Parallel programming

Parallel programming

Lecture given for master students in quantum chemistry

Anthony Scemama

September 22, 2014
Tweet

More Decks by Anthony Scemama

Other Decks in Programming

Transcript

  1. Intro All the source files of this course can be

    found on GitHub: http://github.com/scemama/tccm2014 Warning You are not expected to be able to do by yourself everything I will show! My goal: • Show you different visions of parallel computing • Introduce some words you will here in the future • Show you what exists, what can be done, and how Don't panic and consider this class as general knowledge. If you don't understand something, please STOP ME! 1
  2. What is parallelism? When solving a problem, multiple calculations can

    be carried out concurrently. If multiple computing hardware is used, concurrent computing is called parallel computing. Many levels of parallelism: • Distributed, Loosely-coupled : Computing grids : shell scripts • Distributed, Tightly-coupled : Supercomputers : MPI, sockets, CoArray Fortran, UPC,... • Hybrid: wth accelerators like GPUs, FPGAs, Xeon Phi, etc • Shared memory : OpenMP, threads • Socket-level : Shared cache • Instruction-level : superscalar processors • Bit-level : vectorization All levels of parallelism can be exploited in the same code, but every problem is not parallelizable at all levels. 2
  3. Index Intro 1 What is parallelism? 2 Problem 1 :

    Potential energy surface 7 GNU Parallel 9 Potential energy surface 14 Links 20 Problem 2 : Computation of Pi 21 Inter-process communication 26 Processes vs threads 26 Communication with named pipes 27 Communication with unnamed pipes 31 Sockets 46 Remote procedure call (RPC) 62 3
  4. Problem 3 : Numerical computation of a 2-electron integral 84

    Message Passing Interface 87 Synchronization 89 Point-to-point send/receive operation 89 Collective communications 90 Two-electron integral using MPI 93 Links 101 Coarray Fortran (CAF) 102 Calculation of the 2-electron integral 104 Links 109 Problem 4: Parallelization of a matrix product 110 Threads 118 pthreads 118 Locks 121 4
  5. OpenMP 125 Matrix product : simple OpenMP example 128 Loop

    parallelism 128 Task parallelism 135 Divide and Conquer algorithms 142 Example : Sum 142 Divide and Conquer matrix product 147 Vectorization 159 Automatic vectorization 160 Intel specific Compiler directives 162 Instruction-level parallelism (ILP) 166 Pipelining 167 Out of order execution 170 Branch prediction 170 5
  6. Problem 1 : Potential energy surface We want to create

    the CCSD(T) potential energy surface of the water molecule. 7
  7. Constraints: • We want to compute 25x25x25 = 15625 points

    • We are allowed to use 100 CPU cores simultaneously • We like to use Gaussian09 to calculate the CCSD(T) energy But: • The grid points are completely independent • Any CPU core can calculate any point Optimal solution: work stealing • One grid point is E(r1,r2,angle) • Dress the list of all the arguments (r1,r2,angle) : [ (0.8,0.8,70.), ..., (1.1,1.1,140.) ] (the queue) • Each CPU core, when idle, pops out the head of the queue and computes E(r1,r2,angle) • All the results are stored in a single file • The results are sorted for plotting 8
  8. GNU Parallel GNU parallel executes Linux commands in parallel and

    can guarantee that the output is the same as if the commands were executed sequentially. Example: $ parallel echo ::: A B C A B C is equivalent to: $ echo A ; echo B ; echo C Multiple input sources can be given: $ parallel echo ::: A B ::: C D A C A D 9
  9. B C B D If no command is given after

    parallel the arguments are treated as commands: $ parallel ::: pwd hostname "echo $TMPDIR" /home/scemama lpqdh82 /tmp Jobs can be run on remote servers: $ parallel ::: echo hostname lpqdh82.ups-tlse.fr $ parallel -S lpqlx139.ups-tlse.fr ::: echo hostname lpqlx139.ups-tlse.fr File can be transfered to the remote hosts: 10
  10. $ echo Hello > input $ parallel -S lpqlx139.ups-tlse.fr cat

    ::: input cat: input: No such file or directory $ echo Hello > input $ parallel -S lpqlx139.ups-tlse.fr --transfer --cleanup cat ::: input Hello 11
  11. Convert thousands of images from .gif to .jpg $ ls

    img1000.gif img241.gif img394.gif img546.gif img699.gif img850.gif img1001.gif img242.gif img395.gif img547.gif img69.gif img851.gif [...] img23.gif img392.gif img544.gif img697.gif img849.gif img240.gif img393.gif img545.gif img698.gif img84.gif To convert one .gif file to .jpg format: $ time convert img1.gif img1.jpg real 0m0.008s user 0m0.000s sys 0m0.000s Sequential execution: $ time for i in {1..1011} > do > convert img${i}.gif img${i}.jpg 12
  12. > done real 0m7.936s user 0m0.210s sys 0m0.270s Parallel execution

    on a quad-core: $ time parallel convert {.}.gif {.}.jpg ::: *.gif real 0m2.051s user 0m1.000s sys 0m0.540s 13
  13. Potential energy surface 1. Fetch the energy in an output

    file Running a CCSD(T) calculation with Gaussian09 gives the energy somewhere in the output: CCSD(T)= -0.76329294074D+02 To get only the energy in the output, we can use the following command: g09 < input | grep "^ CCSD(T)=" | cut -d "=" -f 2 2. Script that takes r1, r2 and angle as arguments We create a script run_h2o.sh that runs Gaussian09 for the water molecule taking r 1 , r 2 , and angle as command-line parameters, and prints the CCSD(T) energy: #!/bin/bash r1=$1 14
  14. r2=$2 angle=$3 # Create Gaussian input file, pipe it to

    Gaussian, grep the CCSD(T) # energy cat << EOF | g09 | grep "^ CCSD(T)=" | cut -d "=" -f 2 # CCSD(T)/cc-pVTZ Water molecule r1=${r1} r2=${r2} angle=${angle} 0 1 h o 1 ${r1} h 2 ${r2} 1 ${angle} EOF Example: 15
  15. $ ./run_h2o.sh 1.08 1.08 104. -0.76310788178D+02 $ ./run_h2o.sh 0.98 1.0

    100. -0.76330291742D+02 3. Files containing arguments We prepare a file r1_file containing the r values: 0.75 0.80 0.85 0.90 0.95 1.00 then, a file angle_file containing the angle values: 100. 101. 16
  16. 102. 103. 104. 105. 106. and a file nodefile containing

    the names of the machines and their number of CPUs: 2//usr/bin/ssh compute-0-10.local 2//usr/bin/ssh compute-0-6.local 16//usr/bin/ssh compute-0-12.local 16//usr/bin/ssh compute-0-5.local 16//usr/bin/ssh compute-0-7.local 6//usr/bin/ssh compute-0-1.local 2//usr/bin/ssh compute-0-13.local 4//usr/bin/ssh compute-0-8.local 17
  17. 4. Run with GNU parallel Let's first run the job

    on 1 CPU: $ time parallel -a r1_file -a r1_file -a angle_file \ --keep-order --tag -j 1 $PWD/run_h2o.sh 0.75 0.75 100. -0.76185942070D+02 0.75 0.75 101. -0.76186697072D+02 0.75 0.75 102. -0.76187387594D+02 [...] 0.80 1.00 106. -0.76294078963D+02 0.85 0.75 100. -0.76243282762D+02 0.85 0.75 101. -0.76243869316D+02 [...] 1.00 1.00 105. -0.76329165017D+02 1.00 1.00 106. -0.76328988177D+02 real 15m5.293s user 11m25.679s 18
  18. sys 2m20.194s Running in parallel on 64 CPUs with the

    --keep-order option, the output is the same, but it takes 39x less time! $ time parallel -a r1_file -a r1_file -a angle_file \ --keep-order --tag --sshloginfile nodefile $PWD/run_h2o.sh 0.75 0.75 100. -0.76185942070D+02 0.75 0.75 101. -0.76186697072D+02 0.75 0.75 102. -0.76187387594D+02 [...] 0.80 1.00 106. -0.76294078963D+02 0.85 0.75 100. -0.76243282762D+02 0.85 0.75 101. -0.76243869316D+02 [...] 1.00 1.00 105. -0.76329165017D+02 1.00 1.00 106. -0.76328988177D+02 real 0m23.848s 19
  19. user 0m3.359s sys 0m3.172s Links • O. Tange (2011): GNU

    Parallel - The Command-Line Power Tool, ;login: The USENIX Magazine, February 2011:42-47. • GNU parallel • GNU parallel tutorial 20
  20. Problem 2 : Computation of Pi We want to compute

    the value of with a Monte Carlo algorithm. • The surface of the circle is => For a unit circle, the surface is • The function in the red square is (the circle is ) • The surface in grey corresponds to 21
  21. Z 1 0 q 1¡x2 dx =¼=4 To compute this

    integral, a Monte Carlo algorithm can be used: • Points are drawn randomly in the unit square. • Count how many times the points are inside the circle • The ratio (inside)/(inside+outside) is . 22
  22. Constraints: • A large number of Monte Carlo steps will

    be computed ( ) • We are allowed to use 100 CPU cores simultaneously • We stop when the statistical error is below a given threshold ( ) Optimal algorithm: • Each CPU core computes the its own average over a smaller number of Monte Carlo steps ( ) compute_pi() { result := 0 for i=1 to NMAX { x = random() ; y = random() if ( x^2 + y^2 <= 1 ) { result := result + 1 } } return 4*result/NMAX 23
  23. } • All results obtained on different CPU cores are

    independent, so they are Gaussian-distributed random variables (central-limit theorem) • The are sent to a central server • The central server computes the running average ¼ » ¹ X = 1 M M X i =1 Xi and the variance ¾2 = 1 M¡1 M X i =1 (Xi ¡ ¹ X)2 to compute the statistical error as • The clients compute blocks as long as the central server asks them to do so when is above the target error 24
  24. Client Server X Client X Client X Client X Here,

    the calculations are no more independent: the stopping criterion depends on the results of all previous runs. We have introduced very simple inter-process communications. 25
  25. Inter-process communication Processes vs threads Process: • Has its own

    memory address space • Context switching between processes is slow • Processes interact only through system-provided communication mechanisms • Fork: creates a copy of the current process • Exec: switches to running another binary executable • Spawn: Fork and exec on the child Theads: • Exist as subsets of a process • Context switching between threads is fast • Share the same memory address space : interact via shared memory 26
  26. Communication with named pipes A named pipe is a virtual

    file which is read by a process and written by other processes. It allows processes to communicate using standard I/O operations: 27
  27. Process 1: p1.sh #!/bin/bash # Create two pipes using the

    mkfifo command mkfifo /tmp/pipe /tmp/pipe2 # Unzip the input file and write the result # in the 1st pipe echo "Run gunzip" gunzip --to-stdout input.gz > /tmp/pipe # Zip what comes from the second pipe echo "Run gzip" gzip < /tmp/pipe2 > output.gz # Clear the pipes in the filesystem rm /tmp/pipe /tmp/pipe2 Process 2: p2.sh 29
  28. #!/bin/bash # Read the 1st pipe, sort the result and

    write # in the 2nd pipe echo "Run sort" sort < /tmp/pipe > /tmp/pipe2 Execution: $ ./p1.sh & Run gunzip $ ./p2.sh Run sort Run gzip [1]+ Done ./p1.sh This simple example is equivalent to: gunzip --to-stdout input.gz | sort | gzip > output.gz 30
  29. But the two programs p1.sh and p2.sh: • can be

    started independently : p1 waits for p2 (blocking) • can be run in different shells • named pipes allow multiple processes to write in the same pipe Communication with unnamed pipes Unnamed pipes are equivalent to pipes, but they are opened/closed in the programs themselves. They imply a modification of the source files (apart from using unnamed pipes in the shell with the | operator). 31
  30. #!/usr/bin/env python import sys,os def main(): # Print process ID

    (PID) of the current process print "PID: %d" % (os.getpid()) # Open the pipe for inter-process communication r, w = os.pipe() new_pid = os.fork() if new_pid != 0: # This is the parent process print "I am the parent, my PID is %d"%(os.getpid()) print "and the PID of my child is %d"%(new_pid) # Close write and open read file descriptors os.close(w) 33
  31. r = os.fdopen(r,'r') # Read data from the child print

    "Reading from the child" s = r.read() r.close() print "Read '%s' from the child"%(s) else: # This is the child process print " I am the child, my PID is %d"%(os.getpid()) # Close read and open write file descriptors os.close(r) w = os.fdopen(w,'w') print " Sending 'Hello' to the parent" # Send 'Hello' to the parent w.write( "Hello!" ) w.close() print " Sent 'Hello'" 34
  32. if __name__ == "__main__": main() $ ./fork.py PID: 5804 I

    am the parent, my PID is 5804 and the PID of my child is 5805 I am the child, my PID is 5805 Reading from the child Sending 'Hello' to the parent Sent 'Hello' Read 'Hello!' from the child 35
  33. Computation of with pipes Pseudo-code for i=1 to NPROC {

    pipe(i) := create_pipe() fork() if ( Child process ) { close(pipe(i).read ) open (pipe(i).write) do { X := compute_pi() write X into pipe if ( failure ) { exit process } } } close(pipe(i).write) 36
  34. open (pipe(i).read ) } data := [] N := 0

    do { for i=1 to NPROC { X := pipe(i).read() data := data+[X] N := N+1 ave := average(data) err := error (data) if (error < error_threshold) { print ave and err exit process } } } 37
  35. Python implementation #!/usr/bin/env python NMAX = 10000000 # Nb of

    MC steps/process NMAX_inv = 1.e-7 error_threshold = 1.0e-4 # Stopping criterion NPROC=4 # Use 4 processes import os from random import random, seed from math import sqrt def compute_pi(): """Local Monte Carlo calculation of pi""" # Initialize random number generator seed(None) result = 0. 38
  36. # Loop 10^7 times for i in xrange(NMAX): # Draw

    2 random numbers x and y x = random() y = random() # Check if (x,y) is in the circle if x*x + y*y <= 1.: result += 1 # X = estimation of pi result = 4.* float(result)*NMAX_inv return result import sys def main(): # Reading edges of the pipes r = [None]*NPROC 39
  37. # Running processes pid = [None]*NPROC for i in range(NPROC):

    # Create the pipe r[i], w = os.pipe() # Save the PIDs pid[i] = os.fork() if pid[i] == 0: # This is the child process os.close(r[i]) w = os.fdopen(w,'w') while True: # Compute pi on this process X = compute_pi() # Write the result in the pipe try: 40
  38. w.write("%f\n"%(X)) w.flush() except IOError: # Child process exits here sys.exit(0)

    else: # This is the parent process os.close(w) r[i] = os.fdopen(r[i],'r') data = [] while True: for i in range(NPROC): # Read in the pipe of the corresponding process X = float( r[i].readline() ) data.append( float(X) ) N = len(data) 41
  39. # Compute average average = sum(data)/N # Compute variance if

    N > 2: l = [ (x-average)*(x-average) for x in data ] variance = sum(l)/(N-1.) else: variance = 0. # Compute error error = sqrt(variance)/sqrt(N) print '%f +/- %f'%(average,error) # Stopping condition if N > 2 and error < error_threshold: 42
  40. # Kill children for i in range(NPROC): try: os.kill(pid[i],9) except:

    pass sys.exit(0) if __name__ == '__main__': main() $ ./pi_fork.py 3.142317 +/- 0.000000 3.141778 +/- 0.000000 3.141344 +/- 0.000534 3.141377 +/- 0.000379 3.141422 +/- 0.000297 3.141443 +/- 0.000243 3.141485 +/- 0.000210 43
  41. [...] 3.141513 +/- 0.000041 3.141513 +/- 0.000041 3.141514 +/- 0.000040

    3.141512 +/- 0.000040 3.141513 +/- 0.000040 3.141515 +/- 0.000040 44
  42. 3.1413 3.14135 3.1414 3.14145 3.1415 3.14155 3.1416 3.14165 3.1417 0

    20 40 60 80 100 120 140 160 180 Pi Number of blocks Convergence of the Monte Carlo average 45
  43. Sockets Sockets are analogous to pipes, but they allow both

    ends of the pipe to be on different machines connected by a network interface. An Internet socket is characterized by a unique combination of : • A transport protocol: TCP, UDP, raw IP, ... • A local socket address: Local IP address and port number, for example 192.168.2.2:22 • A remote socket address: Optional (TCP) 46
  44. Server code: HOSTNAME := "server.tccm.fr" PORT := 2014 socket :=

    create_INET_socket() bind( socket, (HOSTNAME, PORT) ) listen(socket) (client_socket, address) := accept(socket) data = recv(client_socket) send(client_socket,"Thank you") close(client_socket) Client code: HOSTNAME := "server.tccm.fr" PORT := 2014 socket := create_INET_socket() connect( socket, (HOSTNAME, PORT) ) message = "Hello, world !!!!!!" 48
  45. send(socket,message) reply = recv(socket) Python implementation Server code: #!/usr/bin/env python

    import sys,os import socket import datetime # For printing the time now = datetime.datetime.now def main(): # Get host name HOSTNAME = socket.gethostname() PORT = 11279 49
  46. print now(), "I am the server : %s:%d"%(HOSTNAME,PORT) # Create

    an INET socket s = socket.socket(socket.AF_INET, socket.SOCK_STREAM) # Bind the socket to the address and port s.bind( (HOSTNAME, PORT) ) # Wait for incoming connections s.listen(5) # Accept connection conn, addr = s.accept() print now(), "Connected by", addr # Buffered read of the socket print now(), "Reading from socket" data = "" 50
  47. while True: message = conn.recv(8) print now(), "Buffer : "+message

    data += message if message == "" or len(message) < 8: break print now(), "Received data : ", data print now(), "Sending thank you..." conn.send("Thank you") print now(), "Closing socket" conn.close() if __name__ == "__main__": main() Client code: 51
  48. #!/usr/bin/env python import sys,os import socket import datetime now =

    datetime.datetime.now def main(): # Get host name HOSTNAME = sys.argv[1] PORT = int(sys.argv[2]) print now(), "The target server is : %s:%d"%(HOSTNAME,PORT) # Create an INET socket s = socket.socket(socket.AF_INET, socket.SOCK_STREAM) # Connect the socket to the address and port of the server 52
  49. s.connect( (HOSTNAME, PORT) ) # Send the data message =

    "Hello, world !!!!!!" print now(), "Sending : "+message s.send(message) # Read the reply of the server data = s.recv(1024) s.close() print now(), 'Received: ', data if __name__ == "__main__": main() Server execution: $ ./sock_server.py 2014-09-04 01:13:49.903443 I am the server : lpqdh82:11279 53
  50. 2014-09-04 01:13:53.387956 Connected by ('127.0.0.1', 44373) 2014-09-04 01:13:53.388007 Reading from

    socket 2014-09-04 01:13:53.388029 Buffer : Hello, w 2014-09-04 01:13:53.388046 Buffer : orld !!! 2014-09-04 01:13:53.388060 Buffer : !!! 2014-09-04 01:13:53.388071 Received data : Hello, world !!!!!! 2014-09-04 01:13:53.388081 Sending thank you... 2014-09-04 01:13:53.388157 Closing socket Client execution: $ ./sock_client.py lpqdh82 11279 2014-09-04 01:13:53.387347 The target server is : lpqdh82:11279 2014-09-04 01:13:53.387880 Sending : Hello, world !!!!!! 2014-09-04 01:13:53.388277 Received: Thank you 54
  51. Computation of with sockets Server: #!/usr/bin/env python HOSTNAME = "localhost"

    PORT = 1666 error_threshold = 4.e-5 # Stopping criterion import sys,os import socket from math import sqrt def main(): data = [] # Create an INET socket s = socket.socket(socket.AF_INET, socket.SOCK_STREAM) 55
  52. # Bind the socket to the address and port s.bind(

    (HOSTNAME, PORT) ) while True: # Wait for incoming connections s.listen(5) # Accept connection conn, addr = s.accept() # Buffered read of the socket X = "" while True: message = conn.recv(128) X += message if message == "" or len(message) < 128: break 56
  53. data.append( float(X) ) N = len(data) # Compute average average

    = sum(data)/N # Compute variance if N > 2: l = [ (x-average)*(x-average) for x in data ] variance = sum(l)/(N-1.) else: variance = 0. # Compute error error = sqrt(variance)/sqrt(N) print '%f +/- %f'%(average,error) 57
  54. # Stopping condition if N > 2 and error <

    error_threshold: conn.send("STOP") break else: conn.send("OK") conn.close() if __name__ == "__main__": main() Client: #!/usr/bin/env python NMAX = 10000000 # Nb of MC steps/process NMAX_inv = 1.e-7 HOSTNAME = "localhost" 58
  55. PORT = 1666 from random import random, seed import socket

    import sys def compute_pi(): """Local Monte Carlo calculation of pi""" # Initialize random number generator seed(None) result = 0. # Loop 10^7 times for i in xrange(NMAX): # Draw 2 random numbers x and y x = random() y = random() # Check if (x,y) is in the circle 59
  56. if x*x + y*y <= 1.: result += 1 #

    X = estimation of pi result = 4.* float(result)*NMAX_inv return result def main(): while True: X = compute_pi() # Create an INET socket s = socket.socket(socket.AF_INET, socket.SOCK_STREAM) # Connect the socket to the address and port of the server try: s.connect( (HOSTNAME, PORT) ) except socket.error: 60
  57. break # Send the data message = str(X) s.send(message) #

    Read the reply of the server reply = s.recv(128) s.close() if reply == "STOP": break if __name__ == '__main__': main() 61
  58. Remote procedure call (RPC) RPC enables software written in different

    languages and running on different computers to work with each other seamlessly. One program running in a process (the client) calls a function belonging to another program running in another process (the server). All the inter-process communication is hidden. 62
  59. 1. The client calls the stub : the parameters are

    converted to a standard representation (de-referencing pointers, big/little endian, etc) 2. The client stub marshals the parameters : they are packed together in a message. 3. The message is sent to the server 4. The server transmits the message to the server stub 5. The server stub unmarshals the message 6. The server calls its subroutine with the parameters 7. The output is sent back to the client using the same mechanism 63
  60. Some RPC implementations: • XML-RPC: XML is the encoding format

    and HTTP is the transport protocol • JSON-RPC: JSON is the encoding format and HTTP is the transport protocol • SOAP: Simple Object Access Protocol. Uses XML for encoding, but can use HTTP, HTTPS, SMTP, UDP, ... transport protocols • CORBA: Common Object Request Broker Architecture • etc... 64
  61. XML-RPC simple example Pseudo-code Server code function_1(x1) { ... }

    function_2(y1,y2) { ... } server := create_XML_RPC_server( (HOSTNAME, PORT) ) server.register ( function_1, function_2 ) server.start() Client code server := connect_XML_RPC_server( (HOSTNAME,PORT) ) result_1 := server.function_1(x1) result_2 := server.function_2(y1,y2) Python implementation 65
  62. Server code #!/usr/bin/env python import SimpleXMLRPCServer import socket class MyServer(object):

    def hostname(self): """Returns the name of the host on which the server runs""" return socket.gethostname() def split(self, string): """Splits a string in a list of words""" return string.split() 66
  63. def main(): # Display the name of the server in

    the standard output host = socket.gethostbyname( socket.gethostname() ) port = 8000 print "Server URL is http://%s:%d"%(host,port) # Create an instance of the server server = SimpleXMLRPCServer.SimpleXMLRPCServer( (host, port) ) # Associate all functions of MyServer with the server server.register_instance( MyServer() ) # Start the server server.serve_forever() if __name__ == '__main__': main() Client code 67
  64. #!/usr/bin/env python from socket import gethostname import sys import xmlrpclib

    # XML-RPC library def main(): host = gethostname() print 'This host is: %s'%(host) # The URL of the server is the 1st argument of the command line url = sys.argv[1] # Create a proxy object for the server server = xmlrpclib.Server(url) # Run the 'hostname' function on the server and print the output remote = server.hostname() 68
  65. print 'Remote host is: %s'%(remote) # Run the 'split' function

    on the server and print the output s = "This is the string to split" splitted = server.split(s) print 'Splitted string has type:', type(splitted) print str(splitted) if __name__ == '__main__': main() Execution scemama@lpqdh82 $ ./xmlrpc_server.py Server URL is http://192.168.2.8:8000 lpqdh82 - - [29/Jul/2014 01:08:06] "POST /RPC2 HTTP/1.1" 200 - lpqdh82 - - [29/Jul/2014 01:08:06] "POST /RPC2 HTTP/1.1" 200 - 69
  66. scemama@pi $ ./xmlrpc_client.py http://192.168.2.8:8000 This host is: pi Remote host

    is: lpqdh82 Splitted string has type: <type 'list'> ['This', 'is', 'the', 'string', 'to', 'split'] 70
  67. Monte Carlo Calculation of with XML-RPC Pseudo-code Server code: data

    = [] server_is_running := False subroutine set_result( X ) { data := data + [X] if ( get_error() <= error_threshold ) { server_is_running := False } } function get_average() { return sum(data) / ( length(data) ) } 71
  68. function get_variance() { average := get_average() v := 0 for

    all x in data { v := variance + (x-average)^2 } return v/(length(data)-1) } function get_error() { return sqrt( get_variance() / ( length(data) ) ) } server := create_XML_RPC_server( (HOSTNAME, PORT) ) server.register ( set_result ) server.start() server_is_running := True while (server_is_running) { 72
  69. server.handle_request() } print get_average(), get_error() Client code: function compute_pi() {

    ... } server := connect_XML_RPC_server( (HOSTNAME,PORT) ) loop := True while (loop) { X := compute_pi() reply := server.set_result(X) loop := ( reply = "CONTINUE" ) } 73
  70. Python implementation Server code: #!/usr/bin/python -u from SimpleXMLRPCServer import SimpleXMLRPCServer

    from math import sqrt from time import gmtime, strftime # Termination condition error_threshold = 1.e-4 class PiServer(object): def __init__(self): """Initialization of the server""" # Data is stored in a list self.data = [] 74
  71. # N is the number of random events self.N =

    0 def set_result(self,value,address): """Adds a value coming from a given host""" self.data.append( value ) self.N += 1 # Termination condition is calculated now if self.N > 4 and self.error() < error_threshold: self.terminate() result = 0 else: result = 1 # Each time a new event is added, display the # current average and error self.print_status(address) return result 75
  72. def terminate(self): """Terminate the run""" global running running = False

    def average(self): """Computes the running average""" return sum(self.data)/self.N def variance(self): """Computes the variance""" x_ave = self.average() l = [ (x-x_ave)*(x-x_ave) for x in self.data ] if self.N < 2: return 0. return sum(l)/(self.N-1) def error(self): 76
  73. """Computes the error bar""" return sqrt(self.variance())/sqrt(self.N) def print_status(self,address): """Displays something

    like: [ 15:39:59 127.0.0.1 ] : 3.141336 +/- 0.000120 ( 7) """ time = strftime("%H:%M:%S", gmtime()) print "[ %8s %15s ] : %f +/- %f (%4d)"%(time, address, self.average(), self.error(),self.N) running = True from socket import gethostbyname, gethostname import sys 77
  74. def main(): # Print the URL and port number of

    the server host = gethostbyname( gethostname() ) port = 8000 print >>sys.stderr, "Server URL is http://%s:%d"%(host,port) # Create the server server = SimpleXMLRPCServer( (host, port), logRequests=False ) # All functions of PiServer are accessible via XML-RPC server.register_instance( PiServer() ) # Run while the global variable 'running' is True while running: server.handle_request() if __name__ == '__main__': main() Client code: 78
  75. #!/usr/bin/env python # Compute X as an average over 10^7

    MC steps NMAX = 10000000 NMAX_inv = 1.e-7 from random import random, seed def compute_pi(): """Local Monte Carlo calculation of pi""" # Initialize random number generator seed(None) result = 0. # Loop 10^7 times for i in xrange(NMAX): # Draw 2 random numbers x and y x = random() 79
  76. y = random() # Check if (x,y) is in the

    circle if x*x + y*y <= 1.: result += 1 # X = estimation of pi result = 4.* float(result)*NMAX_inv return result import sys import xmlrpclib from socket import gethostbyname, gethostname def main(): # The URL of the server is the 1st command line argument url = sys.argv[1] address = gethostbyname(gethostname()) # Proxy for the XML-RPC server 80
  77. server = xmlrpclib.Server(url) loop = True while loop: # Get

    a new estimate of pi pi = compute_pi() # If it is not possible to set the result on the # server, the server is down so stop the calculation try: cont = server.set_result(pi,address) loop = (cont == 1) except: loop = False if __name__ == '__main__': main() Example fo execution using a single client: 81
  78. $ time ./pi_server.py Server URL is http://130.120.229.82:8000 [ 15:43:26 130.120.229.82

    ] : 3.141130 +/- 0.000000 ( 1) [ 15:43:29 130.120.229.82 ] : 3.141475 +/- 0.000345 ( 2) [ 15:43:33 130.120.229.82 ] : 3.141237 +/- 0.000310 ( 3) [ 15:43:37 130.120.229.82 ] : 3.141429 +/- 0.000292 ( 4) [ 15:43:40 130.120.229.82 ] : 3.141494 +/- 0.000235 ( 5) [ 15:43:44 130.120.229.82 ] : 3.141573 +/- 0.000207 ( 6) [ 15:43:48 130.120.229.82 ] : 3.141626 +/- 0.000183 ( 7) [ 15:43:51 130.120.229.82 ] : 3.141663 +/- 0.000163 ( 8) Average is 3.5 seconds/block Example fo execution using a multiple clients: $ time ./pi_server.py Server URL is http://130.120.229.82:8000 [ 15:39:56 127.0.0.1 ] : 3.141700 +/- 0.000000 ( 1) [ 15:39:56 127.0.0.1 ] : 3.141630 +/- 0.000070 ( 2) [ 15:39:57 127.0.0.1 ] : 3.141590 +/- 0.000057 ( 3) 82
  79. [ 15:39:58 127.0.0.1 ] : 3.141404 +/- 0.000191 ( 4)

    [ 15:39:58 130.120.229.23 ] : 3.141325 +/- 0.000167 ( 5) [ 15:39:58 130.120.229.23 ] : 3.141306 +/- 0.000138 ( 6) [ 15:39:59 127.0.0.1 ] : 3.141336 +/- 0.000120 ( 7) [ 15:40:00 127.0.0.1 ] : 3.141444 +/- 0.000150 ( 8) [...] [ 15:40:58 130.120.229.82 ] : 3.141526 +/- 0.000041 ( 177) [ 15:40:58 130.120.229.82 ] : 3.141522 +/- 0.000041 ( 178) [ 15:40:59 127.0.0.1 ] : 3.141524 +/- 0.000041 ( 179) [ 15:40:59 130.120.229.23 ] : 3.141524 +/- 0.000041 ( 180) [ 15:40:59 127.0.0.1 ] : 3.141523 +/- 0.000041 ( 181) [ 15:41:00 127.0.0.1 ] : 3.141521 +/- 0.000040 ( 182) [ 15:41:00 130.120.229.29 ] : 3.141518 +/- 0.000040 ( 183) [ 15:41:00 130.120.229.27 ] : 3.141520 +/- 0.000040 ( 184) [ 15:41:00 127.0.0.1 ] : 3.141517 +/- 0.000040 ( 185) real 1m9.958s user 0m0.168s sys 0m0.028s Average is 0.37 seconds/block 83
  80. Problem 3 : Numerical computation of a 2-electron integral We

    want to compute numerically the value of the following integral: ­ Á1 Á2 jÁ3 Á4 ® = ZZ Á1 (r1 )Á2 (r2 ) 1 r12 Á3 (r1 )Á4 (r2 )dr1 dr2 Constraints: • We need to use Fortran • A large number of points will be computed ( ) Simple solution: • Compute the sum over a fixed number of grid points per CPU • Use the Message Passing Interface (MPI) to communicate 84
  81. Message Passing Interface MPI is a standard Application Programming Interface

    (API) which specifies how processes can communicate together. • Each process has a rank and belongs to a group of processes. • Processes can do point-to-point or collective communications There is no need to pass the IP address and port number. All low-level communication is handled. MPI programs start with a call to the MPI_Init function ! Fortran integer :: ierr call MPI_Init(ierr) // C #include <mpi.h> int MPI_Init(int *argc, char ***argv) 87
  82. // C++ #include <mpi.h> void MPI::Init(int& argc, char**& argv) void

    MPI::Init() MPI programs end with a call to the MPI_Finalize function integer :: ierr call MPI_Finalize(ierr) The rank of the current process is obtained with call MPI_COMM_RANK(MPI_COMM_WORLD, myid, ierr) and the total number of processes is obtained with call MPI_COMM_SIZE(MPI_COMM_WORLD, nproc, ierr) 88
  83. Synchronization call MPI_BARRIER(MPI_COMM_WORLD,ierr) All the processes are blocked until they

    are all at this point. They wait for each other. Point-to-point send/receive operation include ’mpif.h’ <type> :: BUF(*) integer :: n, datatype, tag, comm, ierr integer :: status(MPI_STATUS_SIZE) integer :: sender, receiver if (my_id == sender) then call MPI_SEND(buffer, n, datatype, receiver, tag, comm, ierr) else if (my_id == receiver) then call MPI_RECV(buffer, n, datatype, sender, tag, comm, status, ierr) endif 89
  84. • sender : Rank of the process sending the data

    • receiver : Rank of the process receiving the data • <type> : Type of data (double precision, integer, etc) • buffer : array of type <type> • n : number of elements to send • datatype : MPI type of data (MPI_DOUBLE_PRECISION, MPI_INTEGER4, etc) • tag : Message tag. Used to identify the message. • comm : Communicator. Usually MPI_COMM_WORLD • ierr : if ierr == MPI_SUCCESS, everything went fine • status : Contains some information about the incoming message to track failures Collective communications Broadcast : one-to-all communication. Send the same data to all processes. 90
  85. include ’mpif.h’ <type> :: buffer(*) integer :: n, datatype, sender,

    comm, ierr call MPI_BCAST(buffer, n, datatype, sender, comm, ierr) • buffer : Data to send to all processes • n : Number of elements in buffer Reductions: all-to-one communication. include ’mpif.h’ <type> :: sendbuf(*), recvbuf(*) integer :: n, datatype, op, sender, comm, ierr call MPI_REDUCE(sendbuf, recvbuf, n, datatype, op, sender, comm, ierr) • sendbuf : Buffer of data to send • recvbuf : Buffer in which the data will be received • op : Reduction operation to perform. Examples: MPI_SUM, MPI_MAX, MPI_PROD, etc 91
  86. Two-electron integral using MPI Pseudo-code function f(r1,r2) { ... }

    MPI_Init() myid := MPI_COMM_RANK( MPI_COMM_WORLD ) nproc := MPI_COMM_SIZE( MPI_COMM_WORLD ) dx := (xmax-xmin)/(nmax-1) dv := dx^6 local_result := 0. // For 4 processors, // Processor 0 runs over 1,5,9 ,13,... // Processor 1 runs over 2,6,10,14,... 93
  87. // Processor 2 runs over 3,7,11,15,... // Processor 3 runs

    over 4,8,12,16,... for i = myid+1 to nmax with a step of nproc { for j,k,l,m,n = 1 to nmax { r1(1) := (i-1) * dx + xmin r1(2) := (j-1) * dx + xmin r1(3) := (k-1) * dx + xmin r2(1) := (l-1) * dx + xmin + dx/2 r2(2) := (m-1) * dx + xmin + dx/2 r2(3) := (n-1) * dx + xmin + dx/2 // (+ dx/2 : Avoids divergence in 1/r12) local_result := local_result + f(r1,r2) * dv } } result := MPI_REDUCE(local_result, MPI_SUM, MPI_COMM_WORLD) 94
  88. if (myid = 0) { print result } MPI_Finalize() Fortran

    implementation double precision function f(r1,r2) implicit none double precision, intent(in) :: r1(3), r2(3) ! < Phi_1 (r1) Phi_2 (r1) 1/r12 Phi_3 (r2) Phi_4 (r2) > double precision :: Phi_1, Phi_2, Phi_3, Phi_4 double precision :: r12_inv double precision,parameter :: alpha_1=1.d0 , alpha_3=1.5d0 double precision,parameter :: alpha_2=4.2d0, alpha_4=2.3d0 95
  89. double precision,parameter :: X_1(3)=(/ 0.d0, 0.d0, 0.d0 /) double precision,parameter

    :: X_2(3)=(/ 0.d0, 1.d0, 0.d0 /) double precision,parameter :: X_3(3)=(/ 0.d0, 1.d0, 1.d0 /) double precision,parameter :: X_4(3)=(/ 1.d0, 1.d0, 0.d0 /) Phi_1 = exp (-alpha_1*((r1(1)-X_1(1))*(r1(1)-X_1(1)) + & (r1(2)-X_1(2))*(r1(2)-X_1(2)) + & (r1(3)-X_1(3))*(r1(3)-X_1(3))) ) Phi_2 = exp (-alpha_2*((r2(1)-X_2(1))*(r2(1)-X_2(1)) + & (r2(2)-X_2(2))*(r2(2)-X_2(2)) + & (r2(3)-X_2(3))*(r2(3)-X_2(3))) ) Phi_3 = exp (-alpha_3*((r1(1)-X_3(1))*(r1(1)-X_3(1)) + & (r1(2)-X_3(2))*(r1(2)-X_3(2)) + & (r1(3)-X_3(3))*(r1(3)-X_3(3))) ) 96
  90. Phi_4 = exp (-alpha_4*((r2(1)-X_4(1))*(r2(1)-X_4(1)) + & (r2(2)-X_4(2))*(r2(2)-X_4(2)) + & (r2(3)-X_4(3))*(r2(3)-X_4(3)))

    ) r12_inv = 1.d0/dsqrt ( (r1(1)-r2(1))*(r1(1)-r2(1)) + & (r1(2)-r2(2))*(r1(2)-r2(2)) + & (r1(3)-r2(3))*(r1(3)-r2(3)) ) f = Phi_1 * Phi_2 * r12_inv * Phi_3 * Phi_4 end program bielec implicit none include 'mpif.h' integer :: ierr integer :: myid 97
  91. integer :: nproc integer :: i,j,k,l,m,n integer, parameter :: nmax=30

    double precision, parameter :: xmin = -2.d0, xmax = 2.d0 double precision, external :: f double precision :: r1(3), r2(3) double precision :: local_result, result double precision :: dx,dv ! Initialize the MPI library call MPI_Init(ierr) ! Get the rank of the current process call MPI_COMM_RANK(MPI_COMM_WORLD, myid, ierr) ! Get the the total number of processes 98
  92. call MPI_COMM_SIZE(MPI_COMM_WORLD, nproc, ierr) ! Compute a partial result locally

    local_result = 0.d0 dx = (xmax-xmin)/dble(nmax-1) dv = dx**6 ! For 4 processes, ! Proces 0 runs over 1,5,9 ,13,... ! Proces 1 runs over 2,6,10,14,... ! Proces 2 runs over 3,7,11,15,... ! Proces 3 runs over 4,8,12,16,... do i=myid+1,nmax,nproc r1(1) = dble(i-1) * dx + xmin do j=1,nmax r1(2) = dble(j-1) * dx + xmin do k=1,nmax r1(3) = dble(k-1) * dx + xmin 99
  93. do l=1,nmax r2(1) = dble(l-1) * dx + xmin +

    dx/2 ! + dx/2 : Avoids divergence in r1=r2 do m=1,nmax r2(2) = dble(m-1) * dx + xmin + dx/2 do n=1,nmax r2(3) = dble(n-1) * dx + xmin + dx/2 local_result = local_result + f(r1,r2) * dv enddo enddo enddo enddo enddo enddo ! Sum the local results of all processes ! into the master process call MPI_REDUCE(local_result, result, 1, & 100
  94. MPI_DOUBLE_PRECISION, MPI_SUM, & 0, MPI_COMM_WORLD, ierr) if (myid == 0)

    then print *, result endif ! Terminate the MPI library call MPI_Finalize(ierr) end Links • Open MPI : Open source MPI implementation : http://www.open-mpi.org/ • Open MPI documentation : http://www.open-mpi.org/doc/v1.8/ 101
  95. Coarray Fortran (CAF) Extension of the Fortran 2008 standard. •

    Each running process is called an image. • The number of images is obtained with the built-in num_image() function • The rank of the current process is obtained with this_image() A codimension can be given to arrays in square brackets, for example: integer :: i[*] double precision :: A(10)[*] For any image, • i[2] : value of i in image number 2 • A(5)[4] : value of A(5) in image number 4 Any image can directly have access an element in the memory of another image. PGAS : Partitioned Global Address Space. 102
  96. Much simpler than MPI: • Higher level of abstraction than

    MPI • Types, message sizes, tags, etc are known by the compiler • Compiler can place the communication instructions where it is the best (asynchronous comm) • Better performance obtained by non-experts But: • Experts can get more performance with MPI : more flexibility (lower level) • Having knowledge of how MPI works helps to write efficient (CAF) code 103
  97. Calculation of the 2-electron integral double precision function f(r1,r2) implicit

    none double precision, intent(in) :: r1(3), r2(3) ! < Phi_1 (r1) Phi_2 (r1) 1/r12 Phi_3 (r2) Phi_4 (r2) > double precision :: Phi_1, Phi_2, Phi_3, Phi_4 double precision :: r12_inv double precision,parameter :: alpha_1=1.d0 , alpha_3=1.5d0 double precision,parameter :: alpha_2=4.2d0, alpha_4=2.3d0 double precision,parameter :: X_1(3)=(/ 0.d0, 0.d0, 0.d0 /) double precision,parameter :: X_2(3)=(/ 0.d0, 1.d0, 0.d0 /) double precision,parameter :: X_3(3)=(/ 0.d0, 1.d0, 1.d0 /) double precision,parameter :: X_4(3)=(/ 1.d0, 1.d0, 0.d0 /) 104
  98. Phi_1 = exp (-alpha_1*((r1(1)-X_1(1))*(r1(1)-X_1(1)) + & (r1(2)-X_1(2))*(r1(2)-X_1(2)) + & (r1(3)-X_1(3))*(r1(3)-X_1(3)))

    ) Phi_2 = exp (-alpha_2*((r2(1)-X_2(1))*(r2(1)-X_2(1)) + & (r2(2)-X_2(2))*(r2(2)-X_2(2)) + & (r2(3)-X_2(3))*(r2(3)-X_2(3))) ) Phi_3 = exp (-alpha_3*((r1(1)-X_3(1))*(r1(1)-X_3(1)) + & (r1(2)-X_3(2))*(r1(2)-X_3(2)) + & (r1(3)-X_3(3))*(r1(3)-X_3(3))) ) Phi_4 = exp (-alpha_4*((r2(1)-X_4(1))*(r2(1)-X_4(1)) + & (r2(2)-X_4(2))*(r2(2)-X_4(2)) + & (r2(3)-X_4(3))*(r2(3)-X_4(3))) ) r12_inv = 1.d0/dsqrt ( (r1(1)-r2(1))*(r1(1)-r2(1)) + & 105
  99. (r1(2)-r2(2))*(r1(2)-r2(2)) + & (r1(3)-r2(3))*(r1(3)-r2(3)) ) f = Phi_1 * Phi_2

    * r12_inv * Phi_3 * Phi_4 end program bielec implicit none integer :: i,j,k,l,m,n integer, parameter :: nmax=30 double precision, parameter :: xmin = -2.d0, xmax = 2.d0 double precision, external :: f double precision :: r1(3), r2(3) double precision :: local_result[*], result double precision :: dx,dv 106
  100. ! Compute a partial result locally local_result = 0.d0 dx

    = (xmax-xmin)/dble(nmax-1) dv = dx**6 ! Image 0 runs over 1,5,9 ,13,... ! Image 1 runs over 2,6,10,14,... ! Image 2 runs over 3,7,11,15,... ! Image 3 runs over 4,8,12,16,... do i=this_image()+1,nmax,num_images() r1(1) = dble(i-1) * dx + xmin do j=1,nmax r1(2) = dble(j-1) * dx + xmin do k=1,nmax r1(3) = dble(k-1) * dx + xmin do l=1,nmax r2(1) = dble(l-1) * dx + xmin + dx/2 107
  101. ! + dx/2 : Avoids divergence in r1=r2 do m=1,nmax

    r2(2) = dble(m-1) * dx + xmin + dx/2 do n=1,nmax r2(3) = dble(n-1) * dx + xmin + dx/2 local_result = local_result + f(r1,r2) * dv enddo enddo enddo enddo enddo enddo ! Sum the local results of all processes do i=1,num_images() result = result + local_result[i] enddo 108
  102. if (this_image() == 1) then print *, result endif end

    Links • Coarray Fortran http://www.co-array.org/ • Rice University http://caf.rice.edu/ • Coarray with gfortran http://gcc.gnu.org/wiki/Coarray 109
  103. Problem 4: Parallelization of a matrix product Matrix products are

    usually not written by the user. It is preferable to use optimized libraries to perform linear algebra. A standardized API exists (Lapack) on top of the BLAS API. Every CPU manufacturer provides optimized libraries (MKL, ATLAS, NAG, ACML, CULA, etc). For matrix products, we use DGEMM: • D : double precision • Ge : General • MM : Matrix Multiplication NAME DGEMM - perform one of the matrix-matrix operations C := alpha*op( A )*op( B ) + beta*C 110
  104. SYNOPSIS SUBROUTINE DGEMM ( TRANSA, TRANSB, M, N, K, ALPHA,

    A, LDA, B, LDB, BETA, C, LDC ) CHARACTER*1 TRANSA, TRANSB INTEGER M, N, K, LDA, LDB, LDC DOUBLE PRECISION ALPHA, BETA DOUBLE PRECISION A( LDA, * ), B( LDB, * ), C( LDC,* ) ... Cij = N X k =1 Aik Bkj C = 0. do j=1,N do i=1,N do k=1,N C(i,j) = C(i,j) + A(i,k) * B(k,j) end do 111
  105. end do end do The final matrix can be split,

    such that each CPU core builds part of it. 112
  106. 113

  107. C11 =A11 ¢B11 +A12 ¢B21 C12 =A11 ¢B12 +A12 ¢B22

    C21 =A21 ¢B11 +A22 ¢B21 C22 =A21 ¢B12 +A22 ¢B22 The large N x N matrix product can be performed by doing 8 smaller matrix products of size N/2 x N/2, that can be done simultaneously by 8 CPUs. 114
  108. Data access is slow with respect to calculation: Operation Latency

    (ns) Int ADD 0.3 FP ADD 0.9 FP MUL 1.5 L1 cache 1.2 L2 cache 3.5 L3 cache 13 RAM 79 Infiniband 1 200 Ethernet 50 000 Disk (SSD) 50 000 Disk (15k) 2 000 000 Arithmetic intensity : Flops/memory access 115
  109. Sequential algorithm: • The most efficient operation on a computer

    : ~95% of the peak performance • data access and flops -> High arithmetic intensity -> Compute bound. • (2 x N²) data reads, (N) data writes and (N³) flops • Arithmetic intensity = N/2 4-way parallel algorithm: • Here, the data can not be disjoint between the CPUs • To build one block, 4 blocks are needed • The same block will be read by different CPUs • (2 x N x N/2) data reads, (N/2 x N/2 x N) flops • Arithmetic intensity = N/4 : less than sequential algorithm Difficulty: • A modern CPU can perform 8 FP ADD and 8 FP MUL per cycle (!!!) • A random memory access takes ~300 cycles (4 800 flops!) 116
  110. • A network access takes ~4000 cycles (64 000 flops!)

    • To benefit from distributed parallelism, the matrices have to be very large Proposed solution: Use shared-memory parallelism • Avoids network bottleneck (~10x slower than RAM) • L3 cache sharing optimizes data access (~6x faster than RAM) • Hardware memory prefetchers will mask the RAM latencies 117
  111. Threads pthreads • When starting a new thread, a concurrent

    execution of a function is started in the same memory domain. • A private memory domain is created for the thread • The parent process can wait until all the children threads have finished their work • Fork/join model Example in pseudo-code function f() { ... } t = pthread_create(f); Example in Python 118
  112. #!/usr/bin/env python import threading import time A = 0 def

    f(x): global A time.sleep(1.) A = x print x, "written by thread" def main(): t = threading.Thread(target=f, args = [2] ) print "Before thread starts, A= ", A t.start() time.sleep(0.5) 119
  113. print "A= ", A time.sleep(1.) print "A= ", A time.sleep(1.)

    t.join() print "After join, A=", A if __name__ == '__main__': main() What happens when 2 threads read from the same memory address at the same time? Nothing special What happens when 2 threads write at the same memory address at the same time? If you are lucky, the program crashes. Otherwise, it is unpredictible. 120
  114. Locks To avoid writing simultaneously at the same memory location,

    we introduce Locks: acquire_lock(L) if L is free, the current thread gets the lock. Otherwise, block until the lock can be acquired release_lock(L) the lock is released by the current thread Example of wrong code #!/usr/bin/env python import threading import time A = 0 def f(x): 121
  115. global A for i in range(x): A = A+1 def

    main(): t = [None for i in range(10)] for i in range(10): t[i] = threading.Thread(target=f, args = [100000] ) for i in range(10): t[i].start() for i in range(10): t[i].join() print A if __name__ == '__main__': main() Using a lock: 122
  116. #!/usr/bin/env python import threading import time A = 0 lock

    = threading.Lock() def f(x): global A a = 0 for i in range(x): a = a+1 lock.acquire() A = A+a lock.release() def main(): t = [None for i in range(10)] 123
  117. for i in range(10): t[i] = threading.Thread(target=f, args = [100000]

    ) for i in range(10): t[i].start() for i in range(10): t[i].join() print A if __name__ == '__main__': main() A semaphore is more general than a lock : it can be taken simultaneously by more than 1 thread. 124
  118. OpenMP OpenMP is an extension of programming languages that enable

    the use of multi-threading to parallelize the code using directives given as comments. The same source code can be compiled with/without OpenMP. For example: !$OMP PARALLEL DEFAULT(SHARED) PRIVATE(i) !$OMP DO do i=1,n A(i) = B(i) + C(i) end do !$OMP END DO !$OMP END PARALLEL • !$OMP PARALLEL starts a new multi-threaded section. Everything inside this block is executed by all the threads 125
  119. • !$OMP DO tells the compiler to split the loop

    among the different threads (by changing the loop boundaries for instance) • !$OMP END DO marks the end of the parallel loop. It contains an implicit synchronization. After this line, all the threads have finished executing the loop. • !$OMP END PARALLEL marks the end of the parallel section. Contains also an implicit barrier. • DEFAULT(SHARED) : all the variables (A,B,C) are in shared memory by default • PRIVATE(i) : the variable i is private to every thread Other important directives: • !$OMP CRITICAL ... !$OMP END CRITICAL : all the statements in this block are protected by a lock • !$OMP TASK ... !$OMP END TASK : define a new task to execute • !$OMP BARRIER : synchronization barrier 126
  120. • !$OMP SINGLE ... !$OMP END SINGLE : all the

    statements in this block are executed by a single thread • !$OMP MASTER ... !$OMP END MASTER : all the statements in this block are executed by the master thread • omp_get_thread_num() : returns the ID of the current running thread • omp_get_num_threads() : returns the total number of running threads • OMP_NUM_THREADS : Environment variable (shell) that fixes the number of threads to run 127
  121. Matrix product : simple OpenMP example Loop parallelism A =

    create_matrix() B = create_matrix() // parallelize loop over i and j for i=1 to N using a step of N/2 { for j=1 to N using a step of N/2 { for k=1 to N using a step of N/2 { // C_ij = A_ik.B_kj DGEMM ( C(i,j), A(i,k), B(k,j), (N/2, N/2) ) } } } 128
  122. program submatrix_openmp implicit none integer, parameter :: sze = 5000

    double precision, allocatable, dimension (:,:) :: A, B, C double precision :: cpu_0, cpu_1 integer :: istart(2), iend(2) integer :: jstart(2), jend(2) integer :: i,j integer :: i1,i2,j1,j2,step integer, external :: omp_get_thread_num double precision :: s allocate (A(sze,sze), B(sze,sze), C(sze,sze)) C = 0.d0 step = sze/2 129
  123. !$OMP PARALLEL DEFAULT(NONE) & !$OMP PRIVATE(i1,j1,j2,istart,jstart,iend,jend, & !$OMP cpu_0,cpu_1) &

    !$OMP SHARED(A,B,C,step) !$OMP MASTER call wall_time(cpu_0) !$OMP END MASTER !Build the submatrices !$OMP DO COLLAPSE(2) do i1=1,sze,step do j2=1,sze,step istart(1) = i1 iend(1) = istart(1)+step-1 jstart(1) = j2 130
  124. jend(1) = jstart(1)+step-1 call create_matrix(A,sze,7.d0,istart(1), & iend(1),jstart(1),jend(1)) call create_matrix(B,sze,11.d0,istart(1), &

    iend(1),jstart(1),jend(1)) enddo enddo !$OMP END DO !$OMP MASTER call wall_time(cpu_1) write(0,*) 'Matrix build time : ', cpu_1-cpu_0, 's' call wall_time(cpu_0) !$OMP END MASTER !$OMP DO COLLAPSE(2) do i1=1,sze,step do j2=1,sze,step 131
  125. istart(1) = i1 jstart(2) = j2 iend(1) = istart(1)+step-1 jend(2)

    = jstart(2)+step-1 do j1=1,sze,step jstart(1) = j1 istart(2) = j1 jend(1) = jstart(1)+step-1 iend(2) = istart(2)+step-1 ! Compute the submatrix product call dgemm('N','N', & 1+iend(1)-istart(1), & 1+jend(1)-jstart(1), & 1+jend(2)-jstart(2), & 1.d0, A(istart(1),jstart(1)),sze, & B(istart(2),jstart(2)),sze, & 1.d0, C(istart(1),jstart(2)),sze ) 132
  126. enddo enddo enddo !$OMP END DO !$OMP MASTER call wall_time(cpu_1)

    write(0,*) 'Compute Time : ', cpu_1-cpu_0, 's' !$OMP END MASTER !$OMP END PARALLEL ! Print the sum of the elements s = 0.d0 do j=1,sze do i=1,sze s = s+C(i,j) enddo enddo 133
  127. Task parallelism Shared-memory work stealing A = create_matrix() B =

    create_matrix() queue= [] for i=1 to N using a step of N/2 { for j=1 to N using a step of N/2 { for k=1 to N using a step of N/2 { // C_ij = A_ik.B_kj queue = queue + [ ( i, j, k ) ] } } } sem = semaphore(nproc) 135
  128. function do_work( i,j,k ) { DGEMM (A,B,C,i,j,k) release_semaphore(sem) } do

    while queue is not empty { acquire_semaphore(sem) // Pop out the 1st element of the queue params = queue.pop() pthread_create( do_work, params ) } program submatrix_openmp implicit none integer, parameter :: sze = 5000 double precision, allocatable, dimension (:,:) :: A, B, C 136
  129. double precision :: wall_0, wall_1 integer :: istart(2), iend(2) integer

    :: jstart(2), jend(2) integer :: i,j integer :: i1,i2,j1,j2,step double precision :: s allocate (A(sze,sze), B(sze,sze), C(sze,sze)) C = 0.d0 step = sze/2 !$OMP PARALLEL DEFAULT(NONE) & !$OMP PRIVATE(i1,j1,j2,istart,jstart,iend,jend) & !$OMP SHARED(A,B,C,step,wall_0,wall_1) 137
  130. !$OMP MASTER call wall_time(wall_0) !Build the submatrices do i1=1,sze,step do

    j2=1,sze,step istart(1) = i1 iend(1) = istart(1)+step-1 jstart(1) = j2 jend(1) = jstart(1)+step-1 !$OMP TASK call create_matrix(A,sze,7.d0,istart(1), & iend(1),jstart(1),jend(1)) !$OMP END TASK !$OMP TASK call create_matrix(B,sze,11.d0,istart(1), & iend(1),jstart(1),jend(1)) !$OMP END TASK 138
  131. enddo enddo !$OMP END MASTER !$OMP TASKWAIT !$OMP MASTER call

    wall_time(wall_1) write(0,*) 'Matrix build time : ', wall_1-wall_0, 's' call wall_time(wall_0) do i1=1,sze,step do j2=1,sze,step istart(1) = i1 jstart(2) = j2 iend(1) = istart(1)+step-1 jend(2) = jstart(2)+step-1 do j1=1,sze,step jstart(1) = j1 139
  132. istart(2) = j1 jend(1) = jstart(1)+step-1 iend(2) = istart(2)+step-1 !

    Compute the submatrix product !$OMP TASK call dgemm('N','N', & 1+iend(1)-istart(1), & 1+jend(1)-jstart(1), & 1+jend(2)-jstart(2), & 1.d0, A(istart(1),jstart(1)),sze, & B(istart(2),jstart(2)),sze, & 1.d0, C(istart(1),jstart(2)),sze ) !$OMP END TASK enddo enddo enddo !$OMP END MASTER 140
  133. !$OMP TASKWAIT !$OMP END PARALLEL call wall_time(wall_1) write(0,*) 'Compute Time

    : ', wall_1-wall_0, 's' ! Print the sum of the elements s = 0.d0 do j=1,sze do i=1,sze s = s+C(i,j) enddo enddo deallocate (A,B,C) print *, s end 141
  134. Divide and Conquer algorithms Algorithm based on recursion. The problem

    is divided in sub-problems that are solved in the same way as the large problem. Example : Sum Suppose you want to compute the sum of all the elements of the array A(1:16). This sum can be expressed as the sum of the two halves of the array : S[ A(1:16) ] = S[ A(1:8) ] + S[ A(9:16) ] The S function will be applied recursively. 142
  135. Python #!/usr/bin/python sze_A = 5000000 A = [ i*1.5 for

    i in range(sze_A) ] def sum_half(X): sze = len(X) 143
  136. if sze > 1 : return sum_half(X[:sze/2]) + sum_half(X[sze/2:]) else:

    return X[0] s = sum_half(A) print 'DC : ', s print 'Exact : 1.875000375E+13' Fortran OpenMP program dc implicit none real, allocatable :: A(:) integer, parameter :: sze = 5000000 real :: s integer :: i allocate (A(sze)) 144
  137. ! Initialize array do i=1,sze A(i) = dble(i)*1.5 enddo !$OMP

    PARALLEL DEFAULT(NONE) SHARED(A,s) !$OMP SINGLE call sum_half( A(1), sze, s) !$OMP END SINGLE !$OMP TASKWAIT !$OMP END PARALLEL print *, 'Loop : ', sum(A) print *, 'DC : ', s print *, 'Exact : 1.875000375E+13' 145
  138. end recursive subroutine sum_half(A,sze,s) implicit none integer, intent(in) :: sze

    real, intent(in) :: A(sze) real, intent(out) :: s real :: sa, sb integer :: i, sze_new if ( sze > 1 ) then sze_new = sze/2 !$OMP TASK SHARED(A,sa) FIRSTPRIVATE(sze_new) call sum_half(A(1), sze_new, sa) !$OMP END TASK 146
  139. !$OMP TASK SHARED(A,sb) FIRSTPRIVATE(sze_new,sze) call sum_half(A(sze_new+1), sze-sze_new, sb) !$OMP END

    TASK !$OMP TASKWAIT s = sa+sb else s = A(1) endif end Divide and Conquer matrix product Pseudo-code 147
  140. recursive subroutine divideAndConquer(A,B,C,sze,ie1,je2) if ( (ie1 < 200).and.(je2 < 200)

    ) then call DGEMM else !$OMP TASK SHARED(A,B,C,sze) FIRSTPRIVATE(ie1,je2) call divideAndConquer( & ! +-------+ +---+---+ +---+---+ A(1,1), & ! | X | | | | | X | | B(1,1), & ! +-------+ . + X | + = +---+---+ C(1,1), & ! | | | | | | | | sze, & ! +-------+ +---+---+ +---+---+ ie1/2, & ! A B C je2/2) !$OMP END TASK !$OMP TASK SHARED(A,B,C,sze) FIRSTPRIVATE(ie1,je2) 148
  141. call divideAndConquer( & ! +-------+ +---+---+ +---+---+ A(1,1), & !

    | X | | | | | | X | B(1,1+je2/2), & ! +-------+ . | | X | = +---+---+ C(1,1+je2/2), & ! | | | | | | | | sze, & ! +-------+ +---+---+ +---+---+ ie1/2, & ! A B C je2-(je2/2)) !$OMP END TASK !$OMP TASK SHARED(A,B,C,sze) FIRSTPRIVATE(ie1,je2) call divideAndConquer( & ! +-------+ +---+---+ +---+---+ A(1+ie1/2,1), & ! | | | | | | | | B(1,1), & ! +-------+ . | X | | = +---+---+ C(1+ie1/2,1), & ! | X | | | | | X | | sze, & ! +-------+ +---+---+ +---+---+ ie1-(ie1/2), & ! A B C je2/2) !$OMP END TASK 149
  142. !$OMP TASK SHARED(A,B,C,sze) FIRSTPRIVATE(ie1,je2) call divideAndConquer( & ! +-------+ +---+---+

    +---+---+ A(1+ie1/2,1), & ! | | | | | | | | B(1,1+je2/2), & ! +-------+ . | | X | = +---+---+ C(1+ie1/2,1+je2/2),& ! | X | | | | | | X | sze, & ! +-------+ +---+---+ +---+---+ ie1-(ie1/2), & ! A B C je2-(je2/2)) !$OMP END TASK !$OMP TASKWAIT endif end !$OMP PARALLEL DEFAULT(SHARED) 150
  143. !$OMP SINGLE call divideAndConquer(A,B,C,sze, sze, sze ) !$OMP END SINGLE

    NOWAIT !$OMP TASKWAIT !$OMP END PARALLEL Fortran implementation program submatrix_dc implicit none double precision, allocatable, dimension (:,:) :: A, B, C integer :: istart(2), iend(2) integer :: jstart(2), jend(2) integer, parameter :: sze = 5000 double precision :: wall_0, wall_1 double precision :: s integer :: i1,j1,i2,j2, i,j, step allocate (A(sze,sze), B(sze,sze), C(sze,sze)) 151
  144. call wall_time(wall_0) C = 0.d0 step = sze/2 call wall_time(wall_0)

    !$OMP PARALLEL DEFAULT(NONE) & !$OMP PRIVATE(i1,j1,j2,istart,jstart,iend,jend) & !$OMP SHARED(A,B,C,step) !$OMP SINGLE !Build the submatrices do i1=1,sze,step do j2=1,sze,step istart(1) = i1 iend(1) = istart(1)+step-1 jstart(1) = j2 152
  145. jend(1) = jstart(1)+step-1 !$OMP TASK SHARED(A) call create_matrix(A,sze,7.d0,istart(1), & iend(1),jstart(1),jend(1))

    !$OMP END TASK !$OMP TASK SHARED(B) call create_matrix(B,sze,11.d0,istart(1), & iend(1),jstart(1),jend(1)) !$OMP END TASK enddo enddo !$OMP END SINGLE NOWAIT !$OMP TASKWAIT !$OMP END PARALLEL call wall_time(wall_1) write(0,*) 'Matrix build time : ', wall_1-wall_0, 's' 153
  146. call wall_time(wall_0) !$OMP PARALLEL DEFAULT(SHARED) !$OMP SINGLE call divideAndConquer(A,B,C,sze, sze,

    sze ) !$OMP END SINGLE NOWAIT !$OMP TASKWAIT !$OMP END PARALLEL call wall_time(wall_1) write(0,*) 'Compute Time : ', wall_1-wall_0, 's' ! Print the sum of the elements s = 0.d0 do j=1,sze do i=1,sze s = s+C(i,j) enddo enddo 154
  147. deallocate (A,B,C) print *, s end recursive subroutine divideAndConquer(A,B,C,sze,ie1,je2) implicit

    none double precision :: wall_0, wall_1 integer, intent(in) :: sze double precision, dimension (sze,sze), intent(in) :: A, B double precision, dimension (sze,sze), intent(out) :: C integer, intent(in) :: ie1,je2 if ( (ie1 < 200).and.(je2 < 200) ) then call dgemm('N','N', & ie1, & je2, & 155
  148. sze, & 1.d0, A,sze, & B,sze, & 1.d0, C,sze )

    else !$OMP TASK SHARED(A,B,C,sze) FIRSTPRIVATE(ie1,je2) call divideAndConquer( & A(1,1), & B(1,1), & C(1,1), & sze, & ie1/2, & je2/2) !$OMP END TASK !$OMP TASK SHARED(A,B,C,sze) FIRSTPRIVATE(ie1,je2) 156
  149. call divideAndConquer( & A(1,1), & B(1,1+je2/2), & C(1,1+je2/2), & sze,

    & ie1/2, & je2-(je2/2)) !$OMP END TASK !$OMP TASK SHARED(A,B,C,sze) FIRSTPRIVATE(ie1,je2) call divideAndConquer( & A(1+ie1/2,1), & B(1,1), & C(1+ie1/2,1), & sze, & ie1-(ie1/2), & je2/2) !$OMP END TASK 157
  150. !$OMP TASK SHARED(A,B,C,sze) FIRSTPRIVATE(ie1,je2) call divideAndConquer( & A(1+ie1/2,1), & B(1,1+je2/2),

    & C(1+ie1/2,1+je2/2), & sze, & ie1-(ie1/2), & je2-(je2/2)) !$OMP END TASK !$OMP TASKWAIT endif end 158
  151. Vectorization Parallelism that happens on a single CPU core. SIMD

    : Single Instruction, Multiple Data Execute the same instruction in parallel on all the elements of a vector: Example : AVX vector ADD in double precision: Different instruction sets exist in the x86 micro-architecture: • MMX : Integer (64-bit wide) • SSE -> SSE4.2 : Integer and Floating-point (128-bit) 159
  152. • AVX : Integer and Floating-point (256-bit) • AVX-512 :

    Integer and Floating-point (512-bit) Requirements: 1. The elements of each SIMD vector must be contiguous in memory 2. The first element of each SIMD vector must be aligned on a proper boundary (64, 128, 256 or 512-bit). Automatic vectorization The compiler can generate automatically vector instructions when possible. A double precision AVX auto-vectorized loop generates 3 loops: Peel loop (scalar) First elements until the 256-bit boundary is met Vector loop Vectorized version until the last vector of 4 elements Tail loop (scalar) Last elements 160
  153. 161

  154. Intel specific Compiler directives To remove the peel loop, you

    can tell the compiler to align the arrays on a 32 byte boundary using: double precision, allocatable :: A(:), B(:) !DIR$ ATTRIBUTES ALIGN : 32 :: A, B Then, before using the arrays in a loop, you can tell the compiler that the arrays are aligned. Be careful: if one array is not aligned, this may cause a segmentation fault. !DIR$ VECTOR ALIGNED do i=1,n A(i) = A(i) + B(i) end do To remove the tail loop, you can allocate A such that its dimension is a multiple of 4 elements: 162
  155. n_4 = mod(n,4) if (n_4 == 0) then n_4 =

    n else n_4 = n - n_4 + 4 endif allocate ( A(n_4), B(n_4) ) and rewrite the loop as follows: do i=1,n,4 !DIR$ VECTOR ALIGNED !DIR$ VECTOR ALWAYS do k=0,3 A(i+k) = A(i+k) + B(i+k) end do end do 163
  156. In that case, the compiler knows that each inner-most loop

    cycle can be transformed safely into only vector instructions, and it will not produce the tail and peel loops with the branching. For small arrays, the gain can be significant. For multi-dimensional arrays, if the 1st dimension is a multiple of 4 elements, all the columns are aligned: double precision, allocatable :: A(:,:) !DIR$ ATTRIBUTES ALIGN : 32 :: A allocate( A(n_4,m) ) do j=1,m do i=1,n,4 !DIR$ VECTOR ALIGNED !DIR$ VECTOR ALWAYS do k=0,3 A(i+k,j) = A(i+k,j) * B(i+k,j) end do end do end do 164
  157. Warning In practice, using multiples of 4 elements is not

    always the best choice. Using multiples of 8 or 16 elements can be better because the inner-most loop may be unrolled by the compiler to improve the efficiency of the pipeline. 165
  158. Instruction-level parallelism (ILP) MIMD : Multiple instruction, Multiple data With

    ILP, different execution units are used in parallel. For example, Sandy-Bridge (2011) x86 CPUs can perform simultaneously: • 1 vector ADD • 1 vector MUL • 2 vector LOADs • 1 vector STORE • 1 integer ADD Ideal for a scalar product (or a matrix product): do i=1,N x = x + B(i)*C(i) end do 166
  159. Peak : 4 ADD + 4 MUL per cycle =>

    8 flops/cycle. For a 10-core CPU at 2.8GHz: 8 x 2.8E9 x 10 = 224 Gflops/s in double precision Example: do i=1,N A(i) = X(i) + Y(i) end do and do i=1,N A(i) = 2.d0*(X(i) + Y(i)) end do take the same amount of time. Pipelining Here we consider a typical RISC processor with 4 different stages to perform an operation: 167
  160. 1. Instruction fetch 2. Instruction decode 3. Execution 4. Memory

    access+ write-back Each stage can be executed using different physical units, such that all 4 units can be kept busy: 168
  161. 169

  162. In this example: Latency 4 cycles. It takes 4 cycles

    to perform one single operation Throughput 1 cycle. We get one result every cycle Out of order execution Inside the CPU, the instructions are not executed in the exact sequence of the code, provided that it does not affect the result: independent instructions can be executed in any order. The CPU can choose an execution order that improves the efficiency of the pipeline. Branch prediction When an if statement occurs, two paths can be taken by the program: it is a branch. The pipeline has to be filled differently depending on the branch. 170
  163. Branch prediction: the CPU assumes that one branch is more

    likely to be chosen, and fills the pipeline for it (speculative execution). If the branch is mispredicted, the pipeline is emptied and the calculation is rolled back. Branch mispredictions can have a large penalty on the execution. Many branch predictors exist: • Static predictor : always assume the condition is true • Saturating counter : 1. Strongly not taken 2. Weakly not taken 3. Weakly taken 4. Strongly taken • Two-level adaptive predictor : a branch might be taken depending upon whether the previous two were taken • Local branch prediction : one history buffer (~4 bits) for each conditional • Global branch prediction : keep a global history buffer for all branches • Loop predictor • etc... Example: 171
  164. do i=1,N if ( mod(i,2) == 0 ) then ...

    else ... endif end do • Static : 50% success • Saturating : 50% success • Local : 100% success (history = 1010) Links • "Pipeline-base" by Hellisp - Own work. Licensed under Public domain via Wikimedia Commons - http://commons.wikimedia.org/wiki/File:Pipeline-base.png 172
  165. • "Pipeline, 4 stage" by en:User:Cburnett - Own workThis vector

    image was created with Inkscape.. Licensed under Creative Commons Attribution-Share Alike 3.0 via Wikimedia Commons - http://commons.wikimedia.org/wiki/File:Pipeline,_4_stage.svg 173
  166. Summary • Multiple levels of parallelism : Coarse-grained -> Fine-grained

    • Coarse-grained will give the highest level of parallel efficiency (lowest Communication/Computation ratio) • Different levels of parallelism can be combined 174
  167. The tools you use should be adapted to your problem:

    For example • doing a Monte Carlo calculation using OpenMP is a bad choice: • Shared memory is not required • Communication is generally low • Synchronization barriers can be avoided • Scaling would be limited to the number of cores/node • diagonalizing a matrix with XML-RPC would not give a good scaling: • A lot of communication (matrix products) • Synchronizations necessary If you need to do a Monte Carlo calculation where every Monte Carlo step diagonalizes a very large matrix, you can use OpenMP for the diagonalization and XML-RPC for the distribution of the MC steps. 175
