistent Volumes •Portable, consistent user experience • Across local and remote storage • Across clusters, environments •General mechanism for volume topology •Lowers the barrier for distributed, stateful workloads
14. Raw Block Volumes 1.9 alpha feature goals • Expose Raw block devices in line with Kube primitives • Enable durable access to raw block storage • Provide flexibility for users/vendors to support all storage types • Prior to v1.8 all users got a volume with a filesystem • Break GitHub
16. apiVersion: v1 kind: PersistentVolume metadata: Name: local-volume-1 spec: volumeMode: Block capacity: storage: 100Gi storageClassName: my-class local: path: /dev/xdb nodeAffinity: ... Example: Admin
17. Example: User’s Pod and Claim apiVersion: v1 kind: PersistentVolumeClaim metadata: name: raw-pvc spec: volumeMode: Block accessModes: - ReadWriteOnce storageClassName: my-class resources: requests: storage: 100Gi apiVersion: v1 kind: Pod metadata: name: my-db spec: containers: - name: mysql image: mysql volumeDevices: - name: my-db-data devicePath: /var/lib/mysql volumes: - name: my-db-data persistentVolumeClaim: claimName: raw-pvc
18. Demo See how easy it is to switch between remote and local storage! Replicated MySQL example using StatefulSets: https://kubernetes.io/docs/tasks/run-application/run-replicated-stateful-application/ Try it out yourself: • Follow local volume user guide to bring up a cluster with some local disks • Take existing StatefulSet examples and Helm charts, and change the StorageClassName in the PersistentVolumeClaim to your local StorageClass
19. Summary 1.9 Alpha Features • Local persistent volumes with node affinity and smarter scheduling • Consumption of statically provisioned raw block persistent volumes for Fibre Channel Building blocks for stateful, distributed, performant workloads
20. Future • Dynamically provision volumes during pod scheduling • Dynamically provision raw block volumes • Raw block support for remaining volume plugins: • Local volumes • GCE PD • AWS EBS • GlusterFS • Ceph • Cinder •CSI interface update for block devices
21. Links Local volume user guide https://github.com/kubernetes-incubator/external-storage/tree/master/local-volume Raw Block volume user guide https://kubernetes.io/docs/concepts/storage/persistent-volumes/
22. Questions? Images by Connie Zhou http://kubernetes.io Erin Boyd <eboyd@redhat.com> Michelle Au <msau@google.com> Github: @erinboyd Github: @msau42 Twitter: @erinaboyd Twitter: @_msau42_ Get Involved! • Kubernetes Storage Special-Interest-Group (SIG) • Bi-monthly meetings Thursdays at 9 AM (PST) • http://slack.k8s.io/
