IRPF90 : a Fortran code generator for HPC

IRPF90 presented at PyConFr
Video available here :
http://www.infoq.com/fr/presentations/irpf90-fortran-code-generator-hpc

Transcript

1. IRPF90 : a Fortran code generator for HPC Anthony Scemama¹ <scemama@irsamc.ups-tlse.fr> François Colonna² ¹ Labratoire de Chimie et Physique Quantiques IRSAMC (Toulouse) ² Laboratoire de Chimie Théorique (Paris) 26/10/2014
2. Scientific codes • Scientific codes need speed -> Fortran • Fortran is a low level language -> difficult to maintain • High-level features of Fortran 95 kill the efficiency (pointers, array syntax, etc) -> not a good solution • Less effort in program development and good efficiency with Python/Numpy or Python/F2Py • Other option : use Python to write low level Fortran code 1 / 22 http://irpf90.ups-tlse.fr
3. What is a scientific code? A program is a function of its input data: output = program (input) A program can be represented as a production tree where • The nodes are the variables • The vertices represent the relation needs/needed by Example: u(x,y) = x + y + 1 v(x,y) = x + y + 2 w(x) = x + 3 t(x,y) = x + y + 4 What is the production tree of t( u(d1,d2), v( u(d3,d4), w(d5) ) )? 2 / 22 http://irpf90.ups-tlse.fr
4. What is the production tree of t( u(d1,d2), v( u(d3,d4), w(d5) ) )? u(x,y) = x + y + 1 v(x,y) = x + y + 2 w(x) = x + 3 t(x,y) = x + y + 4 u1 t v d1 d2 u2 w d3 d4 d5 3 / 22 http://irpf90.ups-tlse.fr
5. Fortran way of programming def fu(x,y): return x+y+1 def fv(x,y): return x+y+2 def fw(x) : return x+3 def ft(x,y): return x+y+4 def input_data(): # ... return d1, d2, d3, d4, d5 def main(): # t d1,d2,d3,d4,d5 = input_data()# / \ u1 = fu(d1, d2) # u1 v u2 = fu(d3, d4) # / | | \ w = fw(d5) # d1 d2 u2 w v = fv(u2, w) # / \ \ print ft(u1, v) # d3 d4 d5 4 / 22 http://irpf90.ups-tlse.fr
6. Difficulties The subroutines need to be called in the correct order: • The programmers needs have the knowledge of the production tree • Production trees are usually too complex to be handled by humans • Collaborative work is difficult : any user can alter the production tree • Programmers may not be sure that their modification did not break some other part 5 / 22 http://irpf90.ups-tlse.fr
7. IRP way of programming • There is only one way to build a value : by calling its provider • Provider : • If the value is already built : return the previous value (memo function) • Otherwise : call the providers of the needed entities and then build the value Advantages: • The provider guarantees that the value is valid • Only a local knowledge of the production tree : the needed entities • This is equivalent to calling t( u(d1,d2), v( u(d3,d4), w(d5) ) ). As there is only one set of possible parameters for each function (the needed entities are always the same), the parameters can be embedded inside the functions. IRP : functions with Implicit Reference to Parameters 6 / 22 http://irpf90.ups-tlse.fr
8. Example import sys def irp(f): """All the IRP entities are represented inside a common class. This function generates the provider of an entity. f is the function that builds the entity. """ # Switch the current environment to the class containing the # IRP entities locals = sys._getframe(1).f_locals # Name of the memo value : _f cache = "_"+f.__name__ # Generic provider 7 / 22 http://irpf90.ups-tlse.fr
9. def provider(self): # Check if self._f exists try: result = getattr(self,cache) print " -- Already built "+f.__name__ except AttributeError: # If self._f doesn't exist, build it print " -> Building "+f.__name__ result = f(self) setattr(self,cache,result) print " <- Done building "+f.__name__ # Return self._f return result # Return a class property to call the provider return property(fget=provider) 8 / 22 http://irpf90.ups-tlse.fr
10. class MyProgram(object): def u1(self): # u(x,y) = x + y + 1 return self.d1 + self.d2 + 1 u1 = irp(u1) def u2(self): # u(x,y) = x + y + 1 return self.d3 + self.d4 + 1 u2 = irp(u2) def v(self): # v(x,y) = x + y + 2 return self.u2 + self.w + 2 v = irp(v) def w(self): # w(x) = x + 3 return self.d5 + 3 w = irp(w) 9 / 22 http://irpf90.ups-tlse.fr
11. def t(self): # t(x,y) = x + y + 4 return self.u1 + self.v + 4 t = irp(t) def d(self): return range(1,6) d = irp(d) d1 = property(lambda self: self.d[0]) d2 = property(lambda self: self.d[1]) d3 = property(lambda self: self.d[2]) d4 = property(lambda self: self.d[3]) d5 = property(lambda self: self.d[4]) def main(): p = MyProgram() print "u1 : " ; print p.u1 print "t : " ; print p.t 10 / 22 http://irpf90.ups-tlse.fr
12. main() u1 : # t -> Building u1 # / \ -> Building d # u1 v <- Done building d # / | | \ -- Already built d # d1 d2 u2 w <- Done building u1 # / \ \ 4 # d3 d4 d5 t : -> Building t -- Already built u1 -> Building v -> Building u2 -- Already built d -- Already built d <- Done building u2 -> Building w 11 / 22 http://irpf90.ups-tlse.fr
13. -- Already built d <- Done building w <- Done building v <- Done building t 26 12 / 22 http://irpf90.ups-tlse.fr
14. How to do this with Fortran? Fortran doesn't have exceptions, introspection, properties, etc. Solution IRPF90: • Add a few keywords to Fortran • Use Python to read the code • Python builds the dependence tree • Python writes the missing Fortran source lines to handle the tree Example with IRPF90 BEGIN_PROVIDER [ integer, t ] t = u1+v+4 END_PROVIDER BEGIN_PROVIDER [integer,w] w = d5+3 13 / 22 http://irpf90.ups-tlse.fr
15. END_PROVIDER BEGIN_PROVIDER [ integer, v ] v = u2+w+2 END_PROVIDER BEGIN_PROVIDER [ integer, u1 ] integer :: fu ! u1 = fu(d1,d2) u1 = d1+d2+1 END_PROVIDER BEGIN_PROVIDER [ integer, u2 ] integer :: fu ! u2 = fu(d3,d4) u2 = d3+d4+1 ASSERT (u2 > d3) END_PROVIDER 14 / 22 http://irpf90.ups-tlse.fr
16. integer function fu(x,y) integer :: x,y fu = x+y+1 end function program irp_example print *, 't = ', t end 15 / 22 http://irpf90.ups-tlse.fr
17. Features Arrays BEGIN_PROVIDER [ double precision, A, (dim1, 3) ] ... END_PROVIDER • Allocation of IRP arrays done automatically • Dimensioning variables can be IRP entities, provided before the memory allocation 16 / 22 http://irpf90.ups-tlse.fr
18. Documentation Every subroutine/function/provider can have a documentation section: BEGIN_PROVIDER [ double precision, Fock_matrix_beta_mo, (mo_tot_num_align,mo_tot_num) ] implicit none BEGIN_DOC ! Fock matrix on the MO basis END_DOC ... END_PROVIDER $ irpman fock_matrix_beta_mo 17 / 22 http://irpf90.ups-tlse.fr
19. IRPF90 entities(l) fock_matrix_beta_mo IRPF90 entities(l) Declaration double precision, allocatable :: fock_matrix_beta_mo (mo_tot_num_align,mo_tot_num) Description Fock matrix on the MO basis File Fock_matrix.irp.f Needs ao_num fock_matrix_alpha_ao mo_coef mo_tot_num mo_tot_num_align Needed by fock_matrix_mo IRPF90 entities fock_matrix_beta_mo IRPF90 entities(l) 18 / 22 http://irpf90.ups-tlse.fr
20. Iterative processes Iterative processes may involve cyclic dependencies: TOUCH A : A is valid, but everything that needs A is invalidated 19 / 22 http://irpf90.ups-tlse.fr
21. Meta-programming BEGIN_SHELL [ /bin/bash ] echo print *, \'Compiled by `whoami` on `date`\' echo print *, \'$FC $FCFLAGS\' echo print *, \'$IRPF90\' END_SHELL BEGIN_SHELL [ /usr/bin/python ] for i in range(10): print """ double precision function times_%d(x) double precision, intent(in) :: x times_%d = x*%d end """%locals() END_SHELL 20 / 22 http://irpf90.ups-tlse.fr
22. Many Other features • Color highlighting in Vi • Generation of tags to navigate in the code • Variables can be declared anywhere • Dependencies are known by IRPF90 -> Makefiles are built automatically • No problem using external libraries (MKL, MPI, etc) • Compatible with OpenMP • Support for Coarray Fortran (distributed parallelism) • Codelet generation for code optimization • Generation of Intel Fortran compiler directives to align arrays • Generated code is very efficient (960 Tflops/s on Curie in 2011 with QMC=Chem) • etc... 21 / 22 http://irpf90.ups-tlse.fr
