GLSLでパストレーシングしてコーネルボックスを出す
Search
yumcyawiz
November 28, 2020
Programming
0
510
GLSLでパストレーシングしてコーネルボックスを出す
OSK11月LT会のスライド
Github:
https://github.com/yumcyaWiz/glsl-cornellbox
