Testing an urban theory

Slides for the lecture "Testing an urban theory" @ University of Trento

Transcript

1. Testing an urban theory Marco De Nadai (http://www.marcodena.it)
2. 72 Cities have always been studied IDEAL CITY (XV century)
3. 73 Cities have always been studied IDEAL CITY (XV century) SYSTEM (XIX century)
4. 74 Cities have always been studied IDEAL CITY (XV century) SYSTEM (XIX century) LIVING ORGANISM (XX century)
5. 75 Understand cities New methods New data
6. How can we test an urban theory? 76 1 Take the theory “Operationalize” the theory Does it work? Is it still valid? Why does it matter? 2 3 4
7. 77 Follow or silence please! How to test an urban theory 1 How to lose time http://curvefever.io/ 2
8. Take the theory STEP 1
9. The theory: Jane Jacobs One of the most influential books in city planning • planning models that dominated mid-century planning • American housing policy (HOPE VI) • Melbourne, Toronto etc. 79 1 2 3 4 THEORY TEST Klemek, C. (2011) ‘Dead or Alive at Fifty? Reading Jane Jacobs on her Golden Anniversary’ Dissent, Vol. 58, No. 2, 75–79.
10. The theory: not tested! • Not empirically tested until 2015 • Tested in Seoul, from costly surveys collected in years • Theory from 1961! 80 1 2 3 4 THEORY TEST Sung, Hyungun, Sugie Lee, and SangHyun Cheon. "Operationalizing Jane Jacobs’s Urban Design Theory Empirical Verification from the Great City of Seoul, Korea." Journal of Planning Education and Research (2015.
11. The theory: Jane Jacobs One of the most influential books in city planning • Death: caused by the elimination of pedestrian activity • Life: created by a vital urban fabric at all times of the day 81 1 2 3 4 THEORY TEST
12. Jacobs’ diversity conditions Diversity => Urban vitality There are 4 diversity conditions To be ensured in each city’s district (10,000+ inhabitants) 82 1 2 3 4 THEORY TEST SMALL BLOCKS LAND USE AGED BUILDINGS DENSITY
13. Land Use Mix 2+ primary uses (contemporarily) JACOBS’ VIEW: People come for different purposes, continuously EFFECT: “sidewalk ballet” and “eyes on the street” 83 LAND USE SMALL BLOCKS AGED BUILDINGS DENSITY 1 2 3 4 THEORY TEST
14. Small blocks City blocks should be small/short LAND USE SMALL BLOCKS 84 1 2 3 4 THEORY TEST AGED BUILDINGS DENSITY JACOBS’ VIEW: improves walkability EFFECT: Increase face-to-face interactions
15. Aged buildings Buildings mixed (age and types) 85 AGED BUILDINGS 1 2 3 4 THEORY TEST LAND USE DENSITY SMALL BLOCKS JACOBS’ VIEW: To ensure economic diversity EFFECT: high-/low-income residents new/small enterprises
16. Density Concentration of people and enterprises JACOBS’ VIEW: People have a reason to live in a district EFFECT: Attract people 86 SMALL BLOCKS DENSITY 1 2 3 4 THEORY TEST LAND USE AGED BUILDINGS
17. Necessary, diversity conditions All four factors are necessary 87 LAND USE SMALL BLOCKS AGED BUILDINGS DENSITY 1 2 3 4 THEORY TEST
18. Border Vacuums • Patches of land dedicated to one single use • They could be either bad and good: • Parks are good for pedestrian activity • But they are exposed to criminality and deprivation if not well managed (e.g. night) 88 LAND USE SMALL BLOCKS AGED BUILDINGS DENSITY VACUUMS 1 2 3 4 THEORY TEST
19. “Operationalize” the theory STEP 2
20. The data: 90 1 3 4 THEORY TEST 2
21. The data: 91 1 3 4 THEORY TEST 2 Get the data at: https://developer.foursquare.com/
22. The data: 92 1 3 4 THEORY TEST 2
23. The data: 93 1 3 4 THEORY TEST 2
24. The data: 94 1 3 4 THEORY TEST 2 Get the data at: https://overpass-turbo.eu/
25. The data: 95 1 3 4 THEORY TEST 2
26. The data: 96 1 3 4 THEORY TEST 2 • Urban Atlas: https://land.copernicus.eu/local/urban- atlas/urban-atlas-2012
27. The data: 97 1 3 4 THEORY TEST 2 • ISTAT (Census): https://www.istat.it/it/archivio/104317
28. 98 2 1 3 4 URBAN DESCRIPTION GIS data Does it work? Is it still valid? 3 “Operationalize” the theory
29. “Operationalize” Land Use Mix For district : % = − ( )∈+ %,) log(%,) ) log || %,): % square footage of land use : {residential, commercial, recreation} 99 LAND USE SMALL BLOCKS AGED BUILDINGS DENSITY VACUUMS 1 3 4 THEORY TEST 2 Ref: R. Cervero. Land-use mixing and suburban mobility. University of California Transportation Center, 1989 EFFECT: The higher, the better. 1 0
30. 100 1 3 4 THEORY TEST 2
31. 101 1 3 4 THEORY TEST 2
32. 102 1 3 4 THEORY TEST 2
33. “Operationalize” Small blocks Block size is a proxy for an high number of peoples’ interactions For district : 1 | | ( =∈=>?@AB(%) () EFFECT: The lower, the better 103 LAND USE SMALL BLOCKS AGED BUILDINGS DENSITY VACUUMS 1 3 4 THEORY TEST 2
34. 104 1 3 4 THEORY TEST 2
35. 105 1 3 4 THEORY TEST 2
36. Aged buildings Aged buildings are supposed to be a proxy for new, small enterprises. For district : 1 |% | ( )∈GH % : set of companies EFFECT: The higher, the worse 106 LAND USE SMALL BLOCKS AGED BUILDINGS DENSITY VACUUMS 1 3 4 THEORY TEST 2
37. Aged buildings For district the weighted standard deviation of buildings age. EFFECT: The higher, the better 107 LAND USE SMALL BLOCKS AGED BUILDINGS DENSITY VACUUMS 1 3 4 THEORY TEST 2 MNO = ∑HQR S TH(UHV ̅ U)X Y (Z[R) Z ∑HQR S TH
38. 108 1 3 4 THEORY TEST 2
39. 109 1 3 4 THEORY TEST 2
40. “Operationalize” Density For district : Employment density: |\]^>?_O` ^O?^>OH| MaOMH Population density: |b?^c>Md%?eH| MaOMH EFFECT: The higher, the better 110 LAND USE SMALL BLOCKS AGED BUILDINGS DENSITY VACUUMS 1 3 4 THEORY TEST 2
41. 111 1 3 4 THEORY TEST 2
42. “Operationalize” Vacuums Distance to huge parks for district : 1 % ( )∈gH ( , , ) % : the set of the blocks : the set of parks EFFECT: The higher, the better 112 LAND USE SMALL BLOCKS AGED BUILDINGS DENSITY VACUUMS 1 3 4 THEORY TEST 2
43. 113 1 3 4 THEORY TEST 2
44. Diversity Vitality
45. Call Detail Records Data collected by mobile operators for billing reasons • Unique userID • Gender and age • Geographical location (Antenna) • Datetime 115 1 2 3 4 THEORY TEST
46. Call Detail Records 116 1 2 3 4 THEORY TEST
47. “Operationalize” Vitality • Mobile phone Internet activity as a proxy for urban vitality • We calculate the activity density in each district 1 || ( l∈m | % | : set of hours (180 days x 24h) • Six Italian cities with 100,000+ inhabitants (e.g. Rome, Milan…) • 6 months time span (in 2014) 117 0.2 0.0 0.2 0.4 0.6 0.8 1.0 Land Use Mix 0.8 1.2 1.8 2.7 4.1 6.1 9.3 14.0 21.1 31.9 Activity density ⇥ 103 ROME MILAN 0.8 1.2 1.8 2.7 4.1 6.1 9.3 14.0 21.1 31.9 Activity density 103 1 2 3 4 THEORY TEST MILAN
48. 118 2 1 3 4 URBAN DESCRIPTION Mobile data GIS data Does it work? Is it still valid? 3 “Operationalize” the theory
49. Demo 1 https://github.com/denadai2/test-the- theory- lesson/blob/master/step1_compute_fe atures.ipynb 119
50. Is the theory still valid? STEP 3
51. −3 −2 −1 0 1 2 3 −9 −8 −7 −6 −5 −4 −3 −2 . Is the theory still valid? 121 Intersections density (log + Z-score) Activity density (log) 1 2 3 4 THEORY TEST
52. −3 −2 −1 0 1 2 3 −9 −8 −7 −6 −5 −4 −3 −2 Is the theory still valid? 122 Intersections density (log + Z-score) Activity density (log) 1 2 3 4 THEORY TEST
53. −3 −2 −1 0 1 2 3 −9 −8 −7 −6 −5 −4 −3 −2 R2 : 0.63 Is the theory still valid? 123 Intersections density (log + Z-score) Activity density (log) 1 2 3 4 THEORY TEST
54. Demo 2 https://github.com/denadai2/test-the- theory- lesson/blob/master/step2_exploration. ipynb 124
55. The log Linear Regression 125 = p p + s s + ⋯ + su su + 1 2 3 4 THEORY TEST
56. The log Linear Regression 126 Activity density 1 2 3 4 THEORY TEST = p p + s s + ⋯ + su su +
57. The log Linear Regression 127 Activity density Land Use Mix Employment density 1 2 3 4 THEORY TEST = p p + s s + ⋯ + su su +
58. Demo 3 http://setosa.io/ev/ordinary-least- squares-regression/ and https://github.com/denadai2/test-the- theory- lesson/blob/master/step3_Regression.i pynb 128
59. Jacobs’ theory holds and is still valid 129 1 2 3 4 THEORY TEST Urban metric Beta coefficient Employment density 0.434*** Intersections density 0.191*** Housing types 0.1854*** Closeness highways -0.102*** 3rd places x closeness highways 0.07** Closeness parks x closeness highways -0.07*** − 0.77 *** p-value < 0.001; ** p-value < 0.01; 4-fold Cross-validation: 75% training – 25% testing, 1000 interactions
60. Jacobs’ theory holds and is still valid 130 URBAN VITALITY 1 2 3 4 THEORY TEST URBAN METRICS Predict s: 0.77
61. …But something is different 131 1 2 3 4 THEORY TEST LAND USE SMALL BLOCKS AGED BUILDINGS DENSITY VACUUMS
62. Why does it matter? STEP 4
63. Web data and mobile phone records offer insights on how most urban dwellers experience entire cities 1 2 3 4 THEORY TEST
64. Why does it matter? • Evaluate the districts vitality • Know in advance the best places for retails • Quantifying regulatory interventions • We created the recipe for city that works 134 1 2 3 4 THEORY TEST
65. Let’s test an urban theory 135 1 The Jacobs’ theory We created the metrics We tested the theory Framework for urban vitality 2 3 4
66. Test the un-tested And now?
67. Broken windows theory • City mismanagement • Dirty places • Poor infrastructure Lead to misbehavior => Crime Q: Are people avoiding places where they feel unsafe? 137 Wilson, James Q., and George L. Kelling. "Broken windows." Critical issues in policing: Contemporary readings (1982): 395- 407.
68. 138 Urban perception from Place Pulse Salesses, P., Schechtner, K., & Hidalgo, C. A. (2013). The collaborative image of the city: mapping the inequality of urban perception. PloS one
69. 139 … 1 5 Place Pulse • New York • Boston • Linz • Salzburg Place Pulse 2 • Rome • Milan URBAN PERCEPTION Safety perception: MIT Place Pulse
70. 140 Security perception prediction * B. Zhou, A. Lapedriza, J. Xiao, A. Torralba, and A. Oliva. “Learning Deep Features for Scene Recognition using Places Database.” NIPS, 2014. • Learning human security perception PERCEPTION SCORE [0-10]
71. Demo 4 https://github.com/denadai2/test-the- theory- lesson/blob/master/step_extra_vision.i pynb 141
72. 142 Urban metric Standardized Beta coefficient Population density 0.155** Employees density 0.328** Deprivation -0.022 Distance from the center -0.257** Security perception 0.105** adj − Rs 0.91 ** p-value < 0.001; * p-value < 0.01; Security perception -> presence of people
73. Take home Try to test your favorite theory! 143
74. Thanks @denadai2
