RubyMotion @ a2rb

RubyMotion @ a2rb

Andrew Sardone

December 11, 2012
Tweet

More Decks by Andrew Sardone

Other Decks in Programming

Transcript

  1. Objective-C • Strict superset of C • Adds Smalltalk message

    passing OOP to C Smalltalk myObject say: 'Hello, world!' Objective-C [myObject say: @"Hello, world!"];
  2. Ruby • “A dynamic, open source programming language with a

    focus on simplicity and productivity. ” • Flexible, expressive syntax • Smalltalk meets Perl myObject.say "Hello, world!"
  3. MacRuby An open source Ruby 1.9 implemented directly on top

    of Apple’s Objective-C runtime, LLVM compiler infrastructure, and OS X Foundation frameworks. by Laurent Sansonetti
  4. RubyMotion A commercial toolchain for iOS development Similar to MacRuby,

    it’s Ruby implemented on top of the Objective-C runtime by Laurent Sansonetti
  5. Ruby Objects on Objective-C Runtime dict = {} # {}

    dict.class # Hash dict.superclass # NSMutableDictionary dict.addValue("world", forKey: "hello") # { "hello" => "world" } dict["foo"] = "bar" # { "hello" => "world", "foo" => "bar" }
  6. str = "Ruby Motion" # "Ruby Motion" str.class.ancestors # [String,

    NSMutableString, NSString, Comparable, NSObject, Kernel] str.split.insertObject("Try", atIndex:0) # ["Try", "Ruby", "Motion"]
  7. Toolchain • CLI-based workflow via rake • Statically compiles Ruby

    code to LLVM byte code • Automatic memory management, similar to Automatic Reference Counting (ARC) – not Ruby's normal garbage collection
  8. Statically Compiled class HelloView < UIView def drawRect(rect) end end

    [:class, :HelloView, [:const, :UIView], [:defn, :drawRect, ...]] define internal i32 @"rb_scope__drawRect:__"(i32 %self, i8* nocapture %sel, i32 %rect) { MainBlock: %right_addr.i42 = alloca i32, align 4 %right_addr.i30 = alloca i32, align 4 %right_addr.i = alloca i32, align 4 %argv29 = alloca [4 x i32] %argv29.sub = getelementptr inbounds [4 x i32]* %argv29, i32 0, i32 0 %0 = load i32* @5 %1 = load i8** @6 %2 = call fastcc i32 @vm_ivar_get(i32 %self, i32 %0, i8* %1) switch i32 %2, label %then [ i32 0, label %else i32 4, label %else ] LLVM Ruby AST LLVM IR Assembly… via Rich Kilmer’s RubyConf 2012 Presentation
  9. Ruby NSArray *a = @[ @"Foo", @"Bar" ]; [a enumerateObjectsUsingBlock:^(id

    obj, NSUInteger idx, BOOL *stop) { NSLog(@"%@", obj); }]; # vs. ["Foo", "Bar"].each_with_index { |obj, i| puts obj }
  10. Ruby-fication // UIKit in Objective-c [button addTarget:self action:@selector(buttonTapped:) forControlEvents:UIControlEventTouchUpInside]; //

    Elsewhere - (void)buttonTapped:(id)sender { self.backgroundColor = [UIColor redColor]; } # vs. # BubbleWrap UIControl / UIButton helpers button.when(UIControlEventTouchUpInside) do self.backgroundColor = UIColor.redColor end via http://clayallsopp.com/posts/the-ruby-motion-way/
  11. Testing describe "The Timer view controller" do tests TimerController it

    "has a timer label" do view('Tap to start').should.not == nil end it "starts a timer" do tap 'Start' controller.timer.isValid.should == true end it "increases the timer label value" do label = view('Tap to start') label.text.to_f.should == 0 tap 'Start' proper_wait 1 tap 'Stop' label.text.to_f.should > 1 label.text.to_f.should < 2 end end
  12. Disadvantages? • Another toolchain dependency • Core product is closed-source

    (and $200) • Some tools still missing (lint / better static analysis)
  13. “I'm trying to convince Objective-C developers to look into Ruby

    and Ruby developers to look into Objective-C” – Matt Aimonetti NSBrief #72
  14. Additional Resources • RubyMotion Developer Center rubymotion.com/developer-center/ • RubyMotion Consoler

    – in-browser REPL pieceable.com/rubymotion-console • RubyMotion Tutorial rubymotion-tutorial.com • BubbleWrap – Cocoa wrappers/helpers bubblewrap.io • pinboard.in/u:andrewsardone/t:rubymotion
