Transcript
GitLab 与 libgit2 原理理 Minqi Pan
I’m Minqi Pan github.com/pmq20 twitter @psvr
GitLab 的励志故事 • 2011年年:第⼀一⾏行行代码,基于 Rails 3 • 2012年年:发布 2.1.0~4.0.0 •
2013年年:升级到 Rails 4,发布 6.5.0 在阿姆斯特丹丹注册公司 GitLab B.V. • 2014年年:申请 YC 孵化器成功,发布 7.7.0 获得天使融资12万美⾦金金
GitLab 的励志故事 • 2015年年1⽉月~3⽉月:进驻旧⾦金金⼭山湾区⼭山景城 • 2015年年7⽉月:完成 150万 美元 pre-A 轮融资
• 2015年年9⽉月:完成 570万 美元 A 轮融资 • 2015年年10⽉月:发布 8.1.2
⿊黑盒分析 GitLab
⿊黑盒分析 GitLab HTTP 80 SSH 22 SMTP 25/587
⿊黑盒分析 GitLab Redis Postgre SQL File System
⽩白盒分析 GitLab
⽩白盒分析 NGINX OpenSSH Server Postfix Unicorn Sidekiq Gitlab Workhorse libgit2
gitlab-ci gitlab-rails gitlab-shell mattermost omnibus-ctl git
具体场景分析 • 创建项⽬目 • 通过 HTTP 提交代码 • 通过 SSH
克隆隆项⽬目 • 在⻚页⾯面上查看提交历史
创建项⽬目 浏览器 POST /projects ProjectsController#create CreateService#execute Project#save Postgre SQL NGINX
Unicorn
浏览器 POST /projects … Gitlab::Shell#add_repository GitlabProjects#exec GitlabProjects#add_project $ git \
--git-dir=/home/git/repositories/psvr/repo903.git \ init \ --bare $ /opt/gitlab/embedded/ service/gitlab-shell/ bin/gitlab-projects \ add-project \ psvr/repo903.git FileUtils.ln_sf(“/home/git/gitlab-shell/hooks", "/home/git/repositories/psvr/repo903.git/hooks")
浏览器 POST /projects CreateService#after_create_actions Gitlab::Shell#add_repository ProjectsController#create CreateService#execute Project#save 浏览器 302
重定向
通过 HTTP 提交代码 git push GET http://.../pmq2001/repo903.git/info/ refs?service=git-receive-pack NGINX Gitlab
Workhorse Unicorn func (h *gitHandler) doAuthRequest(r *http.Request) (result *http.Response, err error) GET http://.../pmq2001/repo903.git/ info/refs?service=git-receive-pack 去掉 body
通过 HTTP 提交代码 Unicorn git push … Grack::Auth#auth! Gitlab Workhorse
validated the client request additional request metadata in JSON GET http://.../pmq2001/repo903.git/info/ refs?service=git-receive-pack
通过 HTTP 提交代码 git push GET http://.../pmq2001/repo903.git/info/ refs?service=git-receive-pack … Gitlab
Workhorse $ git \ receive-pack \ --stateless-rpc \ --advertise-refs \ /home/git/repositories/psvr/repo903.git func handleGetInfoRefs (w http.ResponseWriter, r *gitRequest, _ string)
通过 HTTP 提交代码 git push GET http://.../pmq2001/repo903.git/info/ refs?service=git-receive-pack … Gitlab
Workhorse
通过 HTTP 提交代码 git push POST http://.../pmq2001/repo903.git/git- receive-pack NGINX Gitlab
Workhorse Unicorn func (h *gitHandler) doAuthRequest(r *http.Request) (result *http.Response, err error) POST /pmq2001/repo903.git/git-receive- pack 去掉 body
通过 HTTP 提交代码 git push POST http://.../pmq2001/repo903.git/git- receive-pack NGINX Gitlab
Workhorse func handlePostRPC (w http.ResponseWriter, r *gitRequest, rpc string) $ git \ receive-pack \ --stateless-rpc \ /home/git/repositories/psvr/repo903.git
通过 HTTP 提交代码 git push POST http://.../pmq2001/repo903.git/git- receive-pack NGINX Gitlab
Workhorse func handlePostRPC (w http.ResponseWriter, r *gitRequest, rpc string) $ git \ receive-pack \ --stateless-rpc \ /home/git/repositories/psvr/repo903.git $ hooks/pre-receive gitlab-shell
通过 HTTP 提交代码 git push POST http://.../pmq2001/repo903.git/git- receive-pack $ hooks/pre-receive
GitlabAccess#exec … Gitlab Workhorse Unicorn POST "/api/v3/internal/allowed"
通过 HTTP 提交代码 git push POST http://.../pmq2001/repo903.git/git- receive-pack … Unicorn
$ hooks/post-receive Postgre SQL GitlabPostReceive#update_redis Sidekiq PostReceive
通过 HTTP 提交代码 git push POST http://.../pmq2001/repo903.git/git- receive-pack … Unicorn
$ hooks/post-receive GitlabNet#broadcast_message GET /api/v3/internal/broadcast_message Unicorn ProjectCacheWorker Postgre SQL Sidekiq
通过 HTTP 提交代码 git push POST http://.../pmq2001/repo903.git/git- receive-pack NGINX Gitlab
Workhorse
通过 SSH 克隆隆项⽬目 ssh
[email protected]
OpenSSH Server gitlab-shell GitlabShell#exec
通过 SSH 克隆隆项⽬目 ssh
[email protected]
GitlabShell#exec [root@i-jl15ph2j ~]# ssh
[email protected]
Warning: Permanently added 'gitlab.server,1.2.3.4' (RSA) to the list of known hosts. PTY allocation request failed on channel 0 Welcome to GitLab, psvr! Connection to gitlab.server closed. gitlab-shell OpenSSH Server
通过 SSH 克隆隆项⽬目 git clone GitlabShell#verify_access gitlab-shell OpenSSH Server
[email protected]
:psvr/repo903.git
Unicorn POST "/api/v3/internal/allowed"
通过 SSH 克隆隆项⽬目 git clone GitlabShell#verify_access gitlab-shell OpenSSH Server
[email protected]
:psvr/repo903.git
$ git-upload-pack \ /var/opt/gitlab/git-data/repositories/psvr/repo903.git 009bd9be3108e6e60b9954fec57f6ca00d4f74 95170d HEADmulti_ack thin-pack side- band side-band-64k ofs-delta shallow no-progress include-tag multi_ack_detailed 003fd9be3108e6e60b9954fec57f6ca00d4f74 95170d refs/heads/master 0000
在⻚页⾯面上查看提交历史 浏览器 GET Projects::CommitsController#show Repository#commits NGINX Unicorn /psvr/repo903/commits/master gem -
gitlab_git
在⻚页⾯面上查看提交历史 浏览器 GET /psvr/repo903/commits/master gem - gitlab_git … Gitlab::Git::Repository#log $
git \ --git-dir=home/git/repositories/psvr/repo903.git \ -n 10 --format=%H --skip=100 --follow --no-merges
在⻚页⾯面上查看提交历史 浏览器 GET /psvr/repo903/commits/master gem - gitlab_git … Gitlab::Git::Repository#log $
git \ --git-dir=home/git/repositories/psvr/repo903.git \ -n 10 --format=%H --skip=100 --follow --no-merges
在⻚页⾯面上查看提交历史 浏览器 GET /psvr/repo903/commits/master gem - rugged … Rugged::Commit#message rb_git_commit_message_GET
git_commit_message libgit2
libgit2 的特点 portable, pure C, re-entrant, linkable, solid API 提⽰示:对比
ruby 与 mruby
libgit2 是封装良好的 • ⼤大部分头⽂文件位于 src/*.h,是不公开的 • 像最基本的 git_repository 结构体都只有外部声明 •
include/git2/*.h 分类良好,快速定位接⼝口,包含 丰富的注释(对比 mruby =.=) • [ demo ]
libgit2 是抽象良好的 • git2/sys/*_backend.h 解耦, 但是 index 没有解耦 • 通过这些函数挂接新的后端
None
Thank you https://github.com/pmq20/
