1. Easy and effficient programming with IRPF90 Anthony Scemama <scemama@irsamc.ups-tlse.fr> Michel Caffarel <michel.caffarel@irsamc.ups-tlse.fr> Labratoire de Chimie et Physique Quantiques IRSAMC (Toulouse)
2. Introduction • A program is a function of its input data: output = program(input) • A program can be represented as a tree where: • the vertices are the variables • the edges represent the relation 'depends on' • The root of the tree is the output of the program • The leaves are the input data 1
3. u (x, y) = x + y + 1 v (x, y) = x + y + 2 w (x) = x + 3 t (x, y) = x + y + 4 This production tree computes t( u(d 1 , d 2 ), v( u(d 3 , d 4 ), w(d 5 ) ) ) 2
4. Usual programming program exemple_1 implicit none integer :: d1,d2,d3,d4,d5 ! Input data integer :: u1, u2, w, v ! Temporary variables integer :: t ! Output data call read_data(d1,d2,d3,d4,d5) call compute_u(d1,d2,u1) call compute_u(d3,d4,u2) call compute_w(d5,w) call compute_v(u2,w,v) call compute_t(u1,v,t) print * , 't=', t end program 3
5. Alternative way with functions program exemple_2 implicit none integer :: d1,d2,d3,d4,d5 ! Input data integer :: u1, u2, w, v, t ! Variables integer :: compute_u,compute_t,compute_w,compute_w call read_data(d1,d2,d3,d4,d5) u1 = compute_u(d1,d2) u2 = compute_u(d3,d4) w = compute_w(d5) v = compute_v(u2,w) t = compute_t(u1,v) print * , 't=', t end program 4
6. Single-line with functions program exemple_3 implicit none integer :: d1,d2,d3,d4,d5 ! Input data integer :: u, v, w, t call read_data(d1,d2,d3,d4,d5) print * , 't=', & t( u(d1,d2), v( u(d3,d4), w(d5) ) ) end program Now, the sequence of execution is handled by the compiler. 5
7. Same example with IRPF90 program exemple_4 implicit none print * , 't=', t end program That's it! • Using t triggers the exploration of the production tree • Completely equivalent to the previous example, but the parameters of the function t are not expressed • IRP : Implicit Reference to Parameters 6
8. Definition of the nodes of the tree For each node, we write a provider. This is a subroutine whose role is to build the variable and guarantee that it is built properly. file: uvwt.irp.f BEGIN_PROVIDER [ integer, t ] t = u1+v+4 END_PROVIDER BEGIN_PROVIDER [integer,w] w = d5+3 END_PROVIDER BEGIN_PROVIDER [ integer, v ] v = u2+w+2 END_PROVIDER 7
9. BEGIN_PROVIDER [ integer, u1 ] u1 = d1+d2+1 END_PROVIDER BEGIN_PROVIDER [ integer, u2 ] u2 = d3+d4+1 END_PROVIDER 8
10. file : input.irp.f BEGIN_PROVIDER [ integer, d1 ] &BEGIN_PROVIDER [ integer, d2 ] &BEGIN_PROVIDER [ integer, d3 ] &BEGIN_PROVIDER [ integer, d4 ] &BEGIN_PROVIDER [ integer, d5 ] read(*,*) d1 read(*,*) d2 read(*,*) d3 read(*,*) d4 read(*,*) d5 END_PROVIDER 9
11. When you write a provider for x, you only have to focus on • How do I build x? • What are the variables that I need to build x? • Am I sure that x is built correctly when I exit the provider? Using this method: • You don't have to know the execution sequence • If you need a variable (node), you are sure that it has been built properly when you use it • You will never break other parts of the program • Many people can work simultaneously on the same program with minimal effort • If a node has already been built, it will not be built again. The correct value will be returned by the provider. 10
12. Fortran code generation • Run irpf90 in the current directory • irpf90 reads all the *.irp.f files • All the providers are identified • All the corresponding variables (IRP entities) are searched for in the code • The dependence tree is built • Providers are transformed to subroutines (subroutine provide_*) • Calls to provide_* are inserted in the code • Each file *.irp.f generates a module containing the IRP entities, and a Fortran file containing the subroutines/functions • As the dependence tree is built, the dependences between the files are known and the makefile is built automatically 11
14. Generated code example ! -*- F90 -*- ! !-----------------------------------------------! ! This file was generated with the irpf90 tool. ! ! ! ! DO NOT MODIFY IT BY HAND ! !-----------------------------------------------! program irp_program ! irp_example1: 0 call irp_example1 ! irp_example1.irp.f: 0 call irp_finalize_742559343() ! irp_example1.irp.f: 0 end program ! irp_example1.irp.f: 0 subroutine irp_example1 ! irp_example1.irp.f: 1 use uvwt_mod implicit none ! irp_example1.irp.f: 2 character*(12) :: irp_here = 'irp_example1' ! irp_example1.irp.f: 1 13
15. if (.not.t_is_built) then call provide_t endif print *, 't = ', t ! irp_example1.irp.f: 3 end ! irp_example1.irp.f: 4 ! -*- F90 -*- ! !-----------------------------------------------! ! This file was generated with the irpf90 tool. ! ! ! ! DO NOT MODIFY IT BY HAND ! !-----------------------------------------------! module uvwt_mod integer :: u1 logical :: u1_is_built = .False. integer :: u2 logical :: u2_is_built = .False. 14
16. integer :: t logical :: t_is_built = .False. integer :: w logical :: w_is_built = .False. integer :: v logical :: v_is_built = .False. end module uvwt_mod ! -*- F90 -*- ! !-----------------------------------------------! ! This file was generated with the irpf90 tool. ! ! ! ! DO NOT MODIFY IT BY HAND ! !-----------------------------------------------! subroutine provide_u1 use uvwt_mod 15
17. use input_mod implicit none character*(10) :: irp_here = 'provide_u1' integer :: irp_err logical :: irp_dimensions_OK if (.not.d1_is_built) then call provide_d1 endif if (.not.u1_is_built) then call bld_u1 u1_is_built = .True. endif end subroutine provide_u1 subroutine bld_u1 use uvwt_mod use input_mod 16
18. character*(2) :: irp_here = 'u1' ! uvwt.irp.f: 13 u1 = d1+d2+1 ! uvwt.irp.f: 14 end subroutine bld_u1 subroutine provide_u2 use uvwt_mod use input_mod implicit none character*(10) :: irp_here = 'provide_u2' integer :: irp_err logical :: irp_dimensions_OK if (.not.d1_is_built) then call provide_d1 endif if (.not.u2_is_built) then call bld_u2 u2_is_built = .True. endif 17
19. end subroutine provide_u2 subroutine bld_u2 use uvwt_mod use input_mod character*(2) :: irp_here = 'u2' ! uvwt.irp.f: 17 u2 = d3+d4+1 ! uvwt.irp.f: 18 end subroutine bld_u2 subroutine provide_t use uvwt_mod implicit none character*(9) :: irp_here = 'provide_t' integer :: irp_err logical :: irp_dimensions_OK if (.not.u1_is_built) then call provide_u1 endif if (.not.v_is_built) then 18
20. call provide_v endif if (.not.t_is_built) then call bld_t t_is_built = .True. endif end subroutine provide_t subroutine bld_t use uvwt_mod character*(1) :: irp_here = 't' ! uvwt.irp.f: 1 t = u1+v+4 ! uvwt.irp.f: 2 end subroutine bld_t subroutine provide_w use uvwt_mod use input_mod implicit none 19
21. character*(9) :: irp_here = 'provide_w' integer :: irp_err logical :: irp_dimensions_OK if (.not.d1_is_built) then call provide_d1 endif if (.not.w_is_built) then call bld_w w_is_built = .True. endif end subroutine provide_w subroutine bld_w use uvwt_mod use input_mod character*(1) :: irp_here = 'w' ! uvwt.irp.f: 5 w = d5+3 ! uvwt.irp.f: 6 20
22. end subroutine bld_w subroutine provide_v use uvwt_mod implicit none character*(9) :: irp_here = 'provide_v' integer :: irp_err logical :: irp_dimensions_OK if (.not.w_is_built) then call provide_w endif if (.not.u2_is_built) then call provide_u2 endif if (.not.v_is_built) then call bld_v v_is_built = .True. endif 21
23. end subroutine provide_v subroutine bld_v use uvwt_mod character*(1) :: irp_here = 'v' ! uvwt.irp.f: 9 v = u2+w+2 ! uvwt.irp.f: 10 end subroutine bld_v Code execution with debug mode on: $ ./irp_example1 0 : -> provide_t 0 : -> provide_u1 0 : -> provide_d1 0 : -> d1 1 2 3 4 22
24. 5 0 : <- d1 0.0000000000000000 0 : <- provide_d1 0.0000000000000000 0 : -> u1 0 : <- u1 0.0000000000000000 0 : <- provide_u1 0.0000000000000000 0 : -> provide_v 0 : -> provide_w 0 : -> w 0 : <- w 0.0000000000000000 0 : <- provide_w 0.0000000000000000 0 : -> provide_u2 0 : -> u2 0 : <- u2 0.0000000000000000 0 : <- provide_u2 0.0000000000000000 0 : -> v 0 : <- v 0.0000000000000000 0 : <- provide_v 0.0000000000000000 23
25. 0 : -> t 0 : <- t 0.0000000000000000 0 : <- provide_t 0.0000000000000000 0 : -> irp_example1 t = 26 0 : <- irp_example1 0.0000000000000000 24
26. Using subroutines/functions BEGIN_PROVIDER [ integer, u1 ] integer :: fu u1 = fu(d1,d2) END_PROVIDER BEGIN_PROVIDER [ integer, u2 ] integer :: fu u2 = fu(d3,d4) END_PROVIDER integer function fu(x,y) integer :: x,y fu = x+y+1 end function 25
27. Providing arrays An array is considered built when all its elements are built. Its dimensions can be provided variables, constants and intervals (a:b). BEGIN_PROVIDER [ integer, fact_max ] fact_max = 10 END_PROVIDER BEGIN_PROVIDER [ double precision, fact, (0:fact_max) ] integer :: i fact(0) = 1.d0 do i=1,fact_max fact(i) = fact(i-1)*dble(i) enddo END_PROVIDER 26
28. program test print *, fact(5) end $ ./test 0 : -> provide_fact 0 : -> provide_fact_max 0 : -> fact_max 0 : <- fact_max 0.0000000000000000 0 : <- provide_fact_max 0.0000000000000000 0 : -> fact 0 : <- fact 0.0000000000000000 0 : <- provide_fact 0.0000000000000000 0 : -> test 120.00000000000000 0 : <- test 0.0000000000000000 The allocation behaves as follows: • If the array is not already allocated, it is allocated 27
29. • If the array already allocated, check if the dimensions have changed • If the dimensions have not changed, then OK. • Else deallocate the array and re-allocate it with the correct dimensions • All allocations/deallocations are checked with stat=err ! -*- F90 -*- ! !-----------------------------------------------! ! This file was generated with the irpf90 tool. ! ! ! ! DO NOT MODIFY IT BY HAND ! !-----------------------------------------------! subroutine provide_fact_max use fact_mod implicit none character*(16) :: irp_here = 'provide_fact_max' integer :: irp_err 28
30. logical :: irp_dimensions_OK if (.not.fact_max_is_built) then call bld_fact_max fact_max_is_built = .True. endif end subroutine provide_fact_max subroutine bld_fact_max use fact_mod character*(8) :: irp_here = 'fact_max' ! fact.irp.f: 1 fact_max = 10 ! fact.irp.f: 2 end subroutine bld_fact_max subroutine provide_fact use fact_mod implicit none character*(12) :: irp_here = 'provide_fact' integer :: irp_err 29
31. logical :: irp_dimensions_OK if (.not.fact_max_is_built) then call provide_fact_max endif if (allocated (fact) ) then irp_dimensions_OK = .True. irp_dimensions_OK = irp_dimensions_OK.AND. & (SIZE(fact,1)==(fact_max - (-1))) if (.not.irp_dimensions_OK) then deallocate(fact,stat=irp_err) if (irp_err /= 0) then print *, irp_here//': Deallocation failed: fact' print *, ' size: (0:fact_max)' endif if ((fact_max - (-1)>0)) then allocate(fact(0:fact_max),stat=irp_err) if (irp_err /= 0) then print *, irp_here//': Allocation failed: fact' 30
32. print *, ' size: (0:fact_max)' endif endif endif else if ((fact_max - (-1)>0)) then allocate(fact(0:fact_max),stat=irp_err) if (irp_err /= 0) then print *, irp_here//': Allocation failed: fact' print *, ' size: (0:fact_max)' endif endif endif if (.not.fact_is_built) then call bld_fact fact_is_built = .True. endif 31
33. end subroutine provide_fact subroutine bld_fact use fact_mod character*(4) :: irp_here = 'fact' ! fact.irp.f: 5 integer :: i ! fact.irp.f: 6 fact(0) = 1.d0 ! fact.irp.f: 8 do i=1,fact_max ! fact.irp.f: 9 fact(i) = fact(i-1)*dble(i) ! fact.irp.f: 10 enddo ! fact.irp.f: 11 end subroutine bld_fact 32
34. Modifying a variable outside of its provider In iterative processes, a variable needs to be modified outside of its provider. If it is the case, IRPF90 has to be informed of the change by the TOUCH keyword. Example: computing numerical derivatives BEGIN_PROVIDER [ real, dPsi ] x += 0.5*delta_x TOUCH x dPsi = Psi x -= delta_x TOUCH x dPsi = (dPsi - Psi)/delta_x x += 0.5*delta_x SOFT_TOUCH x END_PROVIDER 33
35. Generated code: ! -*- F90 -*- ! !-----------------------------------------------! ! This file was generated with the irpf90 tool. ! ! ! ! DO NOT MODIFY IT BY HAND ! !-----------------------------------------------! subroutine provide_dpsi use y_mod use x_mod implicit none character*(12) :: irp_here = 'provide_dpsi' integer :: irp_err logical :: irp_dimensions_OK if (.not.x_is_built) then call provide_x 34
36. endif if (.not.psi_is_built) then call provide_psi endif if (.not.delta_x_is_built) then call provide_delta_x endif if (.not.dpsi_is_built) then call bld_dpsi dpsi_is_built = .True. endif end subroutine provide_dpsi subroutine bld_dpsi use y_mod use x_mod use y_mod ! x.irp.f: 3 35
37. use y_mod ! x.irp.f: 6 use y_mod ! x.irp.f: 9 character*(4) :: irp_here = 'dpsi' ! x.irp.f: 1 x =x +( 0.5*delta_x) ! x.irp.f: 2 ! ! x.irp.f: 3 ! >>> TOUCH x ! x.irp.f: 3 call touch_x ! x.irp.f: 3 ! <<< END TOUCH ! x.irp.f: 3 if (.not.x_is_built) then call provide_x endif if (.not.psi_is_built) then call provide_psi endif if (.not.delta_x_is_built) then call provide_delta_x endif dPsi = Psi ! x.irp.f: 4 36
38. x =x -( delta_x) ! x.irp.f: 5 ! ! x.irp.f: 6 ! >>> TOUCH x ! x.irp.f: 6 call touch_x ! x.irp.f: 6 ! <<< END TOUCH ! x.irp.f: 6 if (.not.x_is_built) then call provide_x endif if (.not.psi_is_built) then call provide_psi endif if (.not.delta_x_is_built) then call provide_delta_x endif dPsi = (dPsi - Psi)/delta_x ! x.irp.f: 7 x =x +( 0.5*delta_x) ! x.irp.f: 8 ! ! x.irp.f: 9 ! >>> TOUCH x ! x.irp.f: 9 37
39. call touch_x ! x.irp.f: 9 ! <<< END TOUCH (Soft) ! x.irp.f: 9 end subroutine bld_dpsi How this works: 38
40. Templates When pieces of code are very similar, it is possible to use a template: BEGIN_TEMPLATE subroutine insertion_$Xsort (x,iorder,isize) implicit none $type,intent(inout) :: x(isize) integer,intent(inout) :: iorder(isize) integer,intent(in) :: isize $type :: xtmp integer :: i, i0, j, jmax do i=1,isize xtmp = x(i) i0 = iorder(i) j = i-1 39
41. do j=i-1,1,-1 if ( x(j) > xtmp ) then x(j+1) = x(j) iorder(j+1) = iorder(j) else exit endif enddo x(j+1) = xtmp iorder(j+1) = i0 enddo end SUBST [ X, type ] ; real ;; d ; double precision ;; 40
42. i ; integer ;; END_TEMPLATE Generated code: ! -*- F90 -*- ! !-----------------------------------------------! ! This file was generated with the irpf90 tool. ! ! ! ! DO NOT MODIFY IT BY HAND ! !-----------------------------------------------! subroutine insertion_sort (x,iorder,isize) !x.irp.f_tpl_35: 3 implicit none !x.irp.f_tpl_35: 4 character*(14) :: irp_here='insertion_sort' !x.irp.f_tpl_35: 3 real,intent(inout) :: x(isize) !x.irp.f_tpl_35: 5 integer,intent(inout) :: iorder(isize) !x.irp.f_tpl_35: 6 41
43. integer,intent(in) :: isize !x.irp.f_tpl_35: 7 real :: xtmp !x.irp.f_tpl_35: 8 integer :: i, i0, j, jmax !x.irp.f_tpl_35: 9 do i=1,isize !x.irp.f_tpl_35: 11 xtmp = x(i) !x.irp.f_tpl_35: 12 i0 = iorder(i) !x.irp.f_tpl_35: 13 j = i-1 !x.irp.f_tpl_35: 14 do j=i-1,1,-1 !x.irp.f_tpl_35: 15 if ( x(j) > xtmp ) then !x.irp.f_tpl_35: 16 x(j+1) = x(j) !x.irp.f_tpl_35: 17 iorder(j+1) = iorder(j) !x.irp.f_tpl_35: 18 else !x.irp.f_tpl_35: 19 exit !x.irp.f_tpl_35: 20 endif !x.irp.f_tpl_35: 21 enddo !x.irp.f_tpl_35: 22 x(j+1) = xtmp !x.irp.f_tpl_35: 23 iorder(j+1) = i0 !x.irp.f_tpl_35: 24 enddo !x.irp.f_tpl_35: 25 42
44. end !x.irp.f_tpl_35: 27 subroutine insertion_dsort (x,iorder,isize) !x.irp.f_tpl_35: 32 implicit none !x.irp.f_tpl_35: 33 character*(15) :: irp_here='insertion_dsort'!x.irp.f_tpl_35: 32 double precision,intent(inout) :: x(isize)!x.irp.f_tpl_35: 34 integer,intent(inout) :: iorder(isize) !x.irp.f_tpl_35: 35 integer,intent(in) :: isize !x.irp.f_tpl_35: 36 double precision :: xtmp !x.irp.f_tpl_35: 37 integer :: i, i0, j, jmax !x.irp.f_tpl_35: 38 do i=1,isize !x.irp.f_tpl_35: 40 xtmp = x(i) !x.irp.f_tpl_35: 41 i0 = iorder(i) !x.irp.f_tpl_35: 42 j = i-1 !x.irp.f_tpl_35: 43 do j=i-1,1,-1 !x.irp.f_tpl_35: 44 if ( x(j) > xtmp ) then !x.irp.f_tpl_35: 45 x(j+1) = x(j) !x.irp.f_tpl_35: 46 iorder(j+1) = iorder(j) !x.irp.f_tpl_35: 47 else !x.irp.f_tpl_35: 48 43
45. exit !x.irp.f_tpl_35: 49 endif !x.irp.f_tpl_35: 50 enddo !x.irp.f_tpl_35: 51 x(j+1) = xtmp !x.irp.f_tpl_35: 52 iorder(j+1) = i0 !x.irp.f_tpl_35: 53 enddo !x.irp.f_tpl_35: 54 end !x.irp.f_tpl_35: 56 subroutine insertion_isort (x,iorder,isize) !x.irp.f_tpl_35: 61 implicit none !x.irp.f_tpl_35: 62 character*(15) :: irp_here='insertion_isort'!x.irp.f_tpl_35: 61 integer,intent(inout) :: x(isize) !x.irp.f_tpl_35: 63 integer,intent(inout) :: iorder(isize) !x.irp.f_tpl_35: 64 integer,intent(in) :: isize !x.irp.f_tpl_35: 65 integer :: xtmp !x.irp.f_tpl_35: 66 integer :: i, i0, j, jmax !x.irp.f_tpl_35: 67 do i=1,isize !x.irp.f_tpl_35: 69 xtmp = x(i) !x.irp.f_tpl_35: 70 i0 = iorder(i) !x.irp.f_tpl_35: 71 44
46. j = i-1 !x.irp.f_tpl_35: 72 do j=i-1,1,-1 !x.irp.f_tpl_35: 73 if ( x(j) > xtmp ) then !x.irp.f_tpl_35: 74 x(j+1) = x(j) !x.irp.f_tpl_35: 75 iorder(j+1) = iorder(j) !x.irp.f_tpl_35: 76 else !x.irp.f_tpl_35: 77 exit !x.irp.f_tpl_35: 78 endif !x.irp.f_tpl_35: 79 enddo !x.irp.f_tpl_35: 80 x(j+1) = xtmp !x.irp.f_tpl_35: 81 iorder(j+1) = i0 !x.irp.f_tpl_35: 82 enddo !x.irp.f_tpl_35: 83 end !x.irp.f_tpl_35: 85 45
47. Metaprogramming Shell scripts can be inserted in the IRPF90 code, and the output of the script will be inserted in the generated Fortran. For example: program test BEGIN_SHELL [ /bin/bash ] echo print *, \'Compiled by $(whoami) on $(date)\' END_SHELL end Generated code: ! -*- F90 -*- ! !-----------------------------------------------! ! This file was generated with the irpf90 tool. ! ! ! ! DO NOT MODIFY IT BY HAND ! 46
48. !-----------------------------------------------! program irp_program ! test: 0 call test ! test.irp.f: 0 call irp_finalize_491024427() ! test.irp.f: 0 end program ! test.irp.f: 0 subroutine test ! test.irp.f: 1 character*(4) :: irp_here = 'test' ! test.irp.f: 1 print *, 'Compiled by scemama on Mon Jul 8 11:28:16 CEST 2013' ! test.irp.f_shell_4: 1 end ! test.irp.f: 5 Example: Computing powers of x BEGIN_SHELL [ /usr/bin/python ] POWER_MAX = 20 def compute_x_prod(n,d): if n == 0: d[0] = None return d if n == 1: d[1] = None 47
49. return d if n in d: return d m = n/2 d = compute_x_prod(m,d) d[n] = None d[2*m] = None return d def print_subroutine(n): keys = compute_x_prod(n,{}).keys() keys.sort() output = [] print "real function power_%d(x1)"%n print " real, intent(in) :: x1" for i in range(1,len(keys)): output.append( "x%d"%keys[i] ) if output != []: 48
50. print " real :: "+', '.join(output) for i in range(1,len(keys)): ki = keys[i] ki1 = keys[i-1] if ki == 2*ki1: print " x%d"%ki + " = x%d * x%d"%(ki1,ki1) else: print " x%d"%ki + " = x%d * x1"%(ki1) print " power_%d = x%d"%(n,n) print "end" for i in range(POWER_MAX): print_subroutine (i+1) print '' END_SHELL 49
51. ! -*- F90 -*- ! !-----------------------------------------------! ! This file was generated with the irpf90 tool. ! ! ! ! DO NOT MODIFY IT BY HAND ! !-----------------------------------------------! real function power_1(x1) ! power.irp.f_shell_44: 1 character*(7) :: irp_here = 'power_1' ! power.irp.f_shell_44: 1 real, intent(in) :: x1 ! power.irp.f_shell_44: 2 power_1 = x1 ! power.irp.f_shell_44: 3 end ! power.irp.f_shell_44: 4 real function power_2(x1) ! power.irp.f_shell_44: 6 character*(7) :: irp_here = 'power_2' ! power.irp.f_shell_44: 6 real, intent(in) :: x1 ! power.irp.f_shell_44: 7 real :: x2 ! power.irp.f_shell_44: 8 x2 = x1 * x1 ! power.irp.f_shell_44: 9 50
52. power_2 = x2 ! power.irp.f_shell_44: 10 end ! power.irp.f_shell_44: 11 real function power_3(x1) ! power.irp.f_shell_44: 13 character*(7) :: irp_here = 'power_3' ! power.irp.f_shell_44: 13 real, intent(in) :: x1 ! power.irp.f_shell_44: 14 real :: x2, x3 ! power.irp.f_shell_44: 15 x2 = x1 * x1 ! power.irp.f_shell_44: 16 x3 = x2 * x1 ! power.irp.f_shell_44: 17 power_3 = x3 ! power.irp.f_shell_44: 18 end ! power.irp.f_shell_44: 19 real function power_4(x1) ! power.irp.f_shell_44: 21 character*(7) :: irp_here = 'power_4' ! power.irp.f_shell_44: 21 real, intent(in) :: x1 ! power.irp.f_shell_44: 22 real :: x2, x4 ! power.irp.f_shell_44: 23 x2 = x1 * x1 ! power.irp.f_shell_44: 24 x4 = x2 * x2 ! power.irp.f_shell_44: 25 power_4 = x4 ! power.irp.f_shell_44: 26 end ! power.irp.f_shell_44: 27 51
53. real function power_5(x1) ! power.irp.f_shell_44: 29 character*(7) :: irp_here = 'power_5' ! power.irp.f_shell_44: 29 real, intent(in) :: x1 ! power.irp.f_shell_44: 30 real :: x2, x4, x5 ! power.irp.f_shell_44: 31 x2 = x1 * x1 ! power.irp.f_shell_44: 32 x4 = x2 * x2 ! power.irp.f_shell_44: 33 x5 = x4 * x1 ! power.irp.f_shell_44: 34 power_5 = x5 ! power.irp.f_shell_44: 35 end ! power.irp.f_shell_44: 36 real function power_6(x1) ! power.irp.f_shell_44: 38 character*(7) :: irp_here = 'power_6' ! power.irp.f_shell_44: 38 real, intent(in) :: x1 ! power.irp.f_shell_44: 39 real :: x2, x3, x6 ! power.irp.f_shell_44: 40 x2 = x1 * x1 ! power.irp.f_shell_44: 41 x3 = x2 * x1 ! power.irp.f_shell_44: 42 x6 = x3 * x3 ! power.irp.f_shell_44: 43 power_6 = x6 ! power.irp.f_shell_44: 44 end ! power.irp.f_shell_44: 45 52
54. real function power_7(x1) ! power.irp.f_shell_44: 47 character*(7) :: irp_here = 'power_7' ! power.irp.f_shell_44: 47 real, intent(in) :: x1 ! power.irp.f_shell_44: 48 real :: x2, x3, x6, x7 ! power.irp.f_shell_44: 49 x2 = x1 * x1 ! power.irp.f_shell_44: 50 x3 = x2 * x1 ! power.irp.f_shell_44: 51 x6 = x3 * x3 ! power.irp.f_shell_44: 52 x7 = x6 * x1 ! power.irp.f_shell_44: 53 power_7 = x7 ! power.irp.f_shell_44: 54 end ! power.irp.f_shell_44: 55 real function power_8(x1) ! power.irp.f_shell_44: 57 character*(7) :: irp_here = 'power_8' ! power.irp.f_shell_44: 57 real, intent(in) :: x1 ! power.irp.f_shell_44: 58 real :: x2, x4, x8 ! power.irp.f_shell_44: 59 x2 = x1 * x1 ! power.irp.f_shell_44: 60 x4 = x2 * x2 ! power.irp.f_shell_44: 61 x8 = x4 * x4 ! power.irp.f_shell_44: 62 power_8 = x8 ! power.irp.f_shell_44: 63 53
55. end ! power.irp.f_shell_44: 64 real function power_9(x1) ! power.irp.f_shell_44: 66 character*(7) :: irp_here = 'power_9' ! power.irp.f_shell_44: 66 real, intent(in) :: x1 ! power.irp.f_shell_44: 67 real :: x2, x4, x8, x9 ! power.irp.f_shell_44: 68 x2 = x1 * x1 ! power.irp.f_shell_44: 69 x4 = x2 * x2 ! power.irp.f_shell_44: 70 x8 = x4 * x4 ! power.irp.f_shell_44: 71 x9 = x8 * x1 ! power.irp.f_shell_44: 72 power_9 = x9 ! power.irp.f_shell_44: 73 end ! power.irp.f_shell_44: 74 real function power_10(x1) ! power.irp.f_shell_44: 76 character*(8) :: irp_here = 'power_10' ! power.irp.f_shell_44: 76 real, intent(in) :: x1 ! power.irp.f_shell_44: 77 real :: x2, x4, x5, x10 ! power.irp.f_shell_44: 78 x2 = x1 * x1 ! power.irp.f_shell_44: 79 x4 = x2 * x2 ! power.irp.f_shell_44: 80 x5 = x4 * x1 ! power.irp.f_shell_44: 81 54
56. x10 = x5 * x5 ! power.irp.f_shell_44: 82 power_10 = x10 ! power.irp.f_shell_44: 83 end ! power.irp.f_shell_44: 84 real function power_11(x1) ! power.irp.f_shell_44: 86 character*(8) :: irp_here = 'power_11' ! power.irp.f_shell_44: 86 real, intent(in) :: x1 ! power.irp.f_shell_44: 87 real :: x2, x4, x5, x10, x11 ! power.irp.f_shell_44: 88 x2 = x1 * x1 ! power.irp.f_shell_44: 89 x4 = x2 * x2 ! power.irp.f_shell_44: 90 x5 = x4 * x1 ! power.irp.f_shell_44: 91 x10 = x5 * x5 ! power.irp.f_shell_44: 92 x11 = x10 * x1 ! power.irp.f_shell_44: 93 power_11 = x11 ! power.irp.f_shell_44: 94 end ! power.irp.f_shell_44: 95 real function power_12(x1) ! power.irp.f_shell_44: 97 character*(8) :: irp_here = 'power_12' ! power.irp.f_shell_44: 97 real, intent(in) :: x1 ! power.irp.f_shell_44: 98 real :: x2, x3, x6, x12 ! power.irp.f_shell_44: 99 55
57. x2 = x1 * x1 ! power.irp.f_shell_44: 100 x3 = x2 * x1 ! power.irp.f_shell_44: 101 x6 = x3 * x3 ! power.irp.f_shell_44: 102 x12 = x6 * x6 ! power.irp.f_shell_44: 103 power_12 = x12 ! power.irp.f_shell_44: 104 end ! power.irp.f_shell_44: 105 real function power_13(x1) ! power.irp.f_shell_44: 107 character*(8) :: irp_here = 'power_13' ! power.irp.f_shell_44: 107 real, intent(in) :: x1 ! power.irp.f_shell_44: 108 real :: x2, x3, x6, x12, x13 ! power.irp.f_shell_44: 109 x2 = x1 * x1 ! power.irp.f_shell_44: 110 x3 = x2 * x1 ! power.irp.f_shell_44: 111 x6 = x3 * x3 ! power.irp.f_shell_44: 112 x12 = x6 * x6 ! power.irp.f_shell_44: 113 x13 = x12 * x1 ! power.irp.f_shell_44: 114 power_13 = x13 ! power.irp.f_shell_44: 115 end ! power.irp.f_shell_44: 116 real function power_14(x1) ! power.irp.f_shell_44: 118 56
58. character*(8) :: irp_here = 'power_14' ! power.irp.f_shell_44: 118 real, intent(in) :: x1 ! power.irp.f_shell_44: 119 real :: x2, x3, x6, x7, x14 ! power.irp.f_shell_44: 120 x2 = x1 * x1 ! power.irp.f_shell_44: 121 x3 = x2 * x1 ! power.irp.f_shell_44: 122 x6 = x3 * x3 ! power.irp.f_shell_44: 123 x7 = x6 * x1 ! power.irp.f_shell_44: 124 x14 = x7 * x7 ! power.irp.f_shell_44: 125 power_14 = x14 ! power.irp.f_shell_44: 126 end ! power.irp.f_shell_44: 127 real function power_15(x1) ! power.irp.f_shell_44: 129 character*(8) :: irp_here = 'power_15' ! power.irp.f_shell_44: 129 real, intent(in) :: x1 ! power.irp.f_shell_44: 130 real :: x2, x3, x6, x7, x14, x15 ! power.irp.f_shell_44: 131 x2 = x1 * x1 ! power.irp.f_shell_44: 132 x3 = x2 * x1 ! power.irp.f_shell_44: 133 x6 = x3 * x3 ! power.irp.f_shell_44: 134 x7 = x6 * x1 ! power.irp.f_shell_44: 135 57
59. x14 = x7 * x7 ! power.irp.f_shell_44: 136 x15 = x14 * x1 ! power.irp.f_shell_44: 137 power_15 = x15 ! power.irp.f_shell_44: 138 end ! power.irp.f_shell_44: 139 real function power_16(x1) ! power.irp.f_shell_44: 141 character*(8) :: irp_here = 'power_16' ! power.irp.f_shell_44: 141 real, intent(in) :: x1 ! power.irp.f_shell_44: 142 real :: x2, x4, x8, x16 ! power.irp.f_shell_44: 143 x2 = x1 * x1 ! power.irp.f_shell_44: 144 x4 = x2 * x2 ! power.irp.f_shell_44: 145 x8 = x4 * x4 ! power.irp.f_shell_44: 146 x16 = x8 * x8 ! power.irp.f_shell_44: 147 power_16 = x16 ! power.irp.f_shell_44: 148 end ! power.irp.f_shell_44: 149 real function power_17(x1) ! power.irp.f_shell_44: 151 character*(8) :: irp_here = 'power_17' ! power.irp.f_shell_44: 151 real, intent(in) :: x1 ! power.irp.f_shell_44: 152 real :: x2, x4, x8, x16, x17 ! power.irp.f_shell_44: 153 58
60. x2 = x1 * x1 ! power.irp.f_shell_44: 154 x4 = x2 * x2 ! power.irp.f_shell_44: 155 x8 = x4 * x4 ! power.irp.f_shell_44: 156 x16 = x8 * x8 ! power.irp.f_shell_44: 157 x17 = x16 * x1 ! power.irp.f_shell_44: 158 power_17 = x17 ! power.irp.f_shell_44: 159 end ! power.irp.f_shell_44: 160 real function power_18(x1) ! power.irp.f_shell_44: 162 character*(8) :: irp_here = 'power_18' ! power.irp.f_shell_44: 162 real, intent(in) :: x1 ! power.irp.f_shell_44: 163 real :: x2, x4, x8, x9, x18 ! power.irp.f_shell_44: 164 x2 = x1 * x1 ! power.irp.f_shell_44: 165 x4 = x2 * x2 ! power.irp.f_shell_44: 166 x8 = x4 * x4 ! power.irp.f_shell_44: 167 x9 = x8 * x1 ! power.irp.f_shell_44: 168 x18 = x9 * x9 ! power.irp.f_shell_44: 169 power_18 = x18 ! power.irp.f_shell_44: 170 end ! power.irp.f_shell_44: 171 59
61. real function power_19(x1) ! power.irp.f_shell_44: 173 character*(8) :: irp_here = 'power_19' ! power.irp.f_shell_44: 173 real, intent(in) :: x1 ! power.irp.f_shell_44: 174 real :: x2, x4, x8, x9, x18, x19 ! power.irp.f_shell_44: 175 x2 = x1 * x1 ! power.irp.f_shell_44: 176 x4 = x2 * x2 ! power.irp.f_shell_44: 177 x8 = x4 * x4 ! power.irp.f_shell_44: 178 x9 = x8 * x1 ! power.irp.f_shell_44: 179 x18 = x9 * x9 ! power.irp.f_shell_44: 180 x19 = x18 * x1 ! power.irp.f_shell_44: 181 power_19 = x19 ! power.irp.f_shell_44: 182 end ! power.irp.f_shell_44: 183 real function power_20(x1) ! power.irp.f_shell_44: 185 character*(8) :: irp_here = 'power_20' ! power.irp.f_shell_44: 185 real, intent(in) :: x1 ! power.irp.f_shell_44: 186 real :: x2, x4, x5, x10, x20 ! power.irp.f_shell_44: 187 x2 = x1 * x1 ! power.irp.f_shell_44: 188 x4 = x2 * x2 ! power.irp.f_shell_44: 189 60
62. x5 = x4 * x1 ! power.irp.f_shell_44: 190 x10 = x5 * x5 ! power.irp.f_shell_44: 191 x20 = x10 * x10 ! power.irp.f_shell_44: 192 power_20 = x20 ! power.irp.f_shell_44: 193 end ! power.irp.f_shell_44: 194 61
63. IRPF90 for HPC Using the --align option, IRPF90 can introduce compiler directives for the Intel Fortran compiler, such that all the arrays are aligned. The $IRP_ALIGN variable corresponds to this alignment. For example, integer function align_double(i) integer, intent(in) :: i integer :: j j = mod(i,max($IRP_ALIGN,4)/4) if (j==0) then align_double = i else align_double = i+4-j endif end 62
64. BEGIN_PROVIDER [ integer, n ] &BEGIN_PROVIDER [ integer, n_aligned ] integer :: align_double n = 19 n_aligned = align_double(19) END_PROVIDER BEGIN_PROVIDER [ double precision, Matrix, (n_aligned,n) ] Matrix = 0.d0 END_PROVIDER program test print *, size(Matrix,1), size(Matrix,2) end Generated code without alignment: ! -*- F90 -*- ! 63
65. !-----------------------------------------------! ! This file was generated with the irpf90 tool. ! ! ! ! DO NOT MODIFY IT BY HAND ! !-----------------------------------------------! module matrix_mod double precision, allocatable :: matrix (:,:) logical :: matrix_is_built = .False. integer :: n_aligned integer :: n logical :: n_is_built = .False. end module matrix_mod ! -*- F90 -*- ! !-----------------------------------------------! ! This file was generated with the irpf90 tool. ! 64
66. ! ! ! DO NOT MODIFY IT BY HAND ! !-----------------------------------------------! subroutine provide_matrix use matrix_mod implicit none character*(14) :: irp_here = 'provide_matrix' integer :: irp_err logical :: irp_dimensions_OK if (.not.n_is_built) then call provide_n endif if (allocated (matrix) ) then irp_dimensions_OK = .True. irp_dimensions_OK = irp_dimensions_OK.AND.(SIZE(matrix,1)==(n_aligned)) irp_dimensions_OK = irp_dimensions_OK.AND.(SIZE(matrix,2)==(n)) if (.not.irp_dimensions_OK) then deallocate(matrix,stat=irp_err) if (irp_err /= 0) then 65
67. print *, irp_here//': Deallocation failed: matrix' print *, ' size: (n_aligned,n)' endif if ((n_aligned>0).and.(n>0)) then allocate(matrix(n_aligned,n),stat=irp_err) if (irp_err /= 0) then print *, irp_here//': Allocation failed: matrix' print *, ' size: (n_aligned,n)' endif endif endif else if ((n_aligned>0).and.(n>0)) then allocate(matrix(n_aligned,n),stat=irp_err) if (irp_err /= 0) then print *, irp_here//': Allocation failed: matrix' print *, ' size: (n_aligned,n)' endif 66
68. endif endif if (.not.matrix_is_built) then call bld_matrix matrix_is_built = .True. endif end subroutine provide_matrix subroutine bld_matrix use matrix_mod character*(6) :: irp_here = 'matrix' ! matrix.irp.f: 19 Matrix = 0.d0 ! matrix.irp.f: 20 end subroutine bld_matrix subroutine provide_n use matrix_mod implicit none character*(9) :: irp_here = 'provide_n' integer :: irp_err logical :: irp_dimensions_OK if (.not.n_is_built) then call bld_n n_is_built = .True. 67
69. endif end subroutine provide_n subroutine bld_n use matrix_mod character*(1) :: irp_here = 'n' ! matrix.irp.f: 12 integer :: align_double ! matrix.irp.f: 14 n = 19 ! matrix.irp.f: 15 n_aligned = align_double(19) ! matrix.irp.f: 16 end subroutine bld_n integer function align_double(i) ! matrix.irp.f: 1 character*(12) :: irp_here = 'align_double'! matrix.irp.f: 1 integer, intent(in) :: i ! matrix.irp.f: 2 integer :: j ! matrix.irp.f: 3 j = mod(i,max(1,4)/4) ! matrix.irp.f: 4 if (j==0) then ! matrix.irp.f: 5 align_double = i ! matrix.irp.f: 6 68
70. else ! matrix.irp.f: 7 align_double = i+4-j ! matrix.irp.f: 8 endif ! matrix.irp.f: 9 end ! matrix.irp.f: 10 Output: $ ./test 19 19 Generated code with an alignment of 32 bytes: ! -*- F90 -*- ! !-----------------------------------------------! ! This file was generated with the irpf90 tool. ! ! ! ! DO NOT MODIFY IT BY HAND ! !-----------------------------------------------! 69
71. module matrix_mod double precision, allocatable :: matrix (:,:) !DIR$ ATTRIBUTES ALIGN: 32 :: matrix logical :: matrix_is_built = .False. integer :: n_aligned integer :: n logical :: n_is_built = .False. end module matrix_mod ! -*- F90 -*- ! !-----------------------------------------------! ! This file was generated with the irpf90 tool. ! ! ! ! DO NOT MODIFY IT BY HAND ! !-----------------------------------------------! subroutine provide_matrix 70
72. use matrix_mod implicit none character*(14) :: irp_here = 'provide_matrix' integer :: irp_err logical :: irp_dimensions_OK if (.not.n_is_built) then call provide_n endif if (allocated (matrix) ) then irp_dimensions_OK = .True. irp_dimensions_OK = irp_dimensions_OK.AND.(SIZE(matrix,1)==(n_aligned)) irp_dimensions_OK = irp_dimensions_OK.AND.(SIZE(matrix,2)==(n)) if (.not.irp_dimensions_OK) then deallocate(matrix,stat=irp_err) if (irp_err /= 0) then print *, irp_here//': Deallocation failed: matrix' print *, ' size: (n_aligned,n)' endif if ((n_aligned>0).and.(n>0)) then allocate(matrix(n_aligned,n),stat=irp_err) 71
73. if (irp_err /= 0) then print *, irp_here//': Allocation failed: matrix' print *, ' size: (n_aligned,n)' endif endif endif else if ((n_aligned>0).and.(n>0)) then allocate(matrix(n_aligned,n),stat=irp_err) if (irp_err /= 0) then print *, irp_here//': Allocation failed: matrix' print *, ' size: (n_aligned,n)' endif endif endif if (.not.matrix_is_built) then call bld_matrix matrix_is_built = .True. 72
74. endif end subroutine provide_matrix subroutine bld_matrix use matrix_mod character*(6) :: irp_here = 'matrix' ! matrix.irp.f: 19 Matrix = 0.d0 ! matrix.irp.f: 20 end subroutine bld_matrix subroutine provide_n use matrix_mod implicit none character*(9) :: irp_here = 'provide_n' integer :: irp_err logical :: irp_dimensions_OK if (.not.n_is_built) then call bld_n n_is_built = .True. endif end subroutine provide_n subroutine bld_n 73
75. use matrix_mod character*(1) :: irp_here = 'n' ! matrix.irp.f: 12 integer :: align_double ! matrix.irp.f: 14 n = 19 ! matrix.irp.f: 15 n_aligned = align_double(19) ! matrix.irp.f: 16 end subroutine bld_n integer function align_double(i) ! matrix.irp.f: 1 character*(12) :: irp_here = 'align_double'! matrix.irp.f: 1 integer, intent(in) :: i ! matrix.irp.f: 2 integer :: j ! matrix.irp.f: 3 j = mod(i,max(32,4)/4) ! matrix.irp.f: 4 if (j==0) then ! matrix.irp.f: 5 align_double = i ! matrix.irp.f: 6 else ! matrix.irp.f: 7 align_double = i+4-j ! matrix.irp.f: 8 endif ! matrix.irp.f: 9 end ! matrix.irp.f: 10 Output: 74
76. $ ./test 20 19 To remove all compiler directives introduced by the programmer, it is possible to use irpf90 --no-directives. 75
77. More about IRPF90 • ArXiv: http://arxiv.org/abs/0909.5012 • Web site: http://irpf90.ups-tlse.fr 76
