Linux Desktop Printing Systems in the 2020s

This presentation introduces the current Linux printing scenario and driverless printing feature. It is for COSCUP 2023 OSPN Japan special track. https://coscup.org/2023/en/session/9AXGL7

Transcript

1. Linux Desktop Printing Systems in the 2020s Naruhiko NARU Ogasawara (naruoga@gmail.com)
2. 2023.07.29 COSCUP 2023 OSPN Track 2 Who am I • Naruhiko NARU Ogasawara ( 小笠原 徳彦 ) • Desktop FLOSS enthusiast from Chiba, Japan • (Printing, LibreOffice, ...) • former member of OpenPrinting Japan • former an employee of a Japanese printer vendor • Amateur kayaker
3. 2023.07.29 COSCUP 2023 OSPN Track 3 OpenPrinting • https://openprinting.github.io/ • Develops IPP-based printing technology for Linux/Unix Operating System
4. 2023.07.29 COSCUP 2023 OSPN Track 4 How printers are “driven” • Printers are quite different from other peripherals • PDL = Page (or Printer) Description Language Job Control QTY=1, Color=B/W, Size=A4, ... PDL
5. 2023.07.29 COSCUP 2023 OSPN Track 5 CUPS • Common Unix Printing System • The core module of Linux printing system • It handles: • Job control and its user interface • Data filter pipeline to create PDL • No “kernel-land” modules • Now developed by OpenPrinting
6. 2023.07.29 COSCUP 2023 OSPN Track 6 CUPS Application CUPS PDF Generation send Spooler back -end pdftopdf Language filter PPD filter pipeline Ghostscript Poppler printe r driver Configuration
7. 2023.07.29 COSCUP 2023 OSPN Track 7 Job control: PPD • PPD: Postscript Printer Description • The name is came from historical reason, not limited to Postscript • Describe printer capabilities • Color/Monochrome • Supported media size • Supported media type • Finishing feature (duplex, stapling, ...)
8. 2023.07.29 COSCUP 2023 OSPN Track 8 Job control: PPD *PPD-Adobe: "4.3" *FormatVersion: "4.3" *FileVersion: "1.28.15" ... *OpenUI *PageSize/Media Size: PickOne *OrderDependency: 10 AnySetup *PageSize *DefaultPageSize: A4 ... *PageSize A4/A4: "<</PageSize[595.275590551181 841.889763779528]>>setpagedevice" *PageSize A4.Borderless/A4 (Borderless): "<</PageSize[595.275590551181 841.889763779528]>>setpagedevice" ... *CloseUI
9. 2023.07.29 COSCUP 2023 OSPN Track 9 pdftopdf • CUPS semi-builtin filter (in the package “cups-filters”) • Used for page layout of PDF (like N-in-one or N-up)
10. 2023.07.29 COSCUP 2023 OSPN Track 10 Language filter • The “Last” filter of the filter pipeline • To generate the printer-specific data format (PDL; Printer or Page Description Language) • Which draws pictures onto papers • Vector / Raster
11. 2023.07.29 COSCUP 2023 OSPN Track 11 This was a painful era... • Who provides the “printer driver” for a particular printer? • According to the market share of desktop OSes, do printer vendors want to develop their printers’ drivers for Linux? • Can printer vendors support continuously? • (Linux desktop, like Ubuntu, evolves so fast) • Many of PDLs are proprietary, so development of fully-open- sourced drivers is difficult (except PostScript, PCL5e/PCL6)
12. 2023.07.29 COSCUP 2023 OSPN Track 12 Driverless Printing! • Now we don’t need to install “printer drivers” • Instead, connect via Wi-Fi or USB then just work • If the printer support “Apple AirPrint” (or “IPP Everywhere”)
13. 2023.07.29 COSCUP 2023 OSPN Track 13 How it works • When a printer turns on, it let same networks devices know “I’m here, I can print” via mDDNS (Avahi) Linux Desktop CUPS Spooler pdftopdf Raster filter Filter pipeline I’m here, I can print CUPS-browsed
14. 2023.07.29 COSCUP 2023 OSPN Track 14 How it works • CUPS-browsed receive the message, then let CUPS know new printer coming Linux Desktop CUPS Spooler pdftopdf Raster filter Filter pipeline CUPS-browsed Hey CUPS, New printer coming
15. 2023.07.29 COSCUP 2023 OSPN Track 15 How it works • CUPS asks to the printer it’s attributes (capabilities) via IPP Linux Desktop CUPS Spooler pdftopdf Raster filter Filter pipeline CUPS-browsed Tell me your attributes Ok! IPP
16. 2023.07.29 COSCUP 2023 OSPN Track 16 How it works • CUPS generate PPD file from received printer attributes Linux Desktop CUPS Spooler pdftopdf Raster filter Filter pipeline CUPS-browsed Here is a new PPD file! PPD
17. 2023.07.29 COSCUP 2023 OSPN Track 17 How it works • An application can use the PPD to control jobs, and send PDF of page images Linux Desktop CUPS Spooler pdftopdf Raster filter Filter pipeline CUPS-browsed PPD Appli- cation Print this documents with this configuration
18. 2023.07.29 COSCUP 2023 OSPN Track 18 How it works • The filter pipeline has a raster filter to create raster images from PDF which can be accepted the printer. They are sent via IPP with job control commands Linux Desktop CUPS Spooler pdftopdf Raster filter Filter pipeline CUPS-browsed PPD Appli- cation I can create raster images which you can accept
19. 2023.07.29 COSCUP 2023 OSPN Track 19 IPP: Internet Printing Protocol • A printing protocol over HTTP • RFC 2911 https://datatracker.ietf.org/doc/html/rfc2911 • Bi-directional • Get printer status / capabilities / configurations • Post printing job with job control commands
20. 2023.07.29 COSCUP 2023 OSPN Track 20 IPP: GetPrinterAttribute and PPD *PPD-Adobe: "4.3" *FormatVersion: "4.3" *FileVersion: "1.28.15" ... *OpenUI *PageSize/Media Size: PickOne *OrderDependency: 10 AnySetup *PageSize *DefaultPageSize: A4 ... *PageSize A4/A4: "<</PageSize[595.275590551181 841.889763779528]>>setpagedevice" *PageSize A4.Borderless/A4 (Borderless): "<</PageSize[595.275590551181 841.889763779528]>>setpagedevice" ... *CloseUI $ ipptool -tv ipps://EPSON%20EP-879A %20Series._ipps._tcp.local/ get-attributes.test | tee out.txt ... media-default (keyword) = iso_a4_210x297mm media-supported (1setOf keyword) = iso_a4_210x297mm,na_index- 4x6_4x6in,na_5x7_5x7in,na_govt- letter_8x10in,om_hivision_101.6x180.6mm,iso_a5_1 48x210mm,iso_a6_105x148mm,na_letter_8.5x11in,na_ legal_8.5x14in,oe_photo- l_3.5x5in,jpn_hagaki_100x148mm,jis_b5_182x257mm, jpn_chou3_120x235mm,jpn_chou4_90x205mm,om_you1_1 20x176mm,om_you3_98x148mm,jpn_you4_105x235mm,iso _c6_114x162mm,om_cardsize_55x91mm,om_creditcards ize_54x86mm,custom_min_89x127mm,custom_max_215.9 x1117.6mm
21. 2023.07.29 COSCUP 2023 OSPN Track 21 Raster filter(s) • Printer accepts some raster formats: e.g. RAW (application/octet- stream), PWG Raster, URF (Apple Raster) and JPEG • And you can see the filter pipeline definitions in /usr/share/cups/mime/*.conv files document-format-supported (1setOf mimeMediaType) = application/octet-stream,image/pwg-raster,image/urf,image/jpeg application/pdf application/vnd.cups-pdf 66 pdftopdf # if using Ghostscript application/vnd.cups-pdf image/pwg-raster 99 gstoraster # if using Poppler application/vnd.cups-pdf application/vnd.cups-raster 100 pdftoraster application/vnd.cups-raster image/pwg-raster 100 rastertopwg
22. 2023.07.29 COSCUP 2023 OSPN Track 22 Conclusion • Printer drivers are user-land modules within CUPS • The pair of (a) PPD and (b) Language filter • A while ago, using printers in Linux required support from the printer vendor • But now we have a driverless printing feature • This allows Linux users to print Apple AirPrint available printers without vendors’ drivers
23. 2023.07.29 COSCUP 2023 OSPN Track More news...
24. 2023.07.29 COSCUP 2023 OSPN Track 24 Upcoming CUPS 3: no printer drivers https://ftp.pwg.org/pub/pwg/liaison/openprinting/presentations/cups-plenary-may-202
25. 2023.07.29 COSCUP 2023 OSPN Track 25 Printer Application • A Printer Application is a background service, a GUI application, etc. that happens to respond to HTTP and IPP requests. It detects the supported printers and advertises those printers on the localhost as an IPP Everywhere printer. It can also listen on network interfaces (i.e. not just localhost) so provide access to a printer to all client devices on a network. Printer Applications are the recommended architecture for printer drivers. • In short, Virtual IPP-Everywhere Printer • https://openprinting.github.io/documentation/01-printer-application/
26. 2023.07.29 COSCUP 2023 OSPN Track 26 PAPPL • Printer APPLication framework • https://www.msweet.org/pappl/ • PAPPL is a simple C-based framework/library for developing CUPS Printer Applications, which are the recommended replacement for printer drivers.
27. 2023.07.29 COSCUP 2023 OSPN Track 27 Printer Applications using PAPPL • Ghostscript Printer Application for Ghostscript-supported printers, • Gutenprint Printer Application for Gutenprint-supported printers, • HP Printer Application for HP PCL printers, • HPLIP Printer Application for HPLIP-supported printers, • LPrint for DYMO, EPL, and ZPL label printers, and • PostScript Printer Application for PostScript printers.
28. 2023.07.29 COSCUP 2023 OSPN Track 28 When does it come? • Fortunately, CUPS 3.x release postponed at first end of 2024 • So you can use same printing system until then • But time to consider to switch from traditional printer- driver-scenario to driverless printing scenario • Because less printer vendors will release their own printer applications
29. 2023.07.29 COSCUP 2023 OSPN Track 29 Conclusion (2) • A big change is coming to the Linux printing system • Printer drivers will be moved to printer applications • It is unlikely that each printer vendor will create a printer application, so the importance of driverless printing is increasing
30. 2023.07.29 COSCUP 2023 OSPN Track Questions?
