Powering a build pipeline with Docker and Jenkins

Powering a build pipeline with Docker and Jenkins

Continuous Delivery is key to delivering software fast and frequently. Jenkins 2 has made great strides in providing a solution for modeling a build pipeline as code. In addition, Docker invoked from a Gradle build can help with implementing certain aspects of your pipeline. Let's combine the benefits of these tools to implement a streamlined and bullet-proof process.

In this demo-driven talk, you will learn how to construct and operate a declarative pipeline with Jenkins. We'll take a Spring Boot application all the way through the pipeline from building the Docker image, pushing the image to a registry, using it for integration testing and finally deploying the application to a Docker Swarm.

Benjamin Muschko

October 26, 2018
Tweet

More Decks by Benjamin Muschko

Other Decks in Programming

Transcript

  1. Agenda Typical Continuous Delivery uses cases How can Docker help?

    Show me some code! The glue as code in Jenkins
  2. Dockerfile for Spring Boot app FROM openjdk:jre-alpine
 COPY todo-webservice-1.0.jar \

    /app/todo-webservice-1.0.jar
 ENTRYPOINT ["java"]
 CMD ["-jar", "/app/todo-webservice-1.0.jar"]
 HEALTHCHECK CMD wget --quiet --tries=1 --spider \ http://localhost:8080/actuator/health || exit 1
 EXPOSE 8080
  3. Building and running image # Build image from Dockerfile
 docker

    build -t my-todo-web-service:1.0.0 .

 # Run built image in container
 docker run -d -p 8080:8080 my-todo-web-service:1.0.0
  4. Building the image plugins {
 id 'java'
 id 'org.springframework.boot' version

    '2.0.6.RELEASE'
 id 'com.bmuschko.docker-java-application' version '4.0.1'
 } $ ./gradlew dockerBuildImage
  5. Providing a health check dockerCreateDockerfile {
 instruction 'HEALTHCHECK CMD wget

    --quiet --tries=1 \ --spider http://localhost:8080/actuator/health || exit 1'
 }
  6. Pushing image # Log into Docker Hub
 docker login --username=bmuschko

    \ [email protected]

 # Tag the image
 docker tag bb38976d03cf bmuschko/todo-web-service:1.0.0

 # Push image to Docker registry
 docker push bmuschko/todo-web-service
  7. Pushing the image to Docker Hub docker {
 registryCredentials {


    username = 'bmuschko'
 password = System.getenv('DOCKER_PASSWORD')
 email = '[email protected]'
 }
 springBootApplication {
 tag = 'bmuschko/todo-web-service'
 }
 } $ ./gradlew dockerPushImage
  8. Pull image and start/stop container # Pull image from Docker

    registry
 docker pull bmuschko/todo-web-service:latest

 # Start container
 docker run -d -p 8080:8080 -name todo-web-service \ my-todo-web-service:latest

 # Stop container
 docker container stop todo-web-service

 # Remove container
 docker container rm todo-web-service
  9. Using container for tests task createContainer(type: DockerCreateContainer) {
 dependsOn dockerBuildImage


    targetImageId dockerBuildImage.imageId
 portBindings = ['8080:8080']
 autoRemove = true
 }

 task startContainer(type: DockerStartContainer) {
 dependsOn createContainer
 targetContainerId createContainer.containerId
 }

 task startAndWaitOnHealthyContainer(type: DockerWaitHealthyContainer) {
 dependsOn startContainer
 timeout = 60
 targetContainerId createContainer.containerId
 }

 task stopContainer(type: DockerStopContainer) {
 targetContainerId createContainer.containerId
 }

 functionalTest {
 dependsOn startAndWaitOnHealthyContainer
 finalizedBy stopContainer
 } $ ./gradlew functionalTest
  10. Functional test with JUnit 5 public class ToDoWebServiceFunctionalTest {
 @Test


    @DisplayName("can retrieve all items before and after inserting new ones")
 void retrieveAllItems() {
 String allItems = getAllItems();
 assertEquals("[]", allItems);

 ToDoItem toDoItem = new ToDoItem();
 toDoItem.setName("Buy milk");
 toDoItem.setCompleted(false);
 insertItem(toDoItem);

 allItems = getAllItems();
 assertEquals("[{\"id\":1,\"name\":\"Buy milk\",\"completed\":false}]", allItems);
 } } HTTP calls to running container
  11. Docker Compose definition version: "3.7"
 services:
 web-service: ...
 database: ...


    networks:
 todo-net:

 volumes:
 todo-vol: web-service:
 image: "bmuschko/todo-web-service:latest"
 environment:
 - SPRING_PROFILES_ACTIVE=dev
 ports:
 - 8080:8080
 networks:
 - todo-net
 volumes:
 - type: volume
 source: todo-vol
 target: /code
 depends_on:
 - database
 healthcheck:
 test: wget --quiet --tries=1 --spider \ http://localhost:8080/actuator/health || exit 1
 interval: 10s
 timeout: 5s
 retries: 3
  12. Running a multi-container app # Start composed apps
 docker-compose up



 # Stop composed apps
 docker-compose down
  13. Using container for tests plugins {
 id 'com.avast.gradle.docker-compose' version '0.8.8'


    }

 dockerCompose {
 useComposeFiles = ['docker-compose.yml']
 isRequiredBy(project.tasks.integrationTest)
 exposeAsSystemProperties(project.tasks.integrationTest)
 } $ ./gradlew integrationTest
  14. Integration test with JUnit 5 @ExtendWith(SpringExtension.class)
 @SpringBootTest
 public class ToDoServiceImplIntegrationTest

    {
 @Autowired
 private ToDoService toDoService;

 @Test
 public void canCreateNewItemAndRetrieveIt() {
 ToDoItem newItem = newItem("Buy milk");
 assertNull(newItem.getId());
 toDoService.save(newItem);
 assertNotNull(newItem.getId());
 ToDoItem retrievedItem = toDoService.findOne(newItem.getId());
 assertEquals(newItem, retrievedItem);
 } } Calls web service endpoint
  15. Rolling out services to Swarm # Create a new service


    docker service create --name todo-web-service \ --publish 8080:8080 --replicas 5 --secret db-password \ --env SPRING_PROFILES_ACTIVE=prod \ bmuschko/todo-web-service:latest

 # Update an existing service from Swarm Leader
 docker service update --image \ bmuschko/todo-web-service:latest todo-web-service
  16. Creating a Docker secret # Login into Swarm Leader
 ssh

    swarm1
 # Create a password
 printf "prodpwd" | docker secret create db-password -
  17. Calling Gradle from stages pipeline { stages { stage('Compile &

    Unit Tests') { steps { gradlew('clean', 'test') } } } ... } def gradlew(String... args) { sh "./gradlew ${args.join(' ')} -s" }
  18. Injecting credentials & env vars stage('Push Image') { environment {

    DOCKER_USERNAME = "${env.DOCKER_USERNAME}" DOCKER_PASSWORD = credentials('DOCKER_PASSWORD') DOCKER_EMAIL = "${env.DOCKER_EMAIL}" } steps { gradlew('dockerPushImage') } }
  19. Manual deployment to Swarm stage('Deploy to Production') { steps {

    timeout(time: 1, unit: 'DAYS') { input 'Deploy to Production?' } sshagent(credentials: ['ee8346e0-a000-4496-88aa-49977fd97154']) { sh "ssh -o StrictHostKeyChecking=no \ ${env.DOCKER_SWARM_MANAGER_USERNAME}@${env.DOCKER_SWARM_MANAGER_IP} \ docker service update --image bmuschko/todo-web-service:latest \ todo-web-service" } } }
