PyQt で中古オシロスコープを操作
Slides I used in Open Source UN-Conference 2017 Kawagoe
Daniel Sangorrin
April 15, 2017
Transcript
21 slides
PyQt で中古オシロスコープを操作 @daromart http://sangorrin.github.com http://sangorrin.blogspot.com http://sangorrin.blogspot.com Daniel Sangorrin ( ダニエル
)
前回の OSunC 川越 • Octave (Matlab の OSS 版 )
– スライド等は github.com/sangorrin においてある • 発表後、観光してたら… 怪しい人
デッカイ デッカイ カメレオン カメレオン ここ! ここ! 時の鐘 OpenSuse のファン どうぞ!
今回の発表 ヒゲが ヒゲが ない時 ない時 対象物
あるサイトでオシロを購入した • 岩通 BRINGO DS 8812 100MHz 500MS/s • 小さくて、そこそこ安かったけど…
画面右側に 画面右側に 乱れが! 乱れが!
頑張って分解したが、 直せなかった
しかも、もう一度 組み立てると…
なにこれ! なにこれ!
男も悩む… LCD を入れ 替えたら どう? いやー お金の無駄に なるかな~ てか、俺は ソフトのガイ
だぜ!
シリアルポートがあるじゃん • オシロのマニュアルにプロトコルの説明がある! (c) IWATSU ELECTRIC CO.,LTD
運が良ければ少し見えるよ。 さて、シリアルポートを 設定しよう!
これは大事! オシロ オシロ PC PC
Hello world (1/2) (c) IWATSU ELECTRIC CO.,LTD DATE?
Hello world (2/2) Ack '\x06' CR→CR+LF DATE 結果
Qt Designer によるカッコイイ GUI
Signals: クリックするとこの関数を
後は Python コードを書くだけ $ pyuic4 window.ui > window.py $ kate
logic from PyQt4 import QtGui from window import Ui_MainWindow class Main(QtGui.QMainWindow, Ui_MainWindow): def __init__(self, ): super(Main, self).__init__() self.setupUi(self) ... if __name__ == '__main__': app = QtGui.QApplication(sys.argv) main = Main() main.show() sys.exit(app.exec_()) https://github.com/sangorrin/iwatsu-ds-8812-bringo-dso-application.git
決まる! 決まる!
決まる! 決まる!
おわり @daromart http://sangorrin.github.com http://sangorrin.blogspot.com http://sangorrin.blogspot.com スライドはこっち: https://speakerdeck.com/sangorrin (slideshare やめよう! )
