Komunikasi Data • Data = ... ? • Komponen Komunikasi
Data • Tipe Transmisi Data • Kecepatan & Kapasitas Kanal Transmisi • Media Transmisi Data • Protokol Transmisi Data • Mode Transmisi Data • Modulasi Data -
Data = ... ? • Data adalah.... • Data adalah
kumpulan fakta • Data adalah sesuatu yang belum mempunyai arti bagi penerimanya dan masih memerlukan adanya suatu pengolahan • Data adalah representasi atau hasil rekaman atas kejadian, fakta, atau fenomena yang terjadi dalam dunia nyata. • Data --> Sinyal --> Informasi -
Data: Analog Vs Digital • Data dikirim berupa signal elektromagnetik
• Sinyal Analog = Smooth & Continue -
Komponen Komunikasi Data • Sender : The Sender is the
device that sends the data message. It can be a computer, workstation, telephone handset, video camera and so on. • Receiver : The Receiver is the device that receives the data message. It can be a computer, workstation, telephone handset, video camera and so on. • Medium : The transmission medium is the physical path by which a message travels from sender to receiver. It can consists of twisted pair wire, coaxial cable, FOC, laser or radio waves. • Message : The Message is the information to be communicated. It is a combination of text,graphics, image, audio and video. • Protocol : A protocol is a set of rules that govern data communication. It represents an aggrement between the communicating devices. Without a protocol, two devices may be connected but not communicating, just as a person speaking in Tamil cannot be understood bya person who speaks only English. -
Representasi Data • Teks; dikodekan dalam bit (ASCII dan Unicode/UTF)
• Angka; tidak direpresentasikan dengan ASCII untuk menyederhanakan proses • Image; dikodekan dalam bit, kumpulan dari matrix pixel ( (picture element) • Audio (suara atau musik); disampling, dikuantisasi, dikodekan secara biner. • Video (gambar atau film); identik dengan audio -
Demo : Matlab • Membaca data gambar --> imread •
Membaca data suara --> wavread -
Tipe Transmisi Data • Simplex : Transmisi satu arah: Misal:
Radio, Televisi • Half Duplex : Transmisi dua arah bergantian Misal: HT/Walkie talkie • Full Duplex Misal : Telepon, Voice chat -
Media Transmisi (Wired) • Twisted pair --> kabel pasangan terpilin
Unshielded & Shielded Contoh: Kabel telepon • Kabel Koaxial Contoh: Kabel TV • Serat Optik Contoh : Kabel telefon & Internet -
Wireless • Radio wave • Infrared • Bluetooth • Wifi
802.11 b/g/n --> ... GHz • Wimax ?? 3 Khz – 300 GHz 300 Ghz – 430 GHZ -
Kecepatan & Kanal • Kecepatan transmisi = baud / bps
• Kecepatan transmisi bergantung pada kanal Jenis Channel Kapasitas Biaya Total Tingkat Kesalahan Narrow band 50 – 300 bps Rendah Tinggi Voice band 300 – 500 bps Sedang Sedang Broad/wide bad s/d 1 jt bps Tinggi Rendah -
Protokol Komunikasi • TCP/IP (Transfer Control Protocol / Internet Protocol),
merupakan protokol yang Digunakan di internet. Dalam TCP/IP tersedia juga beberapa jasa, seperti HTTP (hypertext transfer protocol), FTP (file transfer protocol), e-mail, telnet (remote login), dll. • SPX/IPX, digunakan pada LAN sistem operasi jaringan Novel Netware • X25, biasa digunakan oleh jaringan perbankan (cabang online, ATM, dll).
