2018 Kubecon EU: Kubernetes Local Persistent Volumes in Production

We give some background on the Local Persistent Volumes feature, and show some examples of how the feature is administered in production.

Michelle Au

May 03, 2018
Tweet

More Decks by Michelle Au

Other Decks in Technology

Transcript

  1. Agenda • Why Kubernetes and local storage at Salesforce •

    Feature overview • Local volume lifecycle • Demo • Future roadmap
  2. Why Kubernetes Local Volumes at Salesforce The success of Salesforce's

    customers is driving storage needs that look exponential or cubic rather than linear Keeping ahead of this curve is the responsibility of our infrastructure team In the last year, our Kubernetes (k8s) fleet size doubled and we energized >10 petabytes storage service capacity
  3. Kubernetes Benefits for Storage Services Our engineers are embracing the

    Kubernetes development lifecycle for storage services across multiple substrates • Leveraging local storage, cloud-native, and secure • Immutable containers, declarative manifests, and active reconciliation • From manifest check in, to production in less than 30 minutes
  4. Use Cases Distributed datastores • Tolerant of node failure and

    data loss • For example: Ceph, Cassandra, Bookkeeper, HDFS, HBase Applications with intensive read/write profiles • Large fast on-disk caches • Avoid cold restarts • Interactive analytic applications
  5. HostPath Volume Problems Not secure Not portable Not disk accountable

    Not scalable Complex operators apiVersion: v1 kind: Pod metadata: name: my-pod spec: nodeName: some-node volumes: - name: data hostPath: path: /mnt/some-disk containers: ...
  6. Local Persistent Volumes Secure Portable Disk accountable Scalable StatefulSets apiVersion:

    v1 kind: Pod metadata: name: my-pod spec: volumes: - name: data persistentVolumeClaim: claimName: my-pvc containers: ...
  7. Feature Status Beta in Kubernetes 1.10 Local disk as a

    Persistent Volume (PV) • Must be formatted and mounted first • Dynamic provisioning NOT supported (yet) Scheduler enhancements • Data gravity • Volume binding looks at Pod requirements • Multiple PVCs in a Pod
  8. Local Volume Lifecycle 1. Node and disk preparation • Specific

    to environment 2. Kubernetes local PV management • Generic to Kubernetes • Provided by local volume STATIC provisioner
  9. Node Preparation Many choices • Partitions • Channel partitioning •

    RAID 0, 1, 5, 6, 10 • LVM • and more... Which one (or more) to choose? It depends...
  10. Node Preparation Workload requirements • Performance • Capacity • Scaling

    • Durability Ops requirements • Cost • Utilization • Repair • Management • Platform limitations • Existing processes and tools
  11. Node Preparation (GKE) 1. Create a cluster or node pool

    with local SSDs 2. Node VM setup script formats and mounts local SSDs to discovery directories for LV provisioner Specific to Google Kubernetes Engine environment https://cloud.google.com/kubernetes-engine/docs/concepts/local-ssd
  12. Node Preparation (Salesforce) Specific to Salesforce environment 1. Manifests describe

    and declare servers configurations 2. Nodeprep daemonset scans new servers 3. Performs volume operations for desired resources a. Partition, clean, and mount 4. Mounts or links resources to discovery directories for LV provisioner 5. Marks node with nodeprep complete label for Daemonset magic
  13. DaemonSet Magic nodeprep daemonset <snip> spec: affinity: nodeAffinity: requiredDuringSchedulingIgnoredDuringExecution: nodeSelectorTerms:

    - matchExpressions: - key: storage.salesforce.com/nodeprep operator: DoesNotExist lv-provisioner daemonset <snip> spec: affinity: nodeAffinity: requiredDuringSchedulingIgnoredDuringExecution: nodeSelectorTerms: - matchExpressions: - key: storage.salesforce.com/nodeprep operator: In values: - mounted Salesforce environment example
  14. Kubernetes PV Management 1. Finds mount points under discovery directories

    2. Creates local PVs 3. Workload consumes and releases PV 4. Volume data cleaned, and PV deleted 5. Repeat Open source LV provisioner that runs in any Kubernetes cluster https://github.com/kubernetes-incubator/external-storage/tree/master/local-volume
  15. Summary Local disk administration is challenging, but can be automated

    • Node prep automation, environment specific • Static local PV provisioner After environment is setup, local PVs are ready for consumption • Same PVC/PV interface as remote storage • Best with StatefulSets
  16. Future Roadmap Raw block volumes • Alpha in Kubernetes 1.10

    and works with LV provisioner v2.1.0 • Higher performance by bypassing FS • Small objects stored in a database • Example: Ceph Luminous Bluestore/Bluefs metadata Dynamic provisioning with LVM • Improved local disk utilization • But performance penalty of shared disks Handle FS formatting and mounting in Kubernetes
  17. Documentation This talk https://speakerdeck.com/msau42 Kubernetes documentation https://kubernetes.io/docs/concepts/storage/volumes/#local https://github.com/kubernetes-incubator/external-storage/tree/master/local-volume Blog posts

    https://kubernetes.io/blog/2018/04/13/local-persistent-volumes-beta https://medium.com/salesforce-engineering/provisioning-kubernetes-local-persistent-volumes-61a82d 1d06b0
  18. Get Involved! Kubernetes Storage special interest group (SIG) • Bi-monthly

    meetings Thursdays at 9 AM PST • http://slack.k8s.io Contact us with questions and feedback! • Github, Slack: msau42 & ianchakeres • Twitter: _msau42_
