SREcon20 Give Your PXE Wings!

SREcon20 Give Your PXE Wings!

What is PXE anyway and why does it work?
System bootstrapping is one of the great mysteries in IT. In this talk, we'll break the entire bootstrapping process down into components. That will allow us to discuss ways to make it faster, simpler, and more reliable. Most importantly, we'll show how you can improve the automation options involved in day two operations for anything that boots.

Rob Hirschfeld

December 08, 2020
Tweet

More Decks by Rob Hirschfeld

Other Decks in Technology

Transcript

  1. Give Your PXE Wings! It’s not magic! How booting actually

    works. Presentation for virtual SREcon 2020 By Rob Hirschfeld, RackN
  2. Rob Hirschfeld @zehicle Co-Founder of RackN We created Digital Rebar

    Bare Metal Provisioning ++ @L8istSh9y Podcast on PXE: http://bit.ly/pxewings
  3. O/S In concept, Provisioning is Easy! We’re just installing an

    operating system on a server or switch! Why is that so hard?! • Bootstrapping • Firmware Limitations • Variation • Networking • Security • Performance • Post configuration O/S Computer
  4. In concept, Provisioning is Easy! We’re just installing an operating

    system on a server or switch! Why is that so hard?! • Bootstrapping • Firmware Limitations • Variation • Networking • Security • Performance • Post configuration Pre- & Post- Config And that’s not even including: • System Inventory • System Validation • Hardware Configuration • Naming & Addressing • Credentials Injection
  5. Exploring Provisioning Approaches Netboot (25/40 min) • PXE • iPXE

    • ONIE • Kickstart • Preseed Esoteric Flavors (5/40 min) • kexec • Secure Boot • BMC Boot Image Deploy (10/40 min) • Packer • Write Boot Part • Cloud Init
  6. Exploring Provisioning Approaches All roads lead to a kernel init

    process Netboot (25/40 min) • PXE • iPXE • ONIE • Kickstart • Preseed Esoteric Flavors (5/40 min) • kexec • Secure Boot • BMC Boot Image Deploy (10/40 min) • Packer • Write Boot Part • Cloud Init
  7. PXE

  8. PXE

  9. Server lpxelinux.0 Bootstrapping is a multi-stage process Firmware PXE DHCP

    NextServer & Options Bootloader Stage 1 Provisioning Service(s) TFTP ipxe.efi Bootloader Stage 2 HTTP(S) O/S ISO HTTP(S) O/S Kernel
  10. Server lpxelinux.0 Each stage is actually a NEW O/S Load

    Firmware PXE DHCP NextServer & Options Bootloader Stage 1 Provisioning Service(s) TFTP ipxe.efi Bootloader Stage 2 HTTP(S) O/S ISO HTTP(S) O/S Kernel DHCP DHCP DHCP DHCP
  11. Server And modern servers can skip TFTP! So… technically, no

    longer PXE Firmware PXE DHCP NextServer & Options Provisioning Service(s) ipxe.efi Bootloader Stage 2 HTTP(S) O/S ISO HTTP(S) O/S Kernel
  12. Provisioning Service(s) Server Provisioning is more than PXE O/S Kernel

    iPXE Bootloader O/S ISO Kickstart Installation Post-Config Config Templates Download Packages Access & Apps
  13. Provisioning Service(s) Server Hardware varies, so Install must be guided

    by templates O/S Kernel Kickstart Config Templates
  14. Provisioning Service(s) Server ISOs are minimal and stale So they

    must be updated O/S Kernel Kickstart Installation Download Packages Repo Mirrors
  15. Provisioning Service(s) Server And then you can actually connect to

    start configuring the system! O/S Kernel Kickstart Installation Post-Config Access & Apps
  16. Provisioning Service(s) Server Automating Provisioning means Connecting all these steps

    together O/S Kernel iPXE Bootloader O/S ISO Kickstart Installation Post-Config Config Templates Download Packages Access & Apps
  17. Infrastrastructure as Code iPXE Bootloader O/S ISO Provisioning Service(s) Server

    But wait…. There’s more to consider! O/S Kernel Kickstart Installation Post-Config Config Templates Download Packages Access & Apps Out of Band Management (BMC, IPMI, Redfish, etc)
  18. Typical PXE Questions Why is this so fragile? What about

    PXE over Wifi? What about using a VLAN? Can I dockerize this? What about setting BIOS & RAID? How can I make this faster?
  19. How can we simplify that?!! At RackN, we’ve been using

    an in memory operating system, “sledgehammer,” based on CentOS. It’s highly optimized to • Run on nearly any hardware • Load very quickly • Collect deep inventory • Have built-in tools for system tasks like hardware config Provisioning Service(s) Server PXE PXE/iPXE Small Footprint RAM only O/S Informed Installation Guided Installation Inventory reboot
  20. Image Based Deployment (10x faster!) Provisioning Service(s) Server PXE PXE/iPXE

    Small Footprint RAM only O/S Write O/S To Drive(s) O/S Image as Archive Informed Installation reboot Machine Init
  21. Container Registries Immutable Provisioning Highly Available Provisioning Service(s) Server PXE

    PXE/iPXE Minimal Footprint RAM only O/S Config & Attach Disks Machine Initialize Load Apps & Containers
  22. ESXi Provisioning Provisioning Service(s) Server O/S Kernel iPXE Bootloader O/S

    ISO weasel restricted CLI/python Config Templates Access & Apps Control via VMw APIs VMware Tooling ESXi
  23. ONIE: Open Network Install Environment Designed for Embedded Systems where

    we’re replacing the O/S as a complete image. Does have DHCP options for a startup script. Provisioning Service(s) Switch Current Firmware DHCP HTTP(S) O/S Image New Firmware
  24. Server Running O/S kexec (kernel execute) New Kernel Provisioning Service(s)

    Normal Provision New O/S Download New Kernel Starts Without Rebooting kexec
  25. Server Running O/S kexec (kernel execute) New Kernel Provisioning Service(s)

    Normal Provision New O/S Download New Kernel New Installation kexec kexec Start iPXE Normal Provision Without Rebooting
  26. Secure Boot Required SIGNED Bootloaders Server Secured Firmware DHCP NextServer

    & Options Provisioning Service(s) Signed ipxe.efi Trusted Bootloader HTTP(S) Signed O/S ISO HTTP(S) Trusted O/S Kernel Enabled Verified Verified TPM
  27. BMC Boot option 1 Server Firmware Install Media Provisioning Service(s)

    BMC Attached O/S Install Kickstart Installation Post-Config Download Packages Access & Apps
  28. BMC Boot option 2 Server Firmware Install Media Provisioning Service(s)

    Bootloader Kickstart Installation Post-Config Download Packages Access & Apps BMC Config Templates DHCP
  29. Thanks! Contact us: Rob Hirschfeld, RackN.com Digital Rebar Behind the

    Firewall, Self-Service Infrastructure as Code Self-Trials: rebar.digital
