The path to memory reduction in RBS

https://docs.google.com/presentation/d/1woy2CHNNTmQbvd0Qc1CA8vz-tnwgp44SDa6yeGPOdcY/edit?usp=sharing

Transcript

1. The path to memory reduction in RBS Money Forward Tech LT大会 vol.2 at Fukuoka Oct. 15th 2024
2. pp self • Pocke • Work for Money Forward • Ruby committer (RBS maintainer) • Rails application developer • From Okayama ◦ My favorite ramen in Okayama🍜 →→
3. Agenda The main theme is reducing memory of RBS and Steep. • Why do I need to reduce memory usage of RBS • Memory Profiling for Ruby • Future plan
4. Glossary • RBS ◦ A library for static typing of Ruby ◦ It provides RBS language, tools, and so on • Steep ◦ A static type checker for Ruby ◦ It uses RBS ◦ It provides CLI tools and LSP server
5. Why do I need to reduce memory usage of RBS?
6. Why is the memory improvement necessary Steep uses too much memory because: • Steep makes resident processes because it works as LSP server • Steep makes many processes ◦ For number of projects using Steep ◦ For number of CPUs because Steep launches workers for parallelization ◦ total_memory = projects.size * CPUs.size * memory_per_process
7. Why is the memory improvement necessary 1 Steep worker process consume ~1.5GB memory in a middle size Rails application e.g. 8 core * 5 project * 1.5GB/proc = 60GB We need to decrease the memory usage in order for Steep to be widely used.
8. Memory Profiling for Ruby
9. Measure. Don't second guess Profiling is important to clarify the bottleneck
10. SamSaffron/memory_profiler Ruby has memory_profiler gem. require 'memory_profiler' arr = [] r = MemoryProfiler.report do Object.new # (1) arr.push Object.new # (2) end r.pretty_print Allocated: (1), (2) Retained: (2)
12. It's really useful gem, but… It is not enough for Steep because: • I want to reduce "peak" memory usage of Steep • It is not efficient to profile peak memory usage
13. Allocated Memory by memory profiler • It traces all allocated memory/objects during profiling • Pros: It's helpful to find a execution time bottleneck caused by memory allocation • Cons: It's not helpful to find the cause of the peak memory usage ◦ Too noisy ◦ Example: Steepのメモリ使用量を改善するつもりが、実行速度の改善をして いた - Money Forward Developers Blog https://moneyforward-dev.jp/entry/2024/07/29/improve-steep-performanc e
14. Retained Memory by memory profiler • It traces all retained memory/objects when the profiling is finished • Pros: It's helpful to find a memory leak • Cons: It's not helpful to find the cause of the peak memory usage ◦ We need to stop profiling on the peak, but the peak is not obvious
15. New memory profiler: Majo🧙 I created a new memory profiler for Ruby to profile peak memory usage. https://github.com/pocke/majo
16. The strategy of Majo • I supposed peak memory usage is approximated as memory usage of long-lived objects • Majo collects allocation info only for long-lived objects ◦ It introduces object lifetime by how many times the object survived GC
17. How Majo cast a spell on Ruby • Ruby provides hooks on Ruby object allocation and `free` • Use TracePoint events ◦ `RUBY_INTERNAL_EVENT_NEWOBJ` ◦ `RUBY_INTERNAL_EVENT_FREEOBJ`
18. CSV format output Majo supports CSV format. It's really useful with Spreadsheet https://docs.google.com/spreadsheets/d/1TnlnLXQTnuDfB3Bhw 0sNp9y2iZObqpkKVeqE--eAdlk/edit?gid=331894152#gid=3318941 52
19. CSV format output on a spreadsheet
20. The result by Majo • Reduce Array allocation during parsing ◦ https://github.com/ruby/rbs/pull/1950 • Reduce Hash allocation during parsing ◦ 不要な処理が実行速度を速くする謎を追う - Money Forward Developers Blog https://moneyforward-dev.jp/entry/2024/09/26/removing-steps-make s-it-slower ◦ I will introduce this patch for the next Ruby version
21. Future plan
22. Future plan I will change Steep's process management more Copy on Write (CoW) friendly.
23. What's Copy on Write It's a technique to wait Copying before Writing This slides focus on CoW for memory management by *nix on `fork`. Note: `fork` is an API to duplicate a process on *nix OS🍴
24. # Memory [1, 2, 3] Copy on Write Example (1) # Process A x = [1, 2, 3] if fork x.push(42) p x else p x end
25. # Memory [1, 2, 3] Copy on Write Example (2) # Process A x = [1, 2, 3] if fork x.push(42) p x else p x end # Process A' x = [1, 2, 3] if fork x.push(42) p x else p x end
26. # Memory [1, 2, 3, 42] # Copying! [1, 2, 3] Copy on Write Example (3) # Process A x = [1, 2, 3] if fork x.push(42) p x else p x end # Process A' x = [1, 2, 3] if fork x.push(42) p x else p x end
27. The current process management of Steep Steep LSP uses Master-Workers structure. Steep Master Steep Worker 3 Steep Worker 2 Steep Worker 1 fork fork fork • Master ◦ Communicate the LSP client and workers • Workers ◦ Process LSP features ◦ Type checking, complement, hover, …
28. The current process management of Steep All workers have different RBS::Environment. Steep Master Steep Worker 3 Steep Worker 2 Steep Worker 1 fork fork fork RBS::Env 1 RBS::Env 3 RBS::Env 2
29. Solution: Fork-Worker and Reforking A CoW friendly process management structure for the Master-Worker model • In the traditional Master-Worker model, workers are forked from the master process • In Fork-Worker, workers are forked from a worker process I borrowed this idea from puma and pitchfork (HTTP server for Ruby) https://github.com/puma/puma/blob/master/docs/fork_worker.md
30. Fork-Worker All workers share the same memory Steep Master Steep Worker 3 Steep Worker 2 Steep Worker 1 fork fork fork RBS::Env
31. Reforking Restart workers after a while Steep Master Steep Worker 3 Steep Worker 2 Steep Worker 1 fork kill kill RBS::Env
32. Reforking Restart workers after a while Steep Master Steep Worker 1 fork RBS::Env
33. Reforking Restart workers after a while Steep Master Steep Worker 3 Steep Worker 2 Steep Worker 1 fork refork refork RBS::Env
34. Conclusion
35. Conclusion • New memory profiler: Majo ◦ It collects long-lived object allocations • Steep will have more CoW-friendly structure ◦ Fork worker and Reforking Thanks for listening!
