Modern Internet Scale Reconnaisance

Network reconnaissance is not what it used to be. The surge in cloud use and temporary infrastructure has turned standard network discovery on its head. Security folks on both sides of the fence are struggling to identify organizational assets as these trends accelerate. This talk will describe how to build an internet-scale network discovery platform using open source software (some old, some new) and a wide range of data sources, most of which are available at zero cost. For the last two years, the presenter has been using this platform to accelerate penetration tests, provide accurate pre-sales project scoping, and help defenders get a handle on their network footprint.

Transcript

1. Modern Internet Scale Reconnaissance HD MOORE BSIDES LAS VEGAS 2017
2. Howdy! Work as a penetration tester / vulnerability researcher / hacker at large Lots of time writing public exploits, blogs, whitepapers, etc A few years of internet scanning projects
3. Introduction A practical guide to building your own reconnaissance platform • Gather raw data for the internet as a whole • Query it locally, fast, and cheap • Make security work better!
4. Shiny New Recon Tools! New tools released since the BSidesLV submission • XRay - https://github.com/evilsocket/xray • Aquatone - https://github.com/michenriksen/aquatone • Web Sight - https://github.com/lavalamp-/ws-docker-community
5. Problem Space Most companies don’t actually know their external footprint Penetration testing scope is rarely accurate or fully known This complicates M&A, IT management, security testing, etc Existing solutions • DNSDB (Robtex) • PassiveTotal • Farsight Passive DNS • OpenDNS Umbrella • Open source OSINT tools • Manual OSINT lookups
6. Current Challenges Discovery is becoming dependent on third-party APIs and services Coverage drastically changes by source and technique Difficult to identify frequently changing infrastructure Cloud discovery is difficult without credentials DevOps deployment tools complicate things
7. Moving to Local Data Pull data from as many sources as possible and cross-reference Use local datasets instead of querying third parties Avoid leaking target information to third parties Complement existing active discovery efforts Dig wider and deeper as needed Find weird & interesting stuff!
8. Build a Platform We want domains, whois information, DNS data, TLS cert data, anything! Collect data on regular intervals, search data for stuff we care about We don’t want to spend a lot of money getting it Storage is relatively cheap, computers are fast Lets go data shopping!
9. Sonar FDNS, RDNS, UDP, TCP, TLS, HTTP, HTTPS scan data FREE Censys.io TCP, TLS, HTTP, HTTPS scan data FREE CT TLS Certificates FREE CZDS DNS zone files for new global TLDs FREE ARIN American IP registry information FREE CAIDA PFX2AS IPv4 Daily snapshots of ASN to IPv4 mappings FREE CAIDA PFX2AS IPv6 Daily snapshots of ASN to IPv6 mappings FREE US Gov US government domain names FREE UK Gov UK government domain names FREE RIR Delegations Regional IP allocations FREE PremiumDrops DNS zone files for com/net/info/org/biz/xxx/sk/us $24.95/mo WWWS.io Domains across many TLDs (~198m) $9.00/mo WhoisXMLAPI.com New domain whois data $109.00/mo https://github.com/hdm/inetdata
10. Downloading Data Grab the inetdata repository: • https://github.com/hdm/inetdata • git clone, cp config/inetdata.json.sample config/inetdata.json • Sign up for APIs, enter credentials and keys as needed Setup inetdata-parsers • Full steps at https://github.com/hdm/inetdata-parsers • Parallel processing friendly (written in Golang) Run inetdata downloader and normalizer • inetdata/bin/download.sh && inetdata/bin/normalize.sh • Wrapped up in the inetdata/bin/daily.sh script • More RAM & more cores helps!
11. Crunching Data Raw data is nice, but cooked data is much more useful Structure the data to match the query use cases Make lookups fast • By IP CIDR • By domain prefix Useful cooked outputs • Sonar DNS (FDNS, RDNS) • CZDS (ICANN gTLDs) • PremiumDrops (Legacy TLDs) • Certificate Transparency logs • Censys.IO IPv4
12. Server Specifications As much RAM and as many cores as possible (4c/16Gb+) • Google Cloud: n1-highmem-4 (4 vCPUs, 26 GB memory) [$122/mo] Lots of storage space (1Tb+ HDD) for long-term archives Fast working directory (SSD/NVMe/etc) for scratch space Ubuntu Linux 16.04 LTS is the easy-mode option for tools Two weeks to bootstrap *everything* A few hours the first day otherwise
13. CPUs > IOPS == pigz CPU cores are substantially cheaper than higher IOPS Reduce required IOPS by compressing data inline Across every pipe, temp directory, artifact file Use parallel versions of compression tools • pigz (gzip) • pbzip2 • lz4 Stick with gzip format for compatibility • Support for Hadoop processing • Support within Java parsers
14. MTBL Databases Sorted String Table (key-value) database by Farsight Security • https://github.com/farsightsec/mtbl • Build key names for each use case • Built-in compression! inetdata-parsers includes the mq mtbl query utility • -domain something.com • -cidr 8.8.8.0/24 • -j for output and pipes • -v / -k for just keys/values • Swiss army knife for searching cooked inetdata output CPU intensive to build (inetdata-parsers), but insanely fast to query Search 1Tb of MTBLs with ~8Gb of memory instantly*
15. Convert Censys.io to MTBL Sign up to obtain credentials, add them to ./config/inetdata.json Clear about 3Tb of space for raw + processed data Install liblz4-tool for inetdata to unpack raw files Download the latest IPv4 dataset with • $ inetdata/bin/download.sh -s censys_ipv4 Convert to MTBL with • $ inetdata/bin/normalize.sh -s censys_ipv4 Query with • $ mq -v -n -cidr 8.8.8.0/24 censys_ipv4/normalized/ipv4-[date].mtbl "{"ip":"8.8.8.8","ipint":134744072,"p53":{"dns":{"lookup":{"additionals": [], "answers": [{"name": "c.afekv.com", "response": "192.150.186.1", "type": "A"}, {"name": "c.afekv.com", "response": "173.194.103.8", "type": "A"}], "authorities": [], "errors": false, "metadata": {}, "open_resolver": true, "questions": [{"name": "c.afekv.com", "type": "A"}], "resolves_correctly": true, "support": true, "timestamp":"2016-11-22 00:13:21"}}},"location":{"city":"Mountain View","continent":"North America","country":"United States","country_code":"US","latitude":37.386000000000003,"longitude":- 122.0838,"postal_code":"94035","province":"California","registered_country":"United States","registered_country_code":"US","timezone":"America/Los_Angeles"},"autonomous_system":{"asn":15169,"country_code":"","description":"GOOGLE - Google Inc., US","name":"GOOGLE","organization":"Google Inc., US","path":[15169],"routed_prefix":"8.8.8.0/24"}}"
16. JSON Line Format JSON is a bulky format, but still better than XML Line-delimited JSON records make life easy • jq • jsawk • dap ARIN to JSONL conversion makes easy greps • $ egrep -i '"email":".*@microsoft\.com”’ pocs.json | jq .city | head "New York" "Redmond" "Dallas" "BOULDER" "ASHBURN" "Redmond"
17. Text Files Forever Everything not in MTBL or JSON is CSV or plain text files Make it easy to pipe data through other tools Unix model for data management
18. Storage Usage by Source ARIN (XML + JSONL): 8Gb/day Sonar FDNS/RDNS (Raw + CSV + MTBL): 200Gb/week ICANN CZDS (Raw + MTBL): 1.5Gb/day PremiumDrops (Raw + MTBL): 4.3Gb/day WWWS.IO (Raw + MTBL): 6.5Gb/day Censys IPv4 (Raw + MTBL): 3Tb/snapshot (huge!) Pick and choose data sources with inetdata/bin/download.sh -s <src> Two years of selective daily datasets is approximately 30Tb
19. Platform Capabilities Regular drops of new data via inetdata + inetdata-parsers Fast lookup by domain name or IP range Common use cases with existing dataset • Find all hostnames for a given domain name (subdomains) • Find all IP ranges for a given domain name • Find all SSL/TLS sites for a given domain name • Find all domains for a given nameserver • Find all usable domain fronting hostnames • Find typo and keyword matching domains • Find all domains with the same registrant • Historical ownership of domains & IPs
20. Next Steps After bootstrapping, add inetdata/bin/daily.sh to cron Add custom scripts to monitor, match, and notify Will dive into specific scenarios during demos Query the datasets to win at security!
21. Certificate Transparency A quick diversion into Certificate Transparency • CT is a Google-run project to track TLS certificates globally • CT logs are append-only historical logs of x509 certificates • CT logs are append-only and publicly readable • CT submissions are mandatory for Chrome support of a CA Home: https://www.certificate-transparency.org/ Search: https://crt.sh/
22. Certificate Transparency Logs Anyone can operate a log, public logs are documented online • https://www.certificate-transparency.org/known-logs Example logs • pilot: https://ct.googleapis.com/pilot • aviator: https://ct.googleapis.com/aviator • rocketeer: https://ct.googleapis.com/rocketeer • submariner: https://ct.googleapis.com/submariner Log servers expose API endpoints (json) • /ct/v1/get-sth (return the head of the log) • /ct/v1/get-sth-consistency (return sth consistency) • /ct/v1/get-entries (return encoded CT records) • /ct/v1/add-pre-chain (submit cert pre chain) • /ct/v1/add-chain (submit cert chain) • /ct/v1/add-json (submit cert chain)
23. Extended Validation in Chrome EV certs must be logged to Certificate Transparency for Chrome support Identify new EV-certificate sites as they are being deployed • Staging sites, pre-production, development environments • Certs with CNs for internal resources
24. Lets Encrypt + CT LetsEncrypt sends all new certificates to the Pilot CT server • LetsEncrypt market share continues to increase • LetsEncrypt integrations are everywhere • This happens almost in real-time Services that use LetsEncrypt are being advertised in CT • Dynamic infrastructure becomes discoverable • New assets become visible immediately
25. Source: Firefox Telemetry
26. Source: Firefox Telemetry
27. Real-time CT Monitoring inetdata-ct-tail provides a firehose of TLS certificate names • Install golang 1.8+ from https://golang.org/dl/ • $ sudo apt-get install libmtbl-dev • $ go get github.com/hdm/inetdata-parsers/cmd/inetdata-ct-tail • $ inetdata-ct-tail -f | grep vpn Add a bloom filter to the pipeline to deduplicate* Feed the output into automated scanning tools Identify dynamic assets as they are provisioned This has a fun security implication…
28. Racing to First Setup Many apps provide admin access to the first person to visit the site We can beat the legitimate user by tailing CT into nmap …then backdoor the server and reset the setup =) $ inetdata-ct-tail -f 2>/dev/null | perl -pe 's/,dns,/\n/g' | cut -f 1 -d , | bloom | grep -v ^\*. | nmap -iL - --min-rate=1000 -PS443 -p 443 --max- retries=1 --script=http-title --min-parallelism=64 -oA ct-tail … |_http-title: Did not follow redirect to https://[nooooo]/wp- admin/setup-config.php
29. Winning a WordPress
30. Lots More!
31. Cloud Discovery: Azure DNS Identify CNAMEs that point into cloudapp.azure.net • $ mq -n -domain cloudapp.azure.com sonar/201707*.mtbl | wc -l > 8529 • $ mq -n -domain cloudapp.azure.com ct/*.mtbl | wc –l > 2865 • Misconfigured DNS can leak the *.internal.cloudapp.net hostnames • Easy attribution from Azure assets back to a known organization
32. Domain Fronting Leverage millions of cloud-hosted domains for your C2 Discover frontable domains by querying Sonar MTBLs • Sonar FDNS generates forward/inverse lookups • Leverage inverse lookups for reverse CNAME • Dump all hostnames within a domain
33. Domain Fronting: Azure $ mq -k -n -domain azureedge.net 201707*.mtbl | wc –l $ mq -v -n -domain azureedge.net sonar/normalized/201707*.mtbl | jq . -r |grep -A 1 r-cname | grep \" | grep -v r-cname | shuf | head • software-download.microsoft.com • static.cdn.salewa.com • www.shama.com • amici.iccf.com • www2.pepsico.com • www.mosaic-collection.com • www.duddingston-golf-club.com • www.eyerecommend.ca • vidzapper.vidzapper.com
34. Domain Fronting: Cloudfront $ mq -k -n -domain cloudfront.net 201707*.mtbl | wc –l $ mq -v -n -domain cloudfront.net sonar/normalized/201707*.mtbl | jq . -r |grep -A 1 r-cname | grep \" | grep -v r-cname | shuf | head • static.demobi.us • wac-cdn.atlassian.com • cdn.stage2.consumerreports.org • www.awtaxi.com.au • dev.makeitsocial.com • static.101hacks.com • www.yourfoodjob.com • eu1static.oktacdn.com
35. Domain Fronting: Fastly $ mq -k -n -domain fastly.net 201707*.mtbl | wc –l $ mq -v -n -domain fastly.net sonar/normalized/201707*.mtbl | jq . -r | grep -A 1 r-cname | grep \" | grep -v r-cname | shuf | head • shop.tinypencil.com • mjdele.github.io • sol-roar-cdn.rebelmouse.com • revan.yelp.com • b2g.bigcartel.com • helmutzechmann.com • eightmedia.github.com • cdn3.skybride.com
36. Discovery: M&A Blackstone acquires Clarion Events for £600m, lets find their hosts: Sonar FDNS: 17 hostnames • $ mq -k -domain clarionevents.com ./data/sonar/*fdns*.mtbl | sort –u Sonar RDNS: 4 hostnames • $ mq -k -domain clarionevents.com ./data/sonar/*rdns*.mtbl | sort -u Certificate Transparency: 10 hostnames • $ mq -k -domain clarionevents.com ./data/ct/*.mtbl | sort –u Combined: 20 hostnames
37. Discovery: Full Asset List All hostnames / IP addresses for a company (McAfee) Sonar DNS: 2216 hostnames $ mq -k -domain mcafee.com sonar-dns/201705*.mtbl | sort –u Certificate Transparency: 537 hostnames $ mq -k -domain mcafee.com ct/*.mtbl | sort -u Combined: 2546 hostnames
38. Summary Local internet datasets can improve your security game Discovery, monitoring, exploitation, exfiltration Costs are relatively low compared to value Keep your client/company identify safe
39. Roadmap More data sources, more normalizers, more configuration options Support for real-time streaming sources (pdns, inetdata-ct-tail) Performance improvements for low-end servers Example analysis scripts for common tasks Split early CT dataset into smaller blocks Automatic data expiration & deletion Build out post-normalize hooks MTBL API daemon + clients
40. Contribute! Fork, fix, expand! Add new datasources! Add new utilities! • https://github.com/hdm/inetdata • https://github.com/hdm/inetdata-parsers Build your own API or service, internal or external Monitor your company’s footprint for changes Dig up fun research for your next talk!
41. Demo Time!
42. Q & A Contact: underflow@hdm.io
