Configuration settings and diagnostic tools for...

Configuration settings and diagnostic tools for better PostgreSQL performance

This presentation named "Configuration settings and diagnostic tools for better PostgreSQL performance" was given at the "How to do database audits for PostgreSQL" event by Peter Petrov (Database Engineer, Postgres Professional). The webinar took place on May 11, 2021.

Postgres Professional

May 11, 2021
Tweet

More Decks by Postgres Professional

Other Decks in Programming

Transcript

  1. 2 Agenda Data checksums and approaches of their activation. Tuning

    PostgreSQL parameters for better performance. List of useful extensions for better diagnostics and troubleshooting. Some examples of Zabbix metrics and fragments of a workload report. Kernel parameters tuning. Debug symbols installation.
  2. 3 data_checksums activation methods and validation initdb –k pg_checksums and

    streaming replication. https://paquier.xyz/postgresql-2/postgres-12-pg-checksums/ https://github.com/credativ/pg_checksums.git for PostgreSQL version <= 11 https://gitlab.com/gitlab-com/gl-infra/infrastructure/-/issues/10827 Data validation must be done by backup utility because it checks all blocks in the database cluster. If there is a mismatch, then the utility can display a warning or finish its job with an error. If there is no mistake, then backup procedure successfully completed.
  3. 4 pg_probackup as a tool for a database cluster backup

    and recovery pg_probackup is a utility to manage backup and recovery of PostgreSQL database clusters. It offers the following benefits: • Incremental backup • Validation and verification • Multiple threads usage to speed up backup and restore • Backup from standby
  4. 5 shared_buffers, work_mem and temp_buffers tuning shared_buffers is used to

    determine how much memory will be allocated for PostgreSQL database for its data caching. A reasonable starting value is ¼ of the memory on the server. work_mem is the advice for the planner about available amount of memory for internal algorithms like sorting and hashing. A reasonable starting value is 10MB. temp_buffers is the maximum amount of memory for storing temporary tables data. If an application doesn’t use it, then this parameter value should be 0.
  5. 6 max_connections tuning max_connections is the maximum number of allowed

    client connections. If max_connections > 1000, consider using connection pooling techniques: • pgbouncer (https://github.com/pgbouncer/pgbouncer) • odyssey (https://github.com/yandex/odyssey) • application server connection pooling (Wildfly)
  6. 7 How much memory should be allocated? shared_buffers + (work_mem

    + temp_buffers) * max_connections should not exceed the maximum amount of memory on the server to avoid forced PostgreSQL main process termination by OOM killer.
  7. 8 Logging parameters in PostgreSQL (1) logging_collector = on log_temp_files.

    Allows to detect queries with heavy temporary files generation. It can be essential to detect recursive queries which are in infinite cycle.
  8. 9 Logging parameters in PostgreSQL (2) Tune log_line_prefix for getting

    more detailed information in a way like this: • %m – timestamp when a log entry was written • %p – PostgreSQL backend identifier • %l - a log entry number inside a PostgreSQL session • %u – database username. • %h – IP-address of PostgreSQL client. • %e – SQLSTATE error code • %x - transaction identifier
  9. 10 Parameters for PostgreSQL planner join_collapse_limit = 30. If the

    value of this parameter is low, then planner can choose non optimal JOINs order.
  10. 11 mamonsu as an active Zabbix agent Mamonsu is a

    monitoring agent for collecting PostgreSQL and system metrics and sending them to Zabbix server: • Works with various operating systems / OSs • 1 agent = 1 database instance • Works with PostgreSQL version >= 9.5 • Provides various metrics related to PostgreSQL activity
  11. 16 List of useful extensions (1) pg_stat_statements for analyzing which

    queries have the longest execution time. pg_stat_kcache for finding queries consuming the most CPU system and user time. auto_explain for finding query plans and parameters for further tuning. pg_wait_sampling for collecting history of wait events and waits profiles.
  12. 17 List of useful extensions (2) pg_profile for creating historic

    workload repository containing various metrics such as: • SQL Query statistics • DML statistics • Schema object statistics • Vacuum-related statistics
  13. 18 List of useful extensions (3) plprofiler for creating performance

    profiles of PL/pgSQL functions and stored procedures. pgpro_stats as a combination of pg_stat_statements, pg_stat_kcache and pg_wait_sampling (only for Postgres Pro customers) pgpro_pwr for gathering information from pgpro_stats (only for Postgres Pro customers)
  14. 21 huge_pages activation (1) If PostgreSQL shared_buffers >= 20GB, it

    is highly recommended to use huge pages to reduce overhead while working with large and continuous regions of memory. For activating it you should take the following steps.
  15. 22 huge_pages activation (2) 1. Determine postmaster pid by watching

    contents of $PGDATA/postmaster.pid. 2. Determine VmPeak by watching contents of /proc/postmaster_pid/status. 3. Determine HugePageSize from /proc/meminfo 4. Divide VmPeak by HugePageSize and save the calculated value in /etc/sysctl.conf file as vm.nr_hugepages = value
  16. 23 transparent_huge_pages deactivation Disable transparent huge pages by executing following

    commands as root user: • echo never > /sys/kernel/mm/transparent_hugepage/enabled • echo never > /sys/kernel/mm/transparent_hugepage/defrag However, some changes must be made to grub config to preserve settings even after the server’s reboot.
  17. 24 Making changes to grub configuration file 1. Install grub2-common

    package. 2. Add hugepage=value at the end of GRUB_CMDLINE_LINUX_DEFAULT in /etc/default/grub file. 3. Add transparent_hugepage=never at the end of GRUB_CMDLINE_LINUX_DEFAULT in /etc/default/grub file. 4. Run update-grub to apply the config to grub and reboot the system.
  18. 25 Checking values of the performance-related parameters After rebooting run

    command grep Huge /proc/meminfo. If HugePages_Total > 0 and AnonHugePages = 0kB then settings have applied correctly. AnonHugePages: 0 kB ShmemHugePages: 0 kB FileHugePages: 0 kB HugePages_Total: 20 HugePages_Free: 20 HugePages_Rsvd: 0 HugePages_Surp: 0 Hugepagesize: 2048 kB Hugetlb: 40960 kB
  19. 26 Memory leak investigation One of our customers noticed that

    some PostgreSQL process was consuming large amount of memory, 1.1GB and asked us to help them in resolving the problem. We need to know function call hierarchy to understand the problem’s origin. Let’s see what it looks like by default without installing any additional packages.
  20. 27 Stack trace without installing any additional packages We can

    see incomplete function call hierarchy which doesn’t help to detect the problem’s origin. To solve this issue, additional packages with debug symbols must be installed. #0 0x0000000000835440 in GetCachedPlan () #1 0x000000000063578d in SPI_plan_get_cached_plan () #2 0x00007f1c6b7528d2 in ?? () from /opt/pgsql/ver- 10/lib/plpgsql.so #3 0x00007f1c6b753b4a in ?? () from /opt/pgsql/ver- 10/lib/plpgsql.so
  21. 28 Debug symbols installation for PostgreSQL (1) Debug symbols allow

    us to get the names of variables, functions and functions calling hierarchy. The debug symbols package’s version must match the server version with minor precision. For example, for PostgreSQL 13.2 the following packages should be installed: • postgresql-client-13-dbsym • postgresql-13-dbgsym • postgresql-plperl-13-dbgsym (in case of using plperl) • postgresql-plpython3-13-dbgsym (in case of using plpython3)
  22. 29 Debug symbols installation for PostgreSQL (2) Some extensions and

    their debug symbols should be installed separately. Let’s consider pg_stat_kcache extension: • postgresql-13-pg-stat-kcache • postgresql-13-pg-stat-kcache-dbgsym
  23. 30 Debug symbols installation for OS (1) echo "deb http://ddebs.ubuntu.com

    $(lsb_release -cs) main restricted universe multiverse deb http://ddebs.ubuntu.com $(lsb_release -cs)-updates main restricted universe multiverse deb http://ddebs.ubuntu.com $(lsb_release -cs)-proposed main restricted universe multiverse" | \ sudo tee -a /etc/apt/sources.list.d/ddebs.list wget --quiet -O - http://ddebs.ubuntu.com/dbgsym-release-key.asc | sudo apt-key add – sudo apt-get update && sudo apt-get install gdb Also debug packages for OS should be installed which can be done the following way:
  24. 31 Debug symbols installation for OS (2) Connect to an

    idle PostgreSQL backend by using sudo gdb –p pid Then gdb will display a list of debug symbols packages that need to be installed. In the case of clean installation of Ubuntu 20.04 the command will looks something like that.
  25. 32 Debug symbols installation for OS (3) apt-get install libxml2-dbgsym

    libssl1.1-dbgsym libcrypto++6-dbg libicu66-dbgsym libc6-dbg libaudit1-dbgsym libkrb5-dbg libldap-2.4-2-dbgsym libsasl2-modules-dbgsym libstdc++6-10-dbg liblz4-1- dbgsym libcrypt1-dbgsym libcap-ng0-dbgsym libkeyutils1-dbgsym libheimntlm0-heimdal-dbgsym libasn1-8-heimdal-dbgsym libhcrypto4-heimdal-dbgsym libidn2-0-dbgsym libunistring2-dbgsym libtasn1-6- dbgsym libnettle7-dbgsym libhogweed5-dbgsym libgmp10-dbgsym libgpg-error0-dbgsym libwind0- heimdal-dbgsym libheimbase1-heimdal-dbgsym libhx509- 5-heimdal-dbgsym libffi7-dbgsym liblzma5-dbgsym
  26. 33 Stack trace after installing packages with debug symbols (1)

    After installing packages with debug symbols, we get a more accurate function call tree. #0 GetCachedPlan (plansource=0x2c4d668, boundParams=boundParams@entry=0x0, useResOwner=1 '\001', queryEnv=0x0) at plancache.c:1308 #1 0x000000000063578d in SPI_plan_get_cached_plan (plan=<optimized out>) at spi.c:1669 #2 0x00007f1c6b7528d2 in exec_simple_check_plan (estate=0x7ffd7f136a00, expr=0x2d42ad0) at pl_exec.c:6954 #3 exec_prepare_plan (estate=0x7ffd7f136a00, expr=0x2d42ad0, cursorOptions=<optimized out>) at pl_exec.c:3743
  27. 34 Setting options for gathering core dump (1) segmentation fault

    is a failure condition associated with memory access violation. The process stops working and generates a core dump file. core dump file is a state of a working memory of a computer program at a specific time of crashing. core_pattern is a template for core dump file’s name. sudo sysctl kernel.core_pattern • kernel.core_pattern = |/usr/share/apport/apport %p %s %c %d %P %E • kernel.core_pattern = |/lib/systemd/systemd-coredump %P %u %g %s %t 9223372036854775808 %h
  28. 35 Setting options for gathering core dump (2) You can

    change kernel.core_pattern setting as follows: sudo sysctl ‘kernel.core_pattern=/tmp/core-%e-%s-%u-%g- %p-%t’ %e – executable filename %s – signal number, which caused core dump generation %u – user identifier of process owner %g – group identifier of process owner %p – terminated process identifier %t – UNIX-time of a dump
  29. 36 Limit settings for PostgreSQL and its client applications (1)

    For client applications like pg_dump, psql and pg_restore limits for maximum file and core dump size should be written in /etc/security/limits.conf as shown below: postgres hard core unlimited postgres soft core unlimited postgres hard fsize unlimited postgres soft fsize unlimited
  30. 37 Limit settings for PostgreSQL and its client applications (2)

    In case of running PostgreSQL as a service by systemd limits can be defined, for example, in a system unit file. For more information, please, consult the following manual page man 5 systemd.exec
  31. 38 Useful links (1) Debug Symbol Packages. https://wiki.ubuntu.com/Debug%20Symbol%20Packages Linux kernel

    documentation. https://www.kernel.org/doc/html/latest/admin- guide/sysctl/kernel.html Apport. https://wiki.ubuntu.com/Apport systemd-coredump. https://man7.org/linux/man- pages/man8/systemd-coredump.8.html Logging in PostgreSQL. https://www.postgresql.org/docs/current/runtime-config- logging.html Planner options in PostgreSQL. https://www.postgresql.org/docs/13/runtime-config-query.html
  32. 39 Useful links (2) pg_checksums for PostgreSQL 12 and higher.

    https://www.postgresql.org/docs/13/app-pgchecksums.html pg_checksums for PostgreSQL version lower than 12. https://github.com/credativ/pg_checksums pg_stat_statements module. https://www.postgresql.org/docs/13/pgstatstatements.html pg_stat_kcache module. https://github.com/powa- team/pg_stat_kcache pg_wait_sampling module. https://github.com/postgrespro/pg_wait_sampling
  33. 40 Useful links (3) auto_explain module. https://www.postgresql.org/docs/13/auto-explain.html pgpro_stats module. https://postgrespro.com/docs/enterprise/12/pgpro-stats

    pg_profile module. https://github.com/zubkov- andrei/pg_profile pgpro_pwr module. https://postgrespro.com/docs/enterprise/12/pgpro-pwr mamonsu. https://github.com/postgrespro/mamonsu pg_probackup. https://github.com/postgrespro/pg_probackup
