Responsive Web Applications
At Squares Conf.
snookca
April 27, 2017
Transcript
114 slides
Responsive Web Applications with Container Queries
A talk more about process than code
None
Beautiful Accounting Software
None
None
None
Goal #1 Evolve the design
Goal #2 Support Multiple Devices
None
None
None
Goal #1 Evolve the design
Goal #2 Support Multiple Devices
Responsive
Responsive
None
None
Device-specific design and development
Designers see a feature through all platforms
None
Goal #1 Evolve the design
Goal #2 Support Multiple Devices
None
None
None
Monolithic app with accessible templates
Ignored Mobile Web
Limited Mobile App
None
None
Each horizontal block is considered in the context of the
viewport
None
None
None
None
None
Each page can more easily be art directed
None
• No orders • One order • Less than one
page of orders • Multiple pages of orders • Has Info Notifications • Tab overflow • Has Warning Notifications • Has limited access to features • Has different apps installed
And now consider all of those things for multiple viewports
A single page in a web application can have dozens
of variations
A component-based site has components respondingly differently to multiple contexts
None
None
With media queries, you have to know the possible interplay
of all objects
With container queries, you only have to know the interplay
within a single object
No spec for container queries
None
None
Declare in: CSS, HTML, or JavaScript
https://github.com/ResponsiveImagesCG/cq-demos .element:media( min-width:500px ) {} https://github.com/tysonmatanich/elementQuery .element[min-width~="500px"] { background-color: #eee;
}
http://elementqueries.com/ @element ".element" and (min-width: 500px) { .element {
background: gold; } }
https://github.com/tysonmatanich/elementQuery .element[min-width~="400px"] { }
To parse CSS, either need to be on same domain
or set up CORS
https://github.com/Snugug/eq.js data-eq-pts="small: 400, medium: 600, large: 900"
At HTML level, requires consistency of implementation across app
We chose JavaScript
elements = [ { "module": ".flex--2x1", "className":"responsiveClass", "minWidth": 768, "maxWidth":
1024 } ]
Going Responsive meant a consistent feature set across all devices
New features automatically have cross-device support
None
Went responsive in under a month†
How the heck do you do that in a month?
None
There’s a discernible delay in execution
It’s not about the properties, it’s about the purpose.
None
None
None
Tried to use grid classes for everything
Had to write extra classes just to define responsive story
Single purpose classes resulted in less edge cases (and less
code!)
Gzip minimizes duplicate properties really well
Tables are difficult
None
None
Avoid too much on the horizontal axis
None
None
None
Goal #1 Evolve the design
Goal #2 Support Multiple Devices
Goal #1 reframed: Allow anybody to make product-wide design changes
quickly and easily
Problem: Different tech stacks
None
Make the right things easy and the wrong things hard
10 5
Yahoo! still does a custom experience per device
Shopify is getting rid of Container Queries
None
None
None
<div class="two-columns"> <div class="col1"> … </div> <div class="col2"> … </div>
</div>
.two-columns { display: flex; flex-wrap: wrap; } .col1, .col2 {
flex-grow: 1; } .col1 { flex-basis: 66%; min-width: 360px; } .col2 { flex-basis: 33%; }
None
<div class="media-body"> <div class="media-content"> </div> <div class="media-actions"> <a href="…"> Button
</a> </div> </div>
.media-body { display: flex; flex-wrap: wrap; }
.media-content { flex-grow: 1; flex-basis: 400px; margin-right: 20px; }
.media-actions { align-self: center; margin: 20px 0; }
None
None
<div class="items"> <div class="box">…</div> <div class="box">…</div> <div class="box">…</div> </div>
.items { display: grid; grid-template-columns: repeat(auto-fit, minmax(400px, 1fr)); }
<div class="box"> <div class="box-image"> <img src="…" height="150" > </div> <div
class="box-content">...</div> </div>
.box { display: flex; flex-wrap: wrap; }
.box-image { flex-grow: 1; flex-shrink: 0; flex-basis: 150px; } .box-image
> img { width: 100%; object-fit: cover; }
.box-content { margin: 10px; flex-shrink: 1; flex-grow: 1; flex-basis: 60%;
}
None
Designers should think Responsive before they need to.
Container Queries enable faster development
Use techniques to avoid media or container queries altogether
http://ricg.io
Thank you. http:/ /snook.ca/ @snookca
