121 slides
-
彼得潘簡介 超級喜歡 Apple,因此從事 Apple 相關的各種⼯作。開發 了⼀點點 iOS App,寫了⼀點點 Swift 程式的書和⽂章,
開了⼀點點 iOS App 開發的課,認識了很多同樣熱愛開發 iOS App 的可愛學⽣。 ps: 還有幫偶像 Penny 製作 App 彼得潘網站 -
⼤綱 • SwiftUI 介紹 & 入⾨ • 開發 MOPCON SwiftUI
App 的過程和各種問題 • MOPCON API 串接,連網跟讀取檔案測試 • 開發 iOS App( iPhone & iPad) • 開發 macOS App • 開發 watchOS App 我們要開發 4 種平台的 App,Go ! -
製作 iOS App 畫⾯的新技術 - SwiftUI • 2019 推出的新技術 (UI:
User Interface) • 同樣的功能,可以寫更少的程式實現。 • 程式愈少,問題(bug)也會愈少。 • 程式更容易理解,可讀性更好。 • Preview: 可以預覽 App 畫⾯ & 執⾏ App,加快 App 開發的速度 • Dynamic replacement: 修改程式後,不⽤重新 compile,在 Live Preview 可操作新版程式⽣成的 App • 資料跟畫⾯有⽅便的同步⽅法,減少問題發⽣的機率。 • iOS,iPadOS,macOS,watchOS,tvOS App 可以採⽤類似的寫法。 • https://developer.apple.com/xcode/swiftui/ -
The best way to build an app is with Swift
and SwiftUI WWDC22 Platforms State of the Union SwiftUI is the preferred app-builder technology Planning your iOS app -
The shortest path to building great apps on every device
WWDC19 SwiftUI On All Devices 從前要學四種不同的技術才能開發不同平台的 App 現在學會 SwiftUI 就能製作不同平台的 App -
Learn once, apply anywhere • 學會 SwiftUI,就能應⽤在不同的平台 • share code:
部分的程式可在不同平台使⽤,不⽤修改 • 並不是寫⼀份 code 就能產⽣每個平台的 App • 每個平台的尺⼨差很多,也有各⾃的強項跟功能,還是要針對不同平台加入 ⼀些程式 -
⽀援多個平台的 UI 元件 WWDC19 SwiftUI On All Devices Picker Toggle
同⼀份程式,⽣成的元件在不同的平台會以平台上標準的樣式呈現 -
之前的 MOPCON App • 使⽤ UIKit 開發 • 使⽤ storyboard
製作畫⾯ • https://cutt.ly/iVR0RHa -
⽤ SwiftUI 開發跨平台的 MOPCON App • 串接 MOPCON API 抓取議程
& 講者資料 • 模仿 2022 的 MOPCON iOS App,製作議程 & 講者⾴⾯ • 開發 iOS,macOS,watchOS 版,⽀援 iPhone, iPad, Mac, Apple Watch • 使⽤ Xcode 14 開發,搭配 iOS 16 SDK,使⽤第 4 代的 SwiftUI API -
如果⼀開始建立的是 iOS App 專案 可以另外新增 Mac Destination Designed for iPad
可以在 Apple silicon 的 Mac 執⾏,畫⾯會是 iPad App 的樣⼦ 製作原⽣的 Mac App,可使⽤ macOS SDK 各種 Mac App 的差異 https://developer.apple.com/documentation/xcode/con f iguring-a-multiplatform-app-target -
Designed for iPad Mac App 開關是 Mac App 的樣式 開關是
iPad App 的樣式 -
定義畫⾯的型別 • SwiftUI UI 元件的型別以 struct 定義,遵從 protocol View •
protocol View 定義跟畫⾯有關 的功能 -
SwiftUI UI 元件的型別以 struct 定義,遵從 protocol View Button,Text & Image
遵從 View,所以 Button,Text 和 Image 都是 View,具有 View 的功能和特性。 -
protocol View • 遵從 protocol View 須定義 property body •
變數 body 決定畫⾯顯⽰的內容 -
some View • body 裡回傳的東⻄必須是某⼀種 view,須遵從 protocol View, 比⽅⽂字,圖片等 •
some 跟 Swift 的 Opaque Types 有關 https://docs.swift.org/swift-book/LanguageGuide/ OpaqueTypes.html -
modi f ier 是 function,呼叫 function 後得到新的 UI 元件,有著新的樣式跟功能 客製
UI 元件樣式 & 功能的 SwiftUI modi f ier http://bit.ly/2IJ7cyd struct ContentView: View { var body: some View { Text("The best way to build an app is with Swift and SwiftUI") .font(.largeTitle) .foregroundColor(.orange) .padding() .background(.blue) .cornerRadius(10.0) .rotationEffect(.degrees(10)) .shadow(radius: 20) .padding() } } func cornerRadius(_ radius: CGFloat, antialiased: Bool = true) -> some View 得到新的 view,加了圓⾓效果 -
ViewBuilder: 從 closure 建立 view • @ViewBuilder 參數可以寫的程式 https://cutt.ly/SlYHZy4
• ViewBuilder https://developer.apple.com/documentation/swiftui/viewbuilder VStack 的 init -
Stack 的組合 & 圖⽂混合 顯⽰圖片的 Image 呼叫 resizable 才能改變圖片⼤⼩
http://bit.ly/2jWn4DM -
利⽤ Spacer,padding,offset 調整元件位置 • Spacer: 長出看不⾒的空間 • padding: 加入間距 •
offset: 從原本的位置偏移 • http://bit.ly/2mSS6xv struct ContentView: View { var body: some View { HStack { Image("peter") .resizable() .scaledToFill() .frame(width: 100, height: 100) Spacer() Text("與 🍎 相遇好幸運") .font(.largeTitle) .offset(x: 10, y: 40) } .padding() .background(.yellow) } } -
在 asset 加入 App Icon • 設定 iOS & macOS
的 App Icon • Xcode 14 的 iOS App icon 只要設 定 1024 * 1024 https://cutt.ly/MBYfU0V -
在 asset 加入開頭畫⾯圖片 & App 使⽤的顏⾊ • AccentColor: App 的主⾊
• background: 背景顏⾊ • light blue: 淡藍⾊ logo -
從 Info 的 Launch Screen 設定開頭畫⾯ 設定 Image Name &
Background color https://cutt.ly/7V7Ek9U 輸入圖片和顏⾊的名字 -
App 寫法參考的 Apple 範例 • Develop in Swift Data Collections
(Xcode 13) 使⽤ generic,protocol & associatedtype 定義 APIRequest & APIService (網路相關程式) https://cutt.ly/3VA3I3R • Earthquake App (網路相關程式) https://cutt.ly/DVA38TW • Food Truck: Building a SwiftUI multiplatform app https://cutt.ly/rVA8kDl • Landmarks App https://cutt.ly/dVA8dtS • Fruta: Building a Feature-Rich App with SwiftUI https://cutt.ly/UV7VW5x • Bringing robust navigation structure to your SwiftUI app (iOS 16 的 NavigationStack & NavigationSplitView) https://cutt.ly/GV7BoVm -
定義時間的 extension DateIntervalFormatter: 取得時間區間的字串 extension DateIntervalFormatter { static let hourMinFormatter
= { let formatter = DateIntervalFormatter() formatter.dateTemplate = "HH:mm" return formatter }() } DateIntervalFormatter.hourMinFormatter.string(from: .now, to: .now.advanced(by: 600)) 13:57 – 14:07 -
把 JSON 放在 development assets ⽅便開發時不連網路測試,從 preview 測試 App 時也不⽤連網路
從 Safari 抓取 JSON 檔 • 加到 Preview Content 下,可以加 到 Preview Assets.xcassets,或是 放在 Preview Content 下 • 只有開發時使⽤,檔案不會包在上 架的 App 裡 • https://cutt.ly/uVA56TX 將 JSON 檔加入專案裡 -
MOPCON JSON 對應的 Decodable 型別 session & speaker 清單 API
回傳的 JSON 第⼀層都是 success, message, data -
MOPCON API 串接的相關檔案 定義 3 個 API 的 request,遵從 protocol
APIRequest 此寫法的相關說明可參考 Apple 的 Develop in Swift Data Collections https://cutt.ly/3VA3I3R protocol APIRequest 宣告網路的相關功能 -
HTTPDataDownloader & TestDownloader 呼叫 httpData 抓資料 連到網路抓資料 判斷 url 的
lastPathComponent,然 後讀取 App 裡的 JSON 檔 比⽅ https://mopcon.org/api/2022/ session 會讀取 session.json -
顯⽰⼤頭照的 SpeakerImage • 使⽤抓取網路圖片的 Nuke 套件 https://github.com/kean/Nuke •
使⽤ SPM 安裝第三⽅套件 https://cutt.ly/yBxABnn • LazyImage 來⾃ NukeUI -
指定 preview 尺⼨的 previewLayout 顯⽰剛好⼤⼩的 sizeThatFits https://cutt.ly/MV6OGzh • 點選箭頭切換到 Selectable
模式,在 Selectable 模式才能讓 preview 變成 previewLayout 指定的⼤⼩。 • 在 Selectable 模式不會連到網路抓資料 -
提供假資料,⽅便 preview 顯⽰資料 Period, Session, Speaker 都有 提供給 preview 的假資料
讀取 JSON 檔,解碼成 Decodable 型別 傳入 Speaker.preview preview 顯⽰時不⽤連到網路抓資料 -
function load 讀取 JSON 檔,解碼成 Decodable 型別 讀取 main bundle
下的檔案 Apple Landmark 範例 https://cutt.ly/IBYmQiq -
4 個⾴⾯共同的樣式 ⼀樣的背景⾊ ⼀樣⾼度的 navigation bar ⼀樣的 tab bar &
navigation bar 顏⾊ 同樣的 modi f ier 要寫很多次,有精簡的⽅法嗎 ? -
⾃訂 modi f ier,遵從 protocol ViewModi f ier,定義 body •
background(Color.background) 深藍⾊的背景 • toolbarBackground(.visible, for: .tabBar, .navigationBar) 顯⽰ navigation bar & tab bar 的背景⾊ • toolbarBackground(Color.background, for: .tabBar, .navigationBar) 將 navigation bar & tab bar 設為深藍⾊ • navigationBarTitleDisplayMode(.inline) navigation bar ⾼度正常,不要放⼤ 套⽤到每個⾴⾯的 CommonStyleModi f ier -
tab bar 沒設定顯⽰背景⾊時,可能會在 tab bar 的背後顯⽰⾴⾯的內容 • TabView 顯⽰分⾴,類似
tab bar controller • tabItem 設定 tab 的 icon & ⽂字 • List 顯⽰表格 • ForEach 將集合裡的資料變成⼀個個 view https://cutt.ly/9BsAQpy -
dark mode & preferredColorScheme(.dark) • MOPCON App 的時間電量是⽩⾊,⽽且許多⽂字也以 ⽩⾊為主,因此很適合 dark
mode • preferredColorScheme(.dark) 可讓整個 view 變 dark mode • ⽅便 preview 畫⾯套⽤的 custom modi fi er • preview 呼叫 preferredColorScheme(.dark) 讓 preview 顯⽰的畫⾯變成 dark mode • 之後會再說明如何讓整個 App 變 dark mode -
The compiler is unable to type-check this expression in reasonable
time; try breaking up the expression into distinct sub-expressions 錯誤的原因是因為 ViewBuilder 參數傳入的 closure 程式太複雜,解法是將某些程式另外 包成 function 或 computed property https://cutt.ly/sBczRMo 為什麼剛剛要另外定義 function calculateRange ? 要是你敢不定義,可怕的事會發⽣呀 -
抓取 speakers 資料的 SpeakersProvider • SwiftUI view 可觀察 ObservableObject,ObservableObject 的
published property 改變時會通知觀察它的 view 更新畫⾯ • 呼叫 send 抓資料,抓到資料後存在 published property speakers,觸發 觀察它的 view 更新畫⾯ -
@MainActor 讓類別 SpeakerProvider 的程式在 main thread 執⾏,確保在 main thread 更新畫⾯
Publishing changes from background threads is not allowed; make sure to publish values from the main thread (via operators like receive(on:)) on model updates. 如果沒有加 @MainActor,會出現在背景 thread 發布資料改變的錯誤 -
顯⽰講者清單的 SpeakerView @StateObject 觀察 ObservableObject,當 ObservableObject 的 published property 改變時更新畫⾯
preview 的 JSON 來源為 local 利⽤ SpeakersProvider 抓資料 -
畫⾯出現時抓資料 • task 畫⾯出現時執⾏非同步的 await 程式抓資料 • if provider.speakers.isEmpty
沒有資料時才抓資料,確保資料只抓⼀次 • SpeakersProvider 抓到資料,存入 speakers, 觸發 SpeakersView 更新畫⾯ -
NavigationStack,NavigationLink & List • NavigationStack 類似 UIKit 的 navigation
controller,控制⾴⾯ 的切換,上⽅顯⽰ navigation bar • List SwiftUI 的表格 • ⽤ ForEach 讀取講者的 array,產⽣每個講者 的 row https://cutt.ly/sBYOg3d • NavigationLink 切換⾴⾯的按鈕,點選跳到 SpeakerDetailView https://cutt.ly/uBsSeRD -
如果沒有呼叫 listRowBackground 設定 row 的顏⾊ row 的顏⾊在 light mode 為⽩⾊,dark
mode 為⿊⾊ 如果忘了寫,沒有設定 row 的顏⾊ light mode dark mode -
隱藏 disclosure indicator https://cutt.ly/DBsSnpF 標準寫法,顯⽰ disclosure indicator 隱藏 disclosure indicator
⽤ ZStack 包住 SpeakerRow & NavigationLink -
加了 Section 才能還沒抓到資料時顯⽰ List 的背景⾊ 分類表格的 Section,可搭配 section header &
footer 正確顯⽰ List 的背景⾊ 沒有顯⽰ List 的背景⾊ -
顯⽰講者詳細資訊的 SpeakerDetailView • 在 preview 也能看到標題 包在 NavigationStack 裡
• Link 點選打開連結的按鈕,比⽅打開 Safari 顯⽰網⾴。此功能要從模 擬器測試,無法從 preview 測試 https://cutt.ly/KBm5KIN • speaker.link -
⽤狀態設計 SwiftUI 畫⾯: State property struct ContentView: View { @State
private var number = 1 var body: some View { Image(systemName: "die.face.\(number).fill") .resizable() .scaledToFit() .frame(width: 200, height: 200) .onTapGesture { number = Int.random(in: 1...6) } } } State property 改變時會觸發畫⾯更新,執⾏ body { } 裡的程式 範例: 骰⼦ App https://cutt.ly/DBEMI9C -
綁定資料的 Binding 元件 struct ContentView: View { @State private var
isRain = true var body: some View { VStack { Image(systemName: isRain ? "cloud.rain.fill" : "sun.max.fill") .resizable() .frame(width: 100, height: 100) Toggle(isOn: $isRain) { Text("今天下雨嗎?") } } .padding() } } @State private var isRain = true binding • 操作元件時將同步修改資料,資料內容改變時,它也會同步更新元件。 https://cutt.ly/SBEMFV9 • State property 加 $ 可產⽣ Binding 型別的資料 -
選擇⽇期的 PeriodPicker @Binding var periodData: PeriodData? binding • 選擇項⽬的 Picker
是⼀種綁定資料的元件 https://cutt.ly/SBs8bwM • Picker 綁定的資料必須是 Hashable • Picker 綁定變數 periodData,Picker 選擇的⽇期改 變時,periodData 會跟著改變,periodData 將儲存 當天的相關議程資訊 • tag($0 as PeriodData?) 是為了綁定 optional • 以 @Binding 宣告 periodData 的原因 參考資料來源的 Binding https://cutt.ly/SBEMVkG -
SessionsView • 切換⾴⾯的 NavigationSplitView, NavigationSplitView 在 iPad 會變成分割畫⾯ (iOS
16 ⽤ NavigationSplitView,舊版⽤ NavigationView) https://cutt.ly/uBsSeRD • @State private var periodData: PeriodData? 選擇的⽇期 & 相關議程 • @State private var session: Session? 選擇的議程 • ZStack & frame(minWidth: 0, maxWidth: .in fi nity, minHeight: 0, maxHeight: .in fi nity) 全螢幕的背景顏⾊ • sessionContentView 顯⽰議程清單 • 點選議程後顯⽰ detail closure 裡的 SessionDetailView -
顯⽰議程清單的 sessionsContentView • 從 PeriodPicker 選⽇期,periodData 將儲存當天的相關議程資訊 • 判斷
event 名稱顯⽰ SessionRow 或 PeriodRow • List 搭配的參數 selection 傳入 $session,點選 SessionRow 後, State property session 會儲存選到的 議程,觸發 NavigationSplitView 的 detail 畫⾯顯⽰ • Session 必須遵從 Identi fi able & Hashable,因為 List 參數 selection 的型別條件為 Hashable,ForEach 的 參數條件為 Identi fi able -
SessionDetailView • 顯⽰圖⽂並排的 Label 顯⽰時間跟地點 https://cutt.ly/7BRftJH •
Divider 顯⽰分隔線 https://cutt.ly/2BRfqwW -
NavigationSplitView 實現 iPad 分割畫⾯ SwiftUI preview Device Settings: ⽅便查看不同顏⾊,⽅向 &
⽂字⼤⼩設定下的 App 畫⾯ https://cutt.ly/nBf2eNt -
App 顯⽰的第⼀個畫⾯ • 遵從 protocol App,在 WindowGroup { } 裡⽣成第⼀個畫⾯
• 呼叫 preferredColorScheme(.dark),讓整個 App 採⽤ dark mode -
iPad List 選取的邊框問題 ? 問題: 選取的 row 背後會變成 accent color,但因為設定
listRowBackground, 因此只會看到框框 沒設定 listRowBackground 時 整個 row 在選取時會變成 accent color -
依據 row 是否選取顯⽰不同的背景顏⾊ • 點選 row 時 State property session
會儲存選到的 session,因此比對 self.session & 參數 session 可判斷是否選取。 • 將 listRowInsets 設為 0,否則 row 的左右會有間距 listRowInsets 調為 0 沒有調整 listRowInsets @State private var session: Session? -
macOS App 的網路連線問題 抓不到資料 • networkd_settings_read_from_ f ile Sandbox is
preventing this process from reading networkd settings f ile at "/Library/Preferences/com.apple.networkd.plist", please add an exception • macOS App 很重視安全,所以預設不讓我們接觸網路,畢竟網路上藏著許多可怕的東⻄呀 -
問題: List 的背後是⿊⾊,選取時 row 的左右兩邊顯⽰ Mac 的 accent color 背後是⿊⾊
選取時 row 的左右兩邊顯⽰ Mac 的 accent color -
• listRowBackground(Color("background")) 選擇 row 時 row 依然維持 listRowBackground 設定的背景⾊。只在 macOS
呼叫, 避免剛剛 iPad 選取 row 的邊框問題 • scrollContentBackground(.hidden) 移除 List 背後的顏⾊ -
設定 iOS, macOS & watchOS App 共⽤的檔案 在 Target Membership
勾選 Watch App • 選擇 swift,asset,json • 按 cmd 鍵⼀次選多個檔案,然後再勾選 Watch App -
在 watchOS App 加入套件 NukeUI 剛剛在 iOS App 已經加過套件,所以可以點選 +
加入,不⽤ 再從 SPM 安裝套件 -
調整 watchOS App 的 picker 樣式 watchOS 不⽀援 segmented 樣式的
picker 點選後出現選單 -
修正 var sessionsContentView 的 List watchOS App 下另外新增 SessionsView,不使⽤ iOS
App 的 SessionsView watchOS 的 List 不⽀援搭配參數 selection -
Command CompileAssetCatalog failed with a nonzero exit code : error:
There are multiple stickers icon set or app icon set instances named "AppIcon". /* com.apple.actool.compilation-results */ /Users/peterpan/Library/Developer/Xcode/DerivedData/MOPCONSwiftUIMultiplatform-cfaczzmiqqawtodqwqecwaayybgp/Build/Intermediates.noindex/ MOPCONSwiftUIMultiplatform.build/Debug-watchsimulator/WatchMOPCON Watch App.build/assetcatalog_generated_info.plist /Users/peterpan/Library/Developer/Xcode/DerivedData/MOPCONSwiftUIMultiplatform-cfaczzmiqqawtodqwqecwaayybgp/Build/Products/Debug-watchsimulator/ WatchMOPCON Watch App.app/Assets.car -
設定 watchOS 的 AppIcon 從 iOS App 的 asset 設定
watchOS AppIcon 以 iOS App asset 的 App Icon 當 watchOS App 的 App Icon -
⼼得 • 寫 SwiftUI 很開⼼,很好玩 • 學習到許多 SwiftUI 製作畫⾯的細節 •
Learn once, apply anywhere • 不同平台還是要做⼀些⼩⼩的調整 • 有些 API 和功能只⽀援某個平台 • 有些寫法在某個平台正常,但在另⼀個平台會出問題 • 可能要依據不同裝置的尺⼨調整畫⾯ • SwiftUI 要特別注意版本問題 MOPCON App 使⽤到⼀些 iOS 16 才⽀援的 API,⽽且同樣的 API 在不同版本的 iOS 可能會 有不同的⾏為和 bug • 未來可以增加的功能: 收藏,下拉更新,search
