stress-ng: finding kernel bugs through stress testing
Stress-ng is a tool that stress tests kernels using deliberately intense testing to shake out various kernel (and hardware) bugs. This talk describes the different stress test methods available in stress-ng, typical kernel test coverage and the future direction of the stress-ng project.
Colin IAN KING
Kernel Recipes PRO
September 30, 2023
Transcript
29 slides
-
stress-ng Finding kernel bugs through stress testing (a software hammer
for kernels and hardware) -
17/09/2023 2 Why do stress testing? • Find breakage points
(kernel panics, races, lock-ups...) • Check for correct behaviour under stress • Test modes of failure (e.g. what happens on low memory?) • Test for stable behaviour outside of expected usage • Exercise scaling/load (CPUs, memory, I/O) – does it scale well? • Burn-in testing (e.g. detecting CPU / disk / memory errors) -
17/09/2023 3 Why use Stress-ng? • Already found 60+ kernel
bugs • ~20 kernel performance improvements • Kernel 0-day performance testing • Used by silicon vendors (new silicon + kernel bring-up) • Used for kernel regression testing (e.g. Ubuntu kernel) • Used in stress testing server and cloud environments • Cited in 80+ academic research papers - synthetic stress testing • LKP-tests (Linux kernel performance test tool) -
17/09/2023 4 Stress-ng, 10 years ago.. • Stress Laptops, Thermal
Overrun • Simple stress tests (stressors) • Compatible with the ‘stress’ tool • Exercised Intel thermal daemon • Ubuntu Laptop enablement -
17/09/2023 5 Data cache Instruction cache Memory CPU Atomic Ops
Vector Ops Floating Point Ops Integer Ops Kernel System Calls Device Ioctls Sysfs, Procfs File systems Signals IPC Virtual Memory GPU Networking Scheduler Interrupts Stress-ng in 2023, 300+ stressors Thermal Paging Processes Bit Ops Register Ops rdrand -
17/09/2023 7 What is a Stressor? stress phase clean-up phase
init phase while (stress_continue()) { do_some_stressing_work(); inc_bogo_op_counter(); } Normally a single process forked from stress-ng Stressor may be one or more child process or one or more pthreads in more complex stress cases. Stressor terminates on SIGALRM or reached maximum bogo-op count -
17/09/2023 8 Stress-ng options Global options Stressor options Run duration
(--timeout, -t) Verify mode (--verify) Performance Metrics (--metrics) Logging (--log-file filename) Perf Events (--perf) ..and many more! Number of instances Optional loop iterations (bogo-ops) Optional per-stressor extra options stress-ng --mmap 4 --mmap-ops 10000 --verify --metrics -
17/09/2023 9 stress-ng --matrix 4 --vm 3 --memthrash 2 --timeout
1m 4 instances of matrix stressor, 3 instances of vm stressor, 2 instances of memthrash stressor all running in parallel for 1 minute vm vm matrix matrix Running multiple stressors in parallel matrix matrix vm memthrash memthrash -
17/09/2023 10 Stressing CPUs stress-ng --matrix 8 --timeout 5m --thermalstat
1 8 instances of matrix stressor, run for 5 minutes and print thermal statistics every second (good mix of cache + compute = toasty silicon) stress-ng --vecmath 2 --fp 2 --cpu 4 -t 200 --tz 2 instances of vector math stressor, 2 instances of floating point stressor, 4 instances of CPU stressor, run for 200 seconds, print thermal zone information at the end and also: af-algo, atomic, branch, bsearch, cache, cacheline, context, cpu, crypt, dekker, eigen, far-branch, flush-cache, fp, goto, hash, heapsort... -
17/09/2023 11 Stressing Memory stress-ng --vm 0 --verify --vmstat 60
-t 1h vm stressor run on all online CPUs, verification enabled, show vmstat stats every minute, soak test for 1 hour stress-ng --memrate 1 -t 1m benchmark memory read/write rates with various sized read/writes for 1 minute stress-ng --brk 0 --stack 0 --bigheap 0 --oom-pipe -t 15m consume memory, force low memory OOM scenarios -
17/09/2023 12 Stressing Networking stress-ng --udp 1 --udp-port 2000 udp
stressor (client/server send/recv) on port 2000, 1 instance stress-ng --sock 4 --sock-domain ipv6 --sock-if lo --sock-port 9000 --sock-protocol tcp --sock-type stream --sock-zerocopy -t 1h tcp ipv6 stream test on loopback, try to use zerocopy on port 9000 and also: dccp, netdev, netlink-proc, netlink-task, ping-sock, rawsock, rawpkt, rawudp, sctp, sockabuse, sockfd, sockmany, tun, udp-flood -
17/09/2023 13 Stressing File Systems stress-ng --iomix 10 --smart --verify
-t 1h --temp-path /mnt/test 10 instances of mixed I/O operations, enable S.M.A.R.T. checks with I/O test verification, 1 hour soak test on filesystem on /mnt/test stress-ng --revio 1 –seek 1 --verify -t 1d 1 reverse I/O stressor (creates lots of extents) and 1 random seek stressor, enable verification, soak test for 1 day and also: access, aio, aiol, chattr, chdir, chmod, chown, copy-file, dentry, dir, dirdeep, dirmany, fallocate, fiemap, file-ioctl, filename, flock, fsize, fstat, getdent, hdd, ioprio, lease, ramfs, readahead, rename, seal, tmpfs... -
17/09/2023 14 Stressing Kernel Interfaces sudo stress-ng --sysfs 4 --procfs
4 --dev 4 traverse and exercise sysfs and procfs, exercise device ioctls stress-ng --enosys 0 --sysinval 0 --vdso 0 --x86syscall 0 exercise non-existent system call numbers, exercise invalid system call argument passing (syzkaller super-lite), exercise vdso system calls, x86 system call mechanism -
17/09/2023 15 -ETOOMUCH Stress Deep breath…. Over 300 stressors! I
cannot cover all of them in a short presentation. I cannot cover all the 900+ options. Please refer to the manual before asking if there is a stressor for a specific test case :-) -
17/09/2023 16 stress-ng --class vm -t 1m --seq 8 run
all stressors in the virtual memory class one after each other for 1 minute with 8 instances per stressor. Stressor classes cpu-cache cpu device filesystem gpu interrupt io memory network os scheduler security vm Stressors are grouped into classes. A stressor can be in one or more classes. A class has one or more related stressors. -
17/09/2023 17 Running multiple stressors sequentially stress-ng --seq 2 --class
network -t 1m run all the network related stressors one after another for 1 minute each, each stressor is run with 2 instances running in parallel stress-ng --seq 8 --with vm,cache,memthrash,mmap -t 1m run each stressor one after another for 1 minute each, each stressor is run with 8 instances running in parallel -
17/09/2023 18 Running permutations of stressors stress-ng --perm 1 --class
scheduler -t 1m run permutations of all the scheduler related stressors one after another for 1 minute each, one instance of each stressor. stress-ng --perm 8 --with brk,bigheap,stack -t 2m run permutations of stressors one after another for 2 minutes each, each stressor is run with 8 instances running in parallel. E.g. brk, brk + bigheap, bigheap, stack, brk + stack, bigheap + stack, brk + bigheap + stack. -
17/09/2023 19 Stressor Methods stress-ng --vm 1 --vm-method flip --vm-bytes
90% --verify execise 90% of available virtual memory using bit-flipping & verification stress-ng --cpu 0 --cpu-method div64 --verify exercise CPUs with 64 bit integer division operations stress-ng --memthrash 1 --memthrash-method spinwrite thrash memory with random spin-looped writes by default, stressors with method options will run sequentially through all their stressing methods -
17/09/2023 20 Useful extra options --verify enable sanity checking (slows
down stressors) --oom-avoid try to avoid out-of-memory kills --klog-check check for kernel crash messages --no-rand-seed use same random seed for test repeatability --exclude list exclude stressors (useful for --class options) --ignite-cpu try to make CPU extra toasty (need root privs) --oomable do not restart an OOM’d stressor --taskset list pin stressors to specific CPUs -
17/09/2023 21 Micro benchmarking • Bogo-ops/sec and metrics can be
useful for micro benchmarking specific use-cases. Use --metrics option. • Performance regression testing. Use same version of stress-ng! -
17/09/2023 22 Perf events • Perf events can be useful
for checking CPU and kernel utilization with the --perf option (use sudo to see more events) -
17/09/2023 23 Does it scale? Does stress performance scale with
number of instances? -
17/09/2023 24 How to build git clone https://github.com/ColinIanKing/stress-ng … install
any dependencies (see the README.md file) cd stress-ng make clean && make -j $(nproc) make pdf ..or install using your favourite distro (maybe old or out of date) ..or use the docker image on the github project page -
17/09/2023 25 What drives stress-ng development? New kernel features (system
calls, ioctls, sysfs/procfs, devices) Kernel gcov coverage holes (checked on each new kernel) Directed coverage testing, another never ending task! New processor features New architectures Kernel bugs (implement some reproducers) User requests or user provided stressors Contributions always welcome! -
17/09/2023 27 Portability – Release Testing Linux BSD UNIX Minix
OpenBSD NetBSD FreeBSD OS X Solaris OpenIndiana Compilers gcc clang tcc pcc icx icc Architectures x86 mips risc-v arm sparc64 alpha hppa m68k sh4 Operating Systems Hurd Haiku Debian/Ubuntu Fedora SUSE ClearLinux Slackware Over 100 virtual machines used DragonFlyBSD Dilos musl-gcc -
17/09/2023 28 Find out more Read the manual (man page),
‘make pdf’ to make PDF version • Plenty of per-stressor information • About 90 pages – a lot of options! • Future work: write a quick start man page Quick start Reference Guide: https://wiki.ubuntu.com/Kernel/Reference/stress-ng
