Hands on ONOS Development ONS 2015

Hands on ONOS Development ONS 2015

This is the introduction to the hands on development tutorial session held at ONS 2015.

ONOS Project

June 14, 2015
Tweet

More Decks by ONOS Project

Other Decks in Programming

Transcript

  1. ONOS Tutorial Sessions • Overview & Setup ◦ ONOS overview,

    description of BYON app ◦ run-time environment & development setup, initial app deployment • Controlling network via intents ◦ enhance NetworkManager to use IntentService to control connectivity ◦ implement a CLI command • Distributed store component ◦ implement DistributedNetworkStore component • Events & Monitoring ◦ enhance core components for event dispatching ◦ implement NetworkMonitor component to intercept events
  2. ONOS Architecture Tenets • High-availability, scalability and performance ◦ required

    to sustain demands of service provider & enterprise networks • Strong abstractions and simplicity ◦ required for development of apps and solutions • Protocol and device behaviour independence ◦ avoid contouring and deformation due to protocol specifics • Separation of concerns and modularity ◦ allow tailoring and customization without speciating the code-base
  3. ONOS Distributed Architecture NB Core API Distributed Core (state management,

    notifications, high-availability & scale-out) SB Core API Protocols Providers Protocols Providers Protocols Providers Protocols Providers Apps Apps
  4. ONOS Distributed Architecture NB Core API Distributed Core (state management,

    notifications, high-availability & scale-out) SB Core API Protocols Providers Protocols Providers Protocols Providers Protocols Providers Apps Apps Distributed Core (state management, notifications, high-availability & scale-out) SB Core API NB Core API Providers Providers Providers Providers Protocols Protocols Protocols Protocols
  5. ONOS Core Subsystems Device Link Host Topology Flow Rule Path

    Packet Statistics Intent Application Leadership Messaging Storage Region Mastership Driver Group Security Flow Objective Event OpenFlow NetConf OVSDB Core Cluster . . . Proxy ARP Mobility L2 Forwarding REST API GUI CLI Network Cfg. SDN IP / BGP Packet / Optical Tunnel . . . OSGi / Apache Karaf Network Virt. Device Cfg. Config UI Extension External Apps Graph Discovery Tenant . . .
  6. Manager Component Manager Component ONOS Core Subsystem Structure Provider Component

    Provider Component App Component Listener notify command command sync & persist add & remove query & command App Component Provider Component Manager Component Manager Component ProviderRegistry Provider ProviderService Service AdminService Listener notify register & unregister command command sensing add & remove query & command Protocols Store Store Provider Component ProviderRegistry Provider ProviderService register & unregister sensing Protocols Service AdminService Store Store sync & persist ProviderRegistry ProviderRegistry Provider Provider ProviderService ProviderService AdminService AdminService Service Service Listener Listener
  7. multi-bundle app ONOS Applications & OSGi simple app multi-feature &

    multi-bundle app bundle bundle bundle bundle bundle feature.xml features.xml bundle bundle features.xml features.xml bundle .oar .oar .oar app.xml app.xml app.xml
  8. ONOS Applications • Application as a mere Component ◦ offers

    no API, self-contained, e.g. reactive forwarding, proxy ARP ◦ generally interacts only with the network environment • Application with Service Interface ◦ offers API; for other Apps, CLI, REST or GUI ◦ interacts with network environment, but also other software entities (hence API) • Application ignited as “service component” ◦ “singleton”, with activate/deactivate/modify methods ◦ ignited by OSGi service component run-time (SCR) ◦ dependencies on other services auto-wired by OSGi SCR • Applications may have their own state; use Store pattern ◦ delegates responsibility for tracking state to a separate component
  9. OSGi Bundles & Karaf Features • OSGi bundles are Java

    JAR files with an enhanced Manifest ◦ bundles have name and version ◦ bundles explicitly require/import other Java packages ◦ bundles explicit provide/export Java packages for others • Karaf features are means to install or uninstall a set of bundles as a group ◦ features are defined via an XML artifact - a feature repository ◦ feature references, but does not deliver the bundle JAR artifacts • Karaf uses Maven repos as OSGi Bundle Repositories for retrieval of feature and bundle artifacts
  10. Service Component Runtime • Components are effectively stateful singletons whose

    life-cycle is controlled by the framework ◦ components defined by OSGI-INF/*.xml files at run-time ◦ ONOS uses maven-scr-plugin to convert Java annotations to OSGI- INF/*.xml files at compile-time • Components can provide @Services to others • Components can @Reference services from others • @Activate, @Modified and @Deactivate methods serve as component life-cycle hooks
  11. Bundle & Feature Shell Commands • Bundle related commands onos>

    bundle:* • Feature related commands onos> feature:* • Service Component Runtime related commands onos> scr:*
  12. Developing ONOS apps • Maven archetypes ◦ onos-bundle-archetype - basis

    for an ONOS bundle or an app ◦ onos-cli-archetype - overlay for apps with CLI extensions ◦ onos-ui-archetype - overlay for apps with GUI extensions ◦ onos-api-archetype - basis for a app Java API bundle • Run mvn archetype:generate to create a working minimal project module • For simpler usage run onos-create-app shell tool
  13. Bundles, Features & ONOS Apps • Apps are delivered via

    ONOS App aRchive (.oar) files ◦ OAR is a JAR with app.xml, features.xml and bundle artifacts ◦ onos-maven-plugin generates an *.oar file as part of Maven build • Apps are managed on the entire ONOS cluster ◦ via REST API: GET|POST|DELETE /onos/v1/applications ◦ via shell tool: onos-app {install|activate|deactivate|uninstall} ◦ via CLI: onos:app {install|activate|deactivate|uninstall} ◦ via GUI • Back-end installation and activation is done via normal feature & bundle services
  14. BYON Application • BYON is a service which allows you

    to spawn virtual networks ◦ All hosts in the virtual networks are interconnected through a full mesh • Each virtual network contains a full mesh of the hosts within it • BYON allows users to interact with it through CLI commands ◦ In particular, list-networks is a CLI command that you will use in this part ◦ Other available CLI commands are: ▪ create-network - provided ▪ add-host - provided ▪ remove-host - to be implemented ▪ remove-network - to be implemented
  15. s1 s2 s3 h2 h1 h3 h4 Physical h2 h1

    h3 h4 h2 h1 h3 h4 Network #2 Network #1 BYON Application Example
  16. Manager Component Manager Component BYON App Structure NetworkMonitor Component Listener

    notify register app id sync & persist NetworkMonitor Component NetworkManager Component NetworkManager Component Provider Service Listener notify register app id Store Store Provider Service NetworkStore NetworkStore sync & persist CoreService CoreService NeworkService NetworkService NetworkListener NetworkListener submit & withdraw intents Provider submit & withdraw intents Provider IntentService IntentService
  17. Environment Overview Container (LXC) onos1 10.0.3.101 Container (LXC) onos2 10.0.3.102

    Container (LXC) onos3 10.0.3.103 Mininet Network Amazon EC2 VM VPN Development on VM (VirtualBox) or Native Development (Mac or Linux) Developer Laptop 192.168.42.1
  18. Environment Setup (Laptop) Development on VM (easiest) 1. Install VirtualBox

    2. Import VM to VirtualBox 3. User: onos / Password: onos Native Development (Mac or Linux) 1. Install IntelliJ (or Eclipse) 2. Install Oracle JDK 8 3. Install apache-maven 4. Install apache-karaf 5. Install curl 6. git clone https://gerrit.onosproject.org/onos 7. Set up the ONOS bash_profile 8. Build onos 9. git clone https://github.com/bocon13/onos-byon
  19. Download Links • IntelliJ IDEA: https://www.jetbrains.com/idea/download/ • Eclipse: https://eclipse.org/downloads/ •

    Oracle JDK8 http://www.oracle.com/technetwork/java/javase/downloads/jdk8-downloads- 2133151.html • Apache Maven (available via brew): https://maven.apache.org/download.cgi?Preferred=ftp: //mirror.reverse.net/pub/apache/ • Apache Karaf (3.0.3): https://karaf.apache.org/index/community/download.html • cURL (available via brew): http://curl.haxx.se/download.html
  20. Environment Setup (VPN to EC2) Mac 1. Choose Apple menu

    (top left corner) > System Preferences, then click Network 2. Click Add (+) at the bottom of the network connection services list, then choose VPN from the Interface pop-up menu. Enter password in Authentication Settings... 3. Click Connect Windows 1. Right-click the network icon in the system tray and select Open Network and Sharing Center 2. Click Set up a new connection or network 3. On the wizard, select Connect to a workplace, and click Next 4. Select Use my internet connection (VPN) 5. Enter user and password, then Connect (Windows only) To disable default gateway: (Note: this must be done before connecting) 1. Open the Network Connections window 2. Right-click the VPN connection > Properties, then click the Networking tab, then TCP/IPv4 3. Click the "Advanced..." button, and uncheck Use default gateway on remote network 4. Click OK three times Server Address: <provided on paper> Test by ping 10.0.3.101 VPN Type: PPTP User: onos Password: onos Encryption: 128 bit
  21. Lab Sections • Lab #1: Basics ◦ build skeletal app

    with a few provided files; build deploy app and test via CLI • Lab #2: Core manager component ◦ implement NetworkService methods; build, deploy, test • Lab #3: Add intents ◦ implement addHost to submit intents; build, deploy, test • Lab #4: Remove intents ◦ implement removeHost to withdraw intents ◦ implement remove-host CLI command; build, deploy, test • Lab #5: Distributed store component ◦ implement NetworkStore using ConsistentMap primitive; build, deploy, test • Lab #6: Events & Monitor ◦ enhance NetworkStore and NetworkManager to propagate NetworkEvents ◦ implement NetworkMonitor component to log events
  22. Lab #1: Import & Build BYON App • Follow Lab

    #1 of the Distributed Tutorial on the ONOS Wiki https://goo.gl/5ezwoI
  23. Lab #1: Recap • Imported the BYON project into IDE

    • Built app via mvn • Deployed app via onos-app command • Verified functionality via list-networks CLI command
  24. Lab #2: Network Manager & Store • Follow Lab #2

    of the Distributed Tutorial on the ONOS Wiki https://goo.gl/0SQkPO
  25. Lab #2: Recap • Referenced NetworkStore component via @Reference •

    Implemented NetworkManager methods to use NetworkStore functionality • Built & re-deployed the app • Verified that network data is correctly tracked
  26. Lab #3: Adding Intents • Follow Lab #3 of the

    Distributed Tutorial on the ONOS Wiki https://goo.gl/Xhe5SE
  27. Lab #3: Recap • Referenced IntentService component via @Reference •

    Enhanced NetworkManager addHost method to create and submit required HostToHostIntents • Built & re-deployed the app • Verified that intent is properly installed • Verified that connectivity is established between hosts
  28. Lab #4: Removing Intents • Follow Lab #4 of the

    Distributed Tutorial on the ONOS Wiki https://goo.gl/ZIjQlU
  29. Lab #4: Recap • Enhanced NetworkManager removeHost method to withdraw

    all required HostToHostIntents • Enhanced NetworkManager removeNetwork method to withdraw all required HostToHostIntents • Implemented and registered CLI commands • Built & re-deployed the app • Verified that intent is properly withdrawn • Verified that connectivity is severed between hosts
  30. Lab #5: Distributed Store • Follow Lab #5 of the

    Distributed Tutorial on the ONOS Wiki https://goo.gl/wx10vS
  31. Lab #5: Recap • Enhanced DistributedNetworkStore to use ONOS ConsistentMap

    distributed primitive • Built & re-deployed the app • Verified that intent is properly distributed to other ONOS instances in the cluster
  32. Lab #6: Event Notifications • Follow Lab #6 of the

    Distributed Tutorial on the ONOS Wiki https://goo.gl/omi8tz
  33. Lab #6: Recap • Defined NetworkEvent and NetworkStoreDelegate • Enhanced

    DistributedNetworkStore to delegate events to NetworkManager component • Enhanced NetworkManager to notify event listeners • Created NetworkMonitor component as event listener • Built & re-deployed the app • Verified that listeners are notified about network events
  34. ONOS Tutorial Recap • Imported project into IDE • Used

    mvn to build and onos-app to deploy app • Used @Reference to get reference to other components • Controlled connectivity between hosts via IntentService • Created a distributed store using ConsistentMap primitive • Implemented CLI commands • Created asynchronous event notification mechanism • Implemented a component as a NetworkEventListener
  35. Wrap-Up • Browse ONOS Wiki https://wiki.onosproject.org/ • Watch ONOS how-to

    screencasts on YouTube https://goo.gl/8Druv0 • Browse ONOS Java API http://api.onosproject.org/ • Join ONOS [email protected] mailing list https://wiki.onosproject.org/display/ONOS/ONOS+Mailing+Lists • Engage with ONOS developers & community
